OpenEye OE-C9616 User manual

Cameras
OE-C9616
OE-C9716
www.openeye.net
6MP 360 Degree IP Camera
User Manual

2
●

33690AA
Important Safeguards
Precautions














4
Regulation
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
For more details information about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you purchased the product.
Warning
Caution
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN

33690AA
TABLE OF CONTENTS

6

33690AA
INTRODUCTION
OVERVIEW
PRODUCT FEATURES








SYSTEM REQUIREMENTS













8
CONNECTIONS
CAMERA BOX CONTENTS

33690AA
DIMENSIONS
OE-C9616 INDOOR
OE-C9716 OUTDOOR

10
REMOVING THE CAMERA COVER

33690AA
CONNECTIONS
Pin
Connection
Definition
1
Power
1
DC12V +
Power connection
2
DC12V -
2
RJ-45
For network and PoE connections
3
microSD card slot
Insert the microSD card into the card slot to store video and images
4
Alarm and Audio I/O
1
Alarm out +
2
Alarm out -
3
Alarm in +
4
Alarm In -
5
Ground
6
Audio out
7
Audio in
5
Built-in microphone
Audio in
6
Reset button
Press and hold this button for 20 seconds to reset the camera to
factory defaults
7
Speaker
Audio out

12
ALARM I/O CONNECTIONS
ETHERNET CABLE CONNECTION
Pin
Definition
1
Alarm out +
2
Alarm out -
3
Alarm in +
4
Alarm in -
5
Ground
6
Audio out
7
Audio in

33690AA
WATERPROOF CABLE CONNECTIONS FOR OUTDOOR
INSTALLATION
FUNCTION CABLE

14
IP66 ETHERNET CABLE

33690AA
SETUP AND CONFIGURATION
OPENEYE NETWORK CAMERA MANAGER
INSTALLATION
STARTING NETWORK CAMERA MANAGER

16
Viewing a Network Camera

33690AA
CAMERA CONFIGURATION
DEVICE ADDRESSING
Finding Network Devices

18
CONNECTING TO THE CAMERA
Resetting the Camera
Administrator/User Privileges

33690AA
Connecting Over the Internet

20
VIEWER SOFTWARE
VIEWER TABS
