1. Introduction
Congratulations on choosing the ClearView C, a desktop video magnifier
developed by Optelec. The ClearView C enables you to read, write, view
photos, do work and so much more. The ClearView C magnifies and
enhances text, objects and images and allows you to view them in your
preferred high contrast color combination, brightness and contrast settings. It
is easy to operate and can be used at home, work and school.
The ClearView C has a unique ergonomic, modular design that focuses on
ease of use, comfortable reading and maximum working space. The high
quality reading table allows you to move text and objects smoothly beneath
the camera. The integrated user-friendly control pad allows you to switch
between basic and advanced functionalities. The unique design of the
ClearView C ensures a comfortable reading posture and fits your home’s
interior perfectly.
1.1. About this manual
This manual will help you to become familiar with the ClearView C features
and operation. Please read this manual thoroughly before using your
ClearView C.
Please note that the ClearView C is a modular system. Different ClearView C
models can be assembled by selecting the various modules. This user
manual covers all of the models currently available. Some features and
functions can be added by installing different modules. It is possible that your
model does not support some of the functions or features described in this
manual.
If you have any questions or suggestions concerning the use of this product,
please contact your Optelec distributor or Optelec’s headquarters by
consulting the contact information page located at the end of this manual. We
greatly appreciate your feedback. We hope you enjoy working with your
ClearView C.

Optelec ClearView C
English Page 7
1.2. What’s in the box?
The ClearView C packaging contains the following:
- The ClearView C
- A power cord
- The wireless Control Pad
- The Instruction Sheet for the wireless Control Pad
- This user manual
- The Instruction Sheet for switching the table setup
Optional:
- The Comfort table tray
If any of these items are missing from your package, please contact your
Optelec distributor.
1.3. Getting to know your ClearView C
The following figures show the ClearView C’s main components.
1. Monitor
2. Reading table
3. C-shaped arm
4. Control Pad
5. X & Y Brake slides
6. Handle
7. Master power switch
8. Camera Box
9. HDMI out
10. HDMI in
11. Power out
12. Power in
13. Camera connection (speech)

Optelec ClearView C
Page 8 English
2. Unpacking and installing
The ClearView C is shipped in one box and is already assembled. All you
have to do is unpack the ClearView C, plug the power cord into the unit and
plug the power cord into the power socket.
To power on the ClearView C, please take the following steps:
- Plug the power cord into the power socket;
- Press the On / Off button at the left side of the Electronic Box.
2.1. Switching the table setup
Compact setup Comfort setup
The ClearView C has two table setups: the Compact setup and the wide
Comfort setup. The Compact setup is the standard setup. If you would like to
have more space, for instance when doing craftwork or reading larger
documents, you can switch to the Comfort setup. Please refer to the
‘Instruction Sheet for switching the table setup’ for step-by-step pictures.

Optelec ClearView C
English Page 9
To switch from the Compact to Comfort setup:
1. Remove the cap from the top of the C-shaped arm;
2. Loosen the black knob;
3. Slide the monitor and the camera box to the right by slightly lifting them;
4. Secure the black knob and place the cap back on the arm;
5. Release the brakes and slide the table top to the right;
6. Loosen the black knob;
7. Slide the table top back to its position and secure the brakes by sliding
them to the middle;
8. Hold the table and pull the arm out until you hear a click;
9. Slide the table top to the right and secure the black knob;
To switch back to the Compact setup:
1. Remove the cap from the top of the C-shaped arm;
2. Loosen the black knob;
3. Slide the monitor and the camera box to the left by slightly lifting them;
4. Secure the black knob and place the cap back on the arm.
5. Release the brakes and slide the table top to the right;
6. Loosen the black knob;
7. Slide the table top back to its position and secure the brakes;
8. Hold the table and push the arm into the table until you hear a click;
9. Slide the table top to the right and secure the black knob;

Optelec ClearView C
Page 10 English
3. Operation
3.1. Introduction
When using the ClearView C, place your hands on the wrist support at the
front of the table for easy access to the Control Pad buttons and for steady
table movement.
The ClearView C is equipped with a wireless Control Pad, located between
the two wrist supports in the reading table. If the Control Pad is placed in the
reading table with the Optelec logo facing you, the ClearView C buttons for
the basic functionality are accessible.
To access the buttons for the advanced functionality, simply rotate the
Control Pad so five rectangular buttons are facing you.
3.2. The Basic Control Pad
The Basic Control Pad is correctly placed in the reading table when the
Optelec logo is facing you, and three large buttons are on top of the Control
Pad.
3.2.1. Power On / Off
To power on both the system and monitor, press the
orange round On / Off button located next to the Zoom dial
on the Control Pad. The ClearView C will start up in the
same viewing mode as when it was powered off.
It takes about 5 seconds for the camera unit to initialize
before it displays an image.
In case the ClearView does not power on, make sure all cables are
connected and that the power switch, located at the left side of the camera
box behind the monitor, is in its ON position.

