Oregon Scientific OUTBREAKER RX107 Series User manual

1
E
Oregon Scientific™ OUTBREAKER
Sports Watch (RX107 series)
User Manual
TABLE OF CONTENTS
Introduction ......................................................................2
Key features .....................................................................3
OUTBREAKER watch ...................................................3
Chest belt (RS107 / RP107 only) ..................................3
Bicycle equipment (RP107 only) ...................................3
PC Kit (RP107 only) .....................................................4
LCD display symbols .....................................................4
How the OUTBREAKER works .......................................6
How the altimeter, thermometer and barometer work ...6
A multi-system facility ....................................................6
TOUR Mode ..................................................................6
PC Software Kit (RP107 only) .......................................6
Getting started .................................................................7
Turn on the watch (first-time use only) ..........................7
Batteries ........................................................................7
Switch between Modes..................................................8
Switch between Mode options .......................................8
Change setting values ...................................................8
Use the HI-GLO backlight..............................................8
Key lock .........................................................................8
Handling the product .....................................................8
CLOCK Mode ....................................................................9
Set clock and measurement units .................................9
Set the alarm .................................................................9
Stopwatch .........................................................................9
Timer .................................................................................10
Temperature display ........................................................10
ALTI-BARO Mode .............................................................10
Access altimeter options................................................11
Set current altitude and resolution .................................11
Set sea-level pressure ...................................................12
View sea-level pressure ................................................12
Set altitude alert.............................................................12
Recall altitude data ........................................................13
Switch between view options.........................................13
Weather forecast ...........................................................13
TOUR Mode ......................................................................14
TOUR memory ..............................................................14
Activate TOUR Mode.....................................................15
Record markers in TOUR Mode ....................................15
Pause TOUR Mode .......................................................15
Deactivate TOUR Mode ................................................15
Clear all TOUR memories .............................................16
CARDIO (Heart Rate) Mode (RS107, RP107 only) .........16
Wearing the chest belt ...................................................17
Training Zones...............................................................17
Set upper and lower heart rate limits for
Training Zone 5 .............................................................18
Activate the Training Zone alarm...................................19
Track heart rate during training .....................................19

E
2
BIKE Mode (RP107 only) .................................................20
Set up for BIKE Mode ....................................................20
Step 1: Attach the equipment to the bicycle ..................20
Step2: Enter wheel circumference................................21
Access the BIKE Mode options .....................................22
View speed and cadence information............................22
PC Kit (RP107 only) .........................................................22
PC Mode............................................................................23
Set up for PC Mode .......................................................23
Use the software............................................................23
PC Mode options ...........................................................23
Download data...............................................................24
Effective use and range...................................................24
Aquatic and outdoor activities........................................24
Safety and care ................................................................25
Safety precautions .........................................................25
Care instructions............................................................25
Troubleshooting guide ....................................................26
Specifications...................................................................27
Warnings...........................................................................29
Additional Resources ......................................................29
Note on compliance .........................................................30
INTRODUCTION
Thank you for selecting the Oregon Scientific OUTBREAKER
Sports Watch as your fitness product of choice. Your new
sports watch is designed to give you many years of reliable
service and includes the following features:
• Clock, calendar, stopwatch and timer functions
• Barometer with local and sea pressure readings
• Weather forecast and temperature readings
• Altimeter readings up to 30,000 feet (9,000 meters)
• Heart rate monitor that gives pulse rate readings during
exercise (RS107/RP107 only)
• Bicycleaccessorykittotakereadingsduringcycling(RP107
only)
• PCdocking stationand softwareto downloadreadings onto
your computer (RP107 only)
TheOUTBREAKERRX107 sportswatchseries comprisesthe
most advanced and patented Baro-compensation technology,
distinguishing between barometric and altitude pressure
changes, and giving you more reliable readings (weather
forecasts, etc.). It is a precision device designed to augment
your daily or weekly exercise program as well as provide you
with accurate and easy to use watch functions.
This manual contains important safety and care information,
and provides step-by-step instructions for using this product.
Readthemanualthoroughly,andkeepitinasafeplaceincase
you need to later refer to it.

3
E
OUTBREAKER WATCH
I
I ITEM NAME DESCRIPTION
1 SELECT/+/> Press to increase value, change Mode display, or
record a marker during TOUR Mode.
2 MODE Press to switch between Modes.
3 ST/SP/- Press to start/pause/stop the Stopwatch/Timer or
decrease value.
4 LIGHT/KEY Press to activate HIGLO- backlight, or press and hold
to activate key lock.
5 FUNC/SET Press to enter a sub-mode or press and hold to change
a value..
CHEST BELT
I ITEM NAME
1 CHEST BELT
2 STRAP
BICYCLE EQUIPMENT (RP107 ONLY)
I
ITEM NAME
1 SPEED SENSOR
2 CADENCE SENSOR
3 BIKE MOUNT
4 MAGNETS/ SCREWS/ NUTS/PADS
5 FIXING STRAPS
6 RUBBER GRIPS (RS107 only)
2
214
5 6
3
KEY FEATURES

