OptiPure QT Series Instruction manual

odels:
P/N 970-09704
Rev: A,04/11/19
QT10-2 QT-2 QTI-2 QT-1+ QTC-2 QTCR-2 QTC-1+
QT10-3 QT-3 QTI-3 QT-2+ QTC-3 QTCR-3 QTC-2+
QTI10-2 QT-4 QTI-4 QTI-1+ QTC-4 QTCR-4 QT1+CR
QTI10-3 QTI-2+ QTI1+CR
Installation, Operation & Maintenance Manual
For: anifold Series QT, QTI, QTC, QTCR
101 S. Gary Ave Roselle, IL 60172
www.optipurewater.com
[phone]

2
DO NOT DISCARD - GI E THIS MANUAL TO THE OWNER AFTER INSTALLATION
● Installation must conform to all local plumbing codes and regulations.
●Do NOT use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system. Systems certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
●Connect system to cold water supply only! Water temperature must not exceed 100°F/38°C.
●Do NOT solder plumbing connections attached to the assembly. High temperature will damage
these components.
●Do NOT over-tighten fitting connections. Always back-up valves and fittings with a wrench to
avoid turning the valve.
●Allow a minimum of 3” under the housing to allow for sump removal and filter replacement.
●Do NOT mount the system near a heat source or above the electrical wiring or any device or
area that would be adversely affected by water.
● Do NOT mount the system behind equipment. The unit must be easily accessible for filter
replacement.
●Failure to change cartridges per recommended intervals with OptiPure replacement cartridges
may lead to system failure and property damage.

3
Introduction:
Your new OptiPure QT-Series FoodService Filtration System will cleanse and condition the tap water
providing optimum water characteristics for their specified applications. The result is reduced
equipment maintenance requirements, longer equipment life and improved quality & consistency of
your products. The OptiPure System is built with the finest, most advanced materials and each
system is quality inspected and pressure tested prior to shipment. Proper system installation and
routine filter changes will ensure years of trouble-free operation and performance.
Please refer to this manual when performing routine filter changes. The instructions make periodic
maintenance quick and easy, and ensure you will receive maximum benefit from your system.
OptiPure Limited Warranty:
All system components and assembly except for replacement filter cartridges, separation
membranes, permeate pumps, electric motors, diaphragm pumps, and rotary vane pumps shall be
warranted against defects in workmanship for a period of 60 months from the date of original
shipment.
Replacement filter cartridges are warranted for defects in material and workmanship only.
embrane failure due to fouling, hydrolysis, oxidation or other damage caused by the local water
conditions is not covered under warranty.
Permeate pumps, electric motors, diaphragm pumps, and rotary vane pumps shall be warranted
against materials and workmanship for a period of 12 months from the date of purchase and are
limited to the terms of warranty extended by the original equipment manufacturer.
Products should only be installed and operated in accordance with the recommended procedures
and guidelines from OptiPure. Products must be maintained and serviced with OptiPure approved
replacement parts and filters. Failure to replace filter cartridges or filter elements at recommended
interval or specified capacity will void warranty.
Contact OptiPure customer service or go to www.optipurewater.com for a detailed copy of the
warranty statement.
Obtaining Warranty Service:
To obtain warranty service the customer should:
1) Contact the authorized OptiPure dealer who supplied the product.
2) Call OptiPure’s customer service department for replacement parts and support.

4
HOW DOES FILTERTRAK WORK?Simple, One-Time Registration of System with FilterTrak!2. Change Notice"Filter Change Due" Notice Generated by FilterTrak and ReceivedMost Filters Shipped Same Day.Filters Changed by On-site Store or Service Personnel. Change Information Recorded in FilterTrak.Choose Upon Set-up to Auto-Ship or Manually Place Filter OrdersFilter Change Acknowledged in FilterTrak3. Order Placed1.Register4. Filters Shipped5.Filters Changed6.AcknowledgementAuthorized DistributorsAvailable Through
Filtertrak® is an online application that
enables low maintenance service and filter
monitoring of water treatment systems,
ensuring customers get the full performance
of their system.
FilterTrak manages timely, proper filter
replacement which:
• Reduces maintenance
• Improves operating efficiency
• Assures the quality of ice, beverages, and
steam generating systems
For more information about FilterTrak,
please contact one of our foodservice
master distributors or go to:
www.optipurewater.com
®

5
System/ Operating Specification & Connections:
Maximum Pressure: 125 psi/8.6 bar
Operating Temperature: 35° - 100°F (2° - 32°C)
Inlet/Outlet Connections:
1/2” NPT ale Fittings Standard on all QT 2, and QT 3 Systems -
3/4” NPT ale Fittings Standard on QT-4, QTI-4, QTC-4
1/2” Push-In-Tube Connection are optional.

