Omron M2 Compact User manual

Digital Automatic Blood Pressure Monitor
Model M2 Compact
• Instruction Manual
• Mode d’emploi
• Gebrauchsanweisung
• Manuale di istruzioni
• Manual de instrucciones
• Gebruiksaanwijzing
• РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
EN
FR
DE
IT
ES
NL
RU
AR
IM-HEM-7102-E-02-10/07
1664464-6C
HEM-7102-IM_main.book Page 1 Friday, October 5, 2007 1:41 PM

2
Contents
Before using the unit
Introduction..................................................................................3
Important Safety Information......................................................4
1. Overview..................................................................................7
2. Preparation............................................................................10
2.1 Installing/Replacing the Batteries......................................10
Operating instructions
3. Using the Unit........................................................................12
3.1 How to Sit Correctly When Taking a Measurement ..........12
3.2 Applying the Arm Cuff .......................................................14
3.3 Taking a Reading..............................................................16
3.4 Instructions for special conditions .....................................20
3.5 Using the Memory Function ..............................................21
4. Quick Reference Guide ........................................................23
Care and maintenance
5. Handling Errors and Problems............................................24
5.1 Error Messages.................................................................24
5.2 Troubleshooting ................................................................26
6. Maintenance and Storage ....................................................28
7. Optional Parts .......................................................................30
8. Technical Data.......................................................................31
9. Some Useful Information about Blood Pressure...............33
HEM-7102-IM_main.book Page 2 Friday, October 5, 2007 1:41 PM

3
EN
Introduction
Thank you for purchasing the OMRON M2 Compact Upper Arm Blood
Pressure Monitor.
The OMRON M2 Compact is a fully automatic blood pressure monitor,
operating on the oscillometric principle. It measures your blood
pressure and pulse rate simply and quickly.
The unit also stores up to 14 measurements in memory.
Please read this instruction manual thoroughly before using
the unit. For specific information about your own blood
pressure, CONSULT YOUR DOCTOR.
Before using the unit
HEM-7102-IM_main.book Page 3 Friday, October 5, 2007 1:41 PM

4
Important Safety Information
Consult your doctor during pregnancy, arrhythmia and arteriosclerosis.
You should never change the dosage of medication prescribed by your
doctor.
Please read this section carefully before using the unit.
Warning:
• Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
(General Usage)
• Always consult your doctor. Self-diagnosis of measurement results
and self-treatment are dangerous.
• People with severe blood flow problems, or blood disorders, should
consult a doctor before using the unit. Cuff inflation can cause internal
bleeding.
(AC Adapter Usage)
• Never plug in or unplug the power cord from the electric outlet with
wet hands.
(Battery Usage)
• If battery fluid should get in your eyes, immediately rinse with plenty of
clean water. Consult a doctor immediately.
Caution:
• Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury to the user or patient or damage to
the equipment or other property.
(General Usage)
• Do not leave the unit unattended with infants or persons who cannot
express their consent.
• Do not use the unit for any purpose other than measuring blood
pressure.
• Do not disassemble the unit or arm cuff.
• Use only the approved arm cuff for this unit. Use of other arm cuffs
may result in incorrect measurement results.
HEM-7102-IM_main.book Page 4 Friday, October 5, 2007 1:41 PM

5
EN
• Make sure that the air tube is not wrapped around other parts of your
body when taking measurements at night. This could result in injury
when the air pressure in the air tube is increased.
• Do not wrap the arm cuff tightly when taking measurements at night.
This could result in injury.
• Do not inflate the arm cuff over 299 mmHg.
• Do not use a mobile phone near the unit. This could cause a
malfunction.
• To inflate the cuff manually, refer to Chapter 3.4. If the cuff is over
inflated, it can cause internal bleeding.
(AC Adapter Usage)
• Use only the original AC adapter designed for this unit. Use of
unsupported adapters may damage and/or may be hazardous to the
unit.
• Plug the AC adapter into the appropriate voltage outlet.
• Do not use the AC adapter if the unit or the power cord is damaged.
Turn off the power and unplug the power cord immediately.
(Battery Usage)
• If battery fluid should get on your skin or clothing, immediately rinse
with plenty of clean water.
• Use only four “AAA” alkaline batteries with this unit. Do not use other
types of batteries.
• Do not insert the batteries with their polarities incorrectly aligned.
• Replace old batteries with new ones immediately. Replace all four
batteries at the same time.
• Remove the batteries if the unit will not be used for three months or
more.
• Do not use new and used batteries together.
General Precautions
• Do not operate unit in a moving vehicle (car, airplane).
• Do not apply strong shocks and vibrations to or drop the unit and arm
cuff.
• Do not take measurements after bathing, drinking alcohol, smoking,
exercising or eating.
• Do not forcibly bend the arm cuff or bend the air tube excessively.
HEM-7102-IM_main.book Page 5 Friday, October 5, 2007 1:41 PM

