Oriental motor PKP56 Series User manual

1
Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should
work with the product.
Use the product correctly after thoroughly reading the“Safety precautions.”
In addition, be sure to observe the contents described in warning, caution,
and note in this manual.
The product described in this manual has been designed and manufactured
to be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any damage caused
through failure to observe this warning.
Safety precautions
The precautions described below are intended to prevent danger or injury
to the user and other personnel through safe, correct use of the product.
Use the product only after carefully reading and fully understanding these
instructions.
Description of signs
Handling the product without observing the instructions
that accompany a "Warning" symbol may result in serious
injury or death.
Handling the product without observing the instructions
that accompany a“Caution”symbol may result in injury
or property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure the
safe use of the product.
Description of graphic symbols
Indicates "prohibited" actions that must not be performed.
Indicates "compulsory" actions that must be performed.
yDo not use the product in explosive or corrosive environments, in
the presence of ammable gases, locations subjected to splashing
water, or near combustibles.
This may cause re or injury.
yDo not forcibly bend, pull or pinch the lead wire or cable.
This may cause re.
yDo not disassemble or modify the product.
This may cause injury.
HM-7455-2
OPERATING MANUAL Thank you for purchasing an Oriental Motor product. This Operating Manual
describes product handling procedures and safety precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
5-Phase Stepping Motor
PKP Series TS Geared Type
yAssign qualied personnel the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product.
Failure to do so my result in re or injury.
yIf this product is used in a vertical application, be sure to provide a
measure for the position retention of moving parts.
Failure to do so may result in injury or damage to equipment.
yInstall the product in an enclosure.
Failure to do so may result in injury.
yConnect the cables securely according to the wiring diagram.
Failure to do so may result in re.
yFor the power supply, use a DC power supply with reinforced
insulation on its primary and secondary sides.
Failure to do so may cause electric shock.
yDo not use the product beyond its specications.
This may cause injury or damage to equipment.
yKeep your ngers and objects out of the openings in the product.
Failure to do so may result in re or injury.
yDo not touch the product while operating or immediately after
stopping.
This may cause a skin burn(s).
yDo not carry the motor by holding the motor output shaft, lead
wire or cable.
Doing so may cause injury.
yKeep the area around the product free of combustible materials.
Failure to do so may result in re or a skin burn(s).
yLeave nothing around the product that would obstruct ventilation.
Failure to do so may result in damage to equipment.
yDo not touch the rotating part (output shaft) while operating the
motor.
Doing so may result in injury.
yProvide a cover over the rotating part (output shaft) of the motor.
Failure to do so may result in injury.
yUse a motor and driver only in the specied combination.
Failure to do so may result in re.
yProvide an emergency stop device or emergency stop circuit so
that the entire equipment will operate safely in the event of a
system failure or malfunction.
Failure to do so may result in injury.
yWhen an abnormal condition has occurred, immediately stop
operation and turn o the driver power.
Failure to do so may result in re or injury.
yThe motor surface temperature may exceed 70 °C
(158 °F) even under normal operating conditions. If the
operator is allowed to approach the running motor,
attach a warning label as shown below in a conspicuous
position.
Failure to do so may result in a skin burn(s).
Warning
label

2
Precautions for use
•When conducting the insulation resistance measurement and
the dielectric strength test, be sure to separate the connection
between the motor and the driver.
Conducting the insulation resistance test or dielectric strength test with the
motor and driver connected may result in damage to the product.
•Do not apply a radial load and axial load in excess of the
specied permissible limit
Operating the motor under an excessive radial load or axial load may damage
the motor bearings (ball bearings). Be sure to operate the motor within the
specied permissible limit of radial load and axial load.
•Motor surface temperature
The motor surface temperature may exceed 100 °C (212 °F) under certain
conditions (operating ambient temperature, operating speed, duty cycle,
etc.). To prevent the bearings (ball bearings) from reaching its usable life
quickly, use the motor in a condition where the surface temperature does not
exceed 100 °C (212 °F).
Use the geared motor in a condition where the gear case temperature does
not exceed 70 °C (158 °F), in order to prevent deterioration of grease and
parts in the gear part.
•Grease leakage
On rare occasions, a small amount of grease may ooze out from the geared
motor. If there is concern over possible environmental damage resulting from
the leakage of grease, check for grease stains during regular inspections.
Alternatively, install an oil pan or other device to prevent leakage from
causing further damage. Oil leakage may lead to problems in the customer’s
equipment or products.
•Holding torque at standstill
The motor holding torque is reduced by the current cutback function of the
driver at motor standstill. When operating the motor, take account of the
motor torque drop at the time of stopping.