E
4
LCD DISPLAY SYMBOLS
SYMBOL DESCRIPTION
The current time.
YR Year setting.
MTH Month setting.
DAY Day setting.
MON Current day of the week.
(MON..SUN)
TRIP TOUR Mode is running time/date cannot be set
HR Hour setting.
MIN Minute setting.
DM/MD Order for date to be displayed.
TIME Time zone setting screen.
SET Displayed when in a setting mode.
UNIT Set Celsius/Fahrenheit for temperature and h/p/Hg,
inHg barometric pressure. Set m/ft for altitude.
PC KIT (RP107 ONLY)
ITEM NAME
1 DOCKING STATION
2 WATCH CONNECTION POINTS
3 MOUNTING CLIPS
4 BUILT-IN RS-232C COMPUTER CONNECTION CABLE
5 SOFTWARE CD-ROM

5
E
Zone The current time set in your second time zone.
AL Shows alarm time, or event alarms
(max/min altitude/heart rate etc)
Shows max/min altitude alarm is deactivated.
Shows if alarm is on or off.
Weather forecast for the next 12-24 hours.
(Sunny/Slightly Cloudy/Cloudy/Rainy)
STW Stopwatch can be started/stopped/reset.
TMR Timer (countdown) can be started/stopped/reset
TEMP Temperature is displayed (in lower second row).
ALTI Altitude is displayed (in lower second row).
HR Heart rate is displayed in lower matrix font.
MEM Memory record (current trip only).
max Shows maximum record
min Shows minimum record
AVG Shows average record
TTL Show total record
RES Change resolution of readings on altimeter
ICON Choose current weather icon.
LOC Local barometric pressure.
SEA Sea pressure (barometric).
SPD Shows vertical speed (historical or current).
Graphical display of your bicycle speed.
Rxxx Receiver (Bike Mount) low battery.
Sxxx Speed sensor low battery.
Cxxx Cadence sensor low battery.
ttl Shows total time of activity.
Shows altitude graphically.
Heart rate (per minute) monitor activated.
Heart rate alert in effect.
Key lock activated.
Z1 (1-5) Shows which training shown is currently selected.
Shows heart beat graphically.
M1 (1..99) Shows which record you are making, or storing
(see TOUR Mode).
WØ (wheel icon) Wheel circumference setting mode.
CAD Pedal speed (revolutions/min).
T1 (1…99) Shows sequence of memories in TOUR Mode.
88% % of memory used in TOUR Mode.
END TOUR is finished.
CLR Ready to clear all tour memories.
donE All tour memories have been cleared.
hpa Pressure shown in Hecto-Pascal’s.
inHg Pressure shown in inches of mercury.
Low battery level (replace batteries)

E
6
HOW THE OUTBREAKER WORKS
The OUTBREAKER sports watch comes equipped with a
barometer (measuring altitude, barometric pressure, and
weatherconditions),aweatherforecastdisplay,athermometer,
aheartratemonitor(RS107/RP107only),andabicyclecomputer
to display information when cycling (RP107 only).
HOW THE ALTIMETER, THERMOMETER, AND
BAROMETER WORK
Thepatentedbaro-compensationtechnologyusedinthiswatch
allows it to distinguish between barometric pressure change
and altitude pressure change. This means it can detect
barometric pressure (localized weather conditions) as distinct
from changes in altitude pressure, and gives more accurate
readings than most average devices (which frequently rely on
manual deactivation before initiating a new forecast).
A MULTI-SYSTEM FACILITY
The product is designed for use during many kinds of activity.
Itcandisplay and storearange of informationofinterest to the
casual and more serious sports or exercise enthusiast. The
watch includes the following Modes: CLOCK, ALTIMETER,
CARDIO (Heart Rate) (RS107/RP107 only), BIKE (RP107
only),andPC(dockingstationandCDROMareoptionalforthe
RA107 and RS107, and are not supplied). It is equipped with
a multi-system facility that allows you to combine information
accordingtoyourpreference,suchasaltitudeandtime,altitude
and heart rate, or bike speed and altitude, etc. You may also
use the stopwatch or timer (countdown) facility in combination
with other functions, and both will continue to run in the
background while you use other features of the watch.
The heart-rate monitor and altimeter features of the
OUTBREAKER watch include customized settings. Maximum
and minimum heart rate limits can be set for use during
exercise,andthealtimetercanbesettoregisterascendingand
descending limits. In both cases a short beep signifies either
limithasbeenexceeded.Thewatchalsohasaclock,calendar,
and pressure reading apparatus, all of which need to be set
according to the current date and location.
TOUR MODE
The watch features a TOUR Mode in which you can record all
data from a single trip, or workout, and then download this
information onto your PC for storage and viewing. The watch
can recall 99 different single tours, trips or workouts.
ThedockingstationandCD-ROMarerequired(optional
for the RA107 and RS107, but not supplied) to download
information from TOUR Mode.
PC SOFTWARE KIT (RP107 ONLY)
A docking station is provided with the watch for connecting to
a computer, along with a CD-ROM for installing the necessary
softwareontoyourcomputer. Youcanalsouse thesoftwareto
change some of the watch settings.
TheRZ910 PC Kitcan be purchasedseparately forthe
RA107 and RS107.
NOTE
NOTE

