INSTRUCTION MANUAL
ESPAÑOL
ENGLISH
3 series
Blood Pressure Monitor
Model BP710N

TABLE OF CONTENTS
2
Before using the Monitor
Introduction ............................................................................................... 3
Important Safety Information..................................................................... 4
Operating Instructions
Know Your Device..................................................................................... 7
Display symbols ....................................................................... 9
Before Taking a Measurement ............................................... 10
Preparation ..............................................................................................11
Battery Installation...................................................................11
Using the Device..................................................................................... 12
Applying the Arm Cuff ............................................................ 12
How to Sit Correctly................................................................ 14
Taking a Measurement ........................................................... 14
Using the Memory Function ................................................... 17
Care and Maintenance
Error Messages and Troubleshooting..................................................... 18
Error Messages...................................................................... 18
Troubleshooting...................................................................... 20
Maintenance and Storage....................................................................... 21
Maintenance........................................................................... 21
Storage................................................................................... 22
Optional Medical Accessories ................................................ 22
Specifications.......................................................................................... 23
FCC Statement ....................................................................................... 24
Limited Warranty..................................................................................... 25
Guidance and Manufacturer’s Declaration ............................................. 26

INTRODUCTION
3
Thank you for purchasing the OMRON®BP710N Blood Pressure Monitor.
Your new blood pressure monitor uses the oscillometric method of blood
pressure measurement. This means the monitor detects your blood movement
through your brachial artery and converts the movements into a digital reading.
An oscillometric monitor does not need a stethoscope so the monitor is simple
to use.
Intended Use
This device is a digital monitor intended for use in measuring blood pressure
and pulse rate in adult patient population. The device detects the appearance of
irregular heartbeats during measurement and gives a warning signal with the
measurement result.
Please read this instruction manual thoroughly before using the device. 
Please keep for future reference. For specific information about your own
blood pressure, CONSULT YOUR PHYSICIAN.

IMPORTANT SAFETY INFORMATION
4
Warning: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
(General Usage)
DO NOT adjust medication based on measurement results from this blood
pressure monitor. Take medication as prescribed by your physician. Only a
physician is qualified to diagnose and treat High Blood Pressure.
The monitor is not intended to be a diagnostic device.
Consult your physician before using the device for any of the following
conditions: common arrhythmias such as atrial or ventricular premature
beats or atrial fibrillation, arterial sclerosis, poor perfusion, diabetes, age,
pregnancy, pre-eclampsia, renal diseases.
Note that PATIENT motion, trembling, shivering may affect the measurement
reading.
Do not use the device on the injured arm or the arm under medical
treatment.
Do not apply the arm cuff on the arm while being on an intravenous drip or
blood transfusion.
Consult your physician before using the device on the arm with an arterio-
venous (A-V) shunt.
Do not use the device with other medical electrical (ME) equipment
simultaneously.
Do not use the device in the area the HF surgical equipment, MRI, or CT
scanner exists, or in the oxygen rich environment.
The air tube may cause accidental strangulation in infants.
Contains small parts that may cause a choking hazard if swallowed by
infants.

IMPORTANT SAFETY INFORMATION
5
Caution: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury to the user or
patient or damage to the equipment or other property.
(General Usage)
Always consult your physician. Self-diagnosis of measurement results and
self-treatment are dangerous.
Consult your physician before using the device for any of the following
conditions:
• If you have had a mastectomy.
• Do not take measurements more than necessary. It may cause bruising
due to blood flow interference.
• People with severe blood flow problems or blood disorders as cuff inflation
can cause bruising.
Remove the arm cuff if it does not start deflating during the measurement.
Do not use this device on infants or persons who cannot express their
intentions.
Do not use the device for any purpose other than measuring blood pressure.
Use only the approved arm cuff for this device. Use of other arm cuffs may
result in incorrect measurement results.
Do not use a mobile phone or other devices that emit electromagnetic fields,
near the device. This may result in incorrect operation of the device.
Do not disassemble the monitor or arm cuff. This may cause an inaccurate
reading.
Do not use in a location with moisture, or a location where water may splash
on the device. This may damage the device.
Do not use the device in a moving vehicle (car, airplane).
Read “If your systolic pressure is more than 210 mmHg” of this instruction
manual, if your systolic pressure is known to be more than 210 mmHg.
Inflating to a higher pressure than necessary may result in bruising where
the arm cuff is applied.

