Orbital Systems R3 OS8733-E User manual

Technology Installation
Orbital Shower Panel R3 (OS8733-E)
5-06-0012
Publication date 2023-09-22

Copyright © 2023,Orbital Systems
All rights reserved. No part of this document may be reproduced or copied in any form or by any means without written
permission from Orbital Systems. The English language version of this document contains the original instructions. All
other language versions are translations of the original instructions.

Table of Contents
Thank you for your purchase ................................................................................................ 4
Prerequisites and Approvals ......................................................................................... 4
Warranty ........................................................................................................................... 5
Service ...................................................................................................................... 5
System Overview .................................................................................................................... 6
Installation Overview .............................................................................................................. 7
Installation System Requirements ................................................................................ 7
Seal mountings in wet zone .......................................................................................... 8
Install Orbital Shower Unit .................................................................................................... 9
Install Sensor Hose, Flush Hose and Recirculation Hose ......................................... 11
Install Sensor Tank Dock ............................................................................................... 13
Install Sensor Tank and Sensor Tank Lock ................................................................. 15
Install Funnel ................................................................................................................... 17
Install Orbital Shower Core .......................................................................................... 18
Install Hose Connections ............................................................................................. 23
Add the Filter Capsule ................................................................................................. 25
Install Panel .................................................................................................................... 27
Install Control Dial ......................................................................................................... 29
Install Panel Lock .......................................................................................................... 33
Next Step ........................................................................................................................ 36
Installing the Shower Head ................................................................................................. 37
Installing the Hand Shower ................................................................................................ 40
Installing the Diverter and Hand Shower ................................................................. 40
Installing the Hand Shower Holder ............................................................................ 45
Shower Activation, Wi-Fi Setup and Installation test .................................................... 48
Page 3 of 49

Thank you for your purchase
This manual applies to model OS8733-E
Read the Safety Guide before starting the installation or before operating the shower.
Thank you for purchasing the Orbital Shower from Orbital Systems. To enjoy the full
potential of the shower please read and follow the procedures in this manual. Make sure
that you fully understand how to operate this shower and make sure that it is properly
maintained in accordance with the instructions given in this manual. Do not discard this
manual, keep it handy for future reference. This manual is valid for all shower models.
When applicable the manual will only be displaying the Orbital Systems Shower Head &
Hand Shower variant.
Prerequisites and Approvals
Orbital Shower is designed and type approved according to the Swedish requirements
in Swedish National Board of Housing and Building & Planning regulations (BBR). The
system is type approved according to RiSE C900373 & C900374, Kiwa 1513; 0753 and
Kiwa safety certificate K100686/02 and DVGW CERT W 540 AS-0605DO0262.
Orbital Shower is CE-marked based on certificate and test reports from third party labs.
If industry regulations and instructions in this manual are followed, Orbital Systems guar-
antees a functional shower system.
Page 4 of 49

Warranty
For Warranty and Liability for Defects information, please visit Orbital Systems web
https://orbital-systems.se/terms-conditions.
Service
Orbital Systems and our team of expert sta are available to assist you if you require
product advice, experience any problems, need to purchase spare parts or to set up a
service appointment.
Repairs should only be carried out by Orbital Systems.
Contact us
•[e-mail]
•www.orbital-systems.com
•Europe: [phone]
Page 5 of 49

System Overview
Orbital Shower Panel R3 (OS8733-E)
4
1
2
3
5
1. Shower Head (optional)
2. Control Dial
3. Hand Shower Kit (Hand shower, Diverter and Holder) (optional)
4. Shower Unit (RSK 835 91 20) and Cabinet (RSK 831 41 82)
5. Drain Unit (RSK 711 54 63) and Outlet unit (RSK 711 99 33)
Preparation and installation of shower area (including piping, connections, water proof-
ing and tiling), installation of cabinet (4) and drain (5) are included in the Fixture installa-
tion manual.
Installation of the Shower unit (4), Control dial (2), Shower head (1) and Hand shower
kit (3) are included in the Technology installation manual. Operation of the shower is
included in the User Guide.
Page 6 of 49

Installation Overview
Installation System Requirements
Connectivity
Internet connection: Password protected Wi-Fi 2,4 GHz / 5 GHz or
Ethernet.
The installation kit contains components
for either Wi-Fi connection OR Ethernet
depending on what has been specified in the
shower order.
Electrical Supply
Residual circuit breaker: One breaker per Shower Core
Power supply: One Phase, 230VAC / 50 Hz / 16A
Mains supply wire: Min. 2.5 mm2(rated for 16A circuit)
Plumbing / Water
Incoming tap water supply
connections:
Separate hot and cold, 2x female G 1/2" swivel
nut.
Incoming cold water temp.
(min-max):
4-25°C
Incoming hot water temp.
(min-max):
50-65°C
Maximum working pressure
tap water:
PN10
Incoming water pressure
(min-max):
2-10 bar
The supply pressure is the fundamental
requirement for the shower flow:
•2 bar: 7.5 litres/min
•3 bar: 9.5 litres/min
•4 bar: 11 litres/min
Recommended water supply
flow:
9 litres/minute per inlet hot and cold
Water hardness (min-max): Required: 3°dH-10°dH
Recommended: 6°dH-10°dH (or a total
hardness of 110-180mg CaCO3/litre)
Water iron content: <0,3mg/litre
Page 7 of 49

