optris CS User manual

Operator’s Manual
optris® CS
Infrared thermometer
www. .com [e-mail]1.800.561.8187

Table of contents 3-
Table of contents
Table of contents .............................................................................................................................................. 3
1General notes ............................................................................................................................................ 7
1.1 Intended use ....................................................................................................................................... 7
1.2 Warranty ............................................................................................................................................. 8
1.3 Scope of delivery ................................................................................................................................ 8
1.4 Maintenance ....................................................................................................................................... 9
2Technical Data ........................................................................................................................................ 10
2.1 Default settings ................................................................................................................................. 10
2.2 General specifications ...................................................................................................................... 13
2.3 Electrical specifications ..................................................................................................................... 14
2.4 Measurement specifications ............................................................................................................. 16
2.5 Optical charts .................................................................................................................................... 17
www. .com [e-mail]1.800.561.8187

-4 -
2.6 Close focus optics ............................................................................................................................. 20
2.7 LED-Functions .................................................................................................................................. 21
2.7.1 Automatic aiming support ......................................................................................................... 21
2.7.2 Self-diagnostic .......................................................................................................................... 22
2.7.3 Temperature code indication .................................................................................................... 23
3Installation ............................................................................................................................................... 25
3.1 Mechanical Installation ..................................................................................................................... 25
3.1.1 Mounting accessories ............................................................................................................... 26
3.1.2 Air purge collar .......................................................................................................................... 27
3.1.3 Other accessories ..................................................................................................................... 29
3.1.4 Tilt assembly ............................................................................................................................. 30
3.2 Electrical Installation ......................................................................................................................... 31
3.2.1 Digital communication ............................................................................................................... 33
www. .com [e-mail]1.800.561.8187

Table of contents 5-
3.2.2 Open collector output ................................................................................................................ 34
3.2.3 Direct connection to a RS232 on the computer ........................................................................ 35
4Schematic circuit diagrams for maintenance applications ................................................................ 36
5IRmobile app ........................................................................................................................................... 39
6Software CompactConnect .................................................................................................................... 41
6.1 Installation ......................................................................................................................................... 41
6.2 Communication settings ................................................................................................................... 43
6.2.1 Serial Interface .......................................................................................................................... 43
6.2.2 Protocol ..................................................................................................................................... 43
7Basics of Infrared Thermometry ........................................................................................................... 44
8Emissivity ................................................................................................................................................ 45
8.1 Definition ........................................................................................................................................... 45
8.2 Determination of unknown emissivity ............................................................................................... 46
8.3 Characteristic emissivity ................................................................................................................... 47
www. .com [e-mail]1.800.561.8187

-6 -
Appendix A – Table of emissivity for metals ............................................................................................... 48
Appendix B - Table of emissivity for non-metals ........................................................................................ 49
Appendix C – Direct connection to a RS232 interface ................................................................................ 50
Appendix D – Smart Averaging ..................................................................................................................... 52
Appendix E – Declaration of Conformity ...................................................................................................... 53
www. .com [e-mail]1.800.561.8187

General notes 7-
1 General notes
1.1 Intended use
Thank you for choosing the optris® CS infrared thermometer.
The sensors of the optris CS series are non-contact infrared temperature sensors. They calculate the surface
temperature based on the emitted infrared energy of objects [►7 Basics of Infrared Thermometry]
The CS sensing head is a sensitive optical system. Please use only the thread for mechanical
installation.
• Avoid abrupt changes of the ambient temperature.
• Avoid mechanical violence on the head – this may destroy the system (expiry of warranty).
• If you have any problems or questions, please contact our service department.
Read the manual carefully before the initial start-up. The producer reserves the right to change
the herein described specifications in case of technical advance of the product.
► All accessories can be ordered according to the referred part numbers in brackets [ ].
www. .com [e-mail]1.800.561.8187

-8 -
1.2 Warranty
Each single product passes through a quality process. Nevertheless, if failures occur contact the customer
service at once. The warranty period covers 24 months starting on the delivery date. After the warranty is
expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted product
components. Warranty does not apply to damages, which result from misuse or neglect. The warranty also
expires if you open the product. The manufacturer is not liable for consequential damage or in case of a non-
intended use of the product.
If a failure occurs during the warranty period the product will be replaced, calibrated or repaired without
further charges. The freight costs will be paid by the sender. The manufacturer reserves the right to
exchange components of the product instead of repairing it. If the failure results from misuse or neglect the
user has to pay for the repair. In that case you may ask for a cost estimate beforehand.
1.3 Scope of delivery
• CS incl. connection cable
• Two mounting nuts
• Quick start guide
www. .com [e-mail]1.800.561.8187

