Otto Bock Avantgarde 4 User manual

Avantgarde 4
Instructions for use (user) ..................................................................................... 3

2 Avantgarde 4

Foreword1 5..............................................................................................................................................................
Product description2 6............................................................................................................................................
Function2.1 6..............................................................................................................................................
Product overview2.2 6..................................................................................................................................
Intended use3 9........................................................................................................................................................
Indications for use3.1 9................................................................................................................................
Special features of the CLT and CLT Ultra options3.1.1 9....................................................................................
Indications3.2 9...........................................................................................................................................
Contraindications3.3 9.................................................................................................................................
Absolute Contraindications3.3.1 9....................................................................................................................
Relative Contraindications3.3.2 9.....................................................................................................................
Safety4 9....................................................................................................................................................................
Explanation of warning symbols4.1 9..............................................................................................................
Safety instructions for use4.2 9......................................................................................................................
Side effects4.3 13........................................................................................................................................
Further information4.4 13..............................................................................................................................
Nameplate and warning labels4.5 13..............................................................................................................
Delivery5 14...............................................................................................................................................................
Scope of delivery5.1 14................................................................................................................................
Options5.2 14.............................................................................................................................................
Storage5.3 14..............................................................................................................................................
Storage during daily use5.3.1 14......................................................................................................................
Storage during extended disuse5.3.2 14............................................................................................................
Preparing the product for use6 14.........................................................................................................................
Assembly6.1 14...........................................................................................................................................
Use7 15......................................................................................................................................................................
Instructions for use7.1 15..............................................................................................................................
Getting in and transferring7.2 16...................................................................................................................
Legrests7.3 16............................................................................................................................................
Removing and attaching the leg supports7.3.1 16...............................................................................................
Folding the foot plate up and down7.3.2 17.......................................................................................................
Adjusting the angle of the elevating leg support7.3.3 18......................................................................................
Removing and fastening the calf strap7.3.4 19...................................................................................................
Adjusting the leg supports7.3.5 20....................................................................................................................
Seat cushion and back upholstery7.4 20.........................................................................................................
Removing and fastening the seat cushion7.4.1 20...............................................................................................
Removing and fastening the back support pad7.4.2 20........................................................................................
Backrest7.5 21............................................................................................................................................
Side panels7.6 21........................................................................................................................................
Removing the side panels7.6.1 21....................................................................................................................
Adjusting the height of the forearm support7.6.2 22............................................................................................
Removing the separate "swing away arm support" with padding7.6.3 22...............................................................
Adjusting an arm support with swivel unit7.6.4 22...............................................................................................
Push handles7.7 23......................................................................................................................................
Adjusting the height of the push handles7.7.1 23................................................................................................
Removing the push handles7.7.2 23..................................................................................................................
Stabiliser bar7.8 24......................................................................................................................................
Drive wheels7.9 24.......................................................................................................................................
Removing and mounting the drive wheels7.9.1 25...............................................................................................
Rear wheel with one-handed operation (double push rings)7.9.2 26......................................................................
Caster wheels and caster forks7.10 27.............................................................................................................
Approach in case of stiffness7.10.1 27................................................................................................................
Wheel locks7.11 27.......................................................................................................................................
Using the wheel locks7.11.1 28..........................................................................................................................
Table of contents
3Avantgarde 4
Table of contents

