Optelec Sentry+ User manual

Sentry+
Sentry+HD
User manual
Bedienungsanleitung

Optelec Sentry+ / Sentry+ HD
English Page 1
Sentry+
Sentry+ HD
User manual
Version 5.0
Copyright 2013 Optelec, The Netherlands
All rights reserved
Optelec
P.O. Box 399
2990 AJ Barendrecht
The Netherlands
Telefon: [phone]. Fax [phone]
E-Mail: [email protected]
Internet: www.optelec.com

Optelec Sentry+ / Sentry+ HD
English Page 2

Optelec Sentry+ / Sentry+ HD
English Page 3
WEEE Notice
The directive on Waste Electrical and Electronic Equipment (WEEE),
which entered into force as European law on 13th February 2003,
resulted in a major change in the treatment of electrical equipment at
end-of-life.
The purpose of this Directive is, as a first priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other forms
of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or its box
indicates that this product must not be disposed of or dumped
with your other household waste. You are liable to dispose of all
your electronic or electrical waste equipment by relocating over
to the specified collection point for recycling of such hazardous waste.
Isolated collection and proper recovery of your electronic and electrical
waste equipment at the time of disposal will allow us to help conserving
natural resources. Moreover, proper recycling of the electronic and
electrical waste equipment will ensure safety of human health and
environment. For more information about electronic and electrical waste
equipment disposal, recovery, and collection points, please contact your
local city centre, household waste disposal service, shop from where you
purchased the equipment, or manufacturer of the equipment.

Optelec Sentry+ / Sentry+ HD
English Page 4

Optelec Sentry+ / Sentry+ HD
English Page 5
Sentry+
Sentry+ HD
User manual
April, 2013
Optelec was founded in 1975 in Rockanje, the Netherlands. Since then,
Optelec has developed and produced innovative products to assist blind
and visually impaired people in their daily activities. Visit the Optelec
website at www.optelec.com for extensive information about Optelec
products and services.
All rights, in particular the rights of reproduction as well as translation, are
reserved. No parts of this manual may be copied, in any form whatsoever,
without written approval by Optelec.
Every effort has been made to ensure that the information contained in
this user manual is correct at the time of issue. Neither Optelec, nor its
agents, assume any responsibility for errors or damages resulting from
use other than described in this manual.

Optelec Sentry+ / Sentry+ HD
English Page 6
Index
1. Introduction .........................................................................................7
About this manual.........................................................................7
2. Important safety information................................................................8
3. What’s in the box?...............................................................................9
4. Getting to know your Sentry+[HD] ...................................................10
Setting up your Sentry+[HD] ......................................................10
Positioning the camera and the camera arm ..............................12
Close-up and distance viewing...................................................12
Use of the built-in object lighting.................................................12
5. Operation of the Sentry+[HD] control panel......................................13
Switch On/Off..............................................................................13
Setting the magnification.............................................................13
Wide screen mode......................................................................13
The overview mode.....................................................................14
Viewing modes............................................................................14
Semi-colours...............................................................................14
Auto-focus On/Off.......................................................................14
Contrast ......................................................................................14
Brightness...................................................................................15
Activating line markers/window blinds ........................................15
Reading line and window shades activating ...............................15
Reading line colours ...................................................................15
Key switch...................................................................................15
Picture switch..............................................................................15
Reset...........................................................................................15
6. Sentry+Specifications.......................................................................16
7. Sentry+HD Specifications.................................................................17
8. Compliances .....................................................................................18
9. Warranty Conditions..........................................................................20
Contact information…………………………………………………………...21

Optelec Sentry+ / Sentry+ HD
English Page 7
1. Introduction
Congratulations on choosing the Sentry+or the Sentry+HD, a high quality
electronic magnifier designed by Optelec. Sentry+[HD] is the term which
is basically used for both devices in this User manual. The Sentry+[HD] is
an auto-focus electronic magnifier designed for use at different locations:
at home, in school or at the office. Use the Sentry+for reading, writing,
viewing photographs, craftwork and much more.
The Sentry+[HD] is designed for optimal efficiency when working with a
stand-alone monitor. The Sentry+[HD] can be operated ergonomically
from the control panel and when used in combination with the Optelec
TwinView monitor it can be connected to a computer.
If you have any questions or suggestions concerning the use of this
product, please contact your Optelec distributor or the Optelec
headquarters using the contact information found at the end of this user
manual. Your feedback is greatly appreciated. We hope you enjoy
working with your Sentry+[HD].
About this manual
This user manual provides a comprehensive guide to the features and
operation of the Sentry+[HD] electronic magnifier. Please read this user
manual carefully before using the Sentry+[HD] and keep it in a safe place
for future reference.