General notes 9-
1.4 Maintenance
Blow off loose particles using clean compressed air. The lens surface can be cleaned with a soft, humid
tissue (moistened with water) or a lens cleaner (e.g. Purosol or B+W Lens Cleaner).
Never use cleaning compounds which contain solvents (neither for the lens nor for the housing).
www. .com [e-mail]1.800.561.8187

-10 -
2 Technical Data
2.1 Default settings
Smart Averaging means a dynamic average adaptation at high signal edges. [Activation via
software only]. [►Appendix D – Smart Averaging]
The default settings can be changed with the optional IR App Connector (USB adapter cable &
software). If the unit is supplied together with the IR App Connector cable the output is already
preset to digital communication (bidirectional).
At time of delivery the unit has the following pre-settings:
Emissivity
0.950
Transmission
1.000
Average time
0.3 s
Smart averaging
active
Smart averaging hysteresis
2 °C
Ambient temperature source
internal (head)
Status-LED function
Self-diagnostic
www. .com [e-mail]1.800.561.8187

Technical Data 11-
Input (IN/ OUT/ green)
inactive
Output (OUT/ yellow)
mV output
Temperature range
0...350 °C
Output voltage
0...3.5 V
Thermocouple output
Inactive
Vcc adjust
inactive
Signal processing
Hold mode: off
Calibration
Gain 1.000/ Offset 0.0
Failsafe
Inactive
For a usage of the CS for online maintenance applications (in electrical cabinets e.g.) the following
recommend settings are already included in the factory default setting (but not active):
OUT
At 3-state output the following settings are default:
Pre-alarm difference: 2 °C
No alarm level: 8 V
Pre-alarm level: 5 V
Alarm level: 0 V
Service voltage: 10 V
www. .com [e-mail]1.800.561.8187

-12 -
IN/ OUT
At Alarm output (open collector) the following settings are default:
Mode: normally closed
Temp code output: activated (for values above alarm level)
Range settings: 0 °C =0 %/ 100 °C = 100 %
Vcc adjust
If activated the following settings are default:
Output voltage range: 0-10 V
Difference mode: activated
Alarm level Alarm value (IN/ OUT pin) Vcc
1 40 °C 11 V
2 45 °C 12 V
3 50 °C 13 V
4 55 °C 14 V
5 60 °C 15 V
6 65 °C 16 V
7 70 °C 17 V
8 75 °C 18 V
9 80 °C 19 V
10 85 °C 20 V
www. .com [e-mail]1.800.561.8187

Technical Data 13-
2.2 General specifications
Environmental rating
IP63
Ambient temperature
-20...80 °C
Storage temperature
-40...85 °C
Relative humidity
10...95 %, non-condensing
Material
Stainless steel
Dimensions
85 mm, M12x1
Weight
58 g
Cable length
1 m (Standard), 3 m, 8 m, 15 m
Cable diameter
4.3 mm
Vibration
IEC 60068-2-6 (sinus shape), IEC 60068-2-64 (broad band noise)
Shock
IEC 60068-2-27 (25G and 50G)
www. .com [e-mail]1.800.561.8187

-14 -
2.3 Electrical specifications
Used Pin
Function
OUT
IN/ OUT
x
Analog
0-5 V 1) or 0-10 V 2)/ scalable
x
Alarm
output voltage adjustable; N/O or N/C
x
Alarm
3-state alarm output (three voltage level for no alarm, pre-alarm, alarm)
x
Analog
programmable open collector output (NPN type) [0-30 V DC/ 50 mA] 4)
x
Temp. Code
Temp. Code Output (open collector (NPN type)) [0-30 V DC/ 50 mA]4)
x
Input
programmable functions:
• external emissivity adjustment
• ambient temperature compensation
• triggered signal output and peak hold function 5)
x
x
Serial digital 3)
uni- (burst mode) or bidirectional
OUT t/c K
Analog
Thermocouple output type K; alternativelyselectable to the mV output (software necessary)
Status LED
green LED with programmable functions:
• alarm indication (threshold independent from alarmoutputs)
• automatic aiming support
• self-diagnostics
• temperature code indication
www. .com [e-mail]1.800.561.8187