Drum brake7.11.2 29........................................................................................................................................
Knee lever wheel lock for user and attendant7.11.3 29..........................................................................................
Using the plug-on wheel lock lever extension7.11.4 30..........................................................................................
Anti-tipper/tip-assist7.12 31............................................................................................................................
Activating and deactivating the anti-tipper7.12.1 31..............................................................................................
Using the tip-assist7.12.2 32..............................................................................................................................
Transport wheels7.13 32................................................................................................................................
Using the transport wheels7.13.1 32...................................................................................................................
Lap belt (seat belt)7.14 33..............................................................................................................................
Tray7.15 33...................................................................................................................................................
Additional options7.16 35...............................................................................................................................
Disassembly and transport7.17 35...................................................................................................................
Use in vehicles for transporting persons with reduced mobility7.18 36..................................................................
Avantgarde DV/DS without CLT and CLT Ultra options7.18.1 36...........................................................................
Required accessories7.18.1.1 36..........................................................................................................................
Using the product in a vehicle7.18.1.2 37...............................................................................................................
Restrictions for use7.18.1.3 39.............................................................................................................................
CLT and CLT Ultra options7.18.2 40..................................................................................................................
Care7.19 40..................................................................................................................................................
Cleaning7.19.1 40............................................................................................................................................
Cleaning by hand7.19.1.1 40................................................................................................................................
Cleaning the seat cushion7.19.1.2 41....................................................................................................................
Cleaning belts/straps7.19.1.3 41..........................................................................................................................
Disinfection7.19.2 41........................................................................................................................................
Maintenance and repair8 42...................................................................................................................................
Maintenance8.1 42.......................................................................................................................................
Maintenance intervals8.1.1 42..........................................................................................................................
Maintenance tasks8.1.2 42..............................................................................................................................
Repair8.2 43...............................................................................................................................................
Inner tube, rim tape and tyre replacement8.2.1 43..............................................................................................
Disposal9 44.............................................................................................................................................................
Disposal information9.1 44............................................................................................................................
Legal information10 44..............................................................................................................................................
Liability10.1 44..............................................................................................................................................
Warranty10.2 44............................................................................................................................................
Service life10.3 44.........................................................................................................................................
Technical data11 45...................................................................................................................................................
Appendices12 46........................................................................................................................................................
Threshold values for wheelchairs transportable by train12.1 46...........................................................................
4 Avantgarde 4
Table of contents

1 Foreword
INFORMATION
Date of last update: 2020-03-16
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in the instruc
tions for use (user).
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
5Avantgarde 4
Foreword

2 Product description
2.1 Function
The wheelchair is intended exclusively for transporting one person on the seat.
The wheelchair can be used on solid ground both indoors and outdoors.
2.2 Product overview
1
Avantgarde DS
Maximum load (in combination with double crossbrace): 140kg
Thanks to its closed frame geometry, the Avantgarde DS exhibits very rigid and sporty driving characteristics.
1 Side panel with clothing guard 9 Drive wheel with handrim
2 Seat/seat pad 10 Release button for quick-release axle
3 Front frame 11 Rear frame
4 Scissor wheel lock 12 Drive wheel adapter
5 Crossbrace 13 Back support tube
6 Single-panel foot plate 14 Push handle
7 Caster fork 15 Back support/back support upholstery
8 Caster wheel
6
Product description
Avantgarde 4

2
Avantgarde DV
Maximum load (in combination with double crossbrace): 140kg
Thanks to its frame geometry, the Avantgarde DV offers precise leg guidance with the possibility of swinging away
and removing the leg supports. When the leg supports are removed, the upright frame front section allows the
wheelchair to be manoeuvred close to objects.
1 Side panel with arm support/arm pad 9 Drive wheel with handrim
2 Seat/seat pad 10 Release button for quick-release axle
3 Front frame with removable, swing-away leg
support
11 Drive wheel adapter
4 Knee lever wheel lock 12 Rear frame
5 Crossbrace 13 Back support tube
6 Single-panel foot plate 14 Back support/back support upholstery
7 Caster fork 15 Push handle
8 Caster wheel
7Avantgarde 4
Product description

3
Avantgarde CLT
Maximum load (in combination with single crossbrace): 100 kg
The Avantgarde CLT is the weight-optimised sports version for particularly active users. In the version CLT "wel
ded", subsequent modification of the wheel position and back support height was sacrificed in favour of saving
additional weight.
1 Side panel 8 Caster wheel
2 Seat/seat pad 9 Drive wheel with handrim
3 Knee lever wheel lock 10 Quick-release axle release button
4 Front frame with removable, swing-away leg
support
11 Rear frame with permanently welded drive
wheel attachment device
5 Crossbrace 12 Back tube
6 Foot plate (here segmented foot plate, alu
minium)
13 Back support/back support upholstery
7 Caster fork 14 Push handle
8
Product description
Avantgarde 4

