Oriental motor K II Series User manual

1
Introduction
 Before using the motor
Only qualied and educated personnel should work with the product. Use the
product correctly after thoroughly reading the section "Safety precautions."
Should you require the inspection or repair of internal parts, contact the Oriental
Motor ofce where you purchased the product.
The product described in this manual has been designed and manufactured
to be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any damage caused
through failure to observe this warning.
 Standard and CE Marking
 This product is recognized by UL under the UL and CSA standards.
Also, it conforms to the China Compulsory Certication System (CCC System).
 The motor is afxed the CE Marking under the Low Voltage Directive.
Refer to p.4 for details.
 RoHS Directive
The products do not contain the substances exceeding the restriction values of
RoHS Directive (2011/65/EU).
Safety precautions
The precautions described below are intended to prevent danger or injury to
the user and other personnel through safe, correct use of the product. Use the
product only after carefully reading and fully understanding these instructions.
Warning
Handling the product without observing the instructions that accompany a
"Warning" symbol may result in serious injury or death.
 Do not use the product in explosive or corrosive environments, in the presence
of ammable gases, or near combustibles. Doing so may result in re, electric
shock or injury.
 Only qualied and educated personnel should be allowed to perform
installation, connection, operation and inspection/troubleshooting of the
product. Handling by unqualied and uneducated personnel may result in re,
electric shock, or injury.
 Do not transport, install the product, perform connections or inspections
when the power is on. Always turn the power off before carrying out these
operations. Failure to do so may result in electric shock.
 Turn off the power in the event the overheat protection device (thermal
protector) is triggered. Failure to do so may result in injury or damage to
equipment, since the motor will start abruptly when the overheat protection
device (thermal protector) is automatically reset.
 The motor is Class І equipment. Install the motor so as to avoid contact with
hands, or ground it to prevent the risk of electric shock.
 Install the motor in an enclosure in order to prevent electric shock or injury.
 Keep the input power voltage within the specied range. Failure to do so may
result in re or electric shock.
 Securely connect the cables in accordance with the connection examples.
Failure to do so may result in re or electric shock.
 Do not forcibly bend, pull or pinch the lead wires. Doing so may result in re
and electric shock.
 Insulate the connection terminals of the supplied capacitor using the supplied
capacitor cap. Failure to do so may result in electric shock.
 Turn off the power in the event of a power failure. Or the motor may suddenly
start when the power is restored and may cause injury or damage to
equipment.
 Do not touch the connection terminal of the capacitor immediately after the
power is turned off (for a period of 30 seconds). The residual voltage may
cause electric shock.
 Do not disassemble or modify the motor. This may cause electric shock or injury.
Caution
Handling the product without observing the instructions that accompany a
"Caution" symbol may result in injury or property damage.
 Do not use the motor beyond its specications. Doing so may result in electric
shock, injury or damage to equipment.
 Do not touch the motor during operation or immediately after stopping. The
surface is hot and may cause a skin burn(s).
 Do not lift the motor by holding the motor output shaft or motor lead wires.
Doing so may result in injury.
 Keep the area around the motor free of combustible materials. Failure to do so
may result in re or a skin burn(s).
 Do not leave anything around the motor that would obstruct ventilation. Doing so
may result in damage to equipment.
 Do not touch the rotating part (output shaft) while operating the motor. Doing
so may result in injury.
 When an abnormality is noted, turn off the power immediately. Failure to do so
may result in re, electrical shock or injury.
 The motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator is
allowed to approach the running motor, attach a warning
label as shown in the gure in a conspicuous position.
Failure to do so may result in a skin burn(s). Warining label
 Dispose the product correctly in accordance with laws and regulations, or
instructions of local governments.
Preparation
 Checking the product
Verify that the items listed below are included. Report any missing or damaged
items to the branch or sales ofce from which you purchased the product.
 Geared motor ....................................... 1 unit
 Capacitor .............................................. 1 piece
 Capacitor cap ....................................... 1 piece
 Hexagonal socket head screw set ........ 1 set
(Hexagonal socket head screws, washers, spring washers 4 pieces each)
 Parallel key ........................................... 1 piece
(Fixed to the output shaft for the solid shaft type)
 Safety cover .......................................... 1 piece (only for hollow shaft type)
 OPERATING MANUAL ......................... 1 copy (this document)
 Checking the model name
Check the model number against the number indicated on the product.
Enter the following code or number in the box () and (o) within the model name.
: Enter a motor classication representing the power supply voltage.
JA : Single-phase 100 V 50/60 Hz JC : Single-phase 200 V 50/60 Hz
o: Enter a number representing the gear ratio.
