Omron INSTRUCTION MANUAL User manual

Compressor Nebulizer
NE-C801
INSTRUCTION MANUAL
TM
NE-C801S-Z_A_M11_110328.pdf
Caution: Federal (USA) law restricts this device to sale by or on the
order of a physician or licensed healthcare practitioner
ENGLISH ESPAÑOL
NE-C801S-Z_A_M_E_SP_041311.indd 1 4/13/11 10:20:13 AM

2
CONTENTS
The illustrations shown in this instruction manual are image drawings and may
differ slightly from the appearance of the actual product.
Before Using the Device
Introduction.........................................................3
IntendedUse........................................................4
Safety Information....................................................5
Know Your Unit......................................................9
Operating Instructions
PreparingtheNebulizerforUse........................................11
AttachingtheAirTube ...............................................14
Using the Device ....................................................15
Care and Maintenance
CleaningafterEachUse..............................................18
DailyDisinfecting...................................................19
ChangingtheAirFilter...............................................20
CaringfortheDevice ................................................21
Troubleshooting
TroubleshootingGuide ...............................................22
Limited Warranty....................................................23
FCC Statement......................................................24
Specifications.......................................................25
Technical Data ......................................................26
Guidance and Manufacturer's Declaration ................................27
NE-C801S-Z_A_M_E_SP_041311.indd 2 4/13/11 10:20:13 AM

3
Thank you for purchasing the OMRON NE-C801 Compressor Nebulizer.
Fill in for future reference.
DATE PURCHASED: __________________
SERIAL NUMBER:____________________
• Staple your purchase receipt here
• Register your product on-line at
www.register-omron.com
This product was developed for the successful treatment of asthma, allergies and other
respiratory disorders. The compressor forces air to the nebulizer. When the air enters the
nebulizer, it converts the prescribed medication into an aerosol of microscopic droplets
that can easily be inhaled.
Your NE-C801 Compressor Nebulizer comes with the following components:
 •Compressor(MainUnit)
 •NebulizerKit
 •Mouthpiece
 •AirTube(PVC,100cm)
 •ACAdapter
 •AirFilters(Packageof5)
 •StorageBag
 •InstructionManual
The following are optional accessories sold separately:
 •Nosepiece
 •AdultMask(PVC)
 •ChildMask(PVC)
Before Using the Device
INTRODUCTION
Please read this instruction manual thoroughly before using the unit.
Please keep for future reference.
For specific information about your own nebulizer,
CONSULT YOUR DOCTOR.
SAVE THESE INSTRUCTIONS
NE-C801S-Z_A_M_E_SP_041311.indd 3 4/13/11 10:20:14 AM

4
The NE-C801 Compressor Nebulizer System is intended to provide air to the pneumatic
nebulizer in order to aerosolize medications for inhalation by the patient for respiratory
disorders. The system is designed for use with pediatric (defined by the prescribed
medication) and adult patients in the home, hospital, and sub-acute settings.
All warnings and cautions described in this manual should be observed.
Intended Use
NE-C801S-Z_A_M_E_SP_082411.indd 4 8/26/11 12:15:10 PM

5
To ensure the correct use of the product, basic safety measures should always be followed
including the warnings and cautions listed in this instruction manual.
OPERATING THE DEVICE
For type, dose, and regime of medication follow the instructions of your physician
or licensed healthcare practitioner.
If you feel anything unusual during use, stop using the device immediately and
consult your physician.
Do not cover the compressor with a blanket, towel, or any other type of cover
during use. This could result in the compressor overheating or malfunctioning.
Do not use the device where the device may be exposed to flammable gas or vapors.
Do not use tap or mineral water in the nebulizer for inhaling purposes.
Clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or optional
masks before using them for the first time after purchase.
If the device has not been used for a long period of time, clean and disinfect the
nebulizer kit, mouthpiece, and optional nosepiece or optional masks before using
them.
Pentamidine is not an approved medication for use with this device.
Always dispose of any remaining medication in the medication cup after each use.
Use fresh medication each time you use the device.
Do not leave the device or its parts where it will be exposed to extreme temperatures
or changes in humidity, such as leaving the device in a vehicle during warm or hot
months, or where it will be exposed to direct sunlight.
Do not use or store the device where it may be exposed to noxious fumes or volatile
substances.
Make sure that the nebulizer kit is clean before use.
Do not use in anaesthetic or ventilator breathing circuits.
Not suitable for use in the presence of flammable anesthetic mixture with air or
oxygen or nitrous oxide.
WARNING Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury to the user or
patient or damage to the equipment or other property.
SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL
SAFETY INFORMATION
NE-C801S-Z_A_M_E_SP_041311.indd 5 4/13/11 10:20:16 AM

