N-EVAP ™
Nitrogen Evaporation System
Models 11634 & 11645
DIGITAL & TIME CONTROL SYSTEM
INSTRUCTION MANUAL
ORGANOMATION ASSOCIATES INC.
266 RIVER ROAD WEST
BERLIN, MA 01503
U. S. A.
Tel: [phone] Fax: [phone]

1
3
4
9
a
5
5
7
11
10
12
20
16
22
24
29
4
27
28
29
25
30
TABLE OF CONTENTS
N-EVAPTM
Forward - Letter from the President
Introduction
Instrument Items Shipped
Instrument Description
Instrument Part Identification
Safety Considerations - Read before operation
Installation
Location
Bath Setup
Instrument Setup
Operation
Instrument Control Identification
Planning and Preparation
Bath Operation
Instrument Operation
Optimization
Maintenance and Cleaning
Trouble Shooting
Technical Information
Parts List
Service and Returns
Shipping - Claims for damage or shortage
Specifications
Wiring Diagrams
Contacting Organomation and its Representatives
Product designs are subject to change without notice
V15.1

V15.1 - 1 -
INTRODUCTIONN-EVAP
Items Shipped
Carefully check the contents of all cartons received for damage which may have
occurred in transit. Retain all cartons and packaging materials until all components have been
checked against the packing slip, the component list below, and the equipment has been
assembled and tested. Contact Organomation Associates Inc. immediately if any damage or
discrepancies are found.
Your shipment should contain one or more of the instruments shown below. Option codes are
listed on the next page.
Instrument Size
34 Position N-EVAP Nitrogen evaporation system
45 Position N-EVAP Nitrogen evaporation system
Flow meter Assembly with Mounting Bracket & Connector Tube
0-30 LPM for 34/45 position N-EVAP
19 ga. x 4” Stainless Steel Luer Lock Needles, blunt end
34 or 45 each for 34 / 45 Position N-EVAP
OA-HEAT Water Bath 1400W, for 34 / 45 position N-EVAP
SS Adapter Tube 1/4” (7 mm) OD
T-Handle Hex Key adjustment tools
1 ea. 3/16” x 8” Long, for 30/45 position N-EVAP
Manual for N-EVAP models 11634, 11645
Pasteur Pippet Adapter with flow controller, 1 Dozen per set (Optional)
Cat #
11634
11645
NA1421
NA0603
B1602
V11291
V11437
V10124
NA0636
N-EVAP and OA-HEAT are Trademarks of Organomation Associates Inc.
