3
Solid-state Timer H3CR
DIN 48 x 48-mm Multifunctional Timer Series
Conforms to EN61812-1 and EN60664-1
(VDE0110) 4 kV/2 for Low Voltage, and EMC
Directives.
Approved by UL and CSA.
Lloyds/NK approvals.
Six-language instruction manual provided.
Broad Line-up of H3CR Series
H3CR
Multifunctional Timer
H3CR-A
H3CR-AS
H3CR-AP
H3CR-A8
H3CR-A8S
H3CR-A8E
Twin Timer
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
Star-delta Timer
H3CR-G8L
H3CR-G8EL
Power OFF-delay Timer
H3CR-HRL
H3CR-H8L
H3CR-H8RL
H3CR-HH3CR-GH3CR-F
Note: H3CR-AS, H3CR-A8S: Transistor output models
11-pin model
8-pin model
8-pin with
instantaneous
contact output
model
11-pin model
8-pin model
8-pin model 8-pin model
11-pin model
H3CR-A
Contents
Solid-state Timer
H3CR-A 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
H3CR-F 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
H3CR-G 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
H3CR-H 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Common to ALL Timers
Operation 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
4
Solid-state Timer H3CR-A
DIN 48 x 48-mm State-of-the-art Multifunctional Timer
A wider power supply range reduces the number of
timer models kept in stock.
A wide range of applications through six or four
operating modes.
Reduced power consumption.
(Except for H3CR-A8E)
Enables easy sequence checks through instanta-
neous outputs for a zero set value at any time
range.
Length, when panel-mounted with a Socket, of 80
mm or less.
Time Setting Rings enable consistent settings and
limit the setting range.
Panel Covers enable various panel designs.
PNP input models available.
Rich variety of inputs: Start, reset, and gate
functions (11-pin models and -AP models ) RC
Ordering Information
11-pin Models
Output Supply voltage Input type Time range Operating mode
(see note 2) Model
Contact 100 to 240 VAC (50/60 Hz)/
100 to 125 VDC No-voltage input 0.05 s to 300 h Six multi-modes: A,
B, B2, C, D, E H3CR-A
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
,,C,,
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC Dual-modes: G, J H3CR-A-300
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC Voltage input Six multi-modes: A,
B, B2, C, D, E H3CR-AP
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
,,C,,
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC No-voltage input 0.1 s to 600 h H3CR-A-301
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
Transistor
(Photocoupler) 24 to 48 VAC (50/60 Hz)/
12 to 48 VDC 0.05 s to 300 h H3CR-AS
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
5
8-pin Models
Output Supply voltage Input type Time range Operating mode
(see note 2) Model
Contact 100 to 240 VAC (50/60 Hz)/
100 to 125 VDC No-input
available 0.05 s to 300 h Four multi-modes: A,
B2, E, J
(P l )
H3CR-A8
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
a a ab e
,,J
(Power supply start)
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC 0.1 s to 600 h H3CR-A8-301
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
Transistor
(Photocoupler) 24 to 48 VAC (50/60 Hz)/
12 to 48 VDC 0.05 s to 300 h H3CR-A8S
Time-limit contact
and instantaneous
tt
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC H3CR-A8E
a d s a a eous
contact 24 to 48 VDC/VAC (50/60 Hz)
Note: 1. Specify both the model number and supply voltage when ordering.
Example: H3CR-A 100 to 240 VAC (50/60 Hz)/100 to 125 VDC
Supply voltage
2. The operating modes are as follows
A: ON-delay D: Signal OFF-delay
B: Flicker OFF start E: Interval
B2: Flicker ON start G: Signal ON/OFF-delay
C: Signal ON/OFF-delay J: One-shot
Model Number Legend:
H3CR-Ajjj-j
123 4
1. Number of Pins
None: 11-pin models
8: 8-pin models
2. Input Type for 11-pin Models
None: No-voltage input (NPN type)
P: Voltage input (PNP type)
3. Output
None: Relay output (DPDT)
S: Transistor output (NPN/PNP universal use)
E: Relay output (SPDT) with instantaneous relay output
(SPDT)
4. Suffix
300: Dual mode models (signal ON/OFF-delay and one-shot)
301: Double time scale (range) models (0.1 s to 600 h)
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
6
Accessories (Order Separately)
Name/specifications Models
Flush Mounting Adapter Y92F-30
gp
Y92F-70
Y92F-71
Mounting Track 50 cm (l) x 7.3 mm (t) PFP-50N
1 m (l) x 7.3 mm (t) PFP-100N
1 m (l) x 16 mm (t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Track Mounting/
FtC tiSkt
8-pin P2CF-08
g
Front Connecting Socket 8-pin, finger safe type P2CF-08-E
11-pin P2CF-11
11-pin, finger safe type P2CF-11-E
Back Connecting Socket 8-pin P3G-08
g
8-pin, finger safe type P3G-08 with Y92A-48G (see note 1)
11-pin P3GA-11
11-pin, finger safe type P3GA-11 with Y92A-48G (see note 1)
Time Setting Ring Setting a specific time Y92S-27
Limiting the setting range Y92S-28
Panel Cover (see note 2) Light gray (5Y7/1) Y92P-48GL
Black (N1.5) Y92P-48GB
Medium gray (5Y5/1) Y92P-48GM
Hold-down Clip (see note 3) For PL08 and PL11 Sockets Y92H-7
For PF085A Socket Y92H-8
Note: 1. Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 or P3GA-11 Socket.