6
Capacity:
Change filters at gallon rating or at least every 6 months, or when pressure gauge needle enters the
red zone on the outlet gauge while water is flowing through the filter system under normal
operating conditions.
odel
Name
Flowrate Capacity Scale
Inhibitor
edia
Reduction of
gpm lpm gallons Liters
QT10-2 3 11.36 30,000 113,550 No Particulate Class I , Chlorine, Taste & Odor
QT10-3 4.5 17.03 45,000 170,325 No Particulate Class I , Chlorine, Taste & Odor
QTI10-2 3 11.36 30,000 113,550 Yes Particulate Class I , Chlorine, Taste & Odor
QTI10-3 4.5 17.03 45,000 170,325 Yes Particulate Class I , Chlorine, Taste & Odor
QT-2 4.5 17.03 45,000 170,325 No Particulate Class I , Chlorine, Taste & Odor
QT-3 6.75 25.55 67,500 255,488 No Particulate Class I , Chlorine, Taste & Odor
QT-4 9.0 34.07 90,000 340,650 No Particulate Class I , Chlorine, Taste & Odor
QTI-2 4.5 17.03 45,000 170,325 Yes Particulate Class I , Chlorine, Taste & Odor
QTI-3 6.75 25.55 67,500 255,488 Yes Particulate Class I , Chlorine, Taste & Odor
QTI-4 9.0 34.07 90,000 340,650 Yes Particulate Class I , Chlorine, Taste & Odor
QT-1+ 2.25 8.52 22,500 85,163 No Particulate Class I , Chlorine, Taste & Odor
QT-2+ 4.5 17.03 45,000 170,325 No Particulate Class I , Chlorine, Taste & Odor
QTI-1+ 2.25 8.52 22,500 85,163 Yes Particulate Class I , Chlorine, Taste & Odor
QTI-2+ 4.5 17.03 45,000 170,325 Yes Particulate Class I , Chlorine, Taste & Odor
QTC-2 4.5 17.03 45,000 170,325 No Chlorine, Taste & Odor and Cyst
QTC-3 6.75 25.55 67,500 255,488 No Chlorine, Taste & Odor and Cyst
QTC-4 9.0 34.07 90,000 340,650 No Chlorine, Taste & Odor and Cyst
QTC-1+ 2.25 8.52 22,500 85,163 No Chlorine, Taste & Odor and Cyst
QTC-2+ 4.5 17.03 45,000 170,325 No Chlorine, Taste & Odor and Cyst
QTCR-2 3.4 12.87 20,000 75,700 No Chloramine, Chlorine, Taste & Odor
QTCR-3 5.1 19.30 30,000 113,550 No Chloramine, Chlorine, Taste & Odor
QTCR-4 6.8 25.74 40,000 151,400 No Chloramine, Chlorine, Taste & Odor
QT1+CR 2.5 9.46 15,000 56,775 No Chloramine, Chlorine, Taste & Odor
QTI1+CR 2.5 9.46 15,000 56,775 Yes Chloramine, Chlorine, Taste & Odor
NOTE: odels with (I) use IsoNet Scale Inhibitor edia

7
141
4"
183
8"
43
4"
141
4"
231
4"
141
4"
231
4"
43
4"
233
8"
231
4"
Model: QT-4
Model: QTI-4
Model: QTC-4
Model: QTCR-4
Model: QT10-2
Model: QTI10-2
Model: QT1+CR
Model: QTI1+CR
Model: QT-1+
Model: QTI-1+
Model: QT-2
Model: QTI-2
Model: QTC-2
Model: QTC-1+
Model: QTCR-2
Model: QT10-3
Model: QTI10-3
Model: QT-2+
Model: QTI-2+
Model: QT-3
Model: QTI-3
Model: QTC-3
Model: QTC-2+
Model: QTCR-3
183
4"
183
8"
43
4"183
4"
231
4"
Dimensional Drawing:

