Optelec Compact+ User manual

Optelec Compact
+
English Page 1
WEEE Notice
The directive on Waste Electrical and Electronic Equipment (WEEE), which entered into force as
European law on 13
th
February 2003, resulted in a major change in the treatment of electrical
equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of WEEE, and in addition, to promote
the reuse, recycling and other forms of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or its box indicates that this product must
not be disposed of or dumped with your other household waste. You are liable to dispose of
all your electronic or electrical waste equipment by relocating over to the specified collection
point for recycling of such hazardous waste. Isolated collection and proper recovery of your
electronic and electrical waste equipment at the time of disposal will allow us to help
conserving natural resources. Moreover, proper recycling of the electronic and electrical
waste equipment will ensure safety of human health and environment. For more information
about electronic and electrical waste equipment disposal, recovery, and collection points,
please contact your local city centre, household waste disposal service, shop from where
you purchased the equipment, or manufacturer of the equipment.
RoHS Compliance
This product is in compliance with Directive 2002/95/EC of the European Parliament and of the Council
of 27 January 2003, on the restriction of the use of certain hazardous substances in electrical and
electronic equipment (RoHS) and its amendments.

Optelec Compact
+
English Page 2
European Union Notice
Products with CE marking comply with the R&TTE Directive (99/5/EC), the EMC Directive
(89/336/EEC), and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following international standards:
IEC 60950-1 2004;
IEC 55022
IEC 55024 (IEC61000-4-2 excluded)
FCC
FCC part 15 Class B

Optelec Compact
+
English Page 3
Compact
+
User Manual
OPN: COMP-WRLD Version 2.4
© 2007 Optelec, the Netherlands
All rights reserved
Optelec
P.O. Box 399
2990 AJ Barendrecht
The Netherlands
Phone: [phone]
E-mail: [email protected]
Internet: www.optelec.com

Optelec Compact
+
English Page 4
Contents
1. Introduction......................................................................................................................... 5
About this manual............................................................................................................ 5
What’s in the box?........................................................................................................... 6
2. Getting to know your Compact+ ......................................................................................... 7
Top side .......................................................................................................................... 7
Front side ........................................................................................................................ 8
Right side ........................................................................................................................ 9
Underside...................................................................................................................... 10
3. Getting started.................................................................................................................. 12
Placing the batteries...................................................................................................... 12
Turning the power on / off ............................................................................................. 13
Using the magnification button ...................................................................................... 13
Selecting a viewing mode.............................................................................................. 13
Using the snapshot button............................................................................................. 14
Writing with the Compact+ ............................................................................................ 15
Using the Compact+ handle.......................................................................................... 15
4. Power and battery use...................................................................................................... 16
Charging the batteries................................................................................................... 16
System Auto Off ............................................................................................................ 17
Appendix A: Safety............................................................................................................... 18
Appendix B: Technical information ....................................................................................... 19

Optelec Compact
+
English Page 5
1. Introduction
Congratulations on choosing the Compact
+
, a pocketsize electronic video magnifier designed
by Optelec.
Optelec’s pocketsize electronic magnifier enlarges, with magnification up to 10 times, and
enhances printed text and on a 4.3” wide screen display.
With its one button simplicity, controlling both magnification and viewing modes, the Compact
+
offers an enhanced design that extends in operating comfort. It is designed for every day use at
any location.
If you have any questions or suggestions concerning the use of this product, please contact
your distributor or the Optelec headquarters using the contact information at the last page of
this manual. Your feedback is greatly appreciated. We hope you enjoy working with your
Compact
+
.
About this manual
This manual will familiarize you with the features and basic operation of the Compact
+
. Please
read this manual carefully before using your device.

Optelec Compact
+
English Page 6
What’s in the box?
The Compact
+
packaging contains the following:
- The Compact
+
pocketsize electronic magnifier
- A detachable neck cord
- A protective carrying pouch
- A power cable with power adapter and 4 plugs (EU, UK, US and AUS)
- This user manual
- The Compact+ rechargeable AA battery pack
If any of these items are missing from your package, please contact your distributor.

Optelec Compact
+
English Page 7
2. Getting to know your Compact
+
When the unit is placed correctly in front of you the display will be facing up and the round
magnification / mode button is at the right side of the unit.
Top side
The following figure shows the top side of the Compact
+
.
4.3” wide screen display mode button
magnification button

Optelec Compact
+
English Page 8
4.3” wide screen display The 4.3” wide screen displays text and images
Mode button Pressing the mode button allows you to select one of the five
viewing modes
Magnification button Turning the lever allows you to change the magnification
Front side
The following figure shows the front side of the Compact
+
.
snapshot button DC IN 5V jack
Snapshot button The snapshot button allows you to temporarily freeze an image
on the screen of an object or text that may be at arm’s length,
enabling you to bring the image closer to your eyes

Optelec Compact
+
English Page 9
DC IN 5V jack The AC power adapter cable connects to this jack. Use only
the model of AC adapter that comes with the Compact
+
. Use of
an adapter other than that supplied with the unit automatically
voids the warranty.
Right side
The following figure shows the right side of the Compact
+
.
on / off switch
On / Off switch Pressing the small round orange button for half a second will
switch the unit on or off

Optelec Compact
+
English Page 10
Underside
The following figure shows the underside of the Compact
+
.
camera battery
unit compartment collapsible,
swing out handle

