Omron HEM-711AC User manual

Automatic Blood Pressure Monitor
with Arm Cuff
Model HEM-711AC
INSTRUCTION MANUAL
ESPAÑOL
ENGLISH
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 1

1
Before Using the Monitor
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating Instructions
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Unit Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Irregular Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Using the AC Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Applying the Arm Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Using the Memory Function . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Care and Maintenance
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Error Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Quick Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
CONTENTS
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 1

2
Thank you for purchasing the Omron HEM-711AC IntelliSense®
Automatic Blood Pressure Monitor.
INTRODUCTION
Fill in for future reference.
DATE PURCHASED: __________________
SERIAL NUMBER: ____________________
Staple your purchase receipt here
Your new digital blood pressure monitor uses the oscillometric method
of blood pressure measurement. This means the monitor detects your
bloods movement through your brachial artery and converts the
movements into a digital reading. An oscillometric monitor does not
need a stethoscope so the monitor is simple to use.
The HEM-711AC comes with the following components:
•Monitor • Standard Adult Arm Cuff
•AC Adapter • Instruction Manual printed in English and Spanish
• Storage Case
The HEM-711AC IntelliSense®Automatic Inflation Blood Pressure
Monitor is intended for home use.
SAVE THESE INSTRUCTIONS
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 2

3
To assure the correct use of the product basic safety measures should
always be followed including the precautions listed below:
þRead all information in the instruction book and any other literature
included in the box before using the unit.
þContact your physician for specific information about your blood
pressure. Follow the instructions of your healthcare provider.
þOperate the unit only as intended. Do not use for any other purpose.
þThe unit is intended for use in measuring blood pressure and pulse
rate in adult patient population. Do not use on infants or persons who
cannot express their intentions.
þDo not use a cellular phone near the unit. It may result in
operational failure.
þDo not plug or unplug the adapter power cord with wet hands.
þChanges or modifications not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
IMPORTANT SAFETY NOTES
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 3

4
BEFORE TAKING A MEASUREMENT
To ensure a reliable reading follow these recommendations:
1. Avoid eating, smoking, and exercising for 30 minutes before
taking a measurement. Rest for at least 15 minutes before taking
the measurement.
2. Stress raises blood pressure. Avoid taking measurements during
stressful times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your left arm.
5. Sit in a chair with your feet flat on the floor. Rest your left arm on
a table so that the cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your
physician. A single measurement does not provide an accurate
indication of your true blood pressure. You need to take and record
several readings over a period of time. Try to measure your blood
pressure at the same time each day for consistency.
8. Wait 2-3 minutes between measurements. The wait time allows the
arteries to return to the condition prior to taking the blood pressure
measurement. You may need to increase the wait time depending on
your individual physiological characteristics.
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 4

5
KNOW YOUR UNIT
Air Jack
Main Unit:
Battery Compartment
START/STOP Button
MEMORY Button
Date/Time Setting Button
Display
AC Adapter Jack
Components:
ArmCuff Air Tube
Air Plug
(Connects to Air Jack) Storage Case
AC Adapter
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 5

6
UNIT DISPLAY
Diastolic Blood Pressure
Systolic Blood Pressure
Memory Symbol
Pulse Display
Date/Time Display
Battery Low Symbol
Average Value Symbol
Heartbeat Symbol
Deflation Symbol
IRREGULAR HEARTBEAT SYMBOL
When the monitor detects an irregular rhythm two or more times during
the measurement, the Irregular Heartbeat Symbol ( )
will appear on the display with the measurement values.
The irregular heartbeat rhythm is defined
as a rhythm that varies by more than or less
than 25% from the average rhythm detected
while the monitor is measuring the
systolic and diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results we
recommend you consult your physician.
Follow the directions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
Irregular Heartbeat Symbol
IRREGULAR HEARTBEAT SYMBOL
Movement Error Symbol
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 6

7
1. Press the ▼indicator on the battery cover
and slide the cover off in the direction of
the arrow.
2. Install 4 “AA” size batteries so the
+ (positive) and - (negative) polarities
match the polarities of the battery
compartment as indicated.
3. Replace the battery cover.
BATTERY REPLACEMENT
Low Battery Indicator
When the Low Battery Indicator appears on the display screen remove
all the batteries. Replace with four new batteries at the same time.
Long-life alkaline batteries are recommended.
NOTE: Measurement values stored in the memory will not be deleted
during battery replacement.
After replacing the batteries, reset the date and time.
Refer to page 10, Setting the Date and Time.
BATTERY INSTALLATION
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 7

8
Use only the authorized Omron AC Adapter, Model Number HEM-ADPT1,
with this monitor. Use of any other adapter may cause damage to the
monitor and will void the user warranty.
To connect the AC Adapter
①Insert the AC Adapter Plug into the AC Adapter Jack on the back side
of the monitor as illustrated.
②Plug the AC Adapter into a 120V AC outlet (60 cycles).
To disconnect the AC Adapter remove the AC Adapter from the electrical
outlet first and then remove the AC Adapter Plug from the monitor.
NOTE: The monitor is designed not to draw power from the batteries
when the AC Adapter is used.
USING THE AC ADAPTER
1
2
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 8

9
The Blood Pressure Monitor automatically stores up to 60 measurement
values with the date and time. The monitor also calculates an average
reading based on the last three measurement values.
Set the monitor to the current date and time before taking a measurement
for the first time. If the current date and time is not set, a default date
and time will display.
1. TO START THE SETTING
Press the Date/Time Setting
button to adjust the date
and time.
The year flashes on the display.
2.SETTING THE YEAR
The year can be set between 2004 and 2030.
When the display reaches 2030, it will return
to 2004.
Press the MEMORY button to advance the
digits one at a time.
Press the Date/Time Setting button to set
the current year.
The month flashes on the display.
SETTING THE DATE AND TIME
STOP
STOP
STOP
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 9