6
OPERATING THE DEVICE (continued)
Do not operate where oxygen is being administered in a closed environment (such
as an oxygen tent).
Provide close supervision when this device is used by, on, or near infants, children
or compromised individuals.
If the device is used continuously, the service life of the device may be shortened.
Limit use to 20 minutes at a time, and allow a 40 minutes interval before using the
device again.
When using the device, the main unit may become hot.
Do not touch the main unit for other than necessary operation such as turning off the
power while nebulizing.
Do not insert any object into the compressor.
Make sure the air filter is clean. If the air filter has changed color or has been used
on average for more than 60 days, replace it with a new one.
Make sure the nebulizer kit is correctly assembled, the air filter is properly installed,
and the air tube is correctly connected to the compressor and the nebulizer kit. Air
may leak from the air tube during use if not securely connected.
Inspect the compressor (main unit) and the nebulizer parts each time before using
nebulizer kit. Make sure no parts are damaged, the nozzle and air tube are not
blocked and the compressor operates normally.
Do not use the device if the air tube is bent.
Do not block the air filter cover.
Do not alter the baffle, the nozzle in the medication cup or any part of the nebulizer kit.
Do not add more than 7mL of medication to the medication cup.
 Donotoperatethedeviceattemperaturesgreaterthan+40˚C(+104˚F).
 Donottiltthenebulizerkitsotheangleofthekitisgreaterthan45˚.Medication
may flow into the mouth.
Do not shake the nebulizer kit while using the device.
Do not subject the compressor or any of the components to strong shocks, such as
dropping on the floor.
This device is approved for human use only.
Do not disassemble or attempt to repair the device or components.
Operate the device only as intended. Do not use the device for any other purpose.
SAFETY INFORMATION
NE-C801S-Z_A_M_E_SP_041311.indd 6 4/13/11 10:20:17 AM

7
OPERATING THE DEVICE (continued)
Dispose of the device, components and optional accessories according to applicable
local regulations. Unlawful disposal may cause environmental pollution.
Use only Omron authorized parts and accessories. Parts and accessories not
approved for use with the device do not perform the expected specification or it may
damage the unit.
Changes or modification not approved by Omron Healthcare will void the user
warranty.
To avoid injury to the nose mucosa, do not squeeze the optional nosepiece into the
back of the nose.
To avoid the medication residue on the face. After nebulization, be sure to wipe the
face after removing the optional masks.
When using this device, there will be some noise and vibration caused by the
pump in the compressor. There will also be some noise caused by the emission
of compressed air from the nebulizer kit. This is normal and does not indicate a
malfunction.
When sterilizing parts by boiling, make sure that the container does not boil dry.
Do not use the device while sleeping or if drowsy.
Do not block the slit between the cap and the inhalation air inlet.
RISK OF ELECTRICAL SHOCK
Do not connect the AC adapter terminal using wire or other metallic conductors.
Do not use the compressor (main unit) or AC adapter while they are wet.
Do not plug or unplug the AC adapter into the electrical outlet with wet hands.
Do not immerse the compressor (main unit) in water or other liquid.
Do not spill water or other liquids on the compressor and AC adapter. These parts
are not waterproof. If liquid spills on these parts, immediately unplug the AC
adapter and wipe off the liquid with gauze or other soft absorbent material.
Do not use or store the device in humid locations, such as a bathroom. Use the
device within the operating temperature and humidity.
Use only the AC adapter designed by Omron for this device. Use of any other AC
adapter may damage the device.
Do not operate the device with a damaged power cord or plug.
Do not use a cellular phone near the device. It may result in an operational failure.
SAFETY INFORMATION
NE-C801S-Z_A_M_E_SP_041311.indd 7 4/13/11 10:20:18 AM

8
SAFETY INFORMATION
RISK OF ELECTRICAL SHOCK (continued)
Do not overload power outlets. Plug the AC adapter into the appropriate voltage
outlet.
Do not use extension cords. Plug the AC adapter directly into the electrical outlet.
Unplug the AC adapter from the electrical outlet after using the device.
Remove the AC adapter from the device after use.
Unplug the AC adapter from the electrical outlet before cleaning the device.
Do not pull the power cord of AC adapter strongly.
MAINTENANCE AND STORAGE
Keep the device out of the reach of unsupervised infants and children. The device
may contain small parts that can be swallowed.
Do not leave the cleaning solution in the nebulizer parts. Rinse the nebulizer parts
with clean hot tap water after disinfecting.
Wash the nebulizer parts after each use. Dry the parts immediately after washing.
Do not store the air tube with moisture or medication remaining in the air tube.
This could result in infection as a result of bacteria.
Store the device and the components in a clean, safe location.
Do not carry or leave the nebulizer kit with medication in the medication cup.
Do not place or attempt to dry the device, components or any of the nebulizer parts
in a microwave oven.
Do not wrap the power cord around the compressor (main unit) and AC adapter.
NE-C801S-Z_A_M_E_SP_041311.indd 8 4/13/11 10:20:19 AM

