Omron IntelliSense HEM-712C User manual

Automatic Blood Pressure Monitor
with Arm Cuff
Model HEM-712C
INSTRUCTION MANUAL
ESPAÑOL
ENGLISH
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 1

2
Before Using the Monitor
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Important Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Before Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operating Instructions
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Unit Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Irregular Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Applying the Arm Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Using the Memory Function
Averaging Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Measurement Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Care and Maintenance
Care and Maintenance .................................18
Error Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
TroubleshootingTips ..................................20
Quick Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
CONTENTS
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 1

3
Thank you for purchasing the Omron®HEM-712C IntelliSense®
Automatic Blood Pressure Monitor.
INTRODUCTION
Fill in for future reference.
DATE PURCHASED: __________________
SERIAL NUMBER: ____________________
Staple your purchase receipt here
Your new digital blood pressure monitor uses the oscillometric method
of blood pressure measurement. This means the monitor detects your
blood’s movement through your brachial artery and converts the
movements into a digital reading. An oscillometric monitor does not
need a stethoscope so the monitor is simple to use.
The HEM-712C comes with the following components:
•Monitor
•Standard Adult Arm Cuff 9''-13'' arm circumference
•Instruction Manual in English and Spanish
The HEM-712C IntelliSense®Automatic Blood Pressure Monitor
is intended for home use.
SAVE THESE INSTRUCTIONS
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 2

4
To assure the correct use of the product basic safety measures should
always be followed including the precautions listed below:
þRead all information in the instruction book and any other literature
included in the box before using the unit.
þContact your physician for specific information about your blood
pressure. Follow the instructions of your healthcare provider.
þOperate the unit only as intended. Do not use for any other purpose.
þThe unit is intended for use in measuring blood pressure and pulse
rate in adult patient population. Do not use on infants or persons who
cannot express their intentions.
þDo not use a cellular phone near the unit. It may result in
operational failure.
þChanges or modifications not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
IMPORTANT SAFETY NOTES
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 3

5
BEFORE TAKING A MEASUREMENT
To ensure a reliable reading follow these recommendations:
1. Avoid eating, drinking alcohol, smoking, exercising, and bathing
for 30 minutes before taking a measurement. Rest for at least
15 minutes before taking the measurement.
2. Stress raises blood pressure. Avoid taking measurements during
stressful times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your left arm.
5. Sit in a chair with your feet flat on the floor. Rest your left arm on
atable so that the cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your
physician. A single measurement does not provide an accurate
indication of your true blood pressure. You need to take and record
several readings over a period of time. Try to measure your blood
pressure at the same time each day for consistency.
8. Wait 2-3 minutes between measurements. The wait time allows the
arteries to return to the condition prior to taking the blood pressure
measurement. You may need to increase the wait time depending on
your individual physiological characteristics.
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 4

6
KNOW YOUR UNIT
Air Jack
Main Unit:
Battery Compartment
START/STOP
Button
MEMORY Button
Date/Time Setting Button
Display
AC Adapter Jack
Components:
Arm Cuff Air Tube
Air Plug
(Connects to Air Jack)
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 5

7
UNIT DISPLAY
IRREGULAR HEARTBEAT SYMBOL
When the monitor detects an irregular rhythm two or more than two
times during the measurement, the Irregular Heartbeat Symbol ( )
will appear on the display with the measurement values.
An irregular heartbeat rhythm is defined
as a rhythm that varies by less than 25%
from the average rhythm or 25% more than
the average rhythm detected while the
monitor is measuring the systolic and
diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results we
recommend you consult your physician.
Followthe directions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
IRREGULAR HEARTBEAT SYMBOL
Diastolic Blood Pressure
Systolic Blood Pressure
Memory Symbol
Pulse Display
Date/Time Display
Low Battery Symbol
Average Value Symbol
Heartbeat Symbol
Deflation Symbol
Irregular Heartbeat Symbol
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 6

8
1. Press the ▲indicator on the battery cover
and slide the cover off in the direction of
the arrow.
2. Install 4 “AA” size batteries so the
+(positive) and - (negative) polarities
match the polarities of the battery
compartment as indicated.
3. Replace the battery cover.
BATTERY REPLACEMENT
Initial Set-Up
When the Low Battery Symbol ( ) appears on the display screen
remove all the batteries. Replace with four new batteries at the same
time. When the LowBattery Symbol ( )blinks a brief period of usage
remains. Long-life alkaline batteries are recommended.
NOTES:
•Measurement values stored in the memory will not be deleted during
battery replacement.
• After replacing the batteries, reset the date and time. Refer to page
10, Setting the Date and Time.
• Dispose of batteries according to applicable local regulations.
BATTERY INSTALLATION
LowBattery Symbol
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 7

9
Set the monitor to the current date and time before taking a measurement
for the first time. If the correct date and time are not set, the measurement
values stored in the memory and the average value will not be correct.
The Blood Pressure Monitor automatically stores up to 30 measurement
values with the date and time. The monitor also calculates an average
reading based on the three most recent measurements taken within 10
minutes of the last reading.
NOTES:
•If only two readings are stored in the memory for the 10-minute
period, the average is based on the two readings.
•If one reading is stored in the memory for the 10-minute period,
this reading is displayed as the average.
1. TO START THE SETTING
Press the Date/Time Setting button to
adjust the date and time.
The year flashes on the display.
SETTING THE DATE AND TIME
HEM-712CN Final 9-20 9/20/05 4:06 PM Page 8

10
SETTING THE DATE AND TIME
2. SETTING THE YEAR
The year can be set between 2005 and
2030. When the display reaches 2030,
it will return to 2005.
Press the MEMORY button to advance
by increments of one year.
Press the Date/Time Setting button to set
the current year.
The month flashes on the display.
NOTE:
•Press and hold the MEMORY button to advance
the date and time values faster.
3. SETTING THE MONTH
Press the MEMORY button to advance by
increments of one month.
Press the Date/Time Setting button to set
the current month.
The day flashes on the display.
4. SETTING THE DAY
Press the MEMORY button to advance by
increments of one day.
Press the Date/Time Setting button to set
the current day.
The hour flashes on the display.
