Orion®SkyLine™Deluxe Green Laser Pointer
#5673
IN 395 Rev A 06/10
Safety label
Power button
INSTRUCTION MANUAL
Corporate Offices: 89 Hangar Way, Watsonville CA 95076 - USA
Toll Free USA & Canada: [phone]
International: [phone]
Customer Support: [email protected]
Copyright © 2021 Orion Telescopes & Binoculars. All Rights Reserved. No part of this product instruction or any of its contents
may be reproduced, copied, modied or adapted, without the prior written consent of Orion Telescopes & Binoculars.
AN EMPLOYEE-OWNED COMPANY
Francais
Deutsche
uPour obtenir le manuel d'utilisation complet,
veuillez vous rendre sur le site Web OrionTele-
scopes.eu/fr et saisir la référence du produit dans
la barre de recherche.
vCliquez ensuite sur le lien du manuel
d’utilisation du produit sur la page de description
du produit.
uWenn Sie das vollständige Handbuch einsehen
möchten, wechseln Sie zu OrionTelescopes.de,
und geben Sie in der Suchleiste die Artikelnum-
mer der Orion-Kamera ein.
vKlicken Sie anschließend auf der Seite mit den
Produktdetails auf den Link des entsprechenden
Produkthandbuches.
Congratulations on your purchase of the Orion SkyLine Deluxe diode
pumped, solid state, frequency doubled green laser pointer. The SkyLine
Deluxe emits a thin but intense beam of green laser light, which in a dark
sky appears to stretch all the way to the stars! The SkyLine Deluxe is a
nifty teaching aid, allowing you to point out stars, planets, and constellations
to other individuals or groups of people. The SkyLine Deluxe’s far-reaching
beam is visible not only by the person holding the pointer, but also by others
standing several feet to the side. It works even in light-polluted or moonlit
skies, though dark skies are best. Unlike other laser pointers, this advanced
design utilizes light control feedback to ensure full optical output power
across broad temperature ranges. This servo control technology provides for
instant bright laser light even during cool outdoor observing.
User Safety Precautions
The SkyLine Deluxe Green Laser Pointer is not a toy! It should be used
responsibly, and only by adults.
• Avoid Direct Eye Exposure.
• Class IIIA / 3R Laser Product.
• DO NOT shine the laser toward people.
• DO NOT shine the laser into or near the eyes of people or
animals. Direct eye contact with beam or bright reection may
cause eye injury.
• DO NOT shine the laser toward moving vehicles of any kind, even
distant ones.
• DO NOT shine the laser at reective surfaces, as the redirected
beam could enter someone’s eye.
• DO NOT shine the laser at aircraft. Shining lasers at aircraft may
be considered a felony.

Operation
Depress the power button to turn the laser beam on. The laser shines for as
long as the power button remains depressed. Releasing the power button
turns the laser beam off. The SkyLine Deluxe’s Class 3R laser is intended for
intermittent, short-duration use as a hand-held pointer. The laser should be
turned on for no more than a minute or two at a time, then left off for a minute
or so. Keeping the power on for longer durations may cause the beam to dim.
This will not damage the laser circuitry, however. After a period of several
minutes with the power off, the beam should shine at full intensity again.
Using the SkyLine Deluxe is a convenient and fun way to point out specic
stars, planets, or regions of the night sky to fellow night sky enthusiasts. It’s
beam is especially useful for tracing constellation patterns. Simply point the
device towards a celestial object of interest and depress the power button.
Please use the SkyLine Deluxe sparingly at public gatherings so as not to
interfere with others’ enjoyment of the night sky. It should not be used where
others are taking astrophotographic exposures, as the light could register on
the resulting image.
Replacing the Batteries
To replace run-down batteries, rotate the end cap near the pocket clip coun-
terclockwise. Remove the two AAA batteries and replace with a fresh pair.
Insert both fresh batteries with the negative (-) end rst. Then thread the end
cap back on, turning it clockwise.
Battery replacement is the only maintenance required by the user.Any main-
tenance, service, or repair concerns other than battery replacement should
be communicated to Orion Customer Service at [phone]. Service is
not allowed by the user. Do not disassemble this product. If service or repair
is required, the unit must be returned to Orion.
Specifications
Laser class: Class 3R
Laser type: Diode-pumped solid state frequency doubled
Output wavelength: 532 nm
Output power: 3.5-4.5mW (continuous wave)
Operating current: 390 mA
Range (in darkness): >1 mile
Switch: Pushbutton (momentary)
Batteries: Two AAA (included)
Battery life: Up to 4 hours of continuous use
Dimensions: 134mm long x 13mm dia. (5.3" x 0.5")
Weight: 65g (2.4 oz.)
This is a Class 3R laser product as classied per IEC 60825-1 Ed.1.2,
2001-2008.
This Class 3R laser product complies with FDA performance standards
for laser products except for deviations pursuant to Laser Notice No. 50
dated July 26, 2001. No scheduled maintenance is necessary to keep this
product in compliance.
Corporate Offices: 89 Hangar Way, Watsonville CA 95076 - USA
Toll Free USA & Canada: [phone]
International: [phone]
Customer Support: [email protected]
Copyright © 2021 Orion Telescopes & Binoculars. All Rights Reserved. No part of this product instruction or any of its contents
may be reproduced, copied, modied or adapted, without the prior written consent of Orion Telescopes & Binoculars.
AN EMPLOYEE-OWNED COMPANY
One-Year Limited Warranty
This Orion product is warranted against defects in materials or workmanship for a peri-
od of one year from the date of purchase. This warranty is for the benet of the original
retail purchaser only. During this warranty period Orion Telescopes & Binoculars will
repair or replace, at Orion’s option, any warranted instrument that proves to be defec-
tive, provided it is returned postage paid. Proof of purchase (such as a copy of the origi-
nal receipt) is required. This warranty is only valid in the country of purchase.
This warranty does not apply if, in Orion’s judgment, the instrument has been abused,
mishandled, or modied, nor does it apply to normal wear and tear. This warranty gives
you specic legal rights. It is not intended to remove or restrict your other legal rights
under applicable local consumer law; your state or national statutory consumer rights
governing the sale of consumer goods remain fully applicable.
For further warranty information, please visit www.OrionTelescopes.com/warranty.