2. The Time Setting Ring and Panel Cover are sold together.
3. Hold-down Clips are sold in sets of two.
Specifications
General
Item H3CR-A/-AS H3CR-AP H3CR-A8/-A8S H3CR-A8E
Operating mode A: ON-delay
B: Flicker OFF start
B2: Flicker ON start
C: Signal ON/OFF-delay
D: Signal OFF-delay
E: Interval
G: Signal ON/OFF-delay (Only for H3CR-A-300)
J: One-shot (Only for H3CR-A-300)
A: ON-delay (power supply start)
B2: Flicker ON start (power supply start)
E: Interval (power supply start)
J: One-shot (power supply start)
Pin type 11-pin 8-pin
Input type No-voltage input Voltage input ---
Time-limit output
type H3CR-A/-A8/-AP: Relay output (DPDT)
H3CR-AS/-A8S: Transistor output (NPN/PNP universal)* Relay output (SPDT)
Instantaneous output
type --- Relay output (SPDT)
Mounting method DIN track mounting, surface mounting, and flush mounting
Approved standards UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 and IEC60664-1 (VDE0110) 4kV/2.
Output category according to EN60947-5-1 for Timers with Contact Outputs.
Output category according to EN60947-5-2 for Timers with Transistor Outputs.
*The internal circuits are optically isolated from the output. This enables universal application as NPN or PNP transistor.
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
7
Time Ranges
Note: When the time setting knob is turned below “0” until the point where the time setting knob stops, the output will operate instantaneously
at all time range settings.
Standard (0.05-s to 300-h) Models
Time unit s (sec) min h (hrs) x10 h (10 h)
Full scale
tti
1.2 0.05 to 1.2 0.12 to 1.2 1.2 to 12
setting 30.3 to 3 3 to 30
12 1.2 to 12 12 to 120
30 3 to 30 30 to 300
Double (0.1-s to 600-h) Models
Time unit s (sec) min h (hrs) x10 h (10 h)
Full scale
tti
2.4 0.1 to 2.4 0.24 to 2.4 2.4 to 24
setting 60.6 to 6 6 to 60
24 2.4 to 24 24 to 240
60 6 to 60 60 to 600
Ratings
Rated supply voltage (see note 1) 100 to 240 VAC (50/60 Hz)/100 to 125 VDC, 24 to 48 VAC (50/60 Hz)/12 to 48 VDC (24 to
48 VAC/VDC for H3CR-A8E) (see note 2)
Operating voltage range 85% to 110% of rated supply voltage (90% to 110% at 12 VDC)
Power reset Minimum power-opening time: 0.1 s
Input No-voltage Input
ON impedance: 1 kΩmax.
ON residual voltage: 1 V max.
OFF impedance: 100 kΩmin.
Voltage Input
Max. permissible capacitance between inputs lines (terminals 6 and 7): 1,200 pF
Load connectable in parallel with inputs (terminals 6 and 7).
•100 to 240 VAC/100 to 125 VDC
High (logic) level: 85 to 264 VAC/85 to 137.5 VDC
Low (logic) level: 0 to 10 VAC/0 to 10 VDC
•24 to 48 VAC/12 to 48 VDC
High (logic) level: 20.4 to 52.8 VAC/10.8 to 52.8 VDC
Low (logic) level: 0 to 2.4 VAC/0 to 1.2 VDC
Power consumption H3CR-A/-A8
•100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON: approx. 2.1 VA (1.6 W) Relay OFF: approx. 1.3 VA (1.1 W)
•24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Relay ON: approx. 0.8 W Relay OFF: approx. 0.2 W
H3CR-AP (see note 3)
•100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON: approx. 2.5 VA (2.2 W) Relay OFF: approx. 1.8 VA (1.7 W)
•24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Relay ON: approx. 0.9 W Relay OFF: approx. 0.3 W
H3CR-A8E
•100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON/OFF: approx. 2 VA (0.9 W)
•24 to 48 VAC/VDC
(When at 24 VDC)
Relay ON/OFF: approx. 0.9 W
H3CR-AS/-A8S
•24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Output ON: 0.3 W Output OFF: 0.2 W
Control outputs Time limit contacts: 5 A at 250 VAC/30 VDC, resistive load (cosφ= 1)
Transistor output: Open collector (NPN/PNP), 100 mA max. at 30 VDC max.,
residual voltage: 2 V max.
