Orbital Systems R3 OS8733-E User manual

Fixture Installation
Orbital Shower Cabinet R3 (OS8733-E)
5-06-0024
Publication date 2023-09-22

Copyright © 2023,Orbital Systems
All rights reserved. No part of this document may be reproduced or copied in any form or by any means without written
permission from Orbital Systems. The English language version of this document contains the original instructions. All
other language versions are translations of the original instructions.

Table of Contents
Thank you for your purchase ................................................................................................ 4
Prerequisites and Approvals ......................................................................................... 4
Approved Waterproofing Membrane .......................................................................... 5
For installations outside of Sweden .................................................................... 5
For installations in Sweden ................................................................................... 5
Warranty ........................................................................................................................... 6
Service ...................................................................................................................... 6
System Overview .................................................................................................................... 7
Installation System Requirements ........................................................................................ 8
Installation Overview .............................................................................................................. 9
Orbital Shower Installation Options ............................................................................ 9
Orbital Shower Installation Requirements .................................................................. 11
Wall Installation .............................................................................................................. 12
Seal mountings in wet zone ......................................................................................... 13
Shower Installation Overview ...................................................................................... 14
Recycling Optimisation Site Suggestion ................................................................... 15
Fixture Installation ................................................................................................................. 16
Component Overview ................................................................................................... 16
Kit Measurements .......................................................................................................... 19
Recommended Kit Measurements ............................................................................ 20
Installation Scenario Displayed in Manual ................................................................ 22
Prepare Shower Area ................................................................................................... 23
Install Drain .................................................................................................................... 27
Install Wall Brackets ...................................................................................................... 31
Prepare Orbital Systems Shower Head ..................................................................... 34
Install Core Cabinet ...................................................................................................... 35
Pipes & Connections .................................................................................................... 37
Install Audio ................................................................................................................... 43
Install Drainage Pipe ..................................................................................................... 47
Prepare for Tiling ......................................................................................................... 48
Apply Waterproofing Membrane .............................................................................. 50
Install Tiling Frame Set ................................................................................................. 55
Tiling ................................................................................................................................ 56
Final Preparations ......................................................................................................... 58
Page 3 of 59

Thank you for your purchase
This manual applies to model OS8733-E
Read the Safety Guide before starting the installation or before operating the shower.
Thank you for purchasing the Orbital Shower from Orbital Systems. To enjoy the full
potential of the shower please read and follow the procedures in this manual. Make sure
that you fully understand how to operate this shower and make sure that it is properly
maintained in accordance with the instructions given in this manual. Do not discard this
manual, keep it handy for future reference. This manual is valid for all shower models.
When applicable the manual will only be displaying the Orbital Systems Shower Head &
Hand Shower variant.
Prerequisites and Approvals
Orbital Shower is designed and type approved according to the Swedish requirements
in Swedish National Board of Housing and Building & Planning regulations (BBR). The
system is type approved according to RiSE C900373 & C900374, Kiwa 1513; 0753 and
Kiwa safety certificate K100686/02 and DVGW CERT W 540 AS-0605DO0262.
Orbital Shower is CE-marked based on certificate and test reports from third party labs.
If industry regulations and instructions in this manual are followed, Orbital Systems guar-
antees a functional shower system.
Page 4 of 59

Approved Waterproofing Membrane
For installations outside of Sweden
The following chapter describes a general waterproofing membrane procedure for instal-
ling Orbital Shower in a wet-room area. Industry rules for how to apply waterproofing
membrane in wet-room areas shall be applied.
For installations in Sweden
Following waterproofing membranes are approved according to Swedish regula-
tions. Choose one of the following and go to http://publiccert.ri.se/sv/Product/In-
dex/C900374?key=PID024128 for separate instructions of how to apply your chosen
waterproofing membrane.
The following sealing layers for the Wallbox and floor luminaire are industry approved ac-
cording to Säker Vatten industry standards (https://www.sakervatten.se/branschregler-
na):
•Adda system F
•Ardex Tricom /A7+A8
•Bostik Pro
•Bostik Universal
•Casco Folie
•Centro CE TM#F System
•Ecodur foliesystem
•FF Kakel foliesystem
•GKH F-System
•KERABLOCK TEX 750
•Kerasafe+
•LIP Foliesystem 27
•Mapeguard WP 90, WP 200
•Midun foliesystem
•Mira Vapourmat
•PCI VG2014 Foliesystem
•Schönox WSF
•Sense Pro system F
•Sopro AEB 815
•Weber TEC Foliesystem
•ZebraSystem F1
Page 5 of 59

