OpenEye OE-C3012T4 User manual

QUICK START GUIDE
This quick start guide provides
only basic information on the
camera’s settings and operation for
initial installation. Please read the
user manual for optimal camera
confi gurations.
Scan the QR code or go to
openeye.net/downloads
Find the latest product
documentation and software.
Copyright ©2021 OpenEye.
All Rights Reserved. Information contained in this
document is subject to change without prior notice.
OpenEye does its best to provide accurate information but
cannot be held responsible for typos or mistakes.
Liberty Lake, WA, USA
509.232.5261
openeye.net
CONNECTIONS
1
1
RJ-45
RJ-45
For network and PoE connections
For network and PoE connections
2
2
Power
Power
(12vDC)*
(12vDC)*
Power connection
Power connection
1
1
2
Waterproof Cable
1
1
Thread lock cap
Thread lock cap
4
4
Rubber “O” ring
Rubber “O” ring
2
2
Rubber plug
Rubber plug
5
5
Camera cable
Camera cable
3
3
RJ45 enclosure
RJ45 enclosure
5432
1
1
1
1
Reset Button
Reset Button
To restore the camera to factory
To restore the camera to factory
defaults:
defaults:
1.
1.
Disconnect power for 30
Disconnect power for 30
seconds.
seconds.
2.
2.
Reconnect power and wait 30
Reconnect power and wait 30
seconds.
seconds.
3.
3.
Press and hold the reset button
Press and hold the reset button
for 20 seconds.
for 20 seconds.
2
2
MicroSD Card Slot
MicroSD Card Slot
Supports up to 512GB microSD
Supports up to 512GB microSD
card for Edge storage.
card for Edge storage.
Do not add or remove the microSD
Do not add or remove the microSD
card when the camera is powered
card when the camera is powered
on.
on.
2
*12vDC power input port should be plugged when not in use.
4MP Outdoor IP Turret
OE-C3012T4
37465AE

CONTENTS
Selecting multiple cameras and enter-
ing IP address 192.168.51.2 will set
an IP address on all selected cameras,
starting at 192.168.51.2 and increase
per camera.
1. Open the Network Camera
Manager application.
2. Select applicable camera(s).
3. Input starting IP address, Subnet
Mask, Gateway, DNS.
4. Apply changes.
5. Wait 60 seconds before refreshing
NCM.
OE-C3012T4
Turret Camera
PRODUCT FEATURES
Camera
Maximum Resolution 2688x1520
Frame Rate at
Maximum Resolution 30FPS @ 4MP H.264/H.265
Total Streams Dual Streaming
ONVIF Profi le S / G / T Compliant
Day/Night True Day / Night
Wide Dynamic Range True WDR
Environmental and Power
Power
Consumption 8.16W maximum
Input Voltage 12vDC / PoE
Pan / Tilt / Rotate
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360°
IP Rating IP67
Self-Tapping
Screws &
Plastic Anchors
Waterproof Cable
Connector
Quick Start
Guide
INSTALLATION
Connect a network cable to the camera
using the RJ45 input and connect the
other end of the cable to your network
switch or recorder.
1. Apply template sticker to desired
camera location.
2. Drill anchor holes using included
mounting template.
3. Remove mounting template.
4. Insert anchors.
5. Mount camera.
6. Connect network cable with
included waterproof cable
connector.
7. Adjust camera view.
Mounting Template
ASSIGNING AN
IP ADDRESS
OpenEye IP cameras are set to DHCP
by default. If a DHCP server is not
detected after 4 minutes, the camera
will default to IP address 192.168.51.2.
If you are not using a DHCP server,
NCM will allow you to batch confi gure
a static IP address.
The IP address for the camera network
on your Apex recorder is 192.168.51.1.
NOTE: To change this IP address please refer
to your Apex recorder manual.
CONNECTING TO THE
IP CAMERA
To access the camera setup menu,
you need to open Network Camera
Manager (NCM) utility. NCM is pre-
installed on all OpenEye Recorders,
and is also available for download on
the OpenEye website for installation on
your personal computer or laptop.
1. Open Network Camera Manager.
2. Locate your camera on the
Network Camera Manager list.
3. To open the web browser, select
the camera and click LOAD.
NOTE: OpenEye IP cameras ship
without a default password.
DEFAULT USERNAME
AND PASSWORD
The admin user password can be set
using the following methods:
1. OpenEye recorders running Apex
2.1 or newer will automatically set
a new unique password if:
• Connected to an M-Series
recorder with a built in PoE
switch.
• Connected to a network
switch through the
camera network port
and selected then added in
setup, if a new password has
not already been set.
NOTE: The NCM software manual can be
found at https://www.openeye.net/
ncm-manual
2. Connect to the camera directly
through a Web Browser and follow
the onscreen prompts.
3. Use the Network Camera Manager
(NCM) Utility.
Username: admin
Set the Default Camera Password
Use the QR code or link for instructions on
defi ning a unique camera password:
https://www.openeye.net/support/faqs/
default-camera-password