Optelec Sentry+ / Sentry+ HD
English Page 8
2. Important safety information
Optelec does not assume any liability or responsibility for incorrectly
detected content of texts or their interpretation by Sentry+[HD].
Please have important documents checked additionally.
Only use the Sentry+[HD] indoors.
Do not expose the Sentry+[HD] to extreme or rapid changes in
temperature or humidity. These conditions may damage the
electronics or optics of the Sentry+[HD].
Do not place the unit on an unstable surface. It may fall, causing
serious damage to the unit or injuries to the user.
To avoid injuries, always assemble, disassemble and handle the
components of the Sentry+[HD] with good care as there are movable
and rotatable parts.
Do not expose the Sentry+[HD] to excessive heat or direct sunlight to
avoid the risk of fire.
Do not remove any parts of the Sentry+[HD]. Contact your Optelec
distributor to service the Sentry+[HD] if necessary. Do not open any
of the components as this will void the warranty. Each component
contains parts which should only be serviced by an Optelec repair
specialist.
To avoid risk of electrical damage, keep the Sentry+[HD] away from
fluids and chemicals
Handle the Sentry+[HD] with care. Rough handling will damage the
internal components.
Do not use the Sentry+[HD] near inadequately shielded medical
devices.
Always unplug the Sentry+[HD] before cleaning. Use a soft damp
cloth to clean the exterior. Do not use cleaning agents or abrasive
materials as they will damage the unit.
Make sure you connect the Sentry+[HD] to an earthed mains power
(AC) outlet for your safety.
Do not use the Sentry+[HD] unit under 0° or above 40° Celsius.
Use of the Sentry+[HD] other than that described in this user manual will
exclude it from warranty conditions.

Optelec Sentry+ / Sentry+ HD
English Page 9
3. What’s in the box?
The Sentry+[HD] package contains the following:
The Sentry+[HD] camera arm
Base plate for the camera arm
Bolt and screw for assembling the base plate and the camera arm
Control panel
2 different lens attachments
Power supply
2 DVI-cables
User manual
If any of these items are missing from your package, please contact your
local Optelec distributor.

Optelec Sentry+ / Sentry+ HD
English Page 10
4. Getting to know your Sentry+[HD]
Setting up your Sentry+[HD]
To set up the Sentry+[HD] please follow the steps described below:
1. Assemble the base plate and the camera arm by using the bolt
and screw provided.
2. Place the assembled unit and the control panel nearby your
monitor on a steady surface.
3. Connect the cable of the Sentry+[HD] camera arm to the camera
connection at the rear of the control panel (look at the picture on
page 11).

Optelec Sentry+ / Sentry+ HD
English Page 11
4. Connect the DVI-cable of your monitor to the as “monitor” labelled
connection of the control panel.
5. By using the delivered DVI-cable connect your computer to the as
“DVI In” labelled connection of the control panel.
6. Additionally you can use a footswitch. Connect this to the first left
connector at the rear of the control panel.
7. Connect the supplied power supply to the power connection at the
back of the control box and plug the power cord into a power
outlet. Your Sentry+[HD] is now ready for use.

