Oval WaterMaster User manual

1
Electromagnetic Flowmeter
WaterMaster〈Transmitter〉
Thank you for choosing the WaterMaster. This product is manufactured under the stringent quality control
and thoroughly tested and inspected before its shipment from our factory.
This instruction manual is designed to assist the user to obtain the best performance of the product
throughout its service life. In order to take sufcient care, please read this manual carefully before the use
and keep it handy for quick reference.
Ins. No. C-901TM-2-E

C-901TM-2-E
2
CONTENTS
1. SAFETY..........................................................................................................................................................3
1.1 Electrical Safety ......................................................................................................................................3
1.2 Symbols ..................................................................................................................................................3
1.3 Health and Safety Considerations ..........................................................................................................4
2. MECHANICAL INSTALLATION .....................................................................................................................5
2.1 Installation Conditions.............................................................................................................................5
2.2 Outline Dimensions.................................................................................................................................7
3. ELECTRICAL INSTALLATION.......................................................................................................................8
3.1 Separately Mounted Transmitter/Sensor Arrangement ..........................................................................8
3.2 Transmitter Terminal Connection............................................................................................................8
3.3 Cable Preparation (Separately Mounted Transmitter only)....................................................................9
3.4 Sensor Cable Connection (Separately Mounted Transmitter) ..............................................................10
3.4.1 Sensor Cable Terminal Connection and Recommended Cable Length .....................................10
3.5 Output Connection ................................................................................................................................11
3.5.1 Pulse Output ................................................................................................................................11
3.5.2 Alarm Output/Logic Output ..........................................................................................................12
3.5.3 Current Output (4 to 20mA) - HART (FEX100) Variant ...............................................................14
3.5.4 Test Point Access ........................................................................................................................14
3.6 Power Supply Connections...................................................................................................................15
3.6.1 AC Power Supply.........................................................................................................................15
3.6.2 DC Power Supply .......................................................................................................................16
3.6.3 DIP Switches for Setting ..............................................................................................................17
3.7 Reassembling Cartridge and Front Cover ............................................................................................17
4. START-UP AND OPERATION.....................................................................................................................19
4.1 Menu and Parameter Navigation ..........................................................................................................19
4.2 Start-up Screens ...................................................................................................................................20
4.3 Security Levels and Access by Passwords...........................................................................................22
4.3.1 Default Passwords.......................................................................................................................23
4.3.2 Entering Passwords.....................................................................................................................23
4.4 Easy Setup............................................................................................................................................24
5. GENERAL SPECIFICATIONS .....................................................................................................................25
6. FLOW RANGE .............................................................................................................................................26
7. PRODUCT CODE EXPLANATION ..............................................................................................................27
7.1 Body......................................................................................................................................................27
7.2 Dedicated Cable for Separately Mounted Type ....................................................................................27
This manual uses the precaution words "NOTE", "CAUTION", and "WARNING" as explained
below:
NOTE: Notes are separated from the general text to bring the user's attention to
important information.
CAUTION: Caution statements inform the user of hazards or unsafe practices which
could result in minor personal injury or product/property damage.
WARNING: Warning statements inform the user of hazards or unsafe practices which
could result in severe personal injury or death.

C-901TM-2-E

Direct current supply only
Alternating current supply only
Both direct and alternating current
supply
The equipment is protected through
double insulation
Warning - Refer to the manual for
instructions
Caution - Risk of electric shock
Protective earth (ground) terminal
Earth (ground) terminal
1. SAFETY
The contents of this manual is only for the purpose of supporting our customers to use our product
efficiently. The use of this manual for other purposes is clearly prohibited. Also, all or part of this manual
shall not be reproduced without our permission in advance.
1.1 Electrical Safety
This instrument complies with the requirements of CEI/IEC 61010-1:2001-2 "Safety Requirements for
Electrical Equipment for Measurement, Control and Laboratory Use", NIST, and OSHA. Refrain from
using the instrument in a way not specified by OVAL, or protection of the instrument may be ruined.
1.2 Symbols
Below are the meaning of symbols indicated on the product label.

C-901TM-2-E

1.3 Health and Safety Considerations
Note the following points in order to use our products safely without any health risks:
・Installation must be executed in compliance with safety requirements of this product, any associated
instruments, and local environment.
・Installation and use of this product and any associated instruments must be in compliance with the
relevant national and regional standards.
・Read the relevant sections of the manual before proceeding.
・Pay attention to the warning labels on containers and packages.
・Only appropriately trained personnel should perform installation, operation, maintenance, and servicing
by following the manual.
・When operating with high pressure and/or high temperature, normal safety precautions must be
performed in order to prevent accidents.
・Keep chemicals away from heat and temperature increase. Powders must be kept dry. Perform normal
safety handling procedures.
・Do not mix two chemicals when disposing.
・Product liability - advice and support provided free of charge are offered in good faith; OVAL will not be
held liable, however.
If safety advice regarding the use of the product written in this manual or relevant hazard data sheets (if
applicable) is required, contact OVAL.
Warnings
・System setting must be performed only by users or personnel with approved right to access (user
privileges).
・Read all related sections of this manual before setting the system or changing system parameters.
・Associated instruments must be installed and used in compliance with relevant national and regional
standards.