6
• When removing the air tube, pull on the edge of the tube at the
connection with the main unit not the middle of the tube.
• Do not inflate the arm cuff when it is not wrapped around your arm.
• Do not wash the arm cuff or immerse it in water.
• Read and follow the “Important information regarding Electro
Magnetic Compatibility (EMC)” in the Technical Data Section.
• Read and follow the “Correct Disposal of This Product” in the
Technical Data Section when disposing of the device and any used
accessories or optional parts.
HEM-7102-IM_main.book Page 6 Friday, October 5, 2007 1:41 PM

7
1.Overview
EN
1. Overview
Main unit
Arm Cuff
A. Display
B. O/I START button
C. M (Memory) button
D. AC adapter jack (for optional
AC adapter)
E. Battery compartment
F. Air jack
G. Arm cuff
(Medium cuff: arm circumference 22-32 cm)
H. Air tube
I. Air plug
A
B C
E
F
D
HG
I
HEM-7102-IM_main.book Page 7 Friday, October 5, 2007 1:41 PM

8
1.Overview
Display
J. Systolic blood pressure
K. Diastolic blood pressure
L. Memory symbol
Displayed when viewing values
stored in memory
M. Battery low symbol
N. Heartbeat symbol
1. Flashes during measurement
2. If flashing after measurement
completed or when viewing
results stored in the memory,
indicates blood pressure out of
recommended range*
O. Pulse display
P. Deflation symbol
Q. Irregular heartbeat symbol
* Note: If your systolic or diastolic
pressure is outside the
standard range (above 135/
85 mmHg) the Heartbeat
symbol ( ) will blink.
Please refer to Chapter 3.3.6.
J
K
M
L
O
N
PQ
HEM-7102-IM_main.book Page 8 Friday, October 5, 2007 1:41 PM

9
1.Overview
EN
Package contents (others)
R. Storage case
S. Four “AAA” alkaline (LR03)
batteries
• Instruction manual
• Guarantee card
• Blood pressure pass
SR
HEM-7102-IM_main.book Page 9 Friday, October 5, 2007 1:41 PM

10
2.Preparation
2. Preparation
2.1
Installing/Replacing the Batteries
1. Turn the main unit upside down.
2. Slide the battery cover in the
direction of the arrow while
pressing the ribbed part of the
cover.
3. Install or replace four “AAA”
size batteries so that the
+ (positive) and - (negative)
polarities match the
polarities indicated on the
battery compartment.
4. Put the battery cover back in place.
Slide the battery cover as indicated, until it clicks into place.
Note: The measurement values continue to be stored in
memory even after the batteries are replaced.
HEM-7102-IM_main.book Page 10 Friday, October 5, 2007 1:41 PM

11
2.Preparation
EN
Battery Life & Replacement
If the battery low symbol ( ) appears on the display, replace all four
batteries at the same time.
- When the battery low symbol ( ) starts to blink, you will still be
able to use the unit for a short while. You should replace the
batteries with new ones ahead of time.
- When the symbol ( ) remains lit, the batteries are exhausted. You
should replace the batteries with new ones at once. Turn the unit off
before replacing the batteries.
• Remove the batteries if the unit will not be used for three months or
more.
• Dispose of batteries according to applicable local regulations.
Four new “AAA” alkaline batteries will last for approximately 300
measurements, when used to take two measurements a day.
Since the supplied batteries are for monitoring use only, they may have
a shorter life and not last for 300 measurements.
Operating instructions
HEM-7102-IM_main.book Page 11 Friday, October 5, 2007 1:41 PM