Instantaneous contact: 5 A at 250 VAC, resistive load (cosφ= 1)
Note: 1. DC ripple rate: 20% max. if the power supply incorporates a single-phase, full-wave rectifier.
2. Each 24-to-48-VAC/12-to-48-VDC model causes an inrush current of approximately 0.85 A. Pay careful attention when attempting
to turn ON power to such a model with non-contact output from a device such as a sensor.
3. The values are for when the terminals 2 and 7 and terminals 10 and 6 are short-circuited, and include the consumption current of the
input circuit.
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
8
Characteristics
Accuracy of
operating time ±0.2% FS max. (±0.2%±10 ms max. in a range of 1.2 s)
Setting error ±5% FS ±50 ms (see note)
Reset time Min. power-opening time: 0.1 s max.
Min. pulse width: 0.05 s (H3CR-A/-AS)
Reset voltage 10% max. of rated voltage
Influence of voltage ±0.2% FS max. (±0.2%±10 ms max. in a range of 1.2 s)
Influence of
temperature ±1% FS max. (±1%±10 ms max. in a range of 1.2 s)
Insulation
resistance 100 MΩmin. (at 500 VDC)
Dielectric strength 2,000 VAC (1,000 VAC for H3CR-AjS), 50/60 Hz for 1 min (between current-carrying metal parts and
exposed non-current-carrying metal parts)
2,000 VAC (1,000 VAC for H3CR-AjS), 50/60 Hz for 1 min (between control output terminals and operating
circuit)
2,000 VAC, 50/60 Hz for 1 min (between contacts of different polarities)
1,000 VAC, 50/60 Hz for 1 min (between contacts not located next to each other)
2,000 VAC, 50/60 Hz for 1 min (between input and control output terminals and operation circuit)
Impulse withstand
voltage 3 kV (between power terminals) for 100 to 240 VAC/100 to 125 VDC, 1 kV for 24 to 48 VAC/12 to 48 VDC
4.5 kV (between current-carrying terminal and exposed non-current-carrying metal parts) for 100 to
240 VAC/100 to 125 VDC, 1.5 kV for 24 to 48 VAC/12 to 48 VDC and 24 to 48 VAC/VDC
Noise immunity ±1.5 kV (between power terminals) and ±600 V (between no-voltage input terminals), square-wave noise by
noise simulator (pulse width: 100 ns/1 µs, 1-ns rise)
Static immunity Malfunction: 8 kV
Destruction: 15 kV
Vibration resistance Destruction: 10 to 55 Hz with 0.75-mm double amplitude each in 3 directions for 2 hours each
Malfunction: 10 to 55 Hz with 0.5-mm double amplitude each in 3 directions for 10 minutes each
Shock resistance Destruction: 1,000 m/s23 times each in 6 directions
Malfunction: 100 m/s23 times each in 6 directions
Ambient
temperature Operating: –10°C to 55°C (with no icing)
Storage: –25°C to 65°C (with no icing)
Ambient humidity Operating: 35% to 85%
Life expectancy Mechanical: 20,000,000 operations min. (under no load at 1,800 operations/h)
Electrical: 100,000 operations min. (5 A at 250 VAC, resistive load at 1,800 operations/h)
EMC (EMI) EN61812-1
Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
(EMS) EN61812-1
Immunity ESD: IEC61000-4-2: 6 kV contact discharge (level 3)
8 kV air discharge (level 3)
Immunity RF-interference from AM Radio Waves: IEC61000-4-3:10 V/m (80 MHz to 1 GHz)
(level 3)
Immunity RF-interference from Pulse-modulated Radio Waves: IEC61000-4-3:10 V/m (900±5 MHz) (level 3)
Immunity Conducted Disturbance: IEC61000-4-6: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC61000-4-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Immunity Surge: IEC61000-4-5: 1 kV line to line
2 kV line to ground (level 3)
Case color Light gray (Munsell 5Y7/1)
Degree of protection IP40 (panel surface)
Weight Approx. 90 g
Note: The value is ±5% FS +100 ms to –0 ms max. when the C, D, or G mode signal of the H3CR-AP is OFF.
