Omron YSC-8361 User manual

1
INSTRUCTION MANUAL
YSC-8361
AC Servo System
Please read the manual before using the Controller
Please keep the manual for easy reference
Version:V.002beta
20160615

2
For your perfect operation and safety, before using your new machine, please
read this instruction manual.
YSC-8361 controller is used for an industrial sewing machine. With industrial
sewing machine, it is normal to carry out work while positioned directly in
front of moving parts such as the needle and thread take-up, and
consequently there is always a danger of injury that can be caused by these
parts. So when you ready to operate the machine, please follow the
instructions from trained personnel and instructors regarding safe and
correct operation.
1. NOTICE
1.1 Work environment
▲Please use 220V AC in ±10% ranges.
▲To avoid the false operate; please keep the product away from the high
electromagnetic interference.
▲Please operate in the area which temperature is 5 ℃~45 ℃and
humidity is 80% or less.
1.2 Notice of installation
▲Turn off the power and unplug the cord before installation.
▲The cables must not set to be near the wheel and other movable parts.
▲To avoid the static interference and current leakage, all grounding must
be done.
1.3 Notice of safety
▲Turn off the power before maintenance and repairs or raising the
machine arms, or changing needle, or threading needle.
▲Please don’t open the box except the professional.
▲When turn on the machine in the first time, use low speed to operate and
check the correct rotation direction.
▲During machine operation, don’t touch any moving parts.
▲All moving parts must use the protective device to avoid the body contact
and objects insertion.
▲When there is water or other liquid, or caustic material on box or motor,
you must stop operation and turn off the power.
▲All connector shouldn’t be plug and unplug when power on.
▲The connector should be plug and unplug in the correct method.

3
2. POWER CONNECTION AND GROUNDING
2.1 Single phase 220V power connection
Green/yellow wire must be connected to the earth.
2.2 Three phase 380V power connection
3. CONNECTOR DIAGRAM
4. OPERATING FIELD P200B
Start tacking
Single start tacking, A is the stitches of forward
sewing; B is the stitches of backward sewing.
They are both in range 1~15
Double start tacking, A is the stitches of
forward sewing; B is the stitches of backward
sewing.They are both in range 1~15。
End tacking
Single end tacking, C is the stitches of backward
sewing; D is the stitches of forward sewing.
They are both in range 1~15
Double end tacking, C is the stitches of
backward sewing; D is the stitches of forward
sewing.They are both in range 1~15
Free Sewing
▲As the pedal is stepped forward, the start tacking(if
selected) will be done automatically, then machine will

4
start normal sewing. Once the pedal returned to
balance, machine will stop immediately.
▲As the pedal stepped backward, the end
tacking, trimming and wiping(if selected) will be
done automatically
Constant-Stitch
Sewing
▲Once the pedal is stepped forward, F, G stitches will
be completed with E times.
▲Constant-Stitch Sewing will perform the number of
segments and times as setting, when the stitches are
zero, machine will stop immediately.
Bar-Tacking
Sewing
▲Once the pedal is stepped forward, all the seams of
bar tacking, A, B, C, D sections will be completed with
E times, and the trimming will be done automatically.
▲The pedal must be returned to balance for next
sewing.
Lower thread
Counter
Enter lower thread counter interface
Soft start
Enable or disable the soft start
Needle Up / Needle
Down
Select the stop position of needle bar
Trimming Enable
Enable or disable the trimming
Interface
Selection
Switch current interface to another
One-Key Default
/Lock keys
Parameter
Function
Enter or exit parameter function interface
Save
Confirm and save current value of parameter
Add
Value increase
Sub
Value decrease
5. OPERATING ELEMENTS
5.1 Single start tacking setting
A Stitches = 0
Seven-segment display A display 『-』.
Sewing process: B stitches back –normal sewing.
A Stitches ≠ 0
Sewing process: A stitches forth –B stitches back –normal sewing
5.2 Double start tacking setting