Technical Data 15-
Vcc adjust mode
10 adjustable emissivity and alarm values by variation of supply voltage/ Service mode for analog output
Output impedances
min. 10 kΩ load impedance
Current draw
10 mA
Power supply
5...30 VDC 6)
1) 0...4.6 V at supply voltage 5 VDC; also valid for alarm output
2) only at supply voltage ≥ 11 V
3) inverted RS232, TTL, 9.6 kBaud
4) loadable up to 500 mA if the mV output is not used
5) High level: > 0.8 V/ Low level: < 0.8 V
6) The CS sensor may only be powered either via USB or externally, but not simultaneously!
1) The t/c wires are indicated with an additional cable marker to avoid wrong connections due to the identical cable colors of other wires
(white, green).
Power supply [white]
Analog output/ TxD (5 V)/ Alarm output [yellow]
Analog input/ RxD (5 V)/ Open collector output [green]
Ground (⊥) [brown]
Thermocouple output type K (+) [green] 1)
Thermocouple output type K (-) [white] 1)
Shield [black]
www. .com [e-mail]1.800.561.8187

-16 -
2.4 Measurement specifications
Temperature range
-50...1030 °C (scalable via Software)
Spectral range
8...14 µm
Optical resolution
15:1
CF-lens (optional)
0.8 mm@ 10 mm
Accuracy 1) 2)
±1.5 °C or ±1.5 % of reading (whichever is greater)
Repeatability 1)
±0.75 °C or ±0.75 % of reading (whichever is greater)
Temperature coefficient 3)
±0.05 K/ K or ±0.05 %/ K (whichever is greater)
Temperature resolution (NETD) 4)
50 mK
Response time
14 ms (90 % Signal/ adjustable to 999 s via Software)
Warm-up time
10 min
Emissivity/ Gain
0,100...1,100 (adjustable via 0-10 VDC input or software)
Transmissivity
0,100...1,000 (adjustable via software)
Interface (optional)
USB programming interface
Signal processing
Average, Peak hold, Valley hold, Advanced peak hold with threshold and
hysteresis, Triggered signal output, Triggered peak hold function (adjustable via
software)
www. .com [e-mail]1.800.561.8187

Technical Data 17-
Software / App
optional (CompactConnect / IRmobile)
1) at ambient temperature 23
 5 °C and object temperatures >0 °C
2) Accuracy for thermocouple output: ±2.5°C or ±1%
3) for ambient temperatures <18 °C and >28 °C
4) at time constant of 200 ms and an object temperature of 200 °C
2.5 Optical charts
• The size of the measuring object and the optical resolution of the infrared thermometer
determine the maximum distance between sensing head and measuring object.
• In order to prevent measuring errors the object should fill out the field of view of the optics
completely. Consequently, the spot should at all times have at least the same size like the
object or should be smaller than that.
The following optical charts show the diameter of the measuring spot in dependence on the distance
between measuring object and sensing head. The spot size refers to 90 % of the radiation energy.
The distance is always measured from the front edge of the sensing head.
www. .com [e-mail]1.800.561.8187

-18 -
As an alternative to the optical diagrams, the spot size calculator can also be used on the
Optris website (https://www.optris.global/spot-size-calculator) or via the Optris calculator app.
The app can be downloaded for free from the Google Play store (see QR code).
D = Distance from front of the sensing
head to the object
S = Spot size
www. .com [e-mail]1.800.561.8187

Technical Data 19-
Figure 1: Optical chart CS (15:1)
Figure 2: Optical chart CS (15:1) with CF-lens (0.8 mm@ 10 mm)
www. .com [e-mail]1.800.561.8187

-20 -
2.6 Close focus optics
• If the CF-lens is used, the transmission has to be set to 0.78. To change this value the
optional USB-Kit (including software) is necessary.
• The assigned transmission (average value) is a characteristic value which may has a certain
scattering. If required the transmission has to be determined.
The optional CF-lens allows the measurement of small objects. The CF optics can also be combined with a
laminar air purge
Figure 3: CF-lens [Order-No.: ACCTCF]
Figure 4: Laminar air purge with integrated CF-lens
[Order-No.: ACCTAPLCF]
www. .com [e-mail]1.800.561.8187

Technical Data 21-
2.7 LED-Functions
The green LED can be programmed for the following functions. For the programming the USB adapter
cable incl. software (option) is necessary. The factory default setting for the LED is self-diagnostic.
LED Alarm
LED lights up ifthe object temperature exceeds ordeceedsan alarm threshold
Automatic aiming support
Sighting feature foran accurate aiming ofthe CS to hot or cold objects
Self-diagnostic
LED is indicating different states of the sensor
Temperature Code indication
Indication of the object temperature via the LED
Off
LED deactivated
2.7.1 Automatic aiming support
The automatic aiming support helps to adjust the unit to an object which has a temperature different to the
background. If this function is activated via software the sensor is looking for the highest object temperature;
means the threshold value for activating the LED will be automatically tuned.
This works also if the sensor is aimed at a new object (with probably colder temperature). After expiration of
a certain reset time (default setting: 10 s) the sensor will adjust the threshold level for activation of the LED
new.
www. .com [e-mail]1.800.561.8187