Optelec ClearView C
English Page 11
3.2.2. Adjusting the magnification
Locate the Zoom dial in the center of the Control Pad. Turn
it clockwise to increase the magnification, and counter-
clockwise to decrease the magnification.
3.2.3. Choosing viewing modes
Pressing the white Mode button inside the Zoom dial will
cycle you through a maximum of five different viewing
modes, depending on how the system is configured:
1. Full color photo mode: This mode displays the
original colors of the pictures and text.
2. Reading mode 1: This mode enhances the
foreground / background contrast. Pictures and text will be displayed in
the configured high contrast foreground and background color, by
default black text on a white background. The foreground and
background colors can be changed in the ClearView C Menu;
3. Reading mode 2 (optional): This mode enhances the foreground /
background contrast. Pictures and text will be displayed in the
configured high contrast foreground and background color, by default
white text on a black background. The foreground and background color
can be changed or disabled in the ClearView C Menu;
4. Reading mode 3 (optional): This mode enhances the foreground /
background contrast. Pictures and text will be displayed in the
configured high contrast foreground and background color. By default
this mode is disabled. The foreground and background color can be
enabled and changed in the ClearView C Menu;
5. Reading mode 4 (optional): This mode enhances the foreground /
background contrast. Pictures and text will be displayed in the
configured high contrast foreground and background color. By default
this mode is disabled. The foreground and background color can be
enabled and changed in the ClearView C Menu.
3.2.4. Object lighting On /Off
Pressing the white Mode button for four seconds turns off
the object lighting. You may want to temporarily turn off the
object lighting to eliminate light reflections. If you press this
button again, you will continue to the next reading mode
and the lights will turn back on. Pressing the button for four
seconds will turn the object lighting back on but will not
advance to the next reading mode.

Optelec ClearView C
Page 12 English
3.2.5. Overview function (position locator)
The overview function provides you with a quick overview
of the text, which helps you to easily locate the part of a
document which is of interest.
Press the blue square Overview button to activate the
overview function. When the overview function is
activated, the ClearView C will automatically zoom out to
the minimum magnification, and will display a crosshair
target to indicate the center of the screen. Position the text you wish to read
in the crosshair’s target by moving the reading table. Once the document has
been positioned, press the button once again to zoom in on the selected text
in your previous magnification setting.
3.2.6. Pointer (position locator)
Pressing the blue square Overview button for three
seconds will activate a red LED light, which shows as a
red spotlight on the reading table. The pointer helps you
locate where the camera looks on the table. For instance:
when writing, place your pen in the red spotlight on the
reading table and the pen will be displayed in the center of
your screen. Press this button once again to deactivate
the LED light. After 30 seconds, the pointer will automatically be deactivated.
3.2.7. Reading table brake and friction control
Use the two sliders at the front of the reading table to apply friction to the left /
right direction or up / down direction movement or to lock the left / right or up /
down direction. When the sliders are positioned towards the outer left and
right edge of the table, the table can move freely up, down, left and right. To
apply more friction, move the sliders towards the center of the table, whereby
the left slider adjusts the friction in the left / right direction, while the right
slider adjusts the friction in the up / down direction. To apply maximum friction
to the left / right movement, slide the left slider to the center of the table.
Alternatively, to apply the maximum friction to the up / down movement, slide
the right slider to the center position. Adjusting the friction or locking the table
can be useful when writing, painting, doing hobbies and crafts, moving the
ClearView C, or when you are not using the ClearView C.