8
5
"
R
INLET>
OUTLET<
1
8
"
R
1
8
"
5"5"5"
R1
8"
R1
8"
INLET>
OUTLET<
1
0
"
R
1
8
"
R
1
8
"
INLET>
OUTLET<
Installation Procedure :
1. Turn off all equipment to be fed by the OptiPure
System.
2. Locate water supply cut-off valve and turn off.
3. We recommend that you install a full-flow ball valve
of the same size or larger than the connection
fittings on the OptiPure System. Installing a ball
valve on the line supplying the OptiPure System
allows the system to be serviced without shutting
off the main water supply. (It will not be necessary
to use this valve when replacing filters.)
4. ount the OptiPure System on a wall stud or
suitable mounting material spanning wall studs.
NOTE: QT-4 Systems full of water can weigh up
to 35 lbs. Use suitable fasteners when mounting
to wall.
5. Run a 1/2” Piping/ Tube or 3/4” Piping / Tubing or
larger feed line from the full-flow ball valve to the
top INLET Connection on the left side of the
OptiPure system. For NPT connection: Use 2-3
wraps of PTFE Thread sealant tape and hold the
inlet male fitting on the system with a wrench when
connecting the feed water line.
NOTE: Ensure all piping / tubing being attached
to OptiPure System is properly supported, to
ensure proper alignment and that piping /
tubing can allow movement associated with the
expansion and contraction of the piping system.
Use hangers and anchors of proper strength to
maintain the proportional share weight of the
piping / tubing and contents. Improper piping /
tubing support can cause undesired stress and
fatigue on plastic fittings of OptiPure System
causing system failure.
NOTE: Do not overtighten connection fittings.
Mounting
Dimensions
Installation Precautions:
• Do NOT install system on line pressure above 100 psi.
• Do NOT install the system backwards with the feed water line connected to the outlet.
• Do NOT use liquid pipe compounds for fitting connections. USE two to three wraps of
PTFE thread sealant tape.
• Do NOT allow system to freeze. Turn off water supply to housing and drain housing if
temperature falls below 33°F.
• Do NOT install system in direct sunlight or where system is exposed to harsh chemicals or
may be subjected to being struck by moving equipment, carts, mops or any other item
that may cause damage.
• IF water hammer is evident, install water hammer arrestors before OptiPure unit.

9
Installation Procedure (continued):
6. Select the appropriate size tubing for the equipment being fed and connect it to the OUTLET
of the OptiPure System.
Unless Flush Valve Assembly or Flushing Line is installed prior to making connection to the
equipment, DO NOT connect the tubing from OUTLET of OptiPure System to the equipment
at this time, this tubing from the OUTLET can be used to flush the system.
7. With OptiPure ulti-Function Valve set in the off position (See Figure 2 on page 10), slowly
open the full-flow ball valve at the water source.
Check for leaks from plumbing leading into the OptiPure System.
8. Flushing of system before use.
NOTE: NO ACTIVATION IS REQUIRED FOR THE OPTIPURE SYSTE TO PERFOR PROPERLY.
FLUSHING IS RECO ENDED TO ALLOW AIR TO ESCAPE THE SYSTE AND RE OVE ANY
CARBON FINES PRIOR TO CONNECTING TO EQUIP ENT.
Three possible flush port connections:
(NOTE: a. and b. allow for convenient flushing after filter replacement.)
a. A Flush Valve Assembly included in the parts pack can be attached to the ulti-Function
Valve port opening. See page 15 for more information. When using this option, connect
the system outlet tubing to the equipment before flushing.
b. A tee (not supplied) can be added on the outlet line from the system. Install a manual
shut-off valve (not supplied) on the branch of the tee. When using this option, connect
outlet tubing from the tee to the equipment before flushing.
c. If no flush valve is installed, use the outlet tubing that is not yet connected to the
equipment for flushing.
Flushing steps:
1. Hold tubing from the chosen flush connection in a bucket or over a sink or drain.
2. Slowly turn the ulti-Function Valve top handle into the Operating Position.
(See Figure 1 on page 10.) Turn Flush Valve Options a. / b. to open positions.
3. Allow water to flush through the OptiPure System for 5 to 10 minutes or until the water
runs clear.
4. Turn ulti-Function Valve to the Off Position. (See Figure 2 on page 10.)
5. If flush connection a. or b. is used, be sure to turn the shut-off valve to the Off position.
If flush connection c. was chosen, connect the outlet tubing to the equipment at this
time. Ensure that the tubing is clean before connecting to the equipment.
9. With tubing connected to equipment. Turn ulti-Function Valve to the Operating Postion
(See Figure 1 on page 10) and check for leaks.
10. If no plumbing leaks, turn on equipment and check for normal operation of equipment.
11. Register your System with FilterTrak.