 Terminal box type
Type Model Model name for
standards 
Degree of
protection
Hollow shaft
type
4IK25T2-GHRo4IK25HP-T2 IP66
5IK40T2-GHRo5IK40HP-T2
5IK90T2-GHRo5IK90HP-T2 IP54
Solid shaft
type
4IK25T2-GARo4IK25HP-T2 IP66
5IK40T2-GARo5IK40HP-T2
5IK90T2-GARo5IK90HP-T2 IP54
4IK25T2-GALo4IK25HP-T2 IP66
5IK40T2-GALo5IK40HP-T2
5IK90T2-GALo5IK90HP-T2 IP54
 Lead wire type
Type Model Model name for
standards 
Degree of
protection
Hollow shaft
type
4IK25-GHRo4IK25HP-
IP20
5IK40-GHRo5IK40HP-
5IK90-GHRo5IK90HP-
Solid shaft
type
4IK25-GARo4IK25HP-
5IK40-GARo5IK40HP-
5IK90-GARo5IK90HP-
4IK25-GALo4IK25HP-
5IK40-GALo5IK40HP-
5IK90-GALo5IK90HP-
 Model name that conforms to the UL Standards and CSA Standards
Installation
 Location for installation
Install it in a well-ventilated location that provides easy access for inspection.
[ Common conditions ]
 Operating ambient temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
 Operating ambient humidity 85%, maximum (non-condensing)
 Area that is free from an explosive atmosphere or toxic gas (such as sulfuric
gas) or liquid
 Area not exposed to direct sun
 Area free of excessive amount dust, iron particles or the like
 Area free of excessive salt
 Area not subject to continuous vibration or excessive shocks
 Area free of excessive electromagnetic noise (from welders, power machinery, etc.)
 Area free of radioactive materials, magnetic elds or vacuum
 Altitude Up to 1000 m (3300 ft.) above sea level
HM-9361-2
OPER ATING MA NU AL Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
Please read it thoroughly to ensure safe operation.
Always keep the manual where it is readily available.
KⅡSeries Induction Motor
Right angle geared type

2
[ Degree of protection IP66 rated motor ]
 Indoors
 Not exposed to oil (oil droplets) or chemicals.
The motor can be used in an environment that is splashed with water.
Not available for use under high pressure jets of water or immersion in water.
[ Degree of protection IP54/20 rated motor ]
 Inside an enclosure that is installed indoors (provide vent holes)
 Area not subject to splashing water (storms, water droplets), oil (oil droplets) or
other liquids
Note Oil leakage may lead to problems in the customer’s equipment or
products. If there is a concern over possible environmental damage
resulting from the leakage of grease, provide an oil tray or similar oil
catching mechanism in order not to cause a secondary damage. On
rare occasions, grease may ooze out from the gearhead.
 How to install the motor
Machine tapped holes on the mounting plate and x the motor on the plate using
set of mounting bolts (provided). The pilot section on the output shaft has been
machined to Ø50 0
- 0.039
mm (h8) [Ø1.9685
0
- 0.0015 in.] for 4IK and Ø58 0
- 0.046
mm (h8)
[Ø2.2835
0
- 0.0018 in.] for 5IK.
Use this pilot section as a guide when aligning the output shaft.
Hexagonal
socket head
screw
Mounting plate
Spring
washer
Washer
Supplied L1
L2
The gure shows a solid shaft type.
Model
Hexagonal socket head screw
Material: Stainless steel Tightening torque
[N·m (lb-in)]
Screw size L1 [mm (in.)] L2 [mm (in.)]
4IK M6 100 (3.94) 11 (0.43) 5.0 (44)
5IK M8 110 (4.33) 8 (0.31) 12 (106)
 When using the supplied hexagonal socket head screw set
Note  When using the gearhead ange to mount the geared motor to
equipment, proper alignment between the hollow shaft inside
dimension and the load shaft is necessary. Keep the alignment
tolerance within 0.02 mm (0.0008 in.). Insufcient alignment may
result in damage to the gearhead internal bearings.
 Do not disassemble the gearhead from the motor.
z Motor with cooling fan
When installing a motor with cooling fan onto a device, leave 10 mm (0.39 in.) or
more behind the fan cover or open a ventilation hole so that the cooling inlet on
the back of the motor cover is not blocked.
 Installing a load to the hollow shaft type
Mounting method of the load varies depending on the load shaft conditions. See
the following gures. The hollow output shaft inside dimension is processed to
a tolerance of H8, and incorporates a key slot for load shaft attachment. A load
shaft tolerance of h7 is recommended. Apply grease on the surface of the load
shaft and inner walls of the hollow output shaft to prevent seizure.