Optelec ClearView C
English Page 13
3.3. The Advanced Control Pad
The Advanced Control Pad is correctly placed in the reading table when five
rectangular buttons are facing you and three larger buttons are on top of the
Control Pad.
3.3.1. Adjusting the image control
If characters or other on-screen elements are not clearly
visible, use the image control to enhance the image and
increase the sharpness. To adjust the image control, press
the white Image Control button marked with a dot and a
“sun” icon once (most left button). Now use the Zoom dial to adjust the image
control. If no button is pressed within three seconds, the Zoom dial will revert
back to its original zoom function.
3.3.2. Activating line markers / window shades
Pressing the grey Lines / Windows button (second button
from the left) cycles you through the line markers, window
shades and full screen camera image modes. Line markers
are used as guides to make reading text easier or to help
you write under the ClearView C. The window shades function is used to
block a part of an image when screen brightness becomes inconvenient or
when you need to concentrate on only one or two lines of text.
3.3.3. Positioning line markers / window shades
When line markers or window shades are activated, the
top or left line or window shade blinks to indicate it can
be moved up, down, left and / or right. Use the Zoom
dial to move the line marker or window shade. Press
the Mode button to adjust the other line or window
shade. To move the other line marker or window shade use the Zoom dial
again. If no button is pressed for 3 seconds, the Zoom dial reverts back to its
original zoom function and the blinking of the line marker or window shade
stops. Press the dial again to disable the line markers / window shades.
3.3.4. Activating the ClearView C Menu
Press the blue Menu button in the middle, marked with the
word “Menu” to activate the ClearView C settings menu.
For more information about the ClearView C menu, please
refer to chapter 4.

Optelec ClearView C
Page 14 English
3.3.5. Switching between the ClearView C and a computer / external
source image
If a computer or another external source is connected to
the ClearView C, press the grey PC button marked with an
arrow (second button from the right) to toggle between the
ClearView C image and the full screen computer image.
To display the computer image on your ClearView C monitor correctly, make
sure that your computer’s resolution is set to 1920 x 1080.
3.3.6. Auto-focus lock
The ClearView C features an automatic focus camera that
produces a sharp on-screen image at any time. When
switching the ClearView C on, the system will start up in
the auto-focus mode. Pressing the Auto-focus button marked with a dot and a
pencil icon (most right button) stops the ClearView C from continuously
operating the auto-focus feature and fixes the focus on the object being
viewed. This can be useful for writing, painting or crafts. When the auto-focus
feature is disabled, an icon with a pencil will be displayed in the top right
corner. To enable the auto-focus, simply press the Auto-focus button and the
icon will disappear from the top right corner to indicate the auto-focus is
switched on again.
3.4. The Control Pad Batteries
The ClearView C Control Pad is powered by two coin cell batteries of the type
CR2025. These batteries last for two to three years. If the Control Pad
buttons stop functioning, and the ClearView C is more than two years old, or
it is more than two years ago that the batteries of the Control Pad have been
changed, please change the batteries. To change the batteries, gently open
the battery tray on the side of the Control Pad and replace the two batteries.
3.5. Pairing the Control Pad
In case the Control Pad is missing or defective, and
needs to be replaced with a new Control Pad, the
new Control Pad needs to be paired with the
ClearView C. To pair the Control Pad follow these
steps:
1. Switch the ClearView C on;
2. Hold the Control Pad vertically and hold the
bottom of the Control Pad against the right side
of the camera box behind the monitor;
3. An icon will appear indicating the start of the
pairing procedure;

Optelec ClearView C
English Page 15
4. Press the On / Off button and the Overview button simultaneously for
five seconds and release the buttons;
5. If the pairing procedure is successful, the pairing icon will disappear;
6. If the ClearView C does not recognize or see the Control Pad, the
pairing sequence will be terminated within 30 seconds and the pairing
icon will disappear. Repeat steps 1 to 5 until the Control pad is correctly
paired. Possible causes for an unsuccessful pairing are:
- The batteries of the Control Pad are empty;
- The wrong buttons were pressed to initiate the pairing process;
- The Control Pad is broken.

Optelec ClearView C
Page 16 English
2. The ClearView C Menu
Allows you to adjust the screen brightness
Allows you to change the colors of the high contrast
modes or disable high contrast modes
Allows you to adjust the ClearView C automatic
standby time
Allows you to reset the ClearView C to its factory
default settings
Shows firmware versions and system information
Allows you to exit the menu
Allows you to enable or disable the object lighting
Allows you to lock or unlock the Advanced Control
Pad buttons
Allows you to configure the automatic power down
time

Optelec ClearView C
English Page 17
Activating the menu
To enter the menu, press the Menu button located at the
front in the middle of the Advanced side of the Control Pad.
To exit the menu, press the Menu button again.
Navigating the menu
Use the Zoom dial to scroll through the menu items. The
Mode button located in the middle of the Zoom dial will
activate the chosen menu item or confirm the selection.
Exiting the menu
To exit the menu, to go back to the previous menu level or
to cancel your choice, press the Menu button on the
Advanced side of the Control Pad.
Menu: Brightness
This menu item allows you to adjust the brightness of the screen.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu items. Select the menu
option Brightness and activate this menu by pressing the Mode button.
- Select the brightness level by using the Zoom dial to decrease or
increase the brightness level. There are five brightness levels to
choose from. The default brightness level is set to 5.
- Press the Mode button to confirm your choice and exit the menu.
Menu: Color
The ClearView C supports four high contrast modes and the default photo
mode. For each of the four high contrast modes, the foreground and
background colors can be configured. Three of the high contrast modes can
be disabled if you prefer to work with one high contrast mode. By default
three are enabled: Full color photo mode, high contrast mode 1 white