7
E
To load new batteries in the chest belt (RS107 and RP107
only) and bike mount:
The chest belt will stop sending signals if its battery is
low. Badtransmissionfromthechestbeltmayalsobetheresult
of poor contact with the skin, surrounding interference, or
placing the receiver watch too far away.
To load new batteries in the bicycle sensors (RP107 0nly):
The sensors will stop sending signals to the watch if
their batteries are low.
Replace the batteries whenever the HIGLO backlight
dims or stops working, or when you see the low battery icon.
NOTE
GETTING STARTED
TURN ON THE WATCH (FIRST-TIME USE ONLY)
Press mode key for 2 seconds or more to activate the LCD
Display
BATTERIES
All batteries are included and already installed. Refer to the
Specifications page for battery types (➔27).
To avoid the possibility of permanently damaging the
watch, we strongly recommend that you take your watch to a
local retailer or jeweler to have the watch battery replaced.
To load new batteries in the watch:
Diagram Instructions
1. Remove the watchband and screw pin.
2. RemovethebackcoverwithasmallPhillipsscrew-
driver.
3. Install the battery by matching the correct polarity.
Always use the correct battery type.
Warning: Reversingthe polaritymaydamage the
product.
4. Replacethecover,screws,screwpin,andwatchband.
(Be sure to replace the O ring properly).
5. Checkthereplacementbatteriesarefittedproperly
by confirming there is a key tone (beep).
C
R
2
0
3
2
Diagram Instructions
1. Insert a coin into the grove. Turn counter-clock-
wise.
2. Insert the battery. Match the correct polarity.
3. Replace the battery compartment. Tighten into
place.
Diagram Instructions
1. Insert a coin into the grove. Turn counter-clock-
wise.
2. Remove the battery and insert a new one.
3. Replace the compartment. Tighten into place.
NOTE
NOTE
NOTE

E
8
The watch will show Cxxx, Rxxx or Sxxx whenever either the
bike mount, cadence or speed sensor batteries are low.
Replace all the batteries at the same time – it is
dangerous to mix old and new batteries.
Used batteries can be harmful to the environment, and
shouldnot bethrownoutwithhousehold rubbish.Contact your
localwastedisposalauthorityforinstructionsonhowtodispose
ofusedbatteries.Protecttheenvironmentbytaking exhausted
batteries to authorized disposal stations.
SWITCH BETWEEN MODES
PresstheMODEbuttontoswitchbetweentheModes:CLOCK,
ALTI-BARO, CARDIO (RS107/RP107 only), BIKE (RP107
only), and PC. A bar shows next to the appropriate Mode (on
the outer ring of the LCD display) when it is selected.
SWITCH BETWEEN MODE OPTIONS
PressSELECT/+toswitch betweentheoptionswithinaMode.
CHANGE SETTING VALUES
PressandholdFUNC/SETfor2secondstoentersettingmode.
Then,press ST/SP/-or SELECT/+ tochange thevalue. Press
FUNC/SET to switch between options, and to confirm the
changes when you are done.
USE THE HI-GLO BACKLIGHT
Press light/key to turn on the HI-GLO backlight on for five
seconds. Once the light is on, press any key to keep it on for a
further five seconds.
In order to save power the light will not work when the battery
islow. If thishappens, change thebattery assoon as possible.
KEY LOCK
Thewatch alsohas akey lockfunction tostop thebuttonsfrom
being accidentally pressed during an activity. To activate it
simply press and hold light/key until a small key icon appears
intherighthandcornerofthescreen.Thefunctionkeysarenow
useless. To reactivate them, press and hold light/key again
until the key icon disappears.
ThealarmwillstillgooffwhiletheKeyLockisactivated.
Pressing any key while in Key lock will stop the alarm.
HANDLING THE PRODUCT
The watch is designed to withstand a wide range of sports
activities, and comes complete with a strong wristband. When
riding(RP107only),makesurethewatchisfirmlyconnectedto
thebikemount,andconnectallbicycleequipmentcarefullyand
securely. See the BIKE Mode section (➔20) for instructions.
NOTE
NOTE
NOTE