Optelec Sentry+ / Sentry+ HD
English Page 12
Positioning the camera and the camera arm
The Sentry+[HD] features a flexible camera head and a rotatable camera
arm. The camera head can be swivelled around a horizontal and a
vertical axis. The camera arm can be rotated around the base. Point the
camera to read a document nearby. When you want to look in the
distance (for example at a blackboard) or at yourself, you need to remove
the close-up lens and turn the camera in a horizontal position. By
loosening the screw lock at the end of the camera arm, you can adjust the
height of the camera (this will affect the magnification range).
Close-up and distance viewing
The position of the camera can be adjusted for desktop or distance
viewing. To view objects within 55 cm, position the close-up lens in front
of the camera unit. To view objects at a more distant proximity, position
the close-up lens away from the camera. To prevent losing the close-up
lens, attach the lens to the top side of the camera head.
Use the near lens with the flattened edgings for the position below and
use the round lens for the upper position.
Use of the built-in object lighting
The double LED-lighting is built in to the camera arm
for use in poorly-lit environments. The lighting can be
switched on and off by pushing the zoom button in the
following order: “step 1/ step 2/ Off”.

Optelec Sentry+ / Sentry+ HD
English Page 13
5. Operation of the Sentry+[HD] control panel
Switch On / Off
Press the On / Off switch, located at the top right Corner of the
control panel to switch on the Sentry+[HD]. The On / Off
indicator light will illuminate when the control panel is switched
on. The monitor needs to be switched on separately.
Setting the magnification
Turning the Zoom control allows you to select the
desired magnification level. The Sentry+[HD] magnifies
text and images from 1 to 70 times the original size on a
22-inch screen. Turning the circular control anti-
clockwise will decrease the magnification. Similarly,
turning the circular control clockwise will increase the
magnification.
Wide screen mode – only at Sentry+
By pressing the Shift key along with the overview
button you can switch between three views:
Widescreen, flexible widescreen and without
widescreen. Widescreen is the factory setting.

Optelec Sentry+ / Sentry+ HD
English Page 14
The overview mode
By pressing the overview key you can activate a crosshair
target on the visual screen, which shows you the centre of
the image of the camera. By pressing this key twice the
crosshair target will disappear.
Viewing modes
Pressing this button will cycle you through three viewing
modes:
1- Full Colour Photo mode
This mode will display text, pictures and objects in full colour.
2- Positive Reading mode
This mode enhances the foreground / background contrast. Pictures
and text will be displayed in black text on a white background.
3- Negative Reading mode
This mode reverses the positive image. Pictures and text will be
displayed as white text on a black background.
Semi-colours
You can activate this function in the Positive and Negative
Reading Modes only. Pressing this button cycles you
through a wide range of different foreground and background colour
combinations. You may choose to display text in a pair of selectable
colours when more contrast is needed or when alternate colour
combinations provide easier reading.
Auto-focus On / Off
The Sentry+[HD] features automatic focusing to produce a
clear image at any time. When the auto-focus is not active
the red LED indicator will illuminate. Press this button to switch to
Focus Lock which stops the Sentry+[HD] from continuously
focusing. This is useful for tasks such as writing, painting or
enjoying craftwork. Pressing this button will re-activate the auto-
focus and the red LED indicator light will turn off again.
Contrast
The contrast changes with the adjustment button, which is
presented on the right. Rotating this button counter
clockwise decreases the contrast and rotating the button
clockwise increases the contrast.

Optelec Sentry+ / Sentry+ HD
English Page 15
Brightness
Turning the button whilst simultaneously
pressing the adjacent Shift button allows you to
adjust the brightness of the Sentry+ [HD] image.
Turn the control anti-clockwise to decrease the
brightness. Turn the circular control clockwise
to increase the brightness.
Activating line markers / window blinds
Pressing this button cycles you through line markers,
window blinds and back to full screen. Horizontal line
markers and window blinds are used to make reading
easier.
Reading line and window shades adjustment
When line markers or window blinds are activated,
turning this circular control will change their orientation.
Reading line colours
By pressing the Shift key along with the Semi-
colours button you can change the reading line
colours. The photo mode can be change
separately. Black is the factory setting.
Key switch
This key enables additional functions. Pressing and
holding this key while rotating the upper adjustment
button allows you to change additional functions such as
line distance, window shade distance and changes in
brightness.
Picture switch
By pressing this button you can switch between the
image from the Sentry+[HD] camera and the PC image.
If you have a footswitch available, you can control
switching the image by pressing the footswitch.
Reset
Press this button when the Sentry+[HD] is switched off.
Switch the Sentry+[HD] on while pressing this button
and keep the button pressed for 2 seconds. The Sentry+
[HD] will now start with the original settings.