Optelec ClearView C
Page 18 English
background with black text and high contrast mode 2 black background with
white text. In addition to the color combinations, there is a greyscale option.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu items. Select the menu
option Color and activate this menu by pressing the Mode button.
- Select one of the four high contrast modes with the Zoom dial and
press the Mode button to confirm your choice.
- To select a new high contrast color combination, use the Zoom dial to
scroll through the list of color combinations. Select a color combination
by pressing the Mode button.
- High contrast modes 2, 3 and 4 can be disabled by selecting ‘off’.
- Press the Mode button to confirm your choice and exit the menu.
You can select the following color combinations:
- Black –White
- White –Black
- Yellow –Black
- Black –Yellow
- Yellow –Blue
- Blue –Yellow
- Black –Red
- Red –Black
- Black –Green
- Green –Black
- Black –Purple
- Purple –Black
- Blue –White
- White –Blue
- Black –Amber
- Amber –Black
- Greyscale
Menu: Light
This menu item allows you to enable or disable the object light –located at
the left and right of the camera –when the unit is switched on. By default, the
object light is enabled. If you select ‘off’, the light will be off when the unit is
switched on.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu. Select the menu option
Light and activate this menu option by pressing the Mode button.
- To enable the object light, select the value ‘on’ with the Zoom dial.
Selecting ‘off’ will disable the object light. Press the Mode button to
confirm your choice and exit the menu.

Optelec ClearView C
English Page 19
Menu: Keylock
This menu item allows you to lock or unlock the Advanced buttons on the
Control Pad, with the exception of the Menu button. If the lock is enabled, the
advanced buttons Brightness, Lines, PC and Auto-focus are locked. The
Menu button remains unlocked.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu. Select the menu option
Lock and activate this menu option by pressing the Mode button.
- To lock the Advanced Control Pad, select ‘on’ with the Zoom dial. Press
the Mode button to confirm your choice. Selecting ‘off’ will unlock the
Advanced Control Pad.
- Press the Mode button to confirm your choice and exit the menu
Menu: Power off
This menu item sets the time before the ClearView C is automatically
powered off. By default, the power off time is set to 5 minutes. These 5
minutes are activated after the default standby time of 15 minutes. By default,
the unit is therefore automatically switched off after 20 minutes. The Power
off time can be set to 5, 15, 30 minutes and to ‘never’.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu items. Select the menu
option Power off and activate this menu by pressing the Mode button.
- Select the time interval with the Zoom dial. Press the Mode button to
confirm your choice. Selecting ‘never’ will disable the automatic power
off function.
- Press the Mode button to confirm your choice and exit the menu.
Menu: Standby
This menu item sets the time before the ClearView C goes into standby mode
to conserve power. Pressing any button will take the unit out of standby
mode. By default, the standby time is set to 15 minutes. The standby time can
be set to 5, 15, 30 minutes and ‘never’.

Optelec ClearView C
Page 20 English
By pressing the On / Off button, the unit will always go into standby mode
first, after which it will power down using the power off time setting.
- Activate the menu by pressing the Menu on the Advanced side of the
Control Pad.
- Use the Zoom dial to scroll through the menu items. Select the menu
option Standby and activate this menu by pressing the Mode button.
- Select the time after which the unit will go into standby mode with the
Zoom dial. Press the Mode button to confirm your choice. Selecting
‘never’ will disable the automatic standby function.
- Press the Mode button to confirm your choice and exit the menu.
Menu: Reset
This menu item lets you reset the ClearView C to the factory default settings.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu. Select the menu option
Reset and activate this menu option by pressing the Mode button.
- To restore the factory defaults, select ‘yes’ by using the Zoom dial.
Choosing ‘no’ will leave all settings as they are.
- Press the Mode button to confirm your choice and exit the menu.
Alternatively:
- Press and hold the Power button for five seconds.
Menu: Information
This menu item displays the firmware versions and system information. No
changes can be made in this menu.
- Activate the menu by pressing the Menu button on the Advanced side
of the Control Pad.
- Use the Zoom dial to scroll through the menu. Select the menu option
Information and activate this menu option by pressing the Mode button.
- To exit the menu, press the Menu button.