9
Air Tube
(PVC, 100 cm)
Nebulizer Kit Holder
Power Switch
Nebulizer Kit
Cap
Inhalation Air Inlet
Inhalation Top
Baffle
Medication Cup
Nozzle
Air Tube Connector
Mouthpiece
KNOW YOUR UNIT
Components and Replacement Parts
Air Tube
Connector
Back View
Power
Connector
Air Filter Cover
*Air filter inside
Air Tube Plug
Air Tube Plug
Compressor (Main Unit)
Nebulizer Kit
NOTE: Only use the NE-C801 Nebulizer Kit with this
Nebulizer.
NE-C801S-Z_A_M_E_SP_041311.indd 9 4/13/11 10:20:22 AM

10
KNOW YOUR UNIT
Components:
Instruction Manual Storage BagAir Filters
Package of 5
Compressor Nebulizer
NE-C801
INSTRUCTION MANUAL
Caution: Federal (USA) law restricts this device to sale by or on the
order of a physician or licensed healthcare practitioner
ENGLISH ESPAÑOL
AC Adapter
Power Plug
Power Cord
Terminal
Accessories and Replacement Parts
Model No.
ACAdapter ........................................ C30AC
 AdultMask(PVC)................................... 9920
 ChildMask(PVC) ................................... 9921
Air Filters (Package of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C30FL
AirFilterCover..................................... C801FC
 AirTube(PVC,100cm) .............................. C801AT
NebulizerKitSet ................................... C801NEB
Includes Nebulizer Kit, Mouthpiece and Air Tube
Nosepiece.......................................... C911
Mouthpiece. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C910
NE-C801S-Z_A_M_E_SP_041311.indd 10 4/13/11 10:20:25 AM

11
WARNING
• Clean and disinfect the nebulizer kit, mouthpiece, and optional nosepiece or
optional masks before using them for the first time after purchase.
• If the device has not been used for a long period of time, or if more than one
person uses the same device, clean and disinfect the nebulizer kit, mouthpiece,
and optional nosepiece or optional masks before using them.
CAUTION
Make sure the air filter is clean. If the air filter has changed color or has been
used on average for more than 60 days, replace it with a new one.
For directions on cleaning and disinfecting refer to page 18 - 19.
For directions on changing the air filter refer to page 20.
1Insert the power plug on the AC adapter into
the power connector on the back side of the
compressor. Plug the AC adapter into the electrical
outlet.
WARNING
Do not plug or unplug the AC adapter into the
electrical outlet with wet hands.
CAUTION
• Do not overload power outlets. Plug the AC adapter
into the appropriate voltage outlet.
• Do not use extension cords. Plug the AC adapter
directly into the electrical outlet.
NOTE: AC adapter can be worked at 100-240V~350mA,50/60Hz.
2Lift up the mouthpiece and the cap to remove them
from the nebulizer kit.
Electrical Outlet
Power Connector
Power Plug
PREPARING THE NEBULIZER FOR USE
Operating Instructions
NE-C801S-Z_A_M_E_SP_041311.indd 11 4/13/11 10:20:28 AM

12
3 Rotatetheinhalationtopcounterclockwise(A)andlift(B)
to remove the inhalation top from the medication cup.
4Add the correct amount of prescribed medication to the medication cup.
WARNING
• For type, dose, and regime of medication follow the instructions
of your physician or licensed healthcare practitioner.
• Do not spill water or other liquids on the compressor and AC
adapter. These parts are not waterproof. If liquid spills on these
parts, immediately unplug the AC adapter and wipe off the liquid
with gauze or other soft absorbent material.
• Do not use tap or mineral water in the nebulizer for inhaling
purposes.
CAUTION
Do not add more than 7mL of medication to the medication cup.
NOTE: Scales on the nebulizer kit are for reference only. The scale on the outside
of the medication cup is with no baffle in place. Please use the scale on your
syringe or vial for accurate measurement of medication.
5 Make sure that the baffle is securely attached to the
inhalation top.
6Place the inhalation top on the medication cup.
Align the protrusion on the inhalation top with the
indentation on the medication cup as illustrated (A).
Turntheinhalationtopclockwiseuntilsecurelyclosed(B).
PREPARING THE NEBULIZER FOR USE
NE-C801S-Z_A_M_E_SP_041311.indd 12 4/13/11 10:20:31 AM

