1 General Notes
1.1 Intended use
Thank you for choosing the optris® CTlaser infrared thermometer.
The sensors of the optris CTlaser series are noncontact infrared temperature sensors. They calculate the
surface temperature based on the emitted infrared energy of objects [►8 Basics of Infrared
Thermometry]. An integrated double laser aiming helps to mark the measurement spot on the object
surface. This lies within the two laser points.
The CTlaser sensing head is a sensitive optical system. Please use only the thread for
mechanical installation.
•Avoid abrupt changes of the ambient temperature.
•Avoid mechanical violence on the head –this may destroy the system (expiry of warranty).
•If you have any problems or questions, please contact our service department.
Read the manual carefully before the initial start-up. The producer reserves the right to change
the herein described specifications in case of technical advance of the product.
www. .com [e-mail]1.800.561.8187

-10 -
► All accessories can be ordered according to the referred part numbers in brackets [ ].
1.2 Warranty
Each single product passes through a quality process. Nevertheless, if failures occur contact the customer
service at once. The warranty period covers 24 months starting on the delivery date. After the warranty is
expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted product
components. Warranty does not apply to damages, which result from misuse or neglect. The warranty also
expires if you open the product. The manufacturer is not liable for consequential damage or in case of a non-
intended use of the product.
If a failure occurs during the warranty period the product will be replaced, calibrated or repaired without
further charges. The freight costs will be paid by the sender. The manufacturer reserves the right to
exchange components of the product instead of repairing it. If the failure results from misuse or neglect the
user has to pay for the repair. In that case you may ask for a cost estimate beforehand.
1.3 Scope of delivery
•CTlaser sensing head with connection cable and electronic box
•Mounting nut and mounting bracket (fixed)
•Operators manual
www. .com [e-mail]1.800.561.8187

General Notes 11-
1.4 Maintenance
Blow off loose particles using clean compressed air. The lens surface can be cleaned with a soft, humid
tissue (moistened with water) or a lens cleaner (e.g. Purosol or B+W Lens Cleaner).
Never use cleaning compounds which contain solvents (neither for the lens nor for the housing).
www. .com [e-mail]1.800.561.8187

-12 -
1.5 Model Overview
The sensors of the CTlaser series are available in the following basic versions:
Model
Model code
Measurement range
Spectral response
Typical applications
CTlaser LT
LT
-50 to 975 °C
8-14 µm
non-metallic surfaces
CTlaser F
LTF
-50 to 975 °C
8-14 µm
fast processes
CTlaser 05M
05M
1000 to 2000 °C
0.525 µm
measurement of liquid metal
CTlaser 1M
1ML
1MH
1MH1
485 to 1050 °C
650 to 1800 °C
800 to 2200 °C
1,0 µm
metals and ceramic surfaces
CTlaser 2M
2ML
2MH
2MH1
250 to 800 °C
385 to 1600 °C
490 to 2000 °C
1.6 µm
metals and ceramic surfaces
CTlaser 3M
3ML
3MH
3MH1
3MH2
3MH3
50 to 400 °C
100 to 600 °C
150 to 1000 °C
200 to 1500 °C
250 to 1800 °C
2.3 µm
metals at low object temperatures (from 50 °C)
CTlaser 4M
4ML
0 to 500 °C
2,2-6 µm
metals at low object temperatures (from 0 °C)
and very fast processes
CTlaser MT
MT
200 to 1450 °C
3.9 µm
measurement through flames
www. .com [e-mail]1.800.561.8187

General Notes 13-
MTH
400 to 1650 °C
CTlaser F2
F2
F2H
200 to 1450 °C
400 to 1650 °C
4.24 µm
measurement of CO2-flame gases
CTlaser F6
F6
F6H
200 to 1450 °C
400 to 1650 °C
4.64 µm
measurement of CO-flame gases
CTlaser G5
G5L
G5H
G5HF
G5H1F
100 to 1200 °C
250 to 1650 °C
200 to 1450 °C
400 to 1650 °C
5,0 µm
measurement of glass
CTlaser G7
G7
100 to 1200 °C
7,9 µm
measurement of glass
CTlaser P7
P7
0 to 710 °C
7.9 µm
plastic foils and surfaces of glass
Table 1: Overview of models
In the following chapters of this manual you will find only the short model codes. On the 1M, 2M, 3M, 4M and G5
models the whole measurement range is split into several sub ranges (L, H, H1 etc.).
www. .com [e-mail]1.800.561.8187