10
Multi-Function alve
The OptiPure anifold System includes a ulti-Function Valve that allows the System to have the
water turned off, or be put into bypass. The white handles on the valve provide a clear indication of
the water flow path in each position. The three points on the tee shape of the handle indicate a path
the flow can take.
Operating Position
This is the position of the handles during
normal operation. Looking at the handle
pointers, you can see that feed water flows
from the INLET port into the filter system and
treated water flows out of the system to the
OUTLET port. The bypass path from inlet to
outlet is blocked.
Off Position
In this position, the inlet water is stopped
before entering the OptiPure System.
Bypass Position
In this position, the INLET water is diverted to
the OUTLET port and all flow to and from the fil-
ters is blocked.
Equipment does not have treated water at this
time, so this should only be used when
issues with filtration are occurring.
Alternate Bypass Position is used when
Outlet connection is switched to right side of
manifold. Note: Non treated water is flowing
thru manifold at this time. See page 11 for
Alternate Outlet Location.
INLET
OUTLET
Raw
Water IN
Treated
Water OUT
Filter
System
Filter System Operating Position
(Service Position)Water
Connections
INLET
OUTLET
OPEN
Raw
Water OFF
Treated
Water OPEN
Filter
System
Incoming Water OFF Position 1
(Primary Off)Water
Connections
INLET
Raw Water
OUTLET
Raw Water
Raw
Water OFF
Treated
Water OFF
Filter
System
Incoming Water BYPASS Position 1
(Standard Plumbing of Outlet)Water
Connections
FIGURE 3
FIGURE 2
FIGURE 1

11
Alternate Outlet Locations
The OptiPure anifold System has the ability to be flexible with treated water outlet locations. The
outlet fitting can be switched to the other end of the anifold System if Inlet and Outlet needs to be
on opposite sides of the system.
Multi-Function alve Wrench
The OptiPure anifold Systems include a wrench to help turn the ulti-Function Valve positions.
Insert wrench as shown to help rotate handles 90 degrees in each direction from Service Position.
REMOVE CLIP
AND FITTING
BOTTOM OUTLETS
FOR FULL FLOW
TOP OUTLET FOR
RESTRICTED
TREATED WATER
FLOW
INLET IS ALWAYS
TOP LEFT PORT
OPENING!
BOTTOM OUTLETS
FOR FULL FLOW
ALTERNATE
OUTLET

12
Replacement Filter Cartridges:
OptiPure Filter Systems are designed, tested, and certified with OptiPure filter cartridges with proven
performance, size and operating capacities. Use of replacement cartridges other than those
specified will void warranties, certifications and may compromise equipment protection, water
quality and cartridge life.
Replacement Cartridges:
System Cartridge Part Number Qty.
QT10-2 CTO-Q10 300-05828 2
QT10-3 CTO-Q10 300-05828 3
QTI10-2 CTOS-Q10 300-05829 2
QTI10-3 CTOS-Q10 300-05829 3
QT-2 CTO-Q 300-05830 2
QT-3 CTO-Q 300-05830 3
QT-4 CTO-Q 300-05830 4
QTI-2 CTOS-Q 300-05835 2
QTI-3 CTOS-Q 300-05835 3
QTI-4 CTOS-Q 300-05835 4
QT-1+ S5-Q 300-05802 1
CTO-Q 300-05830 1
QT-2+ S5-Q 300-05802 1
CTOS-Q 300-05830 2
QTI-1+ S5-Q 300-05802 1
CTOS-Q 300-05835 1
QTI-2+ S5-Q 300-05802 1
CTOS-Q 300-05835 2
QTC-2 XTO-Q 300-05840 2
QTC-3 XTO-Q 300-05840 3
QTC-4 XTO-Q 300-05840 4
QTC-1+ S5-Q 300-05802 1
XTO-Q 300-05840 1
QTC-2+ S5-Q 300-05802 1
XTO-Q 300-05840 2
QTCR-2 CTO-QCR2 300-05833 2
QTCR-3 CTO-QCR2 300-05833 3
QTCR-4 CTO-QCR2 300-05833 4
QT1+CR CTO-Q10 300-05828 1
CTO-QCR 300-05831 1
QTI1+CR CTO-Q10 300-05828 1
CTOS-QCR 300-05832 1