•Allowable torque
When operating the motor at a constant speed, use so that the torque does
not exceed the allowable torque in the specications. Operating the motor in
excess of the allowable torque may cause damage to the gear part.
•Peak torque
Operate the motor so that the sum of the acceleration/deceleration torque
at the starting/stopping of the motor and the load (friction) torque does not
exceed the peak torque in the specications. Operating the motor in excess of
the peak torque may cause damage to the gear part.
•Speed range
Operate the motor at speeds within the speed range. Operating the motor at
a speed outside the speed range may result in a shorter gear life.
•Backlash
The gear output shaft is subject to backlash. To reduce the eect of backlash,
perform positioning operations from one direction only-either from the CW
direction or the CCW direction.
•Rotation direction of the gear output shaft
The relationship between the rotation direction of the motor output shaft
and that of the gear output shaft changes as follows, depending on the gear
ratio.
Gear ratio Rotation direction of the gear output shaft
3.6, 7.2, 10 Same as the motor output shaft
20, 30 Opposite as the motor output shaft
•Make sure to provide measures so that the key is not own o
when operating the motor with key in a state where a load is not
installed.
Flying o the key may result in injury or damage to equipment.
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or
damaged items to the Oriental Motor sales oce from which you purchased
the product.
yMotor ................................................................ 1 unit
yParallel key ...................................................... 1 pc. (Supplied with PKP56)
yMotor mounting screw set........................ 1 bag (Supplied with PKP56)
[Packing contents] Screw.........................4 pcs. [M4×60 mm (2.36 in.)]
Washer...................... 4 pcs.
Spring washer........ 4 pcs.
yOPERATING MANUAL .................................. 1 copy (this document)
How to identify the product model
Check the model number of the motor against the number shown on the
nameplate.
PKP5   N A 2 - TS 
1 2 3 4 5 6 7 8
1 Motor frame size 4: 42 mm (1.65 in.)
6: 60 mm (2.36 in.)
2 Motor length
3 Number of lead wire N: 5 pcs.
4 Motor winding specication 18: Rated current 1.8 A/phase
28: Rated current 2.8 A/phase
5 Shape A: Single shaft
B: Double shaft
6 Reference number
7 Type of gear TS: TS geared type
8 Gear ratio
Names of parts
The pin numbers as well as the colors of lead wires are shown in the gures.
Pilot
Output shaft
Mounting holes
(4 places)
Connector
Pin No.1
Pin No.5
Connector
Connector locks
Motor lead wires
Pin No.5
Blue
Pin No.1
Black
• Connection cable
Pin assignment
Pin No. Lead wire color *
5 Blue
4 Red
3 Orange
2 Green
1 Black
* The colors of lead wires show arrangement of colors of the connection cable
(accessory).

3
Applicable connector/lead wire
Type Model
Connector housing MDF97-5S-3.5C (HIROSE ELECTRIC CO., LTD.)
Contact MDF97-22SC (HIROSE ELECTRIC CO., LTD.)
Designated crimping tool HT801/MDF97-22S (HIROSE ELECTRIC CO., LTD.)
Applicable lead wire
− AWG22 (0.3 mm2)
− Outer sheath diameter:
ø1.2 to 1.5 mm (ø0.047 to 0.059 in.)
− Strip length of the insulation cover:
1.8 to 2.3 mm (0.071 to 0.091 in.)
Connection
•When inserting the connector
Hold the connector main body, and insert it in
straight securely. Inserting the connector in an
inclined state may result in damage to connector
or a connection failure.
•When pulling out the connector
Pull out the connector in straight while releasing
the lock part of the connector. Having the motor
lead wires or pulling out the connector in a state
of being locked may damage the connector.
Secure the lead wires at the connection part to prevent the
connection part from receiving stress due to the exing of the lead
wires or the lead wires’ own mass. Also, do not excessively bend the
lead wires near the connection part of the connector. Applying stress
on the motor lead wires may cause poor contact or disconnection,
leading to malfunction or heat generation.
Bend excessively
Have length allowances
More than 4 times
of the diameter of
the lead wires.
Connection with the drivers of Oriental Motor
Refer to the following table when connecting with the drivers of Oriental
Motor.
“Color” in the table represents the colors of lead wires of the connection cable
(accessory).