5
A Stitches = 0
Sewing process：B stitches back –B stitches forth –B stitches back –
normal sewing.
A Stitches ≠ 0
Sewing process：A stitches forth –B stitches back –A stitches forth –B
stitches back –normal sewing
5.3 Single end tacking setting
A Stitches = 0
Seven-segment display D display 『-』.
Sewing process：C stitches back –end.
A Stitches ≠ 0
Sewing process：C stitches back –D stitches forth –end.
5.4 Double end tacking setting
A Stitches = 0
Sewing process：C stitches back –C stitches forth –C stitches back –end.
A Stitches ≠ 0
Sewing process：C stitches back –D stitches forth –C stitches back –D
stitches forth –end.
5.5 Lower thread counter
Set A11 to “1” to active the counter.
Enter interface: Press Or Special function interface SN F6(refer to
6.6).
Initial counter: Press , the initial value of the lower thread counter
which was set previously will be shown. Adjust it to a suitable value.
How the counter works：
Display initial value
The counter reduces by 1 for every 10 stitches sewn.
If the counter less than 1, the display area will warn and buzzer sounds
for 3 times. After thread trimming, will not start up again. Press
the warning will disappear and sewing will be possible, the counter
reduces continue.
Press again, the display will return to the initial value
5.6 Production counter
Set A11 to “1” to active the counter.
Enter interface：Special function interface SN F2,refer to 6.2
Data acquisition：In SN F2 interface, press will be into collect
process interface, seven-segment display D displays 『L』, seven-segment
displays E,F,G will display the number of stitches for this process. It records
the number of stitches and the number of trimmer. Press to save

6
the data and return SN F2 interface.
How the Counter works: If sewn the number stitches more than the
number of stitches collected 90%, and the number of trimming times more
than collected, the counter add 1.
Clear Counter: press
5.7 Adjust the tacking
Adjusting of RVE.SOL action time
For start/end tacking or bar tacking, if unbalanced situation is appeared during natural
direction to reverse direction, please correct it as below:
Adjusting of RVE.SOL release time
For start/end tacking or bar tacking, if unbalanced situation is appeared during reverse
direction to natural direction, please correct it as below:
5.8 Quick functions on the keypad
Figure 2：Keypad on the machine arm
Foot stroke
Toggle foot stroke level
Start and end
strips
This key cancels the general setting for
sewing start and end strips. If strips are
activated, pressing the key disables the next
strip. If no strips are activated pressing the
key sews the next strip.
Position of the
needle
If the key is selected the needle moves to a
specific position. This position is determined
individually via the parameter settings, more
information read D15, D16
Stitch Length
If this key is selected, the machine sews
using the smaller stitch length selected at
lower adjusting wheel for the stitch length
Additional
thread tension
This key switches on the additional thread
tension
Decrease
parameter T01
增大 T01
增大 T02
Increase
parameter T01
Decrease
parameter T02
Decrease
parameter T02

7
Pause
If the pause switch is triggered, all functions
are locked except parameters, the adjacent
led light up, panel display “PAUSE”
5.9 LOCK THE HOT KEYS AND KEYPAD
if key is triggered, all functions on the keypad and hot keys are invalid.
5.10 ELECTRONIC HAND WHEEL & HOT KEYS
Turning the hand wheel:
The value of “A23” is 1, electronic hand wheel is activated. By turning the
hand wheel, you can move the needle bar forwards or backwards.
Pressing the hand wheel:
THIS IS A CUSTOMIZABLE HOT KEY!
Default: None
Refer to Parameter list, A05
Pressing the Reverse switch:
THIS IS A CUSTOMIZABLE HOT KEY!
Default: Pressing the key changes the sewing direction.
Refer to Parameter list, A04
6. OPERATION OF THE SPECIAL FUNCTION INTERFACE
Press switch to the special function interface from normal function interface, showed
as below:
Display A and B show the SN of function, D~G display contents, press B+ and B- to select
functions:
6.1 Dynamic speed limitation
SN F1：display current speed up limitation, the operator can change the speed
limitation during running.
6.2 Production counter
SN F2：display the production counter.
6.3 Machine phase
SN F3：display the machine phase
6.4 Torque enhancement function at low speed
SN F4：display the level
0: off, 10:maximum
6.5 Measure the instant speed
SN F5：display the instant speed.

8
6.6 Lower thread counter
SN F6：display how much the lower thread is remaining
7. PARAMETER INSTRUCTION
7.1 Setting parameter
Press to enter the parameter Interface.
Display E shows the parameter type, press “E+” and “E-“ key to change it.
Display F, G show the parameter index, press “F+”,“F-“, “G+”, “G-“key to change it.
Displays A, B, C, D show the parameter value, press the keys under them to change it.
For example, figure 4：parameter index is 1, type is P, value of “S01” is 2000, the nixie
tube will blink when change the value. Press to confirm, press to cancel
and return to sewing interface.
figure 4: the parameter interface
7.2 Get the permission of setting o type parameter
Only S, T and A type parameter can be select normally, if you want to change
the O type parameter, you must press key when switching power on,
when panel shows『DO EN』, you get the permission successfully.
7.3 Parameter solidifying
If the operator want to change some parameter’s default value, then select the
parameter, press maintain a moment, after 『SD OK』displaying, the
default value has been changed.
7.4 Resumine parameter through one-key default
Select any parameter in parameter interface, can be used to recall the
default value. The display will be twinkling if the parameter is modified, use
to confirm or to cancel the change
7.5 Controller recovery
Resume the default value of all parameters
Set parameter O17 to “ON”, turn on the power again, after twinkling of
“INIT” finished, all parameters have been default value themselves
Restore Factory Defaults
Set parameter O51 to “ON”, turn on the power again.