13
Filter Change Frequency:
Several situations will mandate filter changes.
Complete filter sets should be changed when any of
the following apply:
• Six (6) onths have passed since unit
installation or previous filter change.
• Reduced water flow.
If filter change frequency is less than 6 months due to
pressure drop, it may be necessary to add
additional prefiltration or evaluate system sizing
recommendations.
Filter Cartridge Replacement Procedure:
I PORTANT: Determine whether all equipment
connected to the OptiPure System must be turned off
prior to shutting off water supply from filters.
1. On ulti-Function Valve Turn Upper handle to the
OFF Position. (See figure 2 on page 10)
2. Relieve pressure downline by opening flush valve
or briefly actuating equipment.
3. Turn cartridge to the left 1/4 turn until the
cartridge stops.
4. Pull down on the cartridge until the cartridge clears
the system connection. Discard old cartridge.
NOTE: Some water will drip from Optipure
System during cartridge removal.
5. Line up the upward-arrow on the new cartridge
with the arrow on the side of the cartridge
connection on the Optipure System. NOTE: Some
cartridges do not have arrows. Reference the Key
Feature in figure when connecting to system.
6. Push cartridge up into head until the base of the
cartridge is next to the base of the filter system.
Turn the cartridge to the right about a 1/4 turn or
until the cartridge stops.
REPEAT Steps 3 thru 6 on additional filters.
7. On ulti-Function Valve Turn Upper Handle to the
Operation Position. (See figure 1 on page 10)
8. Open down-stream flush valve to flush new
cartridge for a recommended 5 to 10 minutes or
until water runs clear.
Operation:
With adequate pressure, normal operation of the OptiPure System is completely automatic.
Dependable operation involves only monitoring of outlet pressure, periodic filter changes and
service documentation.
Filter Cartridge
Arrow / Key Feature
STEP 2
STEP 3
STEP 1
STEP 4
STEP 5
STEP 6
STEP 7

14
Optional Kit
Flush Valve Assembly
(1) Flush Valve Assembly
(8ft) - 3/8” (TUBE NOT SHOWN)
Optional Fitting Kit
1/2” Tube Connection
(2) - Connectors, O-rings, Clips
KIT #:
170-52912
OPTIONAL KITS & REPLACEMENT PARTS
KIT #:
575-92272
Optional Fitting Kit
3/4 NPT MALE Connection
(2) - Connectors, O-rings, Clips
KIT #:
575-92273
Optional Fitting Kit
1/2 NPT MALE Connection
(2) - Connectors, O-rings, Clips
KIT #:
575-92274
Replacement Assembly / Part
Bypass / Multi-Functional Valve
Part:
575-92274
Replacement Assembly / Part
(1) Plug Assembly with O-ring
(1) Manifold, Head Clip
Parts:
575-92264
575-92225
Replacement Assembly / Part
(1) Port Plug Assembly with O-ring
(1) Manifold, Port Clip
Parts:
575-92265
575-92230
Replacement Assembly / Part
(1) PSI Gauge Assembly with O-ring
(1) Manifold, Port Clip
Parts:
575-92266
575-92230
Pressure Gauge Monitoring:
Periodically monitor the pressure gauge on the OptiPure System. If the needle on the gauge ever
enters the red zone (while the connected equipment is in operation and water is flowing through the
system to the equipment) it may be an indication that the filters have become clogged.
Maintenance:
The only routine maintenance your OptiPure System should ever require is periodic filter cartridge
changes. Filter changes are necessary for optimum performance of your foodservice equipment. If
the system sizing recommendations have been followed the OptiPure System is designed to provide
a six (6) month filter replacement interval on most tap water.
Additional Replacement Parts
(Not Shown):
Part# Description
19782 ulti-Function Valve Wrench
575-92233 O-Ring 0-118 (Body & Fittings)
575-92234 O-Ring 0-021 (Body)
575-92235 O-Ring 0-110 (Port)
575-92239 O-Ring 0-120 (Handle Lower)
575-92240 O-Ring 0-122 (Handle Upper)
575-92249 Cover 2 UP
575-92250 Cover 3 UP
575-92251 Cover 4 Up
575-92232 Cover Screw 1/4-.375 Black

15
Flush Kit Optional attachment to Multi-Function alve
To install Flush Valve Assembly:
1. Turn ulti-function Valve to Off Position and relieve pressure to OptiPure System.
2. To remove White Port Plug on ulti-Function Valve remove Port Clip using small flat head
screwdriver. Pull Port Plug out of ulti-Function Valve.
3. Insert Flush Valve Assembly into ulti-Function Valve Port. Replace Port Clip.
4. Install 3/8” Tubing (NOT INCLUDED) into ball valve and direct other end into bucket or sink. Ensure
ball valve is in off position.
5. Turn ulti-Function Valve to the Operating Position and check for leaks.
6. Open ball valve on Flush Valve Assembly to verify water flushing. Turn ball valve off when
flushing is complete.
PORT CLIP
PORT PLUG

anufactured by :
OptiPure
101 S. Gary Ave., Suite A
Roselle, IL 60172
p: 972.881.9797 e: [email protected]
www.optipurewater.com