Warranty
For Warranty and Liability for Defects information, please visit Orbital Systems web
https://orbital-systems.se/terms-conditions.
Service
Orbital Systems and our team of expert sta are available to assist you if you require
product advice, experience any problems, need to purchase spare parts or to set up a
service appointment.
Repairs should only be carried out by Orbital Systems.
Contact us
•[e-mail]
•www.orbital-systems.com
•Europe: [phone]
Page 6 of 59

System Overview
Orbital Shower Cabinet R3 (OS8733-E)
4
1
2
3
5
1. Shower Head (optional)
2. Control Dial
3. Hand Shower Kit (Hand shower, Diverter and Holder) (optional)
4. Shower Unit (RSK 835 91 20) and Cabinet (RSK 205 50 28), located outside the
shower area, or in an adjacent room
5. Drain Unit (RSK 711 54 63) and Outlet unit (RSK 711 99 33)
Preparation and installation of shower area (including piping, connections, water proof-
ing and tiling), installation of cabinet (4) and drain (5) are included in the Fixture installa-
tion manual.
Installation of the Shower unit (4), Control dial (2), Shower head (1) and Hand shower
kit (3) are included in the Technology installation manual. Operation of the shower is
included in the User Guide.
Page 7 of 59

Installation System Requirements
Connectivity
Internet connection: Password protected Wi-Fi 2,4 GHz / 5 GHz or
Ethernet.
The installation kit contains components
for either Wi-Fi connection OR Ethernet
depending on what has been specified in the
shower order.
Electrical Supply
Residual circuit breaker: One breaker per Shower Core
Power supply: One Phase, 230VAC / 50 Hz / 16A
Mains supply wire: Min. 2.5 mm2(rated for 16A circuit)
Plumbing / Water
Incoming tap water supply
connections:
Separate hot and cold, 2x female G 1/2" swivel
nut.
Incoming cold water temp.
(min-max):
4-25°C
Incoming hot water temp.
(min-max):
50-65°C
Maximum working pressure
tap water:
PN10
Incoming water pressure
(min-max):
2-10 bar
The supply pressure is the fundamental
requirement for the shower flow:
•2 bar: 7.5 litres/min
•3 bar: 9.5 litres/min
•4 bar: 11 litres/min
Recommended water supply
flow:
9 litres/minute per inlet hot and cold
Water hardness (min-max): Required: 3°dH-10°dH
Recommended: 6°dH-10°dH (or a total
hardness of 110-180mg CaCO3/litre)
Water iron content: <0,3mg/litre
Page 8 of 59

Installation Overview
Orbital Shower Installation Options
max. 3000mm
The distance between the center of the Orbital Shower Core and the center of the Drain
Unit must not exceed 3000 mm.
Orbital Shower Core placed on the
same wall as the Drain Unit and
Shower Head.
Orbital Shower Core placed on a
wall perpendicular to the Drain Unit
and Shower Head.
Page 9 of 59

Orbital Shower Core placed in a
separate and heated room.
Orbital Shower Core placed in a
separate and heated room.
When installing the Orbital Shower Cabinet model, the Orbital Shower Core is installed
as surface mounted wall mounting outside the shower area "in bathroom with water-
proofing in the floor", or in an adjacent room "without waterproofing in the floor". The
kit only allows for mounting on a wall.. The leakage indicator should end "in rooms with
a waterproof floor". Read about the leakage indicator in Install Drainage Pipe [47]. The
limitation in distance, ensuring full system functionality, is maximum 3000 mm.
Any bends in the sleeves and conduits going to and from Orbital Shower Core needs to
be achieved by using 45° angles. For example, to achieve a 90° bend, two pcs of 45°
bends needs to be used. No more than six 45° bends (maximum three 90° bends) in
total can be used when installing the Orbital Shower. These limitations applies to both
horizontal and vertical bends.
Page 10 of 59

Orbital Shower Installation Requirements
W 500mm, H 915mm, D 150mm
D.
D.
C.
B.
min. 160 mm
X
E. max. 15 mm
A.
X
Finished floor height where it is level.
The following constraints apply to the configuration of system components:
A. The top of the Orbital Shower Core must be placed lower than the bottom of the
head shower.
B. Orbital Shower Core must be positioned minimum 160 mm above the top of the Drain
Unit Frame.
C. Total distance between the Control Dial and Orbital Shower Core cannot exceed 3000
mm.
D. The piping between the Orbital Shower Core, any Shower Heads and the Drain Unit
has to be built with a consistent slope towards the Drain Unit. Total distance between the
Orbital Shower Core and the Drain Unit cannot exceed 3000 mm.
E. The maximum thickness of wall tiles and tile grout cannot exceed 15 mm (wall tile
max.10 mm, tile grout max. 5 mm).
Page 11 of 59