Optelec Compact
+
English Page 11
Battery compartment To place the Compact+ battery pack as supplied or two single
AA batteries, either rechargeable or disposable
Camera unit The Compact
+
features an auto-focus camera that can slide in
two positions; one for reading and one for writing
Handle Pull and swing out the collapsible handle for enhanced reading
comfort

Optelec Compact
+
English Page 12
3. Getting started
Placing the batteries
The Compact
+
battery pack supplied with the unit consists of two AA rechargeable batteries.
We strongly advise you not to remove, open or disassemble the plastic sealing of the
battery pack. Removing this sealing might cause malfunctioning of the batteries.
Install the battery pack as follows:
- Turn the unit upside down
- Press the small half-oval tab at the far end to release the cover of the battery
compartment
- Lift the cover
- Install the battery pack
- Replace the cover of the battery compartment
- Gently press down to lock, until you hear a click

Optelec Compact
+
English Page 13
Turning the power on / off
Switch the unit on and off by pressing the orange button, located at the right side of the unit, for
half a second. By default the Compact
+
will start in high contrast white on black (negative) text
mode.
Using the magnification button
To set the magnification, simply turn the lever of the round button, located next to the
display. Placing the unit on a flat surface, allows you to select one of the three
magnification levels; 5X, 7.5X or 10X. Lifting the unit, allows you to lower the
magnification which is useful to obtain an overview of the object or text being viewed.
Selecting a viewing mode
Pressing the round mode button, located next to the display, allows you to select one
of the five viewing modes.
- Negative mode: reading in high contrast white on black
- Positive mode: reading in high contrast black on white
- Photo mode: view full color text and photos
- High contrast yellow text on a black background: reading in high contrast yellow on
black
- High contrast yellow text on a blue background: reading in high contrast yellow on blue

Optelec Compact
+
English Page 14
Pressing the round mode button for approximately one second, allows you to switch object
lighting off. Object lighting can be turned on and off in each of the above mentioned viewing
modes, facilitating reading of glossy magazines, displays and screens. Pressing the mode
button for one second again, will switch object lighting back on, whereas selecting the next
viewing mode by a short press of the mode button will turn the lighting on too.
Using the snapshot button
The snapshot button allows you to temporary freeze an image on the
screen.
- Hold or place the Compact
+
over the text or image
- Press the oval shaped snapshot button, located at the front side of the unit
- Bring the unit closer to your eyes to view the object or text
- Turn the lever, located next to the display, to change the magnification
- Press the viewing mode button, in the centre of the magnification dial, to change the
viewing mode
- Press the snapshot button again to unfreeze the image

Optelec Compact
+
English Page 15
Writing with the Compact
+
The Compact
+
has an integrated writing facility. Take the unit in your
hand and turn it upside down (display facing down)
- Slide the battery compartment away from you (see picture)
- Put the unit back on your paper (display facing up)
- Press the Compact
+
down on the side of the magnification /
mode button to tilt the Compact+ upwards on one side
- Place your pen under the raised side and you can start writing
Slide the battery compartment to its original position to return to the reading mode.
Using the Compact
+
handle
The Compact
+
has a collapsible, swing out handle; giving
you the feeling you are using a regular magnifying glass.
Simply pull the handle, located on the underside, to
release the handle and swing it out to eventually snap in
place. The collapsible handle gives you extra support and
control for optimal reading comfort.

Optelec Compact
+
English Page 16
4. Power and battery use
When the AC power adapter is not connected, the Compact
+
power source is a battery pack of
two rechargeable AA batteries. Off-the-shelf AA batteries can also be used, either rechargeable
or disposable. Out of concern for the environment and superior power, we advise you to use
rechargeable batteries.
Charging the batteries
To charge the Compact+ battery pack, connect the adapter supplied with the unit to the DC IN
5V jack, located on the front side. Plug the other side into a power outlet. The orange LED
indicator next to the adapter socket will glow continuously while the battery pack is charging.
When the battery pack is fully charged the orange LED light will switch off. If the LED indicator
starts to flash, it means there is a charge problem. Disconnect the adapter, check if the battery
pack is placed correctly in the compartment and try again.
Charging the Compact
+
takes approximately five hours. A fully charged Compact
+
will operate
for approximately two hours and thirty minutes. Please note that, for safety reasons, only the
batteries that came with the Compact
+
can be charged in the unit’s battery compartment.

Optelec Compact
+
English Page 17
For optimal battery life please do not charge the Compact
+
before the “battery empty”
( ) warning is displayed on the screen. Frequent charging of a full battery pack may
damage the battery and reduce its lifetime.
System Auto Off
The Compact
+
will automatically turn off if it is not used for a period of 4 minutes. Pressing the
orange button at the left side will switch the unit on again.

Optelec Compact
+
English Page 18
Appendix A: Safety
•Do not expose the Compact
+
to excessive heat or direct sunlight to avoid the risk of fire.
•Do not remove any parts of the Compact
+
. Contact an Optelec authorized service
organisation in your area.
•To avoid risk of electrical damage, keep your Compact
+
away from fluids and chemicals.
•Handle the Compact
+
with care. Rough handling will damage the internal components.
•Do not use the Compact
+
near inadequately shielded medical devices.
•Contact your dealer to service this equipment if necessary. Do not open your unit as it will
void the warranty.
•Always unplug the system before cleaning. Use a soft damp cloth to clean the exterior. Do
not use cleaning agents or abrasive materials as they will damage your unit.
•Use only the supplied power adapter.
•Do not remove the battery pack when the device is charging.
Use of the Compact
+
other than described in this manual will exclude it from warranty
conditions.