3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The wheelchair is intended for everyday indoor and outdoor use, by the user or an attendant, of people with tem
porary or permanent limitations of the ability to walk, inability to walk or difficulty standing up.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product.
The wheelchair may only be used with the options listed on the product order form.
Ottobock assumes no liability for combinations with medical devices and/or accessories from other manufacturers
outside the modular system.
Combinations based on a combination agreement that have been evaluated for effectiveness and safety are an
exception to this.
3.1.1 Special features of the CLT and CLT Ultra options
When fitted with the CLT option, the wheelchair features a permanently welded drive wheel adapter for mounting
the drive wheel; when fitted with the CLT Ultra option, the wheelchair additionally features a permanently welded
back. In these weight-saving versions, the drive wheel and back height cannot be subsequently adjusted. Further
more, installation of certain options (e.g. anti-tipper) is not possible with these versions.
For these reasons, these wheelchair versions are intended only for experienced users with sporting ambitions who,
thanks to their physiological capabilities, are able to handle the wheelchair proficiently. Before supplying one of
these versions, the user should be examined intensively for suitability (adequate physiological capabilities).
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for use
Hazards during preparation for use
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
9Avantgarde 4
Intended use

WARNING
Settings outside the safety limits
Tipping over, falling due to adjustment errors because of failure to observe the physical/psychological require
ments of the user
►In certain versions and with certain settings, the product tends to tip backwards due to its design. This is an
intentional feature designed to enable users with the corresponding physical prerequisites to manoeuvre
quickly and nimbly.
►Users with the necessary physical and psychological preconditions can be supplied with such versions/set
tings. If the physical/psychological preconditions change, the product may no longer be used with these set
tings. Inform the responsible qualified personnel immediately in this case.
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
Risk of hand injuries
CAUTION
Pinching on components
Pinching, crushing due to lack of caution in danger areas
►Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the wheel
chair.
►Do not reach into the spokes of the rotating drive wheel.
►Pay attention not to pinch parts of your body at the wheel lock lever or between the side or frame parts.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
►Wear wheelchair gloves when travelling at high speeds.
Hazards while driving
WARNING
Improper use of the wheel lock
Falling due to abrupt braking, rolling away of the wheelchair, damage to the wheel lock
►Do not use the wheel lock as a driving brake.
►Apply the wheel lock to prevent the wheelchair from moving on uneven ground or during transfers (e.g.into a
car).
CAUTION
Lack of driving experience
Tipping over, falling due to errors in handling the product
►Practise on level, open ground first.
►Learn with the support of an assistant how the product reacts to changes in centre of gravity, e.g.downward
or upward slopes, inclines or when overcoming obstacles.
CAUTION
Leaning forward in the wheelchair
Tipping over, overturning due to incorrect centre of gravity
►Do not lean too far out of the wheelchair when trying to pick up objects.
►Lean well forward with your upper body when climbing gradients, overcoming obstacles on gradients or on
ramps. If users cannot lean their upper body forward, accompanying persons must support the wheelchair
from behind.
10
Safety
Avantgarde 4

CAUTION
Risky operation
Falling, tipping over backwards due to approaching obstacles incorrectly
►Push slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or downhill slopes and
inclines.
►Never cross obstacles at an angle. Always approach obstacles head on (at an angle of 90°).
►Raise the front wheels before crossing obstacles.
►Avoid collisions with obstacles and dropping off curbs/ledges.
►Avoid riding cross-country.
CAUTION
Lack of tipping resistance on public transport
Tipping over, user falls, damage to the product due to incorrect positioning
►When using public transit, always observe the currently applicable legal requirements and the safety notices
of the public transit operator.
►Use the permanently installed seats in the vehicle. If you depend on using your wheelchair as a seat, please
use the designated wheelchair spaces and safety securing equipment provided. Always ensure that you are
held in place securely.
CAUTION
Incorrect handling at level crossings
User may fall or tip over due to driving error
►Only cross railway systems and railway tracks in the designated areas.
►Negotiate level crossings so the caster wheels of the product cannot get caught in the gap between the rail
and the road surface.
CAUTION
Driving in the dark
Risk of collisions with other traffic participants due to lack of lighting
►Wear bright clothing or clothing with reflectors.
►Install active lighting on your product.
►Ensure that the reflectors on the product are clearly visible.
Hazards when overcoming obstacles
WARNING
Overcoming steps and obstacles without assistance
Tipping over, falling of the user due to failure to observe transportation instructions
►Always have accompanying persons help you negotiate steps and other obstacles.
►Use available facilities (e.g. access ramps or lifts).
►If such facilities are not available, have 2 assistants carry you over the obstacle.
WARNING
Improper lifting by attendants
Tipping over, falling of the user due to lifting by removable components
►Only lift the product by firmly mounted components (e.g. main frame, push handles).
►Be sure that the clamping levers of the height-adjustable push handles are firmly tightened.
11Avantgarde 4
Safety