IMPORTANT SAFETY INFORMATION
6
(Battery Usage)
Do not insert the batteries with their polarities incorrectly aligned.
Use only 4 “AA” alkaline or manganese batteries with this device. Do not use
other types of batteries. Do not use new and used batteries together.
Remove the batteries if the device will not be used for three months or more.
General Precautions
• Do not forcibly crease the arm cuff or the air tube excessively.
• Do not press the air tube while taking a measurement.
• To unplug the air plug, pull on the air plug at the connection with the monitor,
not the tube itself.
• Do not drop the monitor or subject device to strong shocks or vibrations.
• Do not inflate the arm cuff when it is not wrapped around your arm.
• Do not use the device outside the specified environment. It may cause an
inaccurate reading.
• Dispose of the device, components and optional accessories according to
applicable local regulations. Unlawful disposal may cause environmental
pollution.

KNOW YOUR DEVICE
7
Contents:
Monitor, arm cuff, instruction manual, quick start guide
Monitor:
Arm cuff:
A. Display
B. START/STOP button
C. Memory button
D. Battery compartment
E. Air jack
D
E
A
C
B
F
H
G
F. Arm c uff 
(Arm circumference 9” - 17” (22 - 42 cm))
G. Air plug
H. Air tube

KNOW YOUR DEVICE
8
Display:
I. Memory symbol
J. Systolic blood pressure
K. Diastolic blood pressure
L. Low battery symbol
M. Heartbeat symbol
(Flashes during measurement.)
N. Irregular heartbeat symbol
O. Movement error symbol
P. Pulse display / Memory number
Q. Deflation symbol
J
K
L
I
M
P
O
Q
N

KNOW YOUR DEVICE
9
Display symbols
Irregular Heartbeat Symbol ( )
Irregular Heartbeat
Normal Heartbeat
Pulse
Blood pressure
Blood pressure
Short Long
Pulse
When the monitor detects an irregular
rhythm two or more times during the
measurement, the irregular heartbeat
symbol will appear on the display with the
measurement values.
An irregular heartbeat rhythm is defined
as a rhythm that is 25% less or 25% more
than the average rhythm detected while
the monitor is measuring the systolic and
diastolic blood pressure.
If the irregular heartbeat symbol displays with your measurement results, we
recommend you consult your physician. Follow the directions of your physician.
Movement Error Symbol ( )
The movement error symbol is displayed if you move your body during the
measurement. Please remove the arm cuff, and wait 2 - 3 minutes. 
Take another measurement, remain still during measurement.
2013 ESH/ESC Guidelines for the management of arterial hypertension
Definitions of hypertension by office and home blood pressure levels
Office Home
Systolic Blood Pressure ≥140 mmHg≥135 mmHg
Diastolic Blood Pressure ≥90 mmHg≥85 mmHg
These are from statistical values for blood pressure.

KNOW YOUR DEVICE
10
Before Taking a Measurement
To help ensure an accurate reading, follow these directions:
1. Avoid bathing, drinking alcohol or caffeine, smoking, exercising and eating for
30 minutes before taking a measurement. Rest for at least 15 minutes before
taking the measurement.
2. Stress raises blood pressure. Avoid taking measurements during stressful
times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your arm.
5. Sit on a chair with your feet flat on the floor. Rest your arm on a table so that
the arm cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your physician.
A single measurement does not provide an accurate indication of your true
blood pressure. You need to take and record several readings over a period
of time. Try to measure your blood pressure at the same time each day for
consistency.

PREPARATION
11
Battery Installation
1. Remove the battery cover.
2. Insert 4 “AA” batteries as
indicated in the battery
compartment.
3. Replace the battery cover.
Notes:
• When the low battery symbol ( ) appears on the display, turn the
monitor off, then replace all batteries at the same time. Long life alkaline
batteries are recommended.
• The measurement values continue to be stored in memory even after the
batteries are replaced.
• Dispose of the device, components and optional accessories according to
applicable local regulations. Unlawful disposal may cause environmental
pollution.

USING THE DEVICE
12
Applying the Arm Cuff
Remove tight-fitting clothing or tight rolled up sleeve from your left upper arm. 
Do not place the arm cuff over thick clothes.
1. Insert the air plug into the air jack
securely.
2. Wrap the arm cuff firmly in
place around your left upper
arm.
1/2 inch 
(1 - 2 cm)
The bottom edge of the arm cuff
should be 1/2 inch (1 to 2 cm) above
the elbow. Air tube is on the inside
of your arm and aligned with your
middle finger.

USING THE DEVICE
13
3. Secure closed with the
fabric fastener.
Notes:
•When you take a measurement on the right
arm, the air tube will be at the side of your
elbow. Be careful not to rest your arm on
the air tube.
• The blood pressure can differ between the right arm and the left arm, and
the measured blood pressure values can be different. OMRON
recommends to always use the same arm for measurement. If the values
between both arms differ substantially, please check with your physician
which arm to use for your measurements.