12
3.Using the Unit
3. Using the Unit
3.1
How to Sit Correctly When Taking a Measurement
Correct posture during measurement is necessary to get accurate
results.
Notes:
• Measurements should be taken in a quiet place and you should be in
a relaxed, seated position. Make sure that the room is not too hot or
too cold.
• Avoid eating, drinking alcohol, smoking, or exercising for at least 30
minutes before taking a measurement.
• Do not move or talk during measurement.
Correct
Posture
Remove tight fitting clothing from
your upper arm, and any thick
clothing such as a sweater.
Do not place the cuff over thick
clothes and do not roll up your
sleeve if it is too tight.
Sit upright with
your back
straight.
Place your arm on a table so
that the cuff will be at the
same level as your heart.
The gap between the
chair and the top of the
table should be between
25cm to 30cm.
HEM-7102-IM_main.book Page 12 Friday, October 5, 2007 1:41 PM

13
3.Using the Unit
EN
Note: You can take a measurement on either your left or right
arm. The blood pressure can differ between the right
arm and the left arm and therefore also the measured
blood pressure values can be different. Omron
recommends to always use the same arm for
measurement. If the values between the two arms differ
substantially, please check with your physician which
arm to use for your measurement.
Incorrect Posture
These situations could lead to higher blood pressure
values due to strain or the arm cuff being lower than the
heart.
If the arm cuff is at a lower position than your heart use
cushions etc., to adjust the height of your arm.
• Arched back (leaning forwards)
• Sitting cross-legged
• Sitting on a sofa or at a low table
so that you tend to lean forward
HEM-7102-IM_main.book Page 13 Friday, October 5, 2007 1:41 PM

14
3.Using the Unit
3.2 Applying the Arm Cuff
Be sure to wrap the arm cuff correctly so that you get accurate results.
Measurements can be taken in light clothing. However, please remove
thick clothes, such as sweaters, before taking a reading.
1. Insert the air plug into the air
jack on the left side of the
main unit.
2. Put your left arm through the
cuff loop.
Note: If the cuff is not
assembled, pass the
end of the cuff furthest
from the tubing through
the metal D-ring to form
a loop. The smooth
cloth should be on the
inside of the cuff loop.
HEM-7102-IM_main.book Page 14 Friday, October 5, 2007 1:41 PM

15
3.Using the Unit
EN
3. Position the arm correctly.
Taking measurements on the right arm
Apply the cuff so that
the air tube is at the
side of your elbow.
• Be careful not to rest
your arm on the air
tube, or otherwise
restrict the flow of air
to the cuff.
• The cuff should be 1
to 2 cm above the
elbow.
4. When the cuff is positioned correctly, close the fabric fastener
FIRMLY.
1) The air tube should run
down the inside of your
forearm and be in line with
your middle finger.
2) The bottom of the cuff
should be approximately 1
to 2 cm above your elbow.
3) Apply the cuff to your
upper arm so that the
coloured marker (blue
arrow under tube) is
centered on the middle of
your inner arm and points
down the inside of the
arm.
1 to 2 cm
HEM-7102-IM_main.book Page 15 Friday, October 5, 2007 1:41 PM

16
3.Using the Unit
3.3 Taking a Reading
1. Press the O/I START button to turn on the unit.
The cuff starts to inflate automatically.
Sit in a chair with your feet flat on the floor and place your arm
on a table so that the cuff will be at the same level as your
heart. Keep still and do not talk during measurement.
Note: To cancel a measurement, press the O/I START button
to turn off the unit and to release the air in the arm cuff.
2. Inflation stops and the measurement starts with deflating. As
the cuff deflates, the heartbeat symbol ( ) flashes at every
heartbeat.
3. When the measurement is complete, the arm cuff completely
deflates. Your blood pressure and pulse rate are displayed.
4. Check the measurement
results.
The unit automatically stores
blood pressure and pulse
rate into its memory. Refer to
“3.5 Using the Memory
Function”.
Note: Wait 2-3 minutes before taking another blood pressure
measurement. Waiting between readings allows the
arteries to return to the condition prior to taking the
blood pressure measurement.
Diastolic blood
pressure
Systolic blood
pressure
Pulse display
HEM-7102-IM_main.book Page 16 Friday, October 5, 2007 1:41 PM