WARNING
Reduced ground clearance with the "foot-propelled chair" option
Tipping over, falling due to getting caught on obstacles
►Please note that wheelchairs with the "foot-propelled wheelchair" option might fall below the minimum ground
clearance of 40mm depending on the selected settings for the lower leg length and the front seat height.
►Adjust your driving to the reduced ground clearance and exercise particular caution with obstacles on the
ground e.g.steps, curbs and thresholds.
Hazard in case of broken skin
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
Hazards due to fire, heat and cold
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
Hazards due to improper use of the product
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
WARNING
Incorrect pushing or pulling of the wheelchair
Risk of falling, tipping over due to user error
►Only the push handles may be used for pushing or overcoming obstacles. The tip-assist should be used in
addition.
►If a stabiliser bar is installed, it must not be used for pulling or pushing.
►The attendant should make sure that he/she has a secure stance and firm grip (on both sides).
►In case of damage, have the push handles repaired promptly.
CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
12
Safety
Avantgarde 4

CAUTION
Uncontrolled driving behaviour, unexpected sounds or odours
Falling, tipping, collision with persons or nearby objects due to defects
►If any faults, defects or other hazards that can lead to personal injury are detected, the product must be taken
out of service immediately. This includes uncontrolled movements as well as sounds that are unexpected or
previously not noted or odours that deviate significantly from the state of the product at the time of delivery.
►Contact the qualified personnel.
NOTICE
Use under incorrect environmental conditions
Damage to product due to corrosion or abrasion
►Do not use the product in salt water.
►Make sure that the wheel bearings are not damaged by sand or other particles.
4.3 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.4 Further information
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (Nameplate).
INFORMATION
Even in the event of compliance with all applicable guidelines and standards, alarm systems (e.g. in department
stores) may respond to your product. Should this happen, remove your product from the area where the alarm
was triggered.
4.5 Nameplate and warning labels
The nameplates are found on the crossbrace.
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IManufacturer’s reference number for the product variant
JSerial number (PI)3),1)
KGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
13Avantgarde 4
Safety

Label Meaning
Fixation point to attach the product in vehicles for transporting
persons with reduced mobility
5 Delivery
5.1 Scope of delivery
• Wheelchair ready for use
• Instructions for use (user)
• Instructions for use for accessories (depending on equipment)
5.2 Options
The standard model can be fitted to the user's personal requirements thanks to a large range of options. For use of
these options: see Page15 ff.
5.3 Storage
5.3.1 Storage during daily use
The wheelchair should always be stored so it is protected against external influences.
5.3.2 Storage during extended disuse
The wheelchair must be stored in a dry place. Specific information for extended storage: see Page45.
It is not necessary to disassemble or fold up the wheelchair.
Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or the
tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the tyres may
become permanently deformed.
During extended storage, the knee lever wheel lock on wheelchairs with PU tyres (=tubeless tyres) must be
released since tyre deformation may otherwise result.
6 Preparing the product for use
6.1 Assembly
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►When folding the wheelchair out or together, only grip by the specified components.
CAUTION
Failure to verify readiness for use before putting into operation
Tipping, falling due to incorrect adjustment or installation
►Before you start using the wheelchair for the first time, check the chosen wheelchair settings with the support
of qualified personnel.
►After every assembly, check for proper mounting of the drive wheels. The quick-release axles must be
securely locked in the receiver bushings.
►Pay particular attention to the stability against tipping, free running of the drive wheels and correct function of
the wheel locks.
►Check the tyre pressure. The correct tyre pressure is printed on the sidewall. Ensure that the pressure is the
same in both tyres.
INFORMATION
On the topic of disassembly/transport: see Page35.
It only takes a few simple steps to prepare the wheelchair for use:
14
Delivery
Avantgarde 4