USING THE DEVICE
14
How to Sit Correctly
To take a measurement, you need to
be relaxed and comfortably seated,
under comfortable room
temperature. Avoid bathing, drinking
alcohol or caffeine, smoking,
exercising or eating 30 minutes
before taking a measurement.
• Sit on a chair with your feet flat on the
floor.
• Sit upright with your back straight.
• Sit with your back and arm being
supported.
• The arm cuff should be placed on your
arm at the same level as your heart.
Taking a Measurement
Notes:
• To stop the measurement, press the START/STOP button once to deflate the
arm cuff.
• Remain still and quiet while taking a measurement.

USING THE DEVICE
15
1. Press the START/STOP button.
The arm cuff will start to inflate automatically.
START INFLATE DEFLATE COMPLETE
If your systolic pressure is more than 210 mmHg
After the arm cuff starts to inflate, press and hold the START/STOP
button until the monitor inflates 30 to 40 mmHg higher than your
expected systolic pressure.
Notes:
• The monitor will not inflate above 299 mmHg.
Inflating to a higher pressure than necessary may result in bruising
where the arm cuff is applied.

USING THE DEVICE
16
2. Remove the arm cuff.
3. Press the START/STOP button to turn the monitor off.
The monitor automatically stores the measurement result in its memory.
It will automatically turn off after 2 minutes.
Note: Wait 2-3 minutes before taking another measurement. Waiting
between measurements allows the arteries to return to the condition
prior to taking a measurement.
DO NOT adjust medication based on measurement results from this blood
pressure monitor. Take medication as prescribed by your physician. Only a
physician is qualified to diagnose and treat High Blood Pressure.
This device is not intended to be a diagnostic device.
Always consult your physician. Self-diagnosis of measurement results and 
self-treatment are dangerous.
Inflating to a higher pressure than necessary may result in bruising where
the arm cuff is applied.

USING THE DEVICE
17
Using the Memory Function
The monitor automatically stores the results up to 14 sets.
Note: If the memory is full, the monitor will delete the oldest value.
To View the Measurement Values Stored in Memory
1. Press the button.
The Memory number appears for a second
before the pulse rate is displayed. 
The newest set is numbered “1”.
2. Press the button repeatedly to view the values stored in
memory.
To Delete All the Values Stored in Memory
1. Press the button, while the memory symbol appears.
2. While holding the button
down, press the START/STOP
button for more than 3 seconds.
Note: You cannot partially delete the values stored in the memory.

ERROR MESSAGES AND TROUBLESHOOTING
Error Display Cause Solution
Irregular heartbeats are
detected.
Remove the arm cuff. Wait 
2 - 3 minutes and then take
another measurement. Repeat the
steps in “Taking a Measurement”.
If this error continues to appear,
contact your physician.
Movement during
measurement.
Carefully read and repeat the
steps in “Taking a Measurement”.
The batteries are low.
You should replace the batteries
with new ones ahead of time.
Refer to “Battery Installation”.
The batteries are
exhausted.
You should replace the batteries
with new ones at once.
Refer to “Battery Installation”.
Air plug disconnected. Insert the plug securely.
Refer to “Using the Device”.
Arm cuff is applied
too loosely.
Apply the arm cuff tighter.
Refer to “Using the Device”.
Air is leaking from the
armcuff.
Replace the arm cuff with a new one.
Refer to “Optional Medical
Accessories”.
18
Error Messages

ERROR MESSAGES AND TROUBLESHOOTING
Error Display Cause Solution
Movement during
measurement and the
arm cuff has not been
inflated sufficiently.
Repeat measurement. Remain
still and do not talk during
measurement.
Refer to “Taking a Measurement”.
If “E2” appears repeatedly, inflate
the arm cuff manually until it is
30 to 40 mmHg above your
previous measurement result.
Refer to “Taking a Measurement”.
The arm cuff was inflated
exceeding the maximum
allowable pressure, and
then deflated
automatically when
inflating the arm cuff
manually.
Do not touch the arm cuff and/or
bend the air tube while taking a
measurement. Do not inflate the
arm cuff more than necessary.
Refer to “Taking a Measurement”.
Movement during
measurement.
Repeat measurement. Remain
still and do not talk during
measurement.
Refer to “Taking a Measurement”.
Clothing is interfering with
the arm cuff.
Remove any clothing interfering
with the arm cuff.
Refer to “Using the Device”.
Device error. Contact Customer Service.
19

ERROR MESSAGES AND TROUBLESHOOTING
Problem Cause and Solution
No power.
No display appears on the monitor.
Replace all batteries with new ones.
Check the battery installation for
proper placement of the battery
polarities.
Refer to “Battery Installation”.
Measurement values appear too high
or too low.
Blood pressure varies constantly.
Many factors including stress, time of
day, and how you wrap the cuff, may
affect your blood pressure. Review the
sections “Before Taking a
Measurement” and “Taking a
Measurement”.
20
Troubleshooting
