Omron BP742CAN User manual

ENGLISH
5 series
Blood Pressure Monitor
Model BP742CAN
INSTRUCTION MANUAL

2
TABLE OF CONTENTS
Before using the Monitor
Introduction .................................................................................................................. 3
Safety Information ........................................................................................................ 4
Intended Use................................................................................................ 4
Operating the Device .................................................................................. 4
Care and Maintenance ................................................................................ 5
Operating Instructions
Before Taking a Measurement ...................................................................................... 6
Know Your Unit ............................................................................................................ 7
Unit Display .................................................................................................................. 8
Display Symbols ........................................................................................................... 9
Irregular Heartbeat Symbol......................................................................... 9
Movement Error Symbol ............................................................................ 9
Average Value Symbol................................................................................ 9
Heartbeat Symbol/Hypertension Indicator.................................................. 9
Using the Memory Function ..................................................................... 10
Battery Installation .......................................................................................................11
Battery Replacement ................................................................................. 12
Setting the Date and Time ........................................................................................... 13
Applying the Arm Cuff................................................................................................ 15
Applying the Cuff on the Left Arm........................................................... 15
Applying the Cuff on the Right Arm ........................................................ 16
Taking a Measurement ................................................................................................ 17
Special Conditions .................................................................................... 18
Using the Memory Function ....................................................................................... 19
Averaging Function................................................................................... 19
To Display the Measurement Values ........................................................ 19
To Delete All Values Stored in the Memory ............................................ 20
Care and Maintenance ........................................................................................................ 21
Error Indicators............................................................................................................ 22
Troubleshooting Tips ................................................................................................... 23
Fcc Statement............................................................................................................... 24
Limited Warranty ......................................................................................................... 25
Specifications............................................................................................................... 26
TABLE OF CONTENTS

3
INTRODUCTION
Thank you for purchasing the Omron®BP742CAN 5 series Automatic Blood Pressure
Monitor.
Your new blood pressure monitor uses the oscillometric method of blood pressure
measurement. This means the monitor detects your blood’s movement through your
brachial artery and converts the movements into a digital reading. An oscillometric
monitor does not need a stethoscope so the monitor is simple to use.
The BP742CAN comes with the following components:
• Monitor • Standard Adult Arm Cuff • 4 “AA” Alkaline Batteries
• Instruction Manual printed in English and French • Quick Start Guide
The BP742CAN 5 series Automatic Blood Pressure Monitor is intended for home use.
Please read this instruction manual thoroughly before using the unit.
Please keep for future reference.
For specific information about your own blood pressure, CONSULT YOUR DOCTOR.
Fill in for future reference.
DATE PURCHASED:__________________
SERIAL NUIMBER:___________________
• Staple your purchase receipt here
• Register your product on-line at
www.register-omron.com
SAVE THESE INSTRUCTIONS

4
SAFETY INFORMATION
INTENDED USE
This product is designed to measure the blood pressure and pulse rate of people within the
range of the designated arm cuff, following the instructions in this instruction manual.
It is mainly designed for general household use. Please read the “Safety Information” in
this instruction manual before using the unit.
To assure the correct use of the product, basic safety measures should always be
followed including the warnings and cautions listed in this instruction manual.
SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL
WARNING Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury to the user or patient or
damage to the equipment or other property.
OPERATING THE DEVICE
Contact your physician for specific information about your blood pressure. Self-
diagnosis and treatment using measured results may be dangerous. Follow the
instructions of your physician or licensed healthcare provider.
DO NOT adjust medication based on measurement results from this blood pressure
monitor. Take medication as prescribed by your physician. Only a physician is
qualified to diagnose and treat High Blood Pressure.
The monitor is not intended to be a diagnostic device.
If battery fluid should get in your eyes, immediately rinse with plenty of clean
water. Contact a physician immediately.
Read all of the information in the instruction manual and any other literature in the
box before operating the unit.