17
3.Using the Unit
EN
Warning:
Self-diagnosis of measured results and treatment are
dangerous. Please follow the instructions of your doctor.
5. Remove the arm cuff.
6. Press the O/I START button to turn the unit off.
Note: If you forget to turn the unit off, it will automatically shut
itself off after five minutes.
Common Causes of Inaccurate Results
Leaning forwards.Arm cuff is too loose. Movement or talking
during measurement.
Note: If the arm cuff is at a lower position
than your heart use cushions etc., to
adjust the height of your arm.
HEM-7102-IM_main.book Page 17 Friday, October 5, 2007 1:41 PM

18
3.Using the Unit
Important:
• If your systolic or diastolic pressure is
outside the standard range, the heartbeat
symbol will blink when the measurement
result is displayed.
Recent research suggests that the
following values can be used as a guide to
high blood pressure for measurements
taken at home.
This criteria is for home blood pressure measurement.
For professional office blood pressure measurement criteria,
please refer to Chapter 9 “Some Useful Information about
Blood Pressure”.
• Your blood pressure monitor includes
an irregular heartbeat feature.
Irregular heartbeats can influence the
results of the measurement. The
irregular heartbeat algorithm
automatically determines if the
measurement is usable or needs to
be repeated. If the measurement
results are affected by irregular
heartbeats but the result is valid, the result is shown
together with the irregular heartbeat symbol ( ). If the
irregular heartbeats cause the measurement to be invalid,
no result is shown. If the irregular heartbeat symbol ( ) is
shown after you have taken a measurement, repeat the
measurement. If the irregular heartbeat symbol ( ) is
shown frequently, please make your doctor aware of it.
Systolic Blood Pressure Above 135 mmHg
Diastolic Blood Pressure Above 85 mmHg
HEM-7102-IM_main.book Page 18 Friday, October 5, 2007 1:41 PM

19
3.Using the Unit
EN
What is Irregular Heartbeat?
An irregular
heartbeat is a
heartbeat rhythm
that varies by more
than 25% from the
average heartbeat
rhythm detected
while the unit is
measuring the
systolic and diastolic
blood pressure.
If such an irregular rhythm is detected more than twice during
measurement, the irregular heartbeat symbol ( ) appears
on the symbol when the measurement results are displayed.
What is Arrhythmia?
A heartbeat is stimulated by electrical signals that cause the
heart to contract.
Arrhythmia is a condition where the heartbeat rhythm is
abnormal due to flaws in the bio-electrical system that drives
the heartbeat. Typical symptoms are skipped heartbeats,
premature contraction, an abnormally rapid (tachycardia) or
slow (bradycardia) pulse. This can be caused by heart
disease, aging, physical predisposition, stress, lack of sleep,
fatigue etc. Arrhythmia can only be diagnosed by a doctor
through a special examination.
Whether the appearance of the irregular heartbeat symbol
( ) in the results indicates arrhythmia or not can only be
determined by an examination and diagnosis by your doctor.
Warning:
If the irregular heartbeat symbol ( ) is shown
frequently, please make your doctor aware of it.
Conducting self-diagnosis and treatment based on
measurement results is dangerous. Be sure to follow the
instructions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood pressure
Blood pressure
Short Long
Pulse
HEM-7102-IM_main.book Page 19 Friday, October 5, 2007 1:41 PM

20
3.Using the Unit
3.4 Instructions for special conditions
If your systolic pressure is known to be more than 170 mmHg, press
and hold the O/I START button until the arm cuff inflates 30 to 40 mmHg
higher than your suspected systolic pressure.
1. Press the O/I START button
to turn the unit on.
Measurement starts.
2. When the cuff starts to inflate, press the O/I START button
and keep it pressed until the pressure is 30 to 40 mmHg
higher than your suspected systolic pressure.
Note: You cannot inflate the cuff above 299 mmHg. (An error
will be displayed if you try to inflate the cuff above
299 mmHg.)
3. Release the O/I START button when the cuff has been inflated
to the desired pressure.
The cuff starts to deflate and measurement starts.
4. The rest of the procedure is the same as for normal
measurement. Refer to 3.3, steps 2 to 6.
Note: Do not apply more pressure than necessary.
HEM-7102-IM_main.book Page 20 Friday, October 5, 2007 1:41 PM