9
7.6 Disable the safety switch
If you want to disable the function of Safe SW., you can change the value of
“O31”from “1” to “0” normally, in a particular case, for example, the Safe SW. broke
down, you can power on while press “C+” key to disable the function of Safe SW.
warning ： it means potential security problems for you if you disable the function of Safe
SW., so attention please.
7.7 Parameter list
SN
PARAMETER
RANGE
DESCRIPTION
S Type Para
S01
Max Speed
500 ～
3000spm
Unit: stitch/min
S02
Min Speed
150 ～
500spm
Unit: stitch/min
S03
Start tacking speed
500 ～
2000spm
Speed adjustment for
start tacking
S04
End tacking speed
500 ～
2000spm
Speed adjustment for end
tacking
S05
Bar-tacking speed
500 ～
2000spm
Speed adjustment for
bar-Tacking
S06
C-S sewing speed
500 ～
2000spm
Speed adjustment for
constant-stitch sewing
S07
Trimming speed
150 ～
300spm
Speed adjustment for
trimming
S08
Soft start speed
200 ～
500spm
Soft start speed
S09
Speed limit for stroke
height level 1
500 ～
4000spm
S10
Speed limit for stroke
height level 2
500 ～
4000spm
S11
Speed limit for stroke
height level 3
5004 ～
000spm
S12
Speed limit for stroke
height level 4
500 ～
4000spm
T Type Para
T01
RVS action time
1～200（ms）
Action time of the REV
SOL.
T02
RVS release time
1～200（ms）
Release time of the REV
SOL.
T05
Foot lifter delay time
setting
1～500（ms）
Foot lifter Delay time
adjustment for pedal’s
feet lift position
T06
Running-Delay time
setting
1～500（ms）
Running delay time
adjustment for Automatic
Foot Lifter

10
T09
Safety switch-Delay
time setting
1～1000
（ms）
Safety switch-Delay time
adjustment for machine
vibration
T10
Pedal-Delay time
setting
1～200（ms）
Pedal-Delay time
adjustment for pedal
vibration
A type
A01
Needle Position on Stop
0～1
1：Up Position
0：Down Position
A02
0～1
Automatic
Constant-Stitch sewing
1 = On
0 = Off
A03
0～1
Correction stop mode
1 = stop position accord
to D15,D16
0 = random
A04
Reverse switch
function
0～12
You can choose between:
0：none
1：reverse
2：half stitch correction
3：continuously correction
4：half stitch correction at
machine stop，reverse at
machine run
5：continuously correction
at machine stop，reverse
at machine run
6：
7：trim at normal sewing，
foot lifer after trimming
8：foot lifer
9：foot stroke
10 ：single backtack
supression
11：2nd STITCH LENGTH
12：
A05
Hand Wheel Switch
function
0～12
Refer to A04
A06
Trimmer function
selection
0～1
1 = trimmer enable
0 = trimmer disable
A07
Lock Machine Buttons
0～1
Machine Buttons includes
Hot Keys, Hand Wheel
Switch, Reverse Switch.

11
A09
Foot Lifer function
selection
0～1
1 = Foot lifter function
enable
0 = Foot lifter function
disable
A10
Clamp function
selection
0～1
1: Clamp enable
0: Clamp disable
A11
0～1
Production Counter
1 = On
0 = Off
A12
0～1
Lower thread Counter
1 = On
0 = Off
A13
0～1
Pull Back after
Trimming(refer to O35)
1 = On
0 = Off
A14
0～1
Automatic Foot Lifter at
stop
1 = On
0 = Off
A15
0～1
Automatic Foot Lifter
after trimming
1 = On
0 = Off
A16
0～1
Automatic
constant-stitch sewing
after start tacking (only
when A02=0)
1 = On
0 = Off
A17
0～1
Automatic end tacking
for constant-stitch
sewing(only when A02=0)
1 = On
0 = Off
A18
0～1
Search Upper position
when switching the
power on
1 = On
0 = Off
A19
Function when
Half-Heeling the pedal
0～2
Function when
Half-Heeling the pedal
2：thread cutting
1：feet lift