9
E
CLOCK MODE
The time, date (including the day of the week) and time alarm
can be set while the watch is in CLOCK Mode. Follow the
instructions below to set or activate the time, date, zone time,
metric or imperial standards, alarm time, stopwatch and timer.
SET CLOCK AND MEASUREMENT UNITS:
You cannot change these settings while in TOUR
Mode. If you attempt to do so, TRIP will show on the display.
Refer to the TOUR Mode section (➔14).
Diagram Instructions
1.Press MODE to display the CLOCK mode.
2.PressandholdFUNC/SET for2seconds.“24h”will flash
on the display.
3.Press ST/SP/- to change from 24 hour to 12 hour time
display.
4.Press FUNC/SET again. The hour will flash. Press SE-
LECT/+ to move the value up, or ST/SP/- to move the
value down.
Tip: Continuouslypressandholdabuttontofast-change
the value.
5.Repeat Steps 3 – 4 to change the rest of the settings, in
this order: minutes, year, month/date or date/month
display, month, day, time zone (+/- 23 hours), tempera-
ture display (°C / °F), measurement units (feet / meters),
and barometric pressure units (inHg or hPa).
NOTE
SET THE ALARM
STOPWATCH
TheStopwatchworksinCLOCK,ALTI-BARO,
CARDIO, and BIKE modes. From any of
thesemodes,pressSELECT/+todisplay the
stopwatch. Then,
• PressST/SP/-tostart,pause,andstopthe
stopwatch.
• With the stopwatch stopped, press and
hold FUNC/SET to reset.
You can switch to other modes while running the
stopwatch in the background.
NOTE
Diagram Instructions
1. Press MODE to display the CLOCK mode.
2. PressSELECT/+ 3 times to move it into the alarm
setting screen.
3. Press ST/SP/- to activate or deactivate the alarm.
A small bell icon will appear on the left side of the
alarm time when it is activated.
4. PressandholdFUNC/SETfor2seconds,tosetthe
alarmhourandminutes.UsetheSELECT/+orST/
SP/- buttons to change the value. (The alarm will
be automatically activated once the alarm time is
set).

E
10
TIMER
The Timer works in CLOCK, ALTI-BARO,
CARDIO, and BIKE modes. From any of
these Modes, press SELECT/+ to display
the stopwatch. Press FUNC/SET to reset
the Stopwatch, then:
• PressandholdFUNC/SETfor2seconds.
The display will change to TMR.
• Press ST/SP/- or SELECT/+ to change a value.
• Press FUNC/SET to switch between values and accept
changes.
• Press ST/SP/- to start or stop the timer.
• With the timer stopped, press and hold FUNC/SET to reset.
You can switch to other Modes while running the timer
in the background.
To return to STW Mode, you must reset all the timer
values to 0. The timer automatically switches to STW Mode
when it reaches 0.
NOTE
NOTE
NOTE
TEMPERATURE DISPLAY
TheTemperaturecanbedisplayed inCLOCK,
ALTI-BARO,CARDIO,andBIKEModes.From
anyoftheseModes,pressSELECT/+todisplay
the Temperature. The Temperature shows in
eitherCelsiusorFahrenheit,depending onthe
measurement unit you select when setting the
CLOCK (see CLOCK Mode).
Your wrist temperature may affect the reading,
particularly during exercise. Take off the watch and leave it for
15 minutes to get the most accurate reading.
ALTI-BARO MODE
The OUTBREAKER sports watch includes a
barometerthatdistinguishesbetweenpressure
caused by altitude changes and pressure
causedbyweatherconditions.Thistechnology
reducesdiscrepanciesin readingsandmakes
thealtimetermoreaccuratethanmostaverage
devices.
The watch can store and recall the following values:
• Current altitude (updated every 2 seconds)
• Maximum / minimum altitudes attained during your a trip
• Total accumulated maximum / minimum altitudes attained
during your trip

11
E
SET CURRENT ALTITUDE AND RESOLUTION
When you first use the watch, it is important to set the current
altitude and local sea-level pressure so your ascending and
descending altitude can be accurately measured. You can
find the current altitude by comparing your position to a
topographical map, and then entering the value in the watch.
It is necessary to reset the altitude after being in a
pressurized chamber (such as an airplane).
For instructions on setting the sea-level pressure, refer to the
next section.
Tip: You can also set the current altitude and alarm limits with
the help of the PC software (see PC section). (RP107 only)
Thesealevelpressurereadingwillchangeifthealtitude
is adjusted.
• Maximum / minimum altitude alert (sounds an alarm when
exceeded)
• Maximum / ascending, maximum descending speeds
• Current vertical speed
• Rate of altitude change
Thealtitudeisshownittwoways, asanumericvalueindicating
your current altitude, and as a bar chart indicating changes in
altitude. Both values will change as you move about.
In ALTI-BARO Mode, the current altitude is always
displayedinlargerfont,ineveryscreenexcepttheseapressure-
setting screen.
ACCESSING THE ALTIMETER OPTIONS
Press MODE to access the ALTI-BARO mode, then press
SELECT/+ to loop through the options.
NOTE
NOTE
NOTE
Diagram Instructions
1. Press and hold FUNC/SET for 2 seconds while in
ALT mode.
2. Use SELECT/+ or ST/SP/- to change the value.
The value will change in unit increments based on
theresolutionyouset(nextstep)andthemeasure-
mentunityouselectedwhensettingtheCLOCK(➔
9).
3. Press FUNC/SET to switch to the Resolution set-
ting screen, then press ST/SP/- to change the
value. Theresolutionis theincrementatwhichthe
altitude will display: 3 / 10 ft, or 1 / 3 meters.
4. Press FUNC/SET to exit the setting mode.