5
SAFETY INFORMATION
This device is intended for use in measuring blood pressure and pulse rate in the
adult population. Do not use this device on infants or persons who cannot express
their intentions.
Read the Special Conditions section of the instruction manual if your systolic
pressure is known to be more than 220 mmHg. Inflating to a higher pressure than
necessary may result in bruising where the cuff is applied.
Operate the device only as intended. Do not use the device for any other purpose.
Dispose of the device, components and optional accessories according to applicable
local regulations. Unlawful disposal may cause environmental pollution.
Do not use a cellular phone near the device. It may result in an operational failure.
Use only Omron authorized parts and accessories. Parts and accessories not
approved for use with the device may damage the unit.
Use only 1.5 V “AA” alkaline batteries with this device. Do not use other types of
batteries. This may damage the unit.
CARE AND MAINTENANCE
Do not subject the monitor to strong shocks, such as dropping the unit on the floor.
Do not submerge the device or any of the components in water.
Store the device and the components in a clean, safe location.
Changes or modification not approved by the manufacturer will void the user
warranty. Do not disassemble or attempt to repair the unit or components.

6
BEFORE TAKING A MEASUREMENT
To ensure a reliable reading follow these recommendations:
1. Avoid eating, drinking alcohol, smoking, exercising, and bathing for 30 minutes
before taking a measurement. Rest for at least 15 minutes before taking the
measurement.
2. Stress raises blood pressure. Avoid taking measurements during stressful times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your left arm.
5. Sit on a chair with your feet flat on the floor. Rest your left arm on table so that the
cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Wait 2-3 minutes between measurements. The wait time allows the arteries to return
to the condition prior to taking the blood pressure measurement. You may need to
increase the wait time depending on your individual physiological characteristics.
8. Keep a record of your blood pressure and pulse readings for your physician. A
single measurement does not provide an accurate indication of your true blood
pressure. You need to take and record several readings over a period of time. Try to
measure your blood pressure at the same time each day for consistency.

7
KNOW YOUR UNIT
Main Unit:
Components:
Quick Start
Guide
Instruction
Manual
Standard Adult Arm Cuff
Date/Time setting ( )
button
Air Jack
Air plug
Air tube
Display
AC adapter Jack
Battery compartment
Up/Down ( / ) buttons
USER ID
Selection Switch
START/STOP button

8
UNIT DISPLAY
Battery low indicator
User ID symbol (A/B)
Deflation symbol
Pulse display
Heartbeat symbol /
Hypertension Indicator
Date/Time Display
Irregular Heartbeat symbol
Movement error symbol
Average Value symbol
Memory symbol
(Displayed when viewing
values stored in memory)
Diastolic blood pressure
Systolic blood pressure

9
DISPLAY SYMBOLS
IRREGULAR HEARTBEAT SYMBOL ( )
When the monitor detects an irregular rhythm two or more times during the
measurement, the Irregular Heartbeat Symbol ( ) will appear on the display with
the measurement values.
An irregular heartbeat rhythm is defined as a
rhythm that varies by less than 25% from the
average rhythm or 25% more than the average
rhythm detected while the monitor is measuring
the systolic and diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results,
we recommend you consult your
physician. Follow the directions of your
doctor.
MOVEMENT ERROR SYMBOL ( )
The Movement Error Symbol ( ) is displayed if you move your body during the
measurement. Please remove the arm cuff, and wait 2-3 minutes. Reapply the arm cuff
and take another measurement.
AVERAGE VALUE SYMBOL ( )
The Average Value Symbol ( ) is displayed when you press the memory button.
The most recent average reading appears on the display screen.
HEARTBEAT SYMBOL/HYPERTENSION INDICATOR ( )
TAKING A MEASUREMENT
The Heartbeat Symbol ( ) flashes on the display during the measurement. The
Heartbeat Symbol ( ) flashes at every heartbeat.
When the measurement is complete, the Heartbeat Symbol ( ) flashes on the
display with your blood pressure and pulse rate if the reading is above 135 for the
Systolic Blood Pressure value and/or above 85 for the Diastolic Blood Pressure
value.
Normal Heartbeat
Irregular Heartbeat
Pulse
Pulse
Short Long
Blood
pressure
Blood
pressure