12
0：Idle
A20
0～1
Mode of start tacking
1：stitch for stitch
0：normal
A22
0～1
Mode of end tacking
1 = stitch for stitch
0：normal
A23
0～1
Electronic hand wheel
1 =Yes
0 = No
D type Parameter
D01
Up lever
0～359（°）
Angle of needle bar up
lever
D02
Down lever
0～359（°）
Angle of needle bar down lever
D03
0～359（°）
Switch-on angle of
Trimmer SOL
D04
0～359（°）
Switch-off angle of
Trimmer SOL
D05
0～359（°）
Switch-on angle of
Reverse SOL.
D06
0～359（°）
Switch-off angle of
Reverse SOL.
D07
0～359（°）
Switch-on angle of thread
clamp SOL
D08
0～359（°）
Switch-off angle of thread
clamp SOL
D13
0～359（°）
Switch-on angle of thread
tension SOL
D14
0～359（°）
Switch-off angle of
thread tension SOL
D15
0～359（°）
Position of the needle 1
D16
0～359（°）
Position of the needle 2
O Type Parameter
O01
Number of stitches for
the Soft Start
1～10
（stitch）
Number of soft start
stitches
O04
1～1000
（ms）
Delay time for stitch for
stitch tracking. Refer to
A20
O06
0～1
1：Automatic foot lifter
release after the time of
O06
0：No
O07
5～30
（needle）
Refer to O06

13
O17
Resume the default
value of all parameters
0～1
O31
0～1
Safety switch function
1 = enable
0 = disable
O32
0～1
Signal polarity of safety
switch
0: Normal closed
1: Normal opened
O35
0～359
Angle of pull back
function
O51
Restore Factory
Defaults
0～1
O69
0～1
Correction mode
1 = Correction when
machine is stopped.
0 = Can not Correct after
trimming
O72
0～10
torque enhancement
function when running at
low speed
0 = Off
1～10 = level 1-10
O84
0～720
Step width for electronic
hand wheel
O85
0～200
Speed for electronic hand
wheel
O86
0～2
Speed Limit Device to
stroke
0：none
1：Digital
2：Analog
8. HOW TO ADJUST THE ZERO POSITION
Press hold and power on to adjust ZERO position for the machine.
Rotate the motor to ZERO position, displays will show the angle.
Press to confirm and save.
9. ERROE MESSAGES & POSSIBLE TROUBLESHOOTING

14
ERROE
CODE
DESCRIPTION
SOLUTION
PEDAL
Pedal warning
-Check or replace the pedal
-Pedal not connected
-Do not pedal yet
CARE
Safe Switch problem
-Check the Safe Switch
-Replace the safe switch
KEY1
Machine button
warning
-Do not press machine button
-Replace the buttons
E101
High AC voltage fault
-Check mains voltage
-Stabilize mains voltage
-Use generator
E103
High Bus voltage fault
-Check mains voltage
-Stabilize mains voltage
-Use generator
E106
Bus current overload
-Check the encoder and motor
-Replace the encoder
-Replace the motor
E107
Motor blocked
-Eliminate stiff movement in the machine
-Replace the encoder
-Replace the motor
E110
Encoder/Synchronizer
fault
-check or replace the synchronizer for a
belt-drive machine
-check or replace the encoder for a
direct-drive machine
E190，E290
Software Update
Error
-Software update
-Replace the control
E191,
E291
Software Update
Error
-Software update
-Replace the control
E193,
E293
Software Update
Error
-Software update
-Replace the control
E294
Software Update
Communication Error
-Software update
-Replace the control
E199
Software Update
Error
-Software update
-Replace the control
E900
Communication
problem
-Restart the control
-Replace the control
1. Controller Check
Press hold during power on, it will display “TEST” and then enter the Check
interface. Diplay A display check index, the else display contents.
1.1 Pedal
1.2 Synchronizer

15
1.3 Hot Keys
1.4 Motor encoder
1.5 Output Device
Press to test.
Trimmer:
Foot Lifter:
Thread tension:
Thread clamp:
Addition thread tension:
Reverse:
Stitch length:
Stroke:
1.6 Input Switches
Display C：Reverse switch
Display E：Safety Switch
Display G：Knee Stroke Switch
1.7 Electronic Handwheel
Display B：Rotation
Display C：Press Switch
Display DEFG：Encoder
1.8 Speed Limit Device to stroke
Digital Type：
Analog Type：
1.9 AC voltage
1.10 Bus voltage
1.11Software Version
1.12HardwareVersion
1.13Software Release Date
2. Appendix
2.1 Machine ID
2.1.1 How to change the machine ID
Press hold 『A+』key and turn on the power to access to adjust the
machine ID, seven-segment displays F,G will display the ID, change it
and press to save.
2.1.2 Table of maximum speeds
Machine ID
Unit(sti/min)
1
20665 Direct-drive
2000
2
20665 Belt-drive
2000
3
TW1-899-D2T3
2500
4
TW1-898D3T3
2500
5
TW1-999-D2T3
2500
6

16
2.2 Seven-Segment Display Characters Compare Table
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