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
9
Engineering Data
Reference:A maximum current of 0.15 A can be switched at 125 VDC (cosφ= 1)
and a maximum current of 0.1 A can be switched if L/R is 7 ms. In
both cases, a life of 100,000 operations can be expected.
The minimum applicable load is 10 mA (100 mA for H3CR-A8E) at
5 VDC (failure level: P).
Load current (A)
30 VDC L/R = 7 ms
250 VAC/30 VDC
(cosφ= 1)
250 VAC (cosφ= 0.4)
Switching operations (x 10 )
3
10,000
5,000
1,000
500
100
Nomenclature
Power indicator (green) (Flashes when Timer
operates; lit when Timer stops operating) Operating mode display window
Operating mode selector
Select a mode from:
A, B, B2, C, D, and E (H3CR-A, -AP, and -AS)
A, B2, E and J (H3CR-A8, -A8S, and -A8E)
G and J (H3CR-A-300)
Scale range display windows
Time unit display window
Time unit selector (select one
from sec, min, hrs, and 10h)
Time setting
knob (set time)
Output indicator (orange)
(Lit when output)
Time range selector (select one
from 1.2, 3, 12, and 30 at full
scale; with the H3CR-Aj-301,
select from 2.4, 6, 24, or 60 at
full scale. )
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
10
Operation
Block Diagrams
H3CR-A/AS
AC (DC) input
Power supply
circuit
Zero setting
detection
circuit
Oscillation
circuit
Time range/
unit selectors
Counting
circuit
Operating
mode selector
Output circuit
Reset input, start input, and gate input Input circuit Indicator
circuit
Power-ON
indicator Output-ON
indicator
H3CR-AP
AC (DC) input
Power supply
circuit
Zero setting
detection
circuit
Oscillation
circuit
Time range/
unit selectors
Counting
circuit
Operating
mode selector
Output circuit
Start Input circuit Indicator
circuit
Power-ON
indicator Output-ON
indicator
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
11
H3CR-A8/A8S
AC (DC) input
Power supply
circuit
Zero setting
detection
circuit
Oscillation
circuit
Time range/
unit selectors
Counting
circuit Output circuit
Indicator
circuit
Power-ON
indicator Output-ON
indicator
Operating
mode selector
H3CR-A8E
Instantaneous
output circuit
AC (DC) input
Power supply
circuit
Zero setting
detection
circuit
Oscillation
circuit
Time range/
unit selectors
Counting
circuit Output circuit
Indicator
circuit
Power-ON
indicator Output-ON
indicator
Operating
mode selector
I/O Functions
Inputs Start Starts time-measurement.
(for -A/-AS
models) Reset Interrupts time-measurement and resets time-measurement value. No time-measurement is made
and control output is OFF while the reset input is ON.
Gate Prohibits time-measurement.
Outputs Control output Outputs are turned ON according to designated output mode when preset value is reached.
Note: H3CR-AP incorporates start input only.
Downloaded from Elcodis.com electronic components distributor
H3CR-A H3CR-A
12
Timing Chart
Note: 1. The minimum power-opening time (“Rt”) is 0.1 s and the minimum pulse width is 0.05 s.
2. The letter “t” in the timing charts stands for the set time and “t–a” means that the period is less than the time set.
H3CR-A/-AS/-AP*
*H3CR-AP model incorporates start input only.
Operating
mode Timing chart
A:
ON-delay
Power
Output
t
Basic operation
Power
Start
Reset
Output relay (NC)
Output relay (NO)
(Output indicator)
Power indicator
t t
Note: Start input is invalid while the Tim-
er is in operation.
Start
(see note)
B:
Flicker OFF
start Power
Output relay (NO)
(Output indicator)
Power indicator
Start
Reset
Output relay (NC)
Basic operation
Power
Output
t t t t
Note: Start input is invalid while
the Timer is in operation.
Start
(see note)
B2:
Flicker ON
start Basic operation
Power
Output
ttt t
Power
Start
Reset
Output relay (NO)
(Output indicator)
Power indicator
Output relay (NC)
Note: Start input is invalid while the Tim-
er is in operation.
Start
(see note)
C:
Signal
ON/OFF-
delay
Basic operation
Power
Output tt tt
Power
Start
Reset
Output relay (NC)
Power indicator
Output relay (NO)
(Output indicator) Note: Start input is valid and re-
triggerable while the Timer is
in operation.
Start
(see note)
Downloaded from Elcodis.com electronic components distributor
