SEVERIN FM 7631 User manual

3
1
2
3
4
5
6
7
8
9
10
11
12
14
21
20
19
18
17
16
15
13

4

Dear Customer,
Before using the appliance, the user should
read the following instructions carefully.
Connection to the mains supply
Make sure that the supply voltage
corresponds with the voltage marked on the
rating label of the appliance. This product
complies with all binding CE labelling
directives.
Familiarisation
1. Storage compartment for pedicure unit
2. Rotary control
3. Cover
4. Nail-polish dryer
5. Foot massager
6. Roller massage insert for the soles
7. Infrared pad
8. Water-level indicator
9. Right foot-pad with massage studs
10. Power cord with plug
11. Emptying recess
12. Slide switch
13. Battery compartment cover
14. Pedicure unit
15. Aroma chamber
16. Sponge attachment
17. Abrading attachment
18. Filing attachment
19. Brush attachment
20. Left foot-pad with massage studs
21. Rating label (on the side)
Important safety instructions
●Before the appliance is used, the main
body as well as any attachments fitted
should be checked thoroughly for any
defects. If the appliance, for instance, has
been dropped onto a hard surface, it
must no longer be used: even invisible
damage may have adverse effects on its
operational safety.
●If the appliance is being used in a
bathroom, it must be positioned outside
the 0.6 m area (see diagram) in such a
way that the rotary control cannot be
reached by anyone using the shower or
bath.
●Additional protection is provided by
fitting an earth-leakage circuit-breaker,
with a rated tripping current not
exceeding 30mA, into your bathroom
installation. Please consult a qualified
electrician.
●Do not attempt to charge or by any other
means reactivate the batteries of the
pedicure unit; never take batteries apart,
or burn or short-circuit them.
●Always remove the batteries from the
pedicure unit once they are exhausted,
and also during extended periods of non-
use. This will prevent damage from
leakage.
●All batteries in the pedicure unit should
be replaced at the same time. Do not use
batteries of different types or brands, or
those of different capacities.
●Do not leave the foot massager
unattended while it is switched on, nor let
children use it without supervision.
●Do not stand on the foot massager; use it
only while sitting.
●The foot massager becomes hot during
use. Those who are over-sensitive to heat
should take extreme care when using the
appliance.
●Do not operate the foot massager near a
sink, shower or bath.
●This appliance is intended for domestic
use only and is not designed for medical
or commercial applications.
●Always switch the foot massager off and
remove the plug from the wall socket
after use and during cleaning, and also in
case of any malfunction. When removing
the plug from the wall socket, ensure that
your hands are dry.
●The power cord should be regularly
examined for any signs of damage. In the
event of such damage being found, the
appliance must no longer be used.
9
Foot massager


●Always switch the pedicure unit off
before changing any attachments..
●This appliance should only be used with
the attachments provided by the
manufacturer.
●Do not use the pedicure unit if you suffer
from eczema or open wounds on the feet.
●This appliance is not intended for use by
any person (including children) with
reduced physical, sensory or mental
capabilities, or lacking experience and
knowledge, unless they have been given
supervision or instruction concerning the
use of the appliance by a person
responsible for their safety.
●Children should be supervised to ensure
that they do not play with the appliance.
●Keep children well away from packaging
materials, as they are a potential source
of danger e.g. from suffocation.
●No responsibility will be accepted if
damage results from improper use, or if
these instructions are not complied with.
●In order to comply with safety
regulations and to avoid hazards, repairs
of electrical appliances must be carried
out by qualified personnel, including the
replacement of the power cord. If repairs
are needed, please send the appliance to
one of our customer service departments.
The address can be found in the
appendix to this manual.
Foot massager
General information
A foot massage helps to reduce tension in
muscle and tissue areas, enhancing the blood
circulation and simultaneously stimulating
the metabolic process, thus cleansing the
body tissue of waste residues.
- If required, the roller massage insert can
be fitted to the foot-pads. Roller massage
is specifically recommended for the sole
area of the feet.
An infrared pad for heat treatment is
located between the foot pads.
- In order to enhance the massage effect, a
foot massage should be applied using
warm water. A non-foaming bath gel
may also be added.
- The integral heating element located
underneath the studded foot-pads
prevents the warm water from cooling
down too fast, although it is not designed
to heat up the water.
●The user is recommended to refrain from
massage treatment when suffering from
phlebitis in the legs, varicose veins (if
they tend to bleed easily), skin rash,
inflamed or swollen feet or any pain of
unknown origin. If in doubt, consult your
doctor before using the appliance.
Control settings
0 Unit is switched off
1 Bubble function + massage + infrared
2 Warm air stream for nail dryer
3 Massage + infrared
Operation
- Place the foot massager on the floor in
front of a chair.
- If required, the massage inserts for the
foot-reflex zones can be fitted.
- Fill with warm water until the indicated
water level is reached.
- Insert the plug into the wall socket. Make
sure that the rotary control is in the “0”
position.
- Seat yourself comfortably on the chair
and position your feet on the foot pads.
Do not stand on the unit.
- Select the desired function with the
rotary control. The recommended
application time is 10 to 20 minutes.
- After use, set the control switch to “0”
again before removing the plug from the
wall socket.
- Empty out the water afterwards through
the recess.
Nail-polish dryer with aroma function
- Turn the foot massager on and set it to
position 2.
- After applying the nail polish to your toe
10