Seal mountings in wet zone
CAUTION
For installation in Sweden according to current Industry Rules Safe Water
Installation. All mountings in the wet zone must be sealed against the water-
proofing layer of the wall or floor. Material for sealing must adhere to the
substrate and be water-resistant, mold-resistant and aging-resistant.
Seal the drill holes according to industry rules.
Wood Solid construction
1
2
1
2
3
4
•A: Wood / Concrete
•B: Waterproofing membrane
•C: Tile adhesive
•D: Tile
Page 8 of 49

Install Orbital Shower Unit
Component Overview Technology kit Core components and Door
16
2
1
4
3
15
5
6
7
8
9
10
11
12
13
14
1. Panel Door, 1x
2. Orbital Shower Core, 1x
3. Control Dial , 1x (incl fixture 1x, screws 4x)
4. Sensor tank, 1x
5. Clip, 1x
6. Sensor Tank Dock, 1x
7. Sensor Tank Lock, 1x
8. Spring Lock, 1x
9. Filter capsule, 1x
10. Cleaning tablets, 1x
11. Sensor cable, 1x
12. Recirculation hose, 1x
13. Flush hose, 1x
14. Panel latch kit 1x
15. Hose connection, 1x
16. Ethernet kit, 1x
Page 9 of 49

Component Overview Technology kit Shower heads & diverter
1
3
2
8
6
7
9
10
5
4
1. Hand shower with hose, 1x
2. Head shower arm, 1x
3. Head shower, 1x
4. Diverter body, 1x
5. Diverter wall plate, 1x
6. Hand shower holder, 1x
7. Hand shower holder cover, 1x + set screw, 1x
8. Threaded adapter, 1x
9. Screw and tool kit,1x
10. O-ring kit, 1x
Component Overview Technology kit Shower heads
3
2
1
1. Threaded adapter, 1x
2. Head shower arm, 1x
3. Head shower, 1x
Page 10 of 49

Install Sensor Hose, Flush Hose and Recirculation Hose
1.
2. Install Sensor Cable, Flush Hose and Recirculation Hose. Make sure the Sensor Cable
goes first.
Page 11 of 49

3. Pull the Sensor Cable out to where the contact almost reaches the end of the Sensor
T
ank.
Page 12 of 49

Install Sensor Tank Dock
1. NOTICE
Apply lubricant according to industry rules. Make sure that the o-rings are
lubricated.
Connect Hoses to Sensor Tank Dock.
2. Lock Hoses by inserting Clip.
Page 13 of 49

3. Insert Sensor T
ank Dock into Connection Pipe. Push it all the way in.
4. Lock Sensor Tank Dock in place with the Spring Lock.
Page 14 of 49

Install Sensor Tank and Sensor Tank Lock
1. Connect the Sensor Cable to the Sensor Tank.
CAUTION
Make sure to have correct alignment between key and slot in connectors
by aligning the two white lines.
2. Insert Sensor T
ank.
Page 15 of 49

3. Lock the Sensor Tank in position with the Sensor Tank Lock by turning it 90 degrees.
CAUTION
Make sure Sensor Tank is inserted correctly. The edge of the Sensor Tank
should be fully pushed towards and in level with the edge of the Drain
Unit.
Page 16 of 49

Install Funnel
NOTICE
Place the Funnel with the hole oriented to the left! Placing the hole oriented to
the right will disable recirculation.
Page 17 of 49

Install Orbital Shower Core
1. Remove Transport Plugs before installation.
2. Insert Orbital Shower Core into the Wallbox and attach Safety Wire. Keep tilted to
enable electrical installation.
CAUTION
•Heavy equipment. The Orbital Shower Core weighs approx. 25 kg.
•Make sure to attach the Safety Wire before tilting the Orbital Shower
Core.
•Make sure Hoses and Cables are not pinched or kinked.
Page 18 of 49

3. WARNING
Electrical installation should be performed according to industry rules by a
competent electrician.
4.
Page 19 of 49

5.
x1
M8 socket head
6. CAUTION
Make sure to have correct alignment between key and slot in connectors.
Make sure locking ring snaps and connector is locked.
Page 20 of 49
