One Remote Interface Type 2843 User manual

Page 4
Operating with Beolink 1000
Beolink 1000 does not have as many
keys as the receiver’s original remote
control. Thus certain Beolink 1000
keys have got alternative functiona-
lity. To get to this phas to be
pressed first, i.e. pfollowed by
1 on a Beolink 1000 corresponds to
Setup on the original remote control.
The table shows how special Beolink
1000 key operations translate to
operations of the original remote
control.
To be able to operate the receiver
correctly with the Beolink 1000 the
user has to be familiar with operations
with the original remote control as
described in the receiver’s user
manual.
The receiver is automatically turned
on when selecting its source on the
TV with Vtape, DVD, Vaux etc.
We call this function i.
There is therefore no physical button
on the Beolink 1000 named source.
Beolink 1000 Operation
pp OK
q
Menu
x
Exit
pC TXT
pV Lang
pZ Recall
pX Info
hZ TV
hX Radio
hC EPG
hV FAV
p1 Setup
i
Power on
i
fq Power off
Beocompatible Operation via
Oneremote Interface Type 2843
for Smart Terra X
Beo4 and Beolink 1000 are remote control terminals from Bang & Olufsen. Oneremote supplies interface modules that allow third party equipment to be operated via a Bamg & Olufsen remote control system.
made in the EU by www.oneremote.dk
Type 2843v1

Page 2
Congratulations
With the interface module Q5 from
www.oneremote.dk connected to your
Dreambox receiver/decoder and a Bang &
Olufsen TV you can operate the receiver
with your Bang & Olufsen remote control
terminal.
This user guide tells you how.
Plug and Play
The receiver can be connected directly to a
vacant linkequipped AV socket on the Bang
& Olufsen TV with the special Q5 scart
connection cable and adaptor.
The powersupply connects to the Q5 and the
mains.
The Q5 IR diode is taped underneath the
receiver as close as possible to the front and
the receiver’s own IR receiver.
Following the correct programming of the
AV connection the receiver is ready to
operate. For programming of the AV
connection check the Bang & Olufsen TV
User Manual.
If the Bang & Olufsen TV does not have a
vacant useable AV socket a Oneremote AV
Selector can be supplied.
Bang & Olufsen Remote Controls
With your beocompatible* receiver
connected to a Bang & Olufsen TV you may
operate it with your Beolink 1000, 5000,
7000 or Beo4.
With Beo4 the operation is slightly easier.
Thus Beo4 is the recommended remote
control for this receiver.
Operation in a Beolink
Videosystem
In a Bang & Olufsen Beolink videosystem
full operability is ensured in all link rooms.
*Beocompatible means that the equipment can be
operated with a Bang & Olufsen remote control when
connected to a Bang & Olufsen TV.
Page 3
Operating with Beo4
Beo4 does not have as many keys as the
Dreambox receiver’s original remote
control. Thus certain Beo4 keys have got
alternative functionality. To get to this
Ohas to be pressed first, i.e. Ofollowed
by 1 on a Beo4 corresponds to Setup on the
original remote control.
The table shows how special Beo4 key
operations translate to operations of the
original remote control.
To be able to operate the receiver correctly
with the Beo4 the user has to be familiar
with operations with the original remote
control as described in the receiver’s user
manual.
The receiver is automatically turned on
when selecting its source on the TV with
Vtape, DVD, Vaux etc. We call this
function i.
There is therefore no physical button on the
Beo4 named source.
Beo4 Operation
q
Menu
QTV
WRadio
REPG
EFAV
OO OK
oD TXT
oF Lang
oA Recall
oS Info
o1 Setup
i
Power on
i
fq Power off