Optelec Sentry+ / Sentry+ HD
English Page 16
6. Sentry+Specifications
- Camera : 18x optical zoom
- Viewing modes : Full colour photo mode
High contrast black-on-white
High contrast white-on-black
- Semi-colours : 8 foreground / background
colour combinations
- Magnification : 2 to 50 times on a 17“ monitor
- Focus : Autofocus with focus lock and manual
focus
- Monitor output and input: DVI
- Screen frequency : 60 Hz
- Camera movements : 200° tilting and 360° swivel
- Light : LED
- Close-up lens : Removable
- Weight unit : 5.5 kg / 194 ounces
- Weight control panel : 0.85 kg / 30 ounces
- Weight power supply : 0.18 kg / 6.3 ounces
- Power supply input : 100-240 V 50-60 Hz AC
- Power supply output : 12 V / 2 Amp. DC
Operating conditions
Humidity : < 75%, no condensation
Temperature : 0 – 40 °C
Storage & transport conditions
Humidity : < 75%, no condensation
Temperature : -20 – 60 °C
WARNING: The use of accessories, transducers and cables other than
those specified, with the exception of transducers and cables sold by the
manufacturer of the Sentry+as replacement parts for internal
components, may result in increased emissions or decreased immunity of
the Sentry+.
Optelec nor its partners do not take any responsibility when using the
product and its accessories other than those specified in this manual.
For additional questions on the Sentry+ regarding service, installation or
operation, contact your local distributor or nearest Optelec office (details
at the end of this user manual).

Optelec Sentry+ / Sentry+ HD
English Page 17
7. Sentry+HD Specifications
- Camera : 1080 HD 20x optical zoom
- Viewing modes : Full colour photo mode
High contrast black-on-white
High contrast white-on-black
- Semi-colours : 8 foreground / background
colour combinations
- Magnification : 2 to 50 times on a 17“ monitor
- Focus : Autofocus with focus lock and manual
focus
- Monitor output and input: DVI
- Screen frequency : 60 Hz
- Camera movements : 200° tilting and 360° swivel
- Light : LED
- Close-up lens : Removable
- Weight unit : 5.5 kg / 194 ounces
- Weight control panel : 0.85 kg / 30 ounces
- Weight power supply : 0.18 kg / 6.3 ounces
- Power supply input : 100-240 V 50-60 Hz AC
- Power supply output : 12 V / 2 Amp. DC
Operating conditions
Humidity : < 75%, no condensation
Temperature : 0 – 40 °C
Storage & transport conditions
Humidity : < 75%, no condensation
Temperature : -20 – 60 °C
WARNING: The use of accessories, transducers and cables other than
those specified, with the exception of transducers and cables sold by the
manufacturer of the Sentry+HD as replacement parts for internal
components, may result in increased emissions or decreased immunity of
the Sentry+HD.
Optelec nor its partners do not take any responsibility when using the
product and its accessories other than those specified in this manual.
For additional questions on the Sentry+ HD regarding service, installation
or operation, contact your local distributor or nearest Optelec office
(details at the end of this user manual).

Optelec Sentry+ / Sentry+ HD
English Page 18
8. Compliances
This product complies with the safety and EMC requirements of the
directives:
EN60601-1: 2007-07
EN60601-1-2: 2007-12
Optelec
Breslau 4
2993 LT Barendrecht
The Netherlands
EU – Declaration of conformity
Barendrecht, the Netherlands
October 2008
The manufacturer declares that the Sentry+and Sentry+ HD electronic
magnifier complies to the safety guidelines and directives of the European
Community.
This EU – declaration of conformity is based on tests according to the
directives:
EN60601-1: 2007-07 and EN60601-1-2: 2007-12 by an independent
Notified body.
Warning: The use of accessories, power supply units or cables which are
not determined as original replacement equipment can cause higher
emission or lower immunity of the Sentry+and Sentry+HD.
This device bears the CE approval mark
(UL/CSA/TÜV approved)