10
USING THE MEMORY FUNCTION
The Heartbeat Symbol ( ) flashes when the blood pressure reading stored in the
memory is above 135 for the Systolic Blood Pressure value and/or above 85 for the
Diastolic Blood Pressure value.
The Canadian Hypertension Society (CHS) recommends the following guideline for
upper limit of normal for home blood pressure readings:
CHS Home Guideline for Upper Limit of Normal BP
Systolic Blood Pressure 135 mmHg
Diastolic Blood Pressure 85 mmHg
This is a general guideline because blood pressure depends on age and morbidity.
The CHS recommends a lower home blood pressure goal for certain patients,
including people with diabetes or kidney.disease1.
WARNING
The monitor is not intended to be a diagnostic device.
WARNING
Contact your physician for specific information about your blood pressure.
Self-diagnosis and treatment using measured results may be dangerous.
Follow the instructions of your physician or licensed healthcare provider.
Omron Healthcare recommends you contact your physician if the Heartbeat Symbol
( ) flashes on the display with your measurement values.
1Canadian Hypertension Education Program. 2006 Public Recommendations.
DISPLAY SYMBOLS

11
BATTERY INSTALLATION
CAUTION
Use only 1.5V “AA” alkaline batteries with this device.
1. Press the indicator on the battery cover and
slide the cover off in the direction of the arrow.
2. Install 4 “AA” size batteries so the + (positive)
and - (negative) polarities match the polarities
of the battery compartment as indicated.
3. Replace the battery cover.

12
BATTERY REPLACEMENT
Low Battery Indicator
When the Low Battery Indicator appears on the display, turn the monitor off and
remove all the batteries. Replace with four new batteries at the same time. Long-life
alkaline batteries are recommended.
WARNING
If battery fluid should get in your eyes, immediately rinse with plenty of
clean water. Contact a physician immediately.
NOTES: • Turn the unit off before replacing the batteries. If the batteries are removed
while the unit is still on, the date and time will be reset to that of the
previous use. However, the measurement results are not deleted.
• When the batteries are replaced, you may need to reset the date and time. If
“-:--” appears on the display, refer to “Setting the Date and Time”.
• The supplied batteries may have a shorter life.
CAUTION
Dispose of the device, components and optional accessories according to
applicable local regulations. Unlawful disposal may cause environmental
pollution.
BATTERY INSTALLATION

13
SETTING THE DATE AND TIME
Set the monitor to the current date and time before taking a measurement for the first
time. If the date and time are not set correctly, the measurement values stored in the
memory and the average values may not be correct.
1. TO START THE SETTING
Press the Date/Time Setting button ( ) to adjust the date and time.
The year flashes on the display.
2. SETTING THE YEAR
The year can be set between 2010 and 2040. When the
display reaches 2040, it will return to 2010. Press the Up
button ( ) to advance by one year. Press the Date/Time
Setting button ( ) to set the current year.
The month flashes on the display.
NOTES: • Press the Down button ( ) to
decrease the date and time values.
• Press and hold the button to increase or
decrease the date and time values faster.

14
3. SETTING THE MONTH
Press the Up button ( ) to advance by one month.
Press the Date/Time Setting button ( ) to set the current
month.
The day flashes on the display.
4. SETTING THE DAY
Press the Up button ( ) to advance by one day. Press
the Date/Time Setting button ( ) to set the current day.
The hour flashes on the display.
5. SETTING THE HOUR
The time is set using AM or PM. Press the Up button
( ) to advance by one hour. Press the Date/Time Setting
button ( ) to set the current hour.
The minute flashes on the display.
6. SETTING THE MINUTE
Press the Up button ( ) to advance by one minute.
Press the Date/Time Setting button ( ) to set the minute
setting.
7. TO TURN THE MONITOR OFF
Press the START/STOP button.
NOTE: The monitor will automatically turn off five minutes after the minute has
been set.
SETTING THE DATE AND TIME

15
CAUTION
Read all of the information in the instruction manual and any other literature in
the box before operating the unit.
CAUTION
This device is intended for use in measuring blood pressure and pulse rate in
the adult population. Do not use this device on infants or persons who cannot
express their intentions.
APPLYING THE CUFF ON THE LEFT ARM
1. Make sure the air plug is securely inserted
in the main unit.
2. Remove tight-fitting clothing from your upper arm.
3. Apply the cuff to your left upper arm so the
arrow is centered on the inside of your arm
and aligned with your middle finger. The air
tube runs down the inside of your arm. The
bottom of the cuff should be approximately
1/2 “ above your elbow.
4. Wrap the cuff firmly in place around your arm using the
cloth fastening.
APPLYING THE ARM CUFF
Left Arm
Air Tube
Arrow
1/2 inch (1 - 2 cm)