E
12
SET THE SEA-LEVEL PRESSURE
Sea level pressure can change relative to location. To achieve
accurate altitude readings, set the sea-level pressure value
before every trip. Check the newspaper, local news station,
trailmarker, or weatherforecastfor local readings,and always
select the reading nearest to your present location.
The altitude reading will change according to the sea
level pressure adjustment.
VIEW THE SEA-LEVEL PRESSURE
To view a graphical image of the current sea
level pressure reading, press FUNC/SET with
the SEA screen shown in ALTI-BARO Mode.
Press again to return to normal display.
SET ALTITUDE ALERT
Thewatchcanbe settorememberanaltitudelimit(eitherupor
down,butnot both simultaneously). Ifthe alarm is activated,a
seriesofbeeps(at5secondintervals)willsound,andthemode
barwill blink,when youbreach thelimit. Toend thealert, press
any button.
To set the alert limits and activate or deactivate the alert:
NOTE
Diagram Instructions
1. WhileinALTI-BARO Mode, pressSELECT/+ until
the SEA (sea pressure) screen is shown.
2. Press and hold FUNC/SET for two seconds, then
use SELECT/+ or ST/SP/- to change the value.
The value will change in increments of 1 hPa or
.03inHg,depending on themeasurement unit you
selected in CLOCK Mode (see CLOCK mode).
3. Press FUNC/SET again when finished.
Diagram Instructions
1. PressSELECT/+untilyoureachtheAlarmscreen.
(Display reads 'AL' or 'NoAL' at the bottom)
2. Press and hold FUNC/SET for two seconds.
3. You may set the arrow at the bottom of the screen to
a
ascending , or descending limit (but not both). To
change direction, press SELECT/+ or ST/SP/-.
4. PressFUNC/SET again, then press SELECT/+ or
ST/SP/-tochangethealtitudelimit.(The alarmwill
be automatically activated once the limits are set).
5. Alternatively press ST/SP/- if you simply want to
accept a preset altitude alert setting. (Activated
[AL] or deactivated [NoAL]).

13
E
RECALLING ALTITUDE DATA
TheOUTBREAKERallowsyoutotrackthefollowinginformation
as you exercise.
• Max / min altitude attained -- shows the highest or lowest
point you have reached so far in relation to your watch’s
permanent altitude setting.
• Max/minaltitudeaccumulated–representsthetotaldistance
you have ascended or descended; that is, every incline is
addedtogetheror‘accumulated’,andlikewiseeverydecline
is added and ‘accumulated’, to give a total.
• Vertical speed -- how fast you are currently climbing
• Max ascending speed – fastest speed you have climbed
• Maxdescendingspeed–fastestspeedyouhavedescended
The following illustration shows these points:
These display screens are
shown in a loop, and the
information in each screen is
displayed for 30 seconds
(excludingtheALT/SPDvertical
speed screen, which is not on a
timeout)atwhichpointthewatch
returns to ALT Mode.
Clearing the memory
allowsyouto startoveragainon
a new trip, though all the
informationfromyourcurrenttrip
will be lost.
SWITCH BETWEEN VIEW OPTIONS
While in ALT/TIME Mode, press
FUNC/SET to switch between the
view options: max / min altitude, total
ascending / descending altitude, and
speed. Inthespeeddisplay,youcan
view current speed (ascending or
descending), maximum ascending
speed, and maximum descending
speed.
PressSELECT/+orST/SP/-toloopthroughthevaluesforeach
option.
To clear a value from the memory, press and hold FUNC/SET
for 2 seconds.
WEATHER FORECAST
Thebuilt-inbarometerhelpstoforecasttheweatherforthenext
12-24 hours. This reading is based on barometric pressure
changes and has an effective range of 30 to 50 kilometers
(18 – 31 miles). The patented baro-compensation technology
in the OUTBREAKER watch allows it to differentiate between
pressure changes due to altitude, and those due to weather
changes. To avoid inaccurate forecasts, the watch will favor
altitude readings when you are
actually ascending or
descending. This means the weather icon will disappear after
significantverticalmovements.Todisplayanaccurateforecast,
simply remain at any fixed altitude for roughly 5 minutes.
You may wish to set the icon manually for these reasons:
• The speed in the change of icon forecast depends on the
FUNC./SET
FUNC./SET
FUNC./SET
ST/SP/-
SEC/+
ST/SP/-
SEC/+
ST/SP/-
SEC/+
ST/SP/-
SEC/+
NOTE