13
PREPARING THE NEBULIZER FOR USE
7Attach the desired inhalation accessory.
USING THE MOUTHPIECE
Place the cap on the medication cup over the inhalation
air inlet (A).
 Attachthemouthpiece(B).
NOTE: Place the cap on the medication cup when using the
mouthpiece. Using the cap with the mouthpiece will
reduce the amount of medication that is discharged
into the air.
USING THE NOSEPIECE (Optional)
Place the cap on the medication cup over the inhalation
air inlet (A).
 Attachthenosepiece(B).
NOTE: Place the cap on the medication cup when using the
nosepiece. Using the cap with the nosepiece will
reduce the amount of medication that is discharged
into the air.
USING THE CHILD MASK (Optional)
Place the cap on the medication cup over the inhalation
air inlet (A).
Attachthechildmask(B).
NOTE: If the amount of aerosol is too small, it is not necessary
to place the cap.
USING THE ADULT MASK (Optional)
Attach the adult mask to the inhalation top.
NOTE: If the amount of aerosol is too much, place the cap
on the medication cup over the inhalation air inlet.
NE-C801S-Z_A_M_E_SP_041311.indd 13 4/13/11 10:20:36 AM

14
1Twist the air tube plug slightly and push it firmly into the air tube connector
on the upper side of the compressor (A).
2Twist the air tube plug slightly and push it firmly into the air tube connector
 onthebottomofthenebulizerkit(B).
NOTE: Keep the nebulizer kit upright when attaching the air tube. Medication
may spill out of the medication cup.
CAUTION
• Make sure the nebulizer kit is correctly assembled, the air filter is properly
installed, and the air tube is correctly connected to the compressor and
the nebulizer kit. Air may leak from the air tube during use if not securely
connected.
•Do not use the device if the air tube is bent.
3Use the nebulizer kit holder as a temporary holder for the nebulizer kit.
NOTE: Align the mark on the unit with the mark on the nebulizer kit as shown.
ATTACHING THE AIR TUBE
NE-C801S-Z_A_M_E_SP_041311.indd 14 4/13/11 10:20:37 AM

15
WARNING
• Do not use the device where the device may be exposed to flammable gas or
vapors.
• Do not use or store the device in humid locations, such as a bathroom.
Use the device within the operating temperature and humidity.
CAUTION
• Provide close supervision when this device is used by, on, or near infants, children
or compromised individuals.
•
Do not use a cellular phone near the device. It may result in an operational failure.
• Inspect the compressor (main unit) and the nebulizer parts each time before
using the device. Make sure no parts are damaged, the nozzle and air tube are
not blocked and the compressor operates normally.
1Hold the nebulizer kit as illustrated on the right.
CAUTION
• Do not tilt the nebulizer kit so the angle of the kit
is greater than 45˚. Medication may flow into the
mouth.
• Do not shake the nebulizer kit while using the
device.
2Turn the power switch to the on ( ) position.
As the compressor starts, nebulization begins and
aerosol is generated.
To stop nebulization, turn the power switch to the
off ( ) position.
WARNING
Do not cover the compressor with a blanket, towel, or any other type of cover
during use. This could result in the compressor overheating or malfunctioning.
45°
USING THE DEVICE
NE-C801S-Z_A_M_E_SP_041311.indd 15 4/13/11 10:20:41 AM

16
CAUTION
• Do not block the air filter cover.
• Limit use to 20 minutes at a time, and allow a 40 minutes interval before using
the device again.
• When using the device, the main unit may become hot.
• Do not touch the main unit for other than necessary operation such as turning off
the power while nebulizing.
3Inhale medication as instructed by your physician or licensed healthcare
practitioner.
USING THE MOUTHPIECE
Insert the mouthpiece into your mouth. Inhale medication
breathing normally. Exhale normally through the
mouthpiece.
USING THE NOSEPIECE (Optional)
Inhale the medication through the nosepiece as illustrated.
Exhale through the mouth.
USING THE CHILD MASK or THE ADULT MASK (Optional)
Place the mask over the nose and mouth. Pull the elastic
strap over the head. Gently pull on the strap to secure the
mask over the nose and mouth. Inhale the medication.
Exhale normally through the mask.
4Complete the treatment.
WARNING
For type, dose, and regime of medication, follow the instructions of your
physician or licensed healthcare practitioner.
USING THE DEVICE
NE-C801S-Z_A_M_E_SP_041311.indd 16 4/13/11 10:20:43 AM