1) Attach the drive wheels to the quick-release axle mounting (see fig.4). The quick-release axles must not be
removable after releasing the push-button.
INFORMATION: With "lock-release assist" option: see Page25. With "drive wheel for one-handed
operation" option: see Page26.
2) Loosen the safety strap (see fig.5).
3) Unfold the wheelchair (see fig.6).
INFORMATION: While you are next to the wheelchair, tip it slightly toward you and press on the edge
of the seat upholstery closest to you.
4) Only with "drive wheel for one-handed operation" option: Insert the telescoping rod (see Page26).
5) If necessary: Attach the leg supports (see Page16).
Fold down the foot plates. When using a single-panel foot plate, be sure the support of the foot plate is locked
into the receiver (see fig.7).
6) Fit the seat cushion (see Page20). The seat cushion is secured against sliding by being pressed onto the
hook-and-loop closure.
4 5
6 7
7 Use
7.1 Instructions for use
• Attaching loads (e.g.backpacks) can adversely affect stability. Therefore, suspending additional loads on the
wheelchair is not permitted.
• The recommended overall width for manual wheelchairs in an operational state is 700mm. This specification
should ensure unhindered use of escape routes,for example. Please note that the product dimensions can
exceed the recommended value in versions with very large seat widths (for more information see see Page45
ff.).
• The wheelchairs in this series fully satisfy the minimum technical requirements for wheelchairs transportable by
train. However, please note that it is possible that not every individual wheelchair will fulfil the minimum require
ments due to the variation in designs (please see see Page46 for further details).
15Avantgarde 4
Use

7.2 Getting in and transferring
CAUTION
Incorrect handling when getting in
Risk of falling, tipping or rolling away due to incorrect handling
►Activate the wheel lock each time before you get into or out of or transfer to or from the wheelchair.
►Always get into the wheelchair from the side, where possible.
►Never step on the foot plates when getting in and out.
►Do not support yourself on the wheel lock when getting in/out.
Users can choose the method for getting into and out of the wheelchair which is most suitable for them. The
respective procedure should be discussed and practised with a therapist.
As a rule, the frame tubes, seat bottom or side panels can be used as supports for getting into the wheelchair.
If getting in independently is not possible, transferring or getting in always has to be performed with the help of an
assistant. The manufacturer also offers transfer aids for getting in, such as transfer boards.
7.3 Legrests
CAUTION
Improper use of the legrests
Tipping over, falling due to errors in handling the product
►Fold up the footplates before getting in.
WARNING
Reduced ground clearance with the "foot-propelled chair" option
Tipping over, falling due to getting caught on obstacles
►Please note that wheelchairs with the "foot-propelled wheelchair" option might fall below the minimum ground
clearance of 40mm depending on the selected settings for the lower leg length and the front seat height.
►Adjust your driving to the reduced ground clearance and exercise particular caution with obstacles on the
ground e.g.steps, curbs and thresholds.
The legrests support the user's legs.
The height of the legrest has been adjusted by qualified personnel to the length of the user's lower legs.
The angle of the footrest has been set by the qualified personnel so that it allows the ankles to rest in a comfortable
position.
7.3.1 Removing and attaching the leg supports
The leg supports of the Avantgarde DV can be removed to make it easier to get in and out as well as for transport.
Removing the leg supports – leg support with leg support holder
1) Fold the foot plate up (see fig.8).
2) Pull the release lever for the leg support to the side (see fig.9).
3) Swing the leg support out by 90° and remove it from the leg support retainer (see fig.10).
Attaching the leg supports – leg support with leg support holder
1) Hold the leg support 90° out to the side and insert it into the leg support retainer (see fig.11).
2) Swing the leg support into the direction of travel until it engages (see fig.10).
3) Fold the foot plate down (see fig.8).
16
Use
Avantgarde 4