Model Hollow shaft inside
dimensions (H8)
Recommended load shaft
dimensions (h7)
4IK Ø18
+0.027
0
mm (Ø0.7087+0.0011
0 in.) Ø18 0
- 0.018
mm (Ø0.7087 0
- 0.0007 in.)
5IK Ø25
+0.033
0
mm (Ø0.9843
+0.0013
0 in.) Ø25 0
- 0.021
mm (Ø0.9843
0
- 0.0008 in.)
z Stepped load shaft
Mounting method using end plate
End plate
Key
Load shaft
Screw
Hollow output shaft
Spring washer
Mounting method using retaining ring
Hollow output shaft
Spacer
Washer
Screw
Spring washer
Groove for retaining ring
Key
Load shaft
z Non-stepped load shaft
Spacer
Hollow output shaft
Spacer
Washer
Screw
Spring washer
Groove for retaining ring
Key
Load shaft
Note Do not apply excessive or abrupt force to the hollow output shaft
when inserting a load shaft into the hollow output shaft. Excessive or
abrupt force may damage the gearhead internal bearings.
z Installing the safety cover
After installing the load, attach the
safety cover.
When removing the safety cover,
insert a plastic stick with a at tip to
the cutout of the safety cover, and
remove.
Safety cover
(Included)
 Installing a load to the solid shaft type
The shaft of the gearhead has been machined to an outer diameter tolerance
of h7 and is provided with a key slot for connecting the transmission parts.
When connecting the transmission parts, ensure that the shaft and parts have a
clearance t, and always x the parallel key to the output shaft with a screw to
prevent the parts from rattling or spinning. With solid shaft type, use this screw
hole as an auxiliary means for preventing the transmission parts from coming off.
Model Output shaft end tapped hole
4IK M5 Effective depth 10 mm (0.39 in.)
5IK M6 Effective depth 12 mm (0.47 in.)
• Example of using the output
shaft end tapped hole
Fixed screw
Screw
Spacer
Transmission
parts
Fixed screw
Transmission
parts
Note Do not apply excessive force onto the output shaft of the gearhead
using a hammer or other tools. Doing so may cause damage to the
output shaft or bearings.
 Mounting the capacitor
Mount the capacitor securely by using M4
screws(not provided).
Ø4.3 mm
(0.169 in.)
Note  Do not let the screw fastening torque exceed 1 N·m (8.8 lb-in) to
prevent damage to the mounting foot.
 Mount capacitor at least 10 cm (3.94 in.) away from the motor.
If it is located closer, the life of the capacitor will be shortened.
Connection
 Insulate the connecting part of the motor lead wires and power supply.
 Ground the motor using a Protective Earth Terminal.
 Terminal box type
z Connection method to a terminal box
Connection procedure
1.
Loosen the terminal cover mounting screws, and remove the terminal cover
from the terminal box.
2.
Insert the cable through the cable gland, and connect the lead wires to the
terminal block.
Connect the grounding lead wire to the Protective Earth Terminal.
3.
Install the terminal cover on the terminal box.
Terminal cover
Terminal cover mounting screw
(M4-4 pcs.)
Tightening torque:
1.0 to 1.5 N·m (8.8 to 13.2 lb-in)
Terminal box
Cable gland

3
Insert the cable through the cable gland
When inserting the cable
through the cable gland,
loosen the tightening nut.
After connecting to the
terminal block, turn the
tightening nut to secure the
cable. Nipple
[2.0 to 2.5 N·m (17.7 to 22 lb-in)]
Tightening nut
[2.0 to 2.5 N·m (17.7 to 22 lb-in)]
[ ] indicates the value of the tightening torque.
Connection method to a terminal block
 When connecting to the terminal block, use the following crimp terminal.
Round terminal with insulated coating
[Unit: mm (in.)]
Ø4.3 (0.17) or more
18 (0.71) or less
8 (0.31)
or less
 To ensure safety, ground the motor using the Protective Earth Terminal
inside the terminal box.
 Layout of terminals
Z2, U2 and U1 are indicated on the side face of the terminal block.
[ ] indicates the value of the tightening torque.
Terminal block (M4)
[1.0 to 1.2 N·m
(8.8 to 10.6 lb-in)]
Protective Earth Terminal (M4)
[1.0 to 1.5 N·m
(8.8 to 13.2 lb-in)]
Z2 U2 U1
 Use a cable of the following specications.
Applicable cable diameter: Ø7 to Ø13 mm (Ø0.28 to Ø0.51 in.)