17
5Turn the power switch to the off ( ) position.
The compressor turns off and nebulization stops.
6Disconnect the air tube from the nebulizer kit.
Hold the air tube plug and gently pull down to disconnect the air tube plug
from the air tube connector on the bottom of the nebulizer kit.
7Check the air tube. No condensation or moisture should remain in the air tube.
WARNING
Do not store the air tube with moisture or medication remaining in the air tube.
This could result in infection as a result of bacteria.
If any condensation or moisture remains in the air tube, remove the moisture
from the air tube. Follow the directions below:
1. Make sure the air tube is still connected to the air tube connector
on the upper side of the compressor.
2. Press the power switch on. The compressor will start and pump
air through the air tube to expel the moisture.
3. Press the power switch again to turn the compressor off.
8Disconnect the air tube from the compressor. Hold the air tube plug and
gently pull the air tube plug off the air tube connector on the upper side of the
compressor.
9Unplug the AC adapter from the
electrical outlet.
CAUTION
• Unplug the AC adapter from the electrical
outlet after using the device.
• Remove the AC adapter from the device
after use.
• Do not pull the power cord of AC adapter
strongly.
USING THE DEVICE
NE-C801S-Z_A_M_E_SP_041311.indd 17 4/13/11 10:20:45 AM

18
Following cleaning instructions after each use will prevent any remaining
medication in the bottle from drying resulting in the device not nebulizing
effectively and will help prevent infections.
WARNING
Wash the nebulizer parts after each use. Dry the parts immediately after washing.
1Remove the inhalation accessory (mouthpiece, optional masks, or optional
nosepiece) from the nebulizer kit.
2Disconnect the air tube from the nebulizer kit.
3Gently twist the inhalation top counterclockwise and lift to separate the
nebulizer into two sections.
4Discard remaining medication in the medication cup.
WARNING
Always dispose of any remaining medication in the
medication cup after each use. Use fresh medication
each time you use the device.
5Rinse all the parts with hot tap water.
6Hand dry or air dry in a clean environment
using a soft, clean, lint-free cloth.
7Assemble the nebulizer kit and store it in a dry
bag.
Care and Maintenance
CLEANING AFTER EACH USE
NE-C801S-Z_A_M_E_SP_041311.indd 18 4/13/11 10:20:47 AM

19
DAILY DISINFECTING
Disinfect the nebulizer kit and mouthpiece, or optional masks or optional
nosepiece after the last treatment of the day.
To disinfect the parts, use one of the methods described below:
A. Use a commercially available disinfectant. Follow the instructions provided
by the disinfectant manufacturer.
1Submerge the parts in the cleansing solution for the specified period.
2Remove the parts and discard the solution.
3Rinse the parts with clean hot tap water, shake off excess water and allow
to air dry in a clean environment.
B. Parts may be boiled between 15 to 20 minutes.
After boiling, carefully remove the parts, shake off excess water and allow to
air dry in a clean environment.
NOTE: Do not boil air tube, air filter, air filter cover and optional masks.
CAUTION
Do not use an autoclave, EOG gas disinfection or low temperature plasma sterilizer to
disinfect the device.
Handling the Baffle
The baffle is an important part that is used to nebulize medication.
Besuretoobservethefollowingprecautionswhenhandlingit.
CAUTION
• Always wash the baffle after each use.
• Do not use a brush or pin etc., to clean the parts.
• When disinfecting the parts by boiling, be sure to
boil them in plenty of water.
• Do not boil the baffle together with other objects,
other than applicable nebulizer accessories.
• Do not use a microwave oven, dish dryer or hair
dryer to dry parts.
NE-C801S-Z_A_M_E_SP_041311.indd 19 4/13/11 10:20:48 AM

20
If the air filter has changed color or has been used on average for more than 60
days, replace it with a new one. If water or medication has spilled on the air
filter, replace with a new air filter immediately.
1Pull the air filter cover to
remove from the back side
of the compressor.
2Remove the dirty air filter.
CAUTION
• Do not attempt to wash or clean the air filter. Damp air filters can cause
blockages. Do not substitute cotton or any other material for the air filter.
• Wash the air filter cover regularly to prevent any blockage in the cover. Do not
boil. Make sure the cover is dry before inserting the new air filter.
3Insert a new air filter.
CAUTION
Before inserting the new air filter make sure the air filter is clean and free of
dust. Do not operate the device without the air filter. Use only the Omron air
filter designed for this device.
4Put the air filter cover back
on the compressor.
CHANGING THE AIR FILTER
NE-C801S-Z_A_M_E_SP_041311.indd 20 4/13/11 10:20:52 AM