8 9
10 11
Removing the leg supports – elevating leg support
1) Activate the release lever (see fig.12, item1).
2) Swing the leg support outwards and to the side by 90° (see fig.12, item2) and pull up to detach.
Attaching the leg supports – elevating leg support
1) Hold the leg support 90° out to the side and insert the pivot bearing into the leg support retainer (not pictured).
2) Swing the leg support into the direction of travel until it engages.
12
7.3.2 Folding the foot plate up and down
Segmented footplate
►Hold the footplate by the edge and fold it up or down (see fig.8).
Folding up and swinging away the single-panel foot plate
1) Unhook the foot plate on one side and fold it up to the side (see fig.13).
2) If necessary, the folded up foot plate can also be swung away to the side (see fig.14).
17Avantgarde 4
Use

13 14
Folding down the single-panel foot plate
►Fold down the foot plate and make sure that the support of the foot plate is locked into the receiver (see
fig.13).
Additional option "lock for single-panel foot plate"
With this additional option, the foot plate can also be locked in the support (see fig.15).
Proceed as follows to fold the foot plate up and down:
1) Release the lock by pulling on the key ring (see fig.16). Fold the foot plate up to the side.
2) If necessary, the folded up foot plate can also be swung away to the side (see fig.14).
3) Fold down the foot plate and make sure that the foot plate lock engages in the receiver (see fig.15).
15 16
7.3.3 Adjusting the angle of the elevating leg support
1) Turn the release lever upwards to the stop (see fig.17).
Alternative: The leg support can also be elevated without operating the release lever.
2) Simultaneously move the leg support to the desired angle.
3) Twist the release lever back down.
→The leg support automatically snaps into place in the next free position (see fig.18).
18
Use
Avantgarde 4

17 18
7.3.4 Removing and fastening the calf strap
The calf strap offers additional support for the user’s legs. It also prevents the feet from sliding off the foot plate
into the danger area. The calf strap can be removed for cleaning.
Fastening the calf strap
1) Open all hook-and-loop closures.
2) Thread the calf strap through the eyelet on the end piece of the leg support holder and fasten it with hook-and-
loop (see fig.20, see fig.21, item1).
3) Only with segmented plastic foot plates: Thread the calf strap through the eyelet on the side of the foot
plate and fasten it with hook-and-loop (see fig.21, item2; see fig.22).
4) Only with segmented aluminium foot plates: Fasten the calf strap on the underside of the foot plate with
hook-and-loop (not pictured).
5) Adjust the length and fasten the hook-and-loop closure (not pictured).
Removing the calf strap
1) Open all hook-and-loop closures.
2) Remove the calf strap.
19 20
21 22
19Avantgarde 4
Use

7.3.5 Adjusting the leg supports
Further adjustments may be made only by qualified personnel.
7.4 Seat cushion and back upholstery
WARNING
Seat cushions and back support pads may ignite
Burns due to user error
►The seat and back support upholstery as well as seat cushions, padding and covers fulfil the normative
requirements for flame resistance. However, they may still ignite if fire is handled improperly or negligently.
►Keep away from all ignition sources, especially lit cigarettes.
CAUTION
Wear of the seat and back upholstery
Loss of functionality due to prohibited continued use
►Have the seat and back upholstery replaced immediately in case of damage.
The product is equipped with seat and back upholstery. Hook-and-loop fasteners on the seat upholstery are used
to attach the seat cushion. The seat cushion ensures pressure relief during use of the wheelchair. It was chosen by
qualified personnel according to the needs of the user.
7.4.1 Removing and fastening the seat cushion
The seat cushion can be removed from the wheelchair for cleaning.
1) Lay the seat cushion onto the seat upholstery and secure it against sliding by pressing it onto the hook-and-
loop fastener (see fig.23).
2) To remove, detach the seat cushion from the hook-and-loop fastener on the upholstery.
23
7.4.2 Removing and fastening the back support pad
The back padding can be removed from the wheelchair for cleaning.
Removing the back support pad
1) Remove the seat cushion.
2) Pull the back support pad off the seat upholstery towards the rear (see fig.24).
3) Pull the back support pad off the hook-and-loop straps of the back support upholstery (see fig.25).
Fastening the back support pad
1) From the rear, apply the edge of the back support pad to the upper hook-and-loop strap (see fig.25).
2) Fold down the back support pad and secure it to the upholstery straps with hook-and-loop fasteners (see
fig.25).
3) Pull the part of the flap that can be fastened forward and attach it to the seat upholstery with the hook-and-loop
fastener (see fig.24).
20
Use
Avantgarde 4