•Connection with the CVD driver
Driver
CN2 Pin No. Pin No. Color
1 5 Blue
2 4 Red
3 3 Orange
4 2 Green
5 1 Black
Installation
Location for installation
The motor has been designed and manufactured to be incorporated in
equipment. Install it in a well-ventilated location that provides easy access for
inspection. The location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature: −10 to +50 °C (+14 to +122 °F) (non-
freezing)
yOperating ambient humidity 85% or less (non-condensing)
yArea that is free of explosive atmosphere or toxic gas (such as sulfuric gas)
or liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rain, water droplets), oil (oil droplets)
or other liquids
yArea free of excessive salt
yArea not subject to continuous vibration or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power
machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
y1,000 m (3,300 ft.) or lower above sea level
Installation method
The motor can be installed in any direction.
Install the motor onto an appropriate at metal plate having excellent
vibration resistance and heat conductivity.
When installing the motor, secure it with four bolts through the four
mounting holes provided. Do not leave a gap between the motor and metal
plate. The PKP56 come with a motor mounting screw set.
yPKP54
Metal plate
Mounting
holes
P
ilot hole
yPKP56
Secure the motor using the supplied screw
set. [Screw size: M4×60 mm (2.36 in.)]
Metal plate
Mounting holes
Screw set (supplied)
Pilot hole
Model Nominal size Tightening torque
[N·m (oz-in)]
Eective depth of screw
thread [mm (in.)]
PKP54 M4 1.4 (198) 8 (0.315)
PKP56 −
Do not loosen the gear-attaching screws (4 pcs.). Doing so may cause
the accuracy to drop or damage to the product.
Installing a load
When connecting a load to the motor, align the centers of the motor output
shaft and load shaft. Be careful not to damage the output shaft or bearings
when installing a coupling or pulley to the motor output shaft.

4
yUnauthorized reproduction or copying of all or part of this manual is
prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating
to industrial property rights arising from use of any information, circuit,
equipment or device provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without
notice.
yWhile we make every eort to oer accurate information in the manual,
we welcome your input. Should you nd unclear descriptions, errors or
omissions, please contact the nearest oce.
yis a registered trademark or trademark of Oriental Motor
Co., Ltd., in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2017
Published in February 2018
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Permissible radial load and permissible axial load
The radial load and axial load on the motor output shaft must be kept the
permissible values listed in the table below.
zPermissible radial load
Model Gear ratio
Permissible radial load [N (lb.)]
Distance from the tip of motor output shaft
0 mm
(0 in.)
5 mm
(0.20 in.)
10 mm
(0.39 in.)
15 mm
(0.59 in.)
20 mm
(0.79 in.)
PKP544 3.6, 7.2, 10 20 (4.5) 30 (6.7) 40 (9) 50 (11.2) −
PKP543 20, 30 40 (9) 50 (11.2) 60 (13.5) 70 (15.7) −
PKP566 3.6, 7.2, 10 120 (27) 135 (30) 150 (33) 165 (37) 180 (40)
PKP564 20, 30 170 (38) 185 (41) 200 (45) 215 (48) 230 (51)
zPermissible axial load
Model Gear ratio Permissible axial load [N (lb.)]
PKP544 3.6, 7.2, 10 15 (3.3)
PKP543 20, 30
PKP566 3.6, 7.2, 10 40 (9)
PKP564 20, 30
Maintenance/inspection
Inspection
It is recommended that periodic inspections are conducted for the items
listed below after each operation of the motor. If an abnormal condition is
noted, discontinue any use and contact your nearest Oriental Motor sales
oce.
During inspection
yCheck if any of the motor mounting screws come loose.
yCheck if a bearing part (ball bearings) of the motor generates unusual
noises.
yCheck if any of the motor lead wires have a scratch or receive a stress.
yCheck if the connection part with the connector or the driver comes loose.
yCheck if the motor output shaft and the load shaft are out of alignment.
Warranty
Check on the Oriental Motor Website or General Catalog for the product
warranty.
Disposal
Dispose the product correctly in accordance with laws and regulations, or
instructions of local governments.
Specications
Check on the Oriental Motor Website for the product specications.
General specications
Degree of protection IP20
Operation
environment
Ambient
temperature −10 to +50 °C (+14 to +122 °F) (non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 1,000 m (3,300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Storage
environment,
Shipping
environment
Ambient
temperature −20 to +60 °C (−4 to +140 °F) (non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Insulation
resistance
100 MΩ or more when 500 VDC megger is applied between
the case and motor windings.
Dielectric
strength
Sucient to withstand the following conditions applied
between the case and motor windings for 1 minute:
• PKP54: 0.5 kVAC 50/60 Hz
• PKP56: 1.0 kVAC 50/60 Hz
Regulations and standards
RoHS Directive
The products do not contain the substances exceeding the restriction values
of RoHS Directive (2011/65/EU).