-14 -
2 Technical Data
2.1 Factory settings
Smart Averaging means a dynamic average adaptation at high signal edges. [Activation via
software only]. [►Appendix C –Smart Averaging]
Signal output object temperature
0 –5 V
Emissivity
0.970 [LT/ LTF/ MT/ F2/ F6/ G5/ G7/ P7]
1.000 [05M/ 1M/ 2M/ 3M/ 4M]
Transmissivity
1.000
Average time (AVG)
0.2 s [LT]; 0.1 s [LTF/ MT/ F2/ F6/ G5/ G7/ P7]
0.001 s [05M/ 1M/ 2M/ 3M/ 4M]
Smart Averaging
Inactive (active [LTF])
Peak hold
Inactive
Valley hold
Inactive
www. .com [e-mail]1.800.561.8187

Technical Data 15-
LT/ LTF
05M
1ML
1MH
1MH1
2ML
2MH
2MH1
3ML
3MH
3MH1
3MH2
3MH3
Lower limit temperature
range [°C]
0
1000
485
650
800
250
385
490
50
100
150
200
250
Upper limit temperature
range [°C]
500
2000
1050
1800
2200
800
1600
2000
400
600
1000
1500
1800
Lower alarm limit [°C]
(Normally closed)
30
1200
600
800
1200
350
500
800
100
250
350
550
750
Upper alarm limit [°C]
(Normally open)
100
1600
900
1400
1600
600
1200
1400
300
500
600
1000
1200
Lower limit signal output
0 V
Upper limit signal output
5 V
Temperature unit
°C
Ambient temperature compensation
(on LT, LTF, MT, F2, F6, G5, G7, P7
output at OUT-AMB as 0-5 V signal)
internal head temperature probe
Baud rate [kBaud]
115
Laser
inactive
www. .com [e-mail]1.800.561.8187

-16 -
4ML
MT
MTH
F2
F2H
F6
F6H
G5L
G5H
G5HF
G7
P7
Lower limit temperature
range [°C]
0
200
400
200
400
200
400
100
250
200
100
0
Upper limit temperature
range [°C]
500
1450
1650
1450
1650
1450
1650
1200
400
600
1200
710
Lower alarm limit [°C]
(Normally closed)
30
400
600
400
600
400
600
200
350
350
200
30
Upper alarm limit [°C]
(Normally open)
100
1200
1400
1200
1400
1200
1400
500
900
900
500
100
Lower limit signal output
0 V
Upper limit signal output
5 V
Temperature unit
°C
Ambient temperature compensation
(on LT, LTF, MT, F2, F6, G5, G7, P7
output at OUT-AMB as 0-5 V signal)
internal head temperature probe
Baud rate [kBaud]
115 (4M: 921,6)
Laser
inactive
www. .com [e-mail]1.800.561.8187

Technical Data 17-
2.2 General specifications
Sensing head
Electronic box
Environmental rating
IP65 (NEMA-4)
Ambient temperature 1)
-20...85 °C (4ML: -20…70 °C)
Storage temperature
-40...85 °C (3M: -40…125 °C)
-40...85 °C
Relative humidity
10...95 %, noncondensing
Material
Stainless steel
Die casting zinc
Dimensions
100 mm x 50 mm, M48x1.5
89 mm x 70 mm x 30 mm
Weight
600 g
420 g
Cable length
3 m (standard), 8 m, 15 m
Cable diameter
5 mm
Ambient temperature cable
Max. 105 °C [High temperature cable (optional):
180 °C]
Vibration
IEC 60068-2-6 (sinus shaped), IEC 60068-2-64
(broad band noise)
www. .com [e-mail]1.800.561.8187