Applicable lead wire: AWG18 (0.75 mm2) or thicker
Connection cables are available as accessories. Refer to the product catalog
for details.
 Although the O-ring that is set to the matching surface of the terminal cover
is a structure not to fall off easily, install it in the groove portion of the terminal
cover securely if it fell off.
Note  To make shielding function fully effective, use a cable of an appropriate
diameter and observe the specied tightening torque of screws.
 Secure the cable drawn from the motor terminal box so that it does
not receive stress.
z Changing the cable outlet position
The cable outlet position can be changed to the left or right 90-degree direction,
or the 180-degree direction by changing the mounting direction of the terminal
box.
When changing the mounting direction of the terminal box, specify the cable
outlet position based on the equipment to be installed.
Change procedure
1.
Loosen the terminal cover mounting screws, and remove the terminal cover
from the terminal box.
2.
Loosen the terminal box
mounting screws, and remove
the terminal box from the
motor case.
Terminal box mounting screw
(M4-4 pcs.)
Tightening torque:
1.0 to 1.5 N·m (8.8 to 13.2 lb-in)
3.
Change the cable outlet position of the terminal box from the mounting
position at the time of shipment by turning the terminal box itself to the left or
right 90-degree direction, or the 180-degree direction.
Gasket Cable gland
Terminal block
Terminal box
Motor case
Note  Be sure to use the gasket which has been put in the product at the time
of shipment.
 Assemble not to enter any foreign object between the terminal box
and motor case.
 Lead wire type
Connecting Protective Earth Terminal
Ground the motor using the Protective Earth Terminal on the motor.
Applicable crimp terminal:
Insulated round crimp terminal
Terminal screw size: M4
Tightening torque:
1.0 to 1.3 N·m (8.8 to 11.5 lb-in)
Applicable lead wire:
AWG18 (0.75 mm2) or thicker
Ø4.1 (0.16) or more
4.8 (0.19) or less
9.5 (0.37)
or less
[ Unit: mm (in.) ]
Note Do not use screws other than the Protective Earth Terminal screw
attached on the product.
 Wiring diagram
Note Be sure to check the rotation direction before incorporating the motor
in the mechanical equipment.
 Check the gear ratio of the motor before connecting.
 The rotation direction is as viewed from the output shaft end.
The rotation in the clockwise direction represents "CW" and the rotation in the
counterclockwise direction represents "CCW."
 For the hollow shaft type, the rotation direction is the opposite when viewing
from the direction of an arrow side.
Hollow shaft type Solid shaft type
(Right shaft)
Solid shaft type
(Left shaft)
CW
CCW
CW
CCW
CW
CCW
Gear ratio 5to 120
CW
L
N
U1 Z2
U2
Power supply
PE
Terminal box
type
L
N
Black White
Red
Power Supply PE
Lead wire
type
CCW
L
N
U1 Z2
U2
Power supply
PE
Terminal box
type
Black White
Red
Power Supply
L
N
PE
Lead wire
type
Gear ratio 150 to 240
CW
L
N
U1 Z2
U2
Power supply
PE
Terminal box
type
Black White
Red
Power Supply
L
N
PE
Lead wire
type
CCW
L
N
U1 Z2
U2
Power supply
PE
Terminal box
type
L
N
Black White
Red
Power Supply PE
Lead wire
type
Note To change rotation direction of the motor, wait until the motor
completely stops. Otherwise its direction may not change or may
take much time to change.

4
 Unauthorized reproduction or copying of all or part of this manual is
prohibited.
 Oriental Motor shall not be liable whatsoever for any problems relating
to industrial property rights arising from use of any information, circuit,
equipment or device provided or referenced in this manual.
 Characteristics, specications and dimensions are subject to change without
notice.
 is a registered trademark or trademark of Oriental Motor Co.,
Ltd., in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2016
Published in December 2017
Technical Support Tel:[phone]
8:30 A.M. to 5:00 P.M., P.S.T. (M-F)
7:30 A.M. to 5:00 P.M., C.S.T. (M-F)
www.orientalmotor.com
Schiessstraße 44, 40549 Düsseldorf, Germany
Technical Support Tel:[phone]
www.orientalmotor.de
Tel:[phone]
www.oriental-motor.co.uk
Tel:[phone]
www.orientalmotor.fr
Tel:[phone]
www.orientalmotor.it
Tel:[phone]
www.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno,Taito-ku,Tokyo 110-8536
Japan
Tel:[phone]
www.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
 Capacitor connection
The capacitor internal wiring as follows: Capacitor terminals are
internallyelectrically connection in twos; A-B and C-D for easy connection.