Wall Installation
The weight of the Orbital Shower Core is approx. 25 kg. The surrounding structure must
be able to support the forces that will stress the attachment points.
Use the holes located on the back and the sides to fixate the Core wall enclosure.
IMPORTANT
The cabinet must not be placed in a place for bathing or showering.
IMPORTANT
Leakage indication shall be placed with a slope along its entire length and end
in a room with waterproof floors where you can easily detect a leak. The pipe
should not end in place for bathing or showering. Inside diameter of the wire
for indication of leakage must be at least 20 mm. The outlet should not be
placed near more than 60 mm from the waterproofing layer of the floor or
adjacent wall.
The pipe for indication of leakage must be cleaned so that leaking water is
not prevented from flowing out. A cabinet must be placed frost-free on the
construction warm side inside the plastic foil or the steam brake.
Page 12 of 59

Seal mountings in wet zone
CAUTION
For installation in Sweden according to current Industry Rules Safe Water
Installation. All mountings in the wet zone must be sealed against the water-
proofing layer of the wall or floor. Material for sealing must adhere to the
substrate and be water-resistant, mold-resistant and aging-resistant.
Seal the drill holes according to industry rules.
Wood Solid construction
1
2
1
2
3
4
•A: Wood / Concrete
•B: Waterproofing membrane
•C: Tile adhesive
•D: Tile
Page 13 of 59

Shower Installation Overview
Available shower variants:
A: Orbital Systems Shower Head & Hand Shower
B: Orbital Systems Shower Head
IMPORTANT
The image is a principle sketch, and should not be used as an installation
scenario.
Cabinet must also be equipped with a leakage indicator.
Drain Unit HxWxD: 192x812x184 mm
Drain Connection: Ø75 mm
Page 14 of 59

Recycling Optimisation Site Suggestion
Recommended installation
A fully enclosed shower area with floor heating is recommended to optimize recircula-
tion rates.
Page 15 of 59

Fixture Installation
Component Overview
Fixture kit Floor fixtures
2
3
5
6
4
1
1. Drain waterproofing membrane, 1x
2. Tiling frame set, 1x
3. Drain unit, 1x (RSK 711 54 63)
4. Outlet unit, 1x (RSK 711 99 33)
5. Cleaning wipe, 1x
6. Screws & Plugs kit, 1x
Page 16 of 59

Fixture kit Wall fixtures
4
2
3
7
6
1
5
8
9
13
12
14
10
11
15
16
17
1. Retainer Conduit (RSK 188 21 50),10x (Head & Hand)// 5x (Head)
2. Conduit Elbow (RSK 187 79 99 / 188 27 00), 5x (Head & Hand)// 3x (Head)
3. Screws, 6x
4. Fixture, 1x
5. Piping, PEX Hose with Conduit (RSK 188 23 36), 550 cm (Head & Hand)/ 350 cm
(Head)
6. Reducer 50 - 40 mm (RSK 291 03 56)
7. Piping, Conduit for Control Dial (RSK 187 06 65), 350 cm
8. Pipe 50mm, 100 cm AS+ with sleeve, x3 (RSK 283 20 03)
9. Auxiliary components and Drainage pipe components kit, 1x
10. Wallbox UNI Push V2 (RSK 188 21 81 / 188 26 57) x1, screws, 8x (Head & Hand) / 4x
(Head)
11. Fitting, 40 mm x45°, M-F, 2x (RSK 291 03 41)
12. Bend, 50 mm x 45°, M - F, x6 (RSK 283 20 31)
13. Core Cabinet,1x (RSK 205 50 28)
14. WLAN Antenna, 1x
15. Splash Protection Sheet Set, 1x
16. Core Cabinet Frame, 1x
17. Door, 1x
Provided by Customer:
1. Waterproofing Conduit Membrane for Diverter
2. Waterproofing Conduit Membrane for Shower Head
3. Waterproofing Conduit Membrane for Control Dial
4. Waterproofing Conduit Membrane for Pipe to Orbital Shower Core
Page 17 of 59

Audio kit
1
3
2
4
5
6
7
1. Audio fixture
2. Speaker with speaker cable
3. Amplifier with amplifier cable and stub antenna
4. Puck antenna (only used for Orbital Shower Cabinet)
5. Rod antenna (only used for Orbital Shower Hatch)
6. Assembly kit to the rod antenna
7. Cable to the rod antenna
Page 18 of 59

Kit Measurements
915 mm
27 mm
150 mm
500 mm
Control Dial Head shower/Hand
shower
Incoming hot water Ethernet
Incoming cold water Drain
Power supply Leakage indication
Page 19 of 59

Recommended Kit Measurements
X
1100 mm
1450 mm
150 mm 150 mm
X
Finished floor height where it is level.
Page 20 of 59