-18 -
Shock
IEC 60068-2-27 (25G and 50G)
Software (optional)
CompactConnect
1) Laser will turn off automatically at ambient temperatures >50 °C. The functionality of the LCD display can be limited at ambient
temperatures below 0 °C.
2.3 Electrical specifications
Power supply
8–36 VDC (4M: 8-30 VDC / 5 V USB / max. 1,2 W)
Current draw
Max. 160 mA
Aiming laser
635 nm, 1 mW, On/ Off via programming keys or software
Outputs/ analog
(For 4M output 1 and 2 are freely selectable: Analog mA/mV, Alarm mA/mV, TCK)
Channel 1
selectable: 0/ 4–20 mA, 0–5/ 10 V, thermocouple (J or K) or alarm output (Signal source:
object temperature)
Channel 2 (LT/ LTF/ MT/ F2/ F6/ G5/ G7/ P7 only)
Head temperature [-20...180 °C] as 0–5 V or 0–10 V output or alarm output (Signal source
switchable to object temperature or electronic box temperature if used as alarm output)
Alarm output
Open collector (NPN type) output at Pin AL2 [24 V/ 50 mA]
Output impedances
mA
Max. loop resistance 500 Ω(at 8-36 VDC)
www. .com [e-mail]1.800.561.8187

Technical Data 19-
mV
Min. 100 kΩload impedance
Thermocouple
20 Ω
Digital interfaces
USB, RS232, RS485, Profibus DP, Modbus RTU, Ethernet (optional plug-in modules)
Relay outputs
2 x 60 VDC/ 42 VACRMS, 0.4 A; optically isolated (optional plug-in module)
Functional inputs
F1-F3; software programmable for the following functions:
- external emissivity adjustment
- ambient temperature compensation
- trigger (reset of hold functions)
4M: I/O1-3 pins freely selectable via software
www. .com [e-mail]1.800.561.8187

-20 -
2.4 Measurement specifications [LT models]
LT
LTF
Temperature range (scalable)
-50...975 °C
Spectral range
8...14 µm
Optical resolution
75:1
50:1
System accuracy 1) 2) 3)
±1 °C or ±1 %
±1,5 °C or ±1,5 %
Repeatability 1) 3)
±0.5 °C or ±0.5 %
±1 °C or ±1 %
Temperature coefficient 4)
±0,05 K/ K or ±0,05 %/ K
NETD 3) 5)
0.1 K
0.5 K
Response time (90 % signal)
120 ms
9 ms
Warm-up time
10 min
Emissivity/ Gain, Transmissivity
0.100...1.100 (adjustable via programming keys or software)
Signal processing
Average, peak hold, valley hold (adjustable via programming keys or software)
1) at ambient temp. 23 ±5 °C; at object temperatures >0 °C (LT) / ≥ 20 °C (LTF); response time=1 s
2) Accuracy for thermocouple output: ±2.5 °C or ±1 %, whichever is greater
3) ε=1
4) for ambient temperatures (head) <18 °C and >28 °C; whichever is greater
5) at time constant of 200 ms (LT) / 100 ms (LTF) and an object temperature of 25 °C
www. .com [e-mail]1.800.561.8187

Technical Data 21-
2.5 Measurement specifications [05M model]
05M
Temperature range (scalable)
1000…2000 °C
Spectral range
0.525 µm
Optical resolution
150:1
System accuracy1) 2) 3)
± 1 % TMeas (≤ 1100 °C)
± (0.3 % TMeas + 2 °C) (>1100 °C)
Repeatability 1) 3)
± 0.5 % TMeas (≤ 1100 °C)
± (0.1 % TMeas + 1 °C) (>1100 °C)
Temperature coefficient 4)
±0,05 K/ K or ±0,05 %/ K
NETD 3) 5)
0.2 K
Response time (90 % signal) 6)
1 ms
Emissivity/ Gain
0.100...1.100 (adjustable via programming keys or software)
Transmissivity
0.100...1.000 (adjustable via programming keys or software)
Signal processing
Average, peak hold, valley hold (adjustable via programming keys or software)
1) at ambient temp. 23 ±5 °C; whichever is greater; response time=1 s
2) Accuracy for thermocouple output: ±2.5 °C or ±1 %, whichever is greater
3) ε =1 4) for ambient temperatures (head) <18 °C and >28 °C; whichever is greater 5) at time constant 1 ms and object
temperature=start of measurement range + 50 °C 6) with dynamic adaptation at low signal levels
www. .com [e-mail]1.800.561.8187