For easy to install terminals use 187 series FASTON terminals (TE Connectivity).
Use the supplied capacitor cap to insulate the capacitor terminal
187 series
Capacitor cap
Capacitor
AB
CD
Note For lead wire connection, use one lead wire for each individual
terminal.
Operation
When the power is turned on, the motor rotates.
Note  Make sure that the motor case temperature does not exceed 90 °C
(194 °F) when operating the motor. Operation exceeding case temperature
90 °C (194 °F) may signicantly deteriorate the coils and ball bearings of
the motor and shorten the motor's life span. Motor case temperature can
be measured by xing a thermometer on the motor surface. It can also be
measured using thermo tape or a thermocouple.
 When an ambient temperature is low, since the load torque may increase
by the viscosity increment of the oil seal or grease, the motor starting may
take a long time or the motor rotation speed may fall.
However, if the operation is continued for a while, the oil seal or grease
will be warmed up, and the motor can be driven at the normal rotation
speed.
Time rating
Continuous operation is possible (continuous rating).
Overheat protection for locked condition
The motor is equipped a function of overheat protection for when the motor
output shaft is locked.
 Thermally protected motors
"TP" is marked on the motor nameplate. This motor contains a built-in automatic
return type thermal protector in the motor windings. If the motor internal
temperature exceeds the specied value, the thermal protector is activated and
the motor is stopped.
Always turn the power off before performing inspections.
Operating temperature of thermal protector
Open (motor standstill)...............130±5 °C (266±9 °F)
Close (resuming operation)........85±20 °C (185±36 °F)
Troubleshooting
When the motor cannot be operated correctly, refer to the contents provided in
this section and take appropriate action. If the problem persists, contact your
nearest ofce.
Phenomena Check items
Motor does not rotate.
Motor sometimes rotates
and stops.
Check the power supply voltage.
Connect the power supply and the motor orrectly.
Connect the supplied capacitor correctly.
If terminal blocks or crimp terminals are used,
check them for poor connection.
Keep the load at or below the allowable value.
The motor rotates in the
direction opposite to the
specied direction.
Connect the supplied capacitor correctly.
The connection varies depending on the gear
ratio of the gearhead.
The rotation direction is as viewed from the
output shaft end.
Check the reference direction.
Motor temperature
abnormally high.
[Motor case temperature
exceeds 90 °C (194 °F)]
Check the power supply voltage.
Connect the supplied capacitor correctly.
Review the ventilation condition.
Standard and CE Marking
 This product is recognized by UL under the UL and CSA standards.
Also, it conforms to the China Compulsory Certication System (CCC System).
 The motor is afxed the CE Marking under the Low Voltage Directive.
 UL Standards, CSA Standards, CCC System
Applications for standard Certication Body / File No.
UL 1004-1, UL 1004-3 UL / UL File No. E64197
CSA C22.2 No.100, CSA C22.2 No.77
GB/T 12350 CQC
 Thermal Class: 130 (B)
 CE Marking
 Applications for standard
EN 60034-1, EN 60034-5, EN 60664-1
Momentary excess torque based on EN 60034-1
Model Momentary excess torque Momentary excess torque represents a
maximum torque that can maintain the
operation for 15 seconds without stalling
or abrupt speed change even if the torque
is increased gently while operating at rated
voltage and rated frequency.
4IK25
5IK40 130% of the rated torque
5IK90 140% of the rated torque
 Installation conditions (For EN standard)
Terminal box type: Overvoltage category ІІ, Pollution degree 3, Class І equipment
Lead wire type: Overvoltage category ІІ, Pollution degree 2, Class І equipment
When the machinery to which the motor is mounted requires overvoltage
category ІІІ specications, install the motor in a cabinet that connect to power
supply via an isolation transformer.
 Standards for accessories
Capacitor: UL File No.E83671 (CYWT2),
VDE License Nos.112847 (capacitors with a rated voltage of 250 VAC),
114747 (capacitors with a rated voltage of 450 VAC)
Capacitor cap: UL File No.E56078 (YDTU2)
 The motor temperature rise tests
Temperature rise tests required by the above standards are performed in a state
that has been attached a heat radiation plate instead of a gearhead.
The size and material for the heat radiation plates are as follows.
[ Size ] 4IK25: 135×135 mm (5.31×5.31 in.)
5IK40: 165×165 mm (6.50×6.50 in.)
 5IK90: 200×200 mm (7.87×7.87 in.)
[ Thickness ] 5 mm (0.20 in.)
[ Material ] Aluminum alloy