E
14
speed of barometric change and in some cases may take
longer (up to 24hrs) than desired.
• Settingtheiconcanspeeduptheadjustmentfortheweather
forecast.
• It is necessary to set the icon after exposure to artificial
environments, such as an airplane cabin, which may cause
incorrect readings.
The forecast will be displayed at the top of the watch as one of
these four icons:
The current barometric pressure reading (in hPa or inHg,
depending on the measurement unit you set in CLOCK Mode)
shows at the bottom of the display.
To set the weather icon manually, follow these instructions:
When functioning normally the watch automatically
updates the forecast every 15 minutes.
Diagram Instructions
1. While in the ALTI-BARO Mode, press SELECT/+
until LOC shows at the bottom of the display.
2. Press and hold FUNC/SET for two seconds.
3. Press SELECT/+ or ST/SP/- to change the icon.
4. Press FUNC/SET to save your changes.
NOTE
TOUR MODE
TherearetwowaysofusingthememoryontheOUTBREAKER.
First, the watch computer will record information as you train,
for display only. This means you can check the information
during or after your exercise, but there will be no record once
you clear the memory in preparation for your next training
event.
Torecord andstore thisinformation (forupto 99different trips,
depending on the size of each record – see below) you must
activate the TOUR Mode and view the records through the PC
software.
The information from a TOUR can only be viewed
through the PC software.
TOUR MEMORY
Tourmodeallowsyoutorecordandstoredatadisplayedonthe
watch, which can then be downloaded onto your PC. Up to 99
TOURs can be recorded and stored to the PC software.
Depending on the model you purchase, the information you
choosetorecord(seebelow),andthetimeusedbyTOURsyou
havealreadystoredon thewatch,theavailablememory length
may vary. The average memory storage capacities in real-
time,(takingadatasampleevery5seconds),assumingdefault
settings (see Specifications: Tour Mode) and no TOURs have
been saved for each model are as follows:
NOTE
Model Total recording time available
RA107 598 min (10 hours)
RS107 508 min (8.5 hours)
RP107 659 min (11 hours)

15
E
The watch can record and store up to 99 different trips,
providing there is enough remaining memory.
Default sampling time for readings in TOUR Mode is every 5
seconds. To increase the gap between samplings, and thus
increase the memory capacity, you can adjust this setting
through the PC software.
ACTIVATE TOUR MODE:
For best results, perform these
stepsimmediatelybeforeyoubegin
your trip.
1. Simultaneously press FUNC/
SET and MODE. The TOUR
END screen will display.
2. Press and hold FUNC/SET for
two seconds. The TOUR number (T1, T2, etc.) will show at
thebottomofthedisplay. Youarenowrecordinginformation.
The percentage (%) at the top indicates the total used
memory.
3.TostoptheTOUR,pressandholdFUNC/SETfor2seconds.
ENDwillshowatthebottomofthedisplay.TheTourdatawill
be stopped.
4. To begin another TOUR, press and hold FUNC/SET for 2
seconds. The new TOUR number (T3, etc.) will show at the
bottom of the display. You are recording information again.
5. Press MODE to return to the CLOCK display.
Used watch memory is given as a percentage. It is
recommended that you download information to your PC and
clear all TOUR memories when this figure approaches 100%.
When the used memory hits 100% it will no longer record, and
any future readings will not be recorded.
RECORD MARKERS IN TOUR MODE
Themarkerfunctionisusedtomarkaparticularpositionduring
a TOUR. To place a marker, press and hold SELECT/+ when
the TOUR Mode is in use.
The marker will only be shown in the PC data, once it
has been downloaded from the watch.
PAUSE TOUR MODE:
1. If you are not already in TOUR
Mode, simultaneously press
FUNC/SET and MODE. The
TOUR number will display. The
percentage (%) at the top indi-
cates the total used memory.
2. PressFUNC/SET. REST shows
at the bottom of the display.
3.Press ST/SP/- to turnthe rest on(paused) or off(recording).
DEACTIVATE TOUR MODE:
For best results, perform
these steps immediately
after you end your trip.
1. Simultaneously press
FUNC/SET and MODE.
The TOUR number will
display. The percentage
(%) at the top indicates the total used memory.
NOTE
NOTE
2 sec