nails, place your feet on the middle pad.
- If the aroma function is required, pull out
the nail-dryer insert from the main unit.
Add a few drops of scented oil to the
sponge inside the aroma chamber, then
slide the nail-dryer insert back into the
main unit until it locks into place.
-
Switch off the foot massager after use.
Pedicure unit
Batteries
This pedicure unit requires 2 type AA / 1.5
V batteries; the use of alkaline batteries is
preferable, as they last longer than standard
carbon-zinc batteries. The batteries are
inserted as follows:
- Slide the battery compartment cover in
the direction indicated by the arrow and
take it off.
- Insert the batteries according to the
schematic diagram inside the
compartment, ensuring correct polarity
(+/-).
- Replace the compartment cover and
slide it back until it is heard locking into
place.
●A significant decrease in operating speed
is a clear indication that the batteries are
exhausted, and that they should be
replaced.
●Always remove the batteries from the
pedicure unit during extended periods of
non-use. This will prevent damage to the
appliance from leakage.
●Never dispose of old batteries in your
domestic garbage. Old batteries must be
disposed of through local ‘special
garbage collection points’.
Using the pedicure unit
With the appliance switched off, fit the
attachment required onto the front of the
pedicure unit and push it in as far as it will
go.
- Sponge attachment: for polishing toe
nails.
- Abrading attachment: for shortening and
shaping toe nails.
- Cleaning brush: for cleaning the nails
after filing, and for removing skin
particles remaining after the treatment. It
is also useful for preparing the nail
surfaces for polishing.
- Filing attachment: for filing and other
treatment of the nail surfaces.
The slide-switch on the pedicure unit allows
for two different speed settings.
The feet should be treated after a hot bath
or shower, as calluses and nails will be
softened in this way.
Always switch the pedicure unit off after use.
A decrease in operating speed indicates low
battery capacity. When this occurs, switch off
the pedicure unit and replace the batteries.
Cleaning and care
●Before cleaning the appliance, ensure it is
disconnected from the power supply.
●To avoid the risk of electric shock, do not
clean the housing of the foot massager
with water and do not immerse it in
water.
●Do not use abrasives or harsh cleaning
solutions.
Foot massager
- The inside and the exterior of the foot
massager may be cleaned with a slightly
damp lint-free cloth. Use household
tissue paper to wipe dry afterwards.
Special, commercially available cleaning
agents for synthetic materials may also be
used for cleaning.
Pedicure unit
- The exterior of the pedicure unit may be
wiped with a dry cloth.
- The inserts may be cleaned as necessary
with an alcohol solution.
Disposal Do not dispose of old or defective
appliances in domestic garbage;
this should only be done through
public collection points.
11

Guarantee
This product is guaranteed against defects in
materials and workmanship for a period of
two years from the date of purchase. Under
this guarantee the manufacturer undertakes
to repair or replace any parts found to be
defective, providing the product is returned
to one of our authorised service centres. This
guarantee is only valid if the appliance has
been used in accordance with the
instructions, and provided that it has not
been modified, repaired or interfered with
by any unauthorised person, or damaged
through misuse.
This guarantee naturally does not cover
wear and tear, nor breakables such as glass
and ceramic items, bulbs etc. If the product
fails to operate and needs to be returned,
pack it carefully, enclosing your name and
address and the reason for return. If within
the guarantee period, please also provide the
guarantee card and proof of purchase.
12