16
APPLYING THE CUFF ON THE RIGHT ARM
When taking a measurement using the right arm, use this instruction for Step 3.
Apply the cuff to your right upper arm so the
arrow and the air tube runs along the inside
of your arm. The bottom of the cuff should be
approximately 1/2 “ above your elbow.
NOTE: Be careful not to rest your arm on the air tube. This will restrict the flow of air
to the cuff.
APPLYING THE ARM CUFF
Arrow
Right Arm

17
1. Press the START/STOP button to turn the monitor on.
All symbols appear on the display.
2. Select your USER ID (A or B).
3. Sit on a chair with your feet flat on the floor.
Place your arm on a table so the cuff is level
with your heart.
Keep still and do not talk during measurement.
4. Press the START/STOP button.
The cuff starts to inflate automatically. As the cuff inflates, the monitor
automatically determines your ideal inflation level.
Remain still and do not move your arm until the entire measurement process is
completed.
NOTE: To stop the inflation or measurement, push the START/STOP button. The
monitor will stop inflating, start deflating, and will turn off.
TAKING A MEASUREMENT

18
TAKING A MEASUREMENT
5. Inflation stops automatically and the measurement is started. As the cuff deflates,
decreasing numbers appear on the display and the Heartbeat Symbol ( ) flashes.
6. When the measurement is complete, the arm cuff completely
deflates. Your blood pressure and pulse rate are displayed.
7. Press the START/STOP button to turn the monitor off.
NOTE: The monitor will automatically turn off after
five minutes.
SPECIAL CONDITIONS
CAUTION
Inflating to a higher pressure than necessary may result in bruising where the
cuff is applied.
If your systolic pressure is known to be more than 220 mmHg, press and hold the
START/STOP button until the monitor inflates 30 to 40 mmHg higher than your
expected systolic pressure.
NOTE: • Do not apply more pressure than necessary.
• The monitor will not inflate above 299 mmHg.
When the measurement is complete, the arm cuff completely deflates. Your blood
pressure and pulse rate are displayed.

19
USING THE MEMORY FUNCTION
The monitor is designed to store the blood pressure and the pulse rate in the memory
for two people (USER A and USER B) every time a measurement is completed. The
monitor automatically stores up to 30 sets of measurement values (blood pressure and
pulse rate) for each user (A and B). When 30 sets of measurement values are stored, the
oldest record is deleted to save the most recent values.
AVERAGING FUNCTION
The monitor calculates the average reading based on the three most recent sets of
measurement values taken within 10 minutes of the most recent reading.
NOTE: If two sets of measurement values are stored in the memory for the 10 minutes
period, the average is based on the two sets of measurement values. If one set
of measurement values is stored, this is displayed as the average.
TO DISPLAY THE MEASUREMENT VALUES
1. Press the START/STOP button to turn the monitor on.
2. Select your USER ID (A or B).
3. Press the Up or Down button ( / ). The Average Value Symbol ( )
appears on the display when the average reading is shown.
4. Press the Up or Down button ( / ) to display the sets of measurement
values.
Press the Down button ( ) repeatedly
Average value →most recent set of measurement values →the older readings →
back to the average value
Press the Up button ( ) repeatedly
Average value →oldest set of measurement values →the more recent readings →
back to the average value

20
USING THE MEMORY FUNCTION
NOTES: • The measurement value number is displayed
briefly in the Pulse Display area when you
press the Up/Down buttons ( / ).
• The date and time are alternately displayed
with the measurement values.
• If the date and time are not set, “-:--” is
displayed with the measurement values.
• Press the button repeatedly to display the
next values.
• Press and hold the button to display the
values faster.
TO DELETE ALL VALUES STORED IN THE MEMORY
The values stored in the memory are deleted by USER ID. You cannot partially delete
values stored in the memory. All values for the user you select will be deleted.
1. Press the START/STOP button to turn the monitor on.
2. Select your USER ID (A or B).
3. While holding the Down button ( ), press the START/STOP button down
for more than five seconds until the display appears as it does in the following
illustration.
4. Press the START/STOP button to turn the monitor off.
NOTE: The monitor will automatically turn off after five minutes.
Alternating
display