E
16
2. PressandholdFUNC/SET for twoseconds. ThisENDSthe
TOUR recording session.
3. Press MODE to return to the CLOCK display.
CLEAR ALL TOUR MEMORIES
Forbestresults,performthesestepsafteryoudownloadTOUR
information to the PC software.
Either:
1. Download the information to you PC (the TOUR will be
automatically cleared.
Or:
1. Deactivate the TOUR
Mode. With the END
screenshown,pressthe
FUNC/SETbutton. CLR
shows at the bottom of
the display.
2. Press and hold FUNC/
SET until donE shows at the bottom of the display.
3. Press FUNC/SET again to display 0% and confirm all data
has been cleared.
4. Press MODE to return to the CLOCK display.
Themaximumandminimumvaluesforthevarioussub-
modes (i.e., max heart rate, or max altitude, etc) will remain
after all data has been cleared.
NOTE
CARDIO (HEART RATE) MODE
(RS107/RP107 ONLY)
The OUTBREAKER watch is
equipped with a CARDIO Mode
and heart rate chest belt, which
together allow you to measure
yourheartrate(from25-240beats
perminute)whileexercising.You
can track your heart rate while in
the ALTI-BARO, CARDIO, or
BIKE Modes, and with the following features: Stopwatch,
Timer, Temperature, and Altimeter display.
There are five screens in the CARDIO Mode including the
HEART RATE/CLOCK/HR chart (starting) screen. They are:
• HEART RATE/CLOCK/HR
chart (starting) screen,
• HEARTRATE/HRalarmon/off/
screen,
• HEART RATE/STW (stop-
watch) screen,
• HEART RATE/TEMP (tem-
perature) screen,
• HEART RATE/ALTI (altimeter)
screen.
To move between them, simply
press SELECT/+.

17
E
WEARING THE CHEST BELT
You must wear the chest belt to measure your heart rate.
This OUTBREAKER watch is specially designed to
work with the chest belt with which it was sold. It is not
recommended you use any other chest belt with this watch, as
the transmission may not work.
Tips: The transmission from the belt is dependent on good
contactwith theskin andproximity tothe receiverwatch. Make
sure the transmitting section of the belt is against the skin, not
blocked by chest hair, and close enough to the receiver watch
(approximately 30 inches) to send a clear signal. Sweat or gel
can help to improve the signal, and remember it is not
instantaneous. If no signal is received immediately, wait for a
few seconds for the signal to get through.
An old battery may weaken the transmission and
reception power. Replace the battery if the performance is
progressively worse.
Once you have good contact with the chest belt, will begin
toflash.Thismeansthesignalisbeingsentand yourheartrate
will soon appear in place of the large 0. Your heart rate will be
displayed as the larger font in every screen of this Mode, and
can also be displayed in a smaller font, below the line, while in
BIKEMode.Ifyouremovethechestbelt,orthewatchismoved
too far away from it, the signal will be broken.
The CARDIO Mode will stop functioning after no signal
is received for 5 or more minutes.
When you are measuring your heart rate, keep the
watchawayfromsignalgeneratingsources,suchasTVs,PCs,
and car engines, as these may impair the reading.
TRAINING ZONES
The OUTBREAKER watch is
equippedwithaspecialTrainingZone
feature that allows you to pre-select
the optimal heart rate range (50-240
beats per minute) for your activity.
For example, the amount of exertion
required for a stroll in the park is
different from the amount of exertion required for weight lifting
tobuild muscle mass. Withthe Training Zonefeature, youcan
set and then monitor the upper and lower heart rate limits
(Training Zone) that best support your training activity and
goals.
Diagram Instructions
1. Wet the conductive pads on the underside
ofthe chestbeltwith fewdrops ofwater ora
conductivegel toensure abetter,solid con-
tact.
2. Putonthebelt,wrappingitaroundtheupper
chest so the heart rate monitor is in the
middleofthechest,tuckedsnuglyunderthe
pectoral muscles.
3. Adjust the belt for comfort and best contact
with the skin.
NOTE
NOTE
NOTE
NOTE

E
18
Thecalculationfordeterminingyourupperandlowerheartrate
limits is as follows.
Once you know your maximum heart range, you can set the 5
Training Zones (described below) with the PC software (refer
to the online help). With the OUTBREAKER watch, you can
directlysetyourupperandlowerlimitsforTrainingZone5,and
can set an alarm to sound whenever you exceed the limits for
the selected Training Zone.
Warning: The heart rate limits for Training Zones 1 – 4 are
basedon theprofile fora 20-year-oldyoung man. Ifyou donot
meetthisprofile,weHIGHLYRECOMMENDthatyoueitherset
the limits for Training Zones 1 – 4 using the PC software, or
follow the steps below to set the limits for Training Zone 5.
The recommended Training Zones are as follows:
High-altitudeactivitiesmayelevateyourmaximumheart
rate. You can override the zone preference by adjusting the
value through the PC (all zones), or by manually adjusting
Zone 5.
SET UPPER AND LOWER HEART RATE LIMITS
FOR TRAINING ZONE 5
1.PressMODEtoaccesstheCARDIO
(heart rate) Mode.
2.PressSELECT/+toswitchtotheAL
(Alarm) setting.
3. Press and hold FUNC/SET for two
seconds.Thezonenumberwillflash
at the bottom of the screen. The upper limit is shown above
the line in larger font, and the lower limit is below. (You may
adjust the value for upper and lower rate limits in Zones 1-
4byusingthePCsoftware.Otherwisepressing ST/SP/-will
simply activate or deactivate the preset alarm).
4. Press SELECT/+ or ST/SP/- to switch to Zone 5.
5. Press FUNC/SET again to display the SET screen
NOTE
Sex Maximum Heart Lower limit Upper limit
Range (MHR)
Men 220 – age = MHR
Women 230 – age = MHR
Zone MHR range Description
(min – max %)
1 50 – 60% ModerateActivity–Thislow-intensityzoneisgoodforwarm-
ups,cooldowns,andactivitiessuchasbriskwalking.Itisalso
good for beginners and those who want to strengthen their
cardiovascular systems.
2 60 – 70% Weight Management – Up to 85% of calories burned in this
zone are from fat cells. Moderate exercises such as light
jogging or swimming are good for this zone.
3 70 – 80% Aerobic Zone – Increases strength and endurance. It works
withinthebody’soxygenintakecapability,burnsmorecalories,
and can be maintained for a long period of time.
4 80 – 90% Anaerobic Zone – Generates speed and power. It works at
or above the body’s oxygen intake capability, builds muscle,
and cannot be maintained for a long period of time.
5 90 – 100% Red Line Zone – This high-intensity zone can only be
maintained in short bursts or intervals, as it pushes your
muscles and cardiovascular system beyond their capacity.
NOTE
MHR x (lower training zone %) MHR x (upper training zone %)

19
E
6. Press SELECT/+ or ST/SP/- to change the upper heart rate
limit.
7. Repeat Steps 5 – 6 to set the lower heart rate limit.
8. Press FUNC/SET when finished.
Heart rate range is between (upper 26-240 bpm) and
(lower 25-239 bpm).
ACTIVATE THE TRAINING ZONE ALARM
Once activated, the Training Zone Alarm will sound whenever
youexceedthe upper orlower heart rate limitsfor the selected
Training Zone.
1. From the CARDIO Mode, press SELECT/+ to switch to the
AL (Alarm) screen.
2. Press and hold FUNC/SET for two seconds.
3. Press SELECT/+ or ST/SP/- to select the desired Training
Zone.
4. Press FUNC/SET.
5. Press ST/SP/- to turn the alarm off or on.
TRACK HEART RATE DURING TRAINING
TosetuptheOUTBREAKERwatchso
thatit can trackyourheart rate activity
during training, first do the following:
1. Put on the chest belt (refer to the
“Wearing the Chest belt” section).
2.PressMODEtoaccesstheCARDIO
Mode and check to make sure the watch is receiving your
heart rate signals.
3. Select the Training Zone that is most appropriate for your
activity (refer to previous section).
4. Activate the Stopwatch or Timer in CARDIO Mode (refer to
the Stopwatch / Timer section).
5. Set up the TOUR Mode if you want to store a long-term
record of your heart rate history that spans several training
sessions or activities (refer to the TOUR Mode section).
Once you complete these steps, you are ready to begin
exercising. After you finish, reset the Stopwatch or Timer to
zero, then press FUNC/SET to have the following metrics
displayed in 5-second intervals:
• Time and date in M1 or M2….M99 (all current data will be
storedunderM1,whilepreviousdataisstoredunderM2and
so on until M99).
• Average heart rate during exercise and Total exercise time
• Upper Training Zone limit and time spent above limit
• Lower Training Zone limit and time spent below limit
• Total time spent exercising within the heart rate limits
If you have more than one set (M1-M99) of training
records, press SELECT/+ or ST/SP/- to loop through the
records.
NOTE
NOTE

E
20
STEP 1: ATTACH THE EQUIPMENT TO THE BICYCLE
BIKE MODE (RP107 ONLY)
The OUTBREAKER sports watch comes complete with a
bicyclecomputer(andaccessories),whichrecordsanddisplays
the following information:
• Speed: 0– 255km/houror 0– 158mile/hour,depending on
the measurement unit you select (refer to the Clock Mode
section)
• Average speed (Max:255km/hr or 158 mile/hr)
• Maximum speed (Max:255km/hr or 158 mile/hr)
• Cadence: 0 – 255 rpm (pedal revolutions per minute)
• Distance traveled (Max:999.9 km or 620 miles)
• Totaldistancetravelled(Max:99,999.9kmor620,000miles)
• Total time spent cycling
The BIKE Mode comprises pioneering technology that uses
two wireless sensors instead of one. The high frequency of
each sensor (915.2 MHz) eliminates possible interference
betweenthecadenceandsignalsensors,ensuringyouaccurate
performance measurements.
SET UP FOR BIKE MODE
To set up the BIKE Mode you must first do two things:
1. Attach the measuring equipment to your bicycle:speed
sensor (front wheel), cadence sensor (pedal), two magnets
(frontwheel andpedal),and bikemount (handlebar). Refer
to the next section for instructions.
2.Specifyyourwheelcircumference. Seebelowforinstructions.
Max 5 mm
Max 100 cm