C-901TM-2-E

2. MECHANICAL INSTALLATION
2.1 Installation Conditions
Fig. 2.1 Location selection
Fig. 2.2 Operating temperature range (ambient)
Fig. 2.4 Vibration
60/70℃
(Integrallymounted/
Separatelymounted)
Min.
-20℃
Fig. 2.3 Shade
Securesufficientspacefor
readingdisplay.

C-901TM-2-E

Fig. 2.5 Leakage
Fig. 2.6 Degree of protection
Fig. 2.7 Access to transmitter
IP67 (NEMA 4X)
Submersiondurationoftransmitter:
1m<12hours(accumulatedtime)
Positionaccessibletotransmitter

C-901TM-2-E

Fig. 2.8 Dimension of integrally mounted transmitter
Fig. 2.9 Dimension of separately mounted transmitter
118
103 202
201
Unit: mm
2.2 Outline Dimensions
205
103 R3.2
71
179
152
Unit: mm
Install the separately mounted transmitter in stable place using three M5 screws.
(M5 screws are not provided as accessories.)
CAUTION:

C-901TM-2-E

Fig. 3.1 Separately mounted transmitter installed on roadside cabinet
Fig. 3.2 Access to transmitter terminals
3. ELECTRICAL INSTALLATION
3.1 Separately Mounted Transmitter/Sensor Arrangement
Powersupply
3.2 Transmitter Terminal Connection
○
A
○
A
○
A
○
A
○
B
○
C
○
C
○
C
○
D
○
A
○
B
○
C
○
D
○
E
○
E
Housing
Innerdeviceoftransmitter(cartridge)
Backplaneboard
Frontcover
Screw
Powerindicator(LED)
Screw
Turnlock
Turningdirection
Cable for bonding connection must be 4mm2(< 10AWG) or more.
CAUTION:
WARNING: Isolate the transmitter from the power supply device before detaching the front cover.

C-901TM-2-E
9
Fig. 3.3 Cable glands/cable entries
Refer to Fig. 3.2.
1. Loosen four screws on the front cover without removing them.
2. Detach the front cover.
3. Conrm that power indicator (LED) on the backplane is turned off.
4. If unable to see the screws , unlock the turn lock and turn the transmitter cartridge to align the
screw holes and screw heads.
5. Loosen three screws on the transmitter cartridge and lift the transmitter cartridge off the housing.
Sparecablegland
OutputcableglandOutputcablegland
Powersupplycablegland
Outputterminals
Powersupplyterminals Sensorcableterminals
Backplaneboard
Internalground(AlternativePE)
Internalground(AlternativePE)
Externalground
Outputconnectiontestpoints
(Checkpinsformaintenance)
3.3 Cable Preparation (Separately Mounted Transmitter Only)
Cable for connection to the transmitter and sensor terminal box is included with the product. Preparation
of cable terminals must be performed by the customer, however.
1. Remove insulation of the cable as shown in Fig. 3.4 on page 10 and expose each core wire, then
cut the core wires to designated length.
2. Bundle screen wires D1/TFE (Orange) and D2 (Yellow) with outer drain wire by twisting, then cover
the bundle with a sleeve (Green/Yellow).
WARNING:
While power indicator (LED) is turned on, power is still supplied to the transmitter.
Isolate the power supply from the transmitter before proceeding further.

C-901TM-2-E
10
Fig. 3.4 Sensor cable connection - separately mounted transmitter
3.4.1 Sensor Cable Terminal Connection and Recommended Cable Length
*Innerwire
**ConnectthedrainwiretoterminalSCRforcathodicallyprotectedsystem
(orincaseswhereagroundscrewofthetransmitterhousingisunavailable).
M1
Brown
M2
Red
SCR
screen
D1/TFE
Orange
D2
Yellow
3
Green
(sleeve)
S2
Blue
(screen)
S1
E2
Blue
(*signal)
E1
Purple
(*signal)
Purple
(screen)
Cutcablesto70mm Cutcablesto60mm
RefertoSection3.3onpage9fornecessary
cablepreparationbeforeconnectingthecable.
**Drainwire
(Twistscreenwires
D1/TFE(Orange)and
D2(Yellow)withouter
drainwireintoabundle,
thencoverwithsleeve
(Green/Yellow).
3.4 Sensor Cable Connection (Separately Mounted Transmitter)
Make the connection as instructed as follows:
1. Make sure to use the cable included with the product.
2. Bundle screen wires D1/TFE (Orange) and D2 (Yellow) with outer drain wire by
twisting, then cover the bundle with a sleeve (Green/Yellow).
3. For normal (not cathodically protected) system, connect drain wire to ground
screw.
4. Connect the drain wire to terminal SCR for cathodically protected system and
ensure that each signal wire is not touching the transmitter housing.
5. If a ground screw of the transmitter housing is unavailable, connect the drain
wire to terminal SCR for cathodically protected system.
6. After wiring, make sure that cable glands are securely tightened. Do not over-
tighten if using plastic cable glands in order to avoid damaging sealing
properties. Firmly tighten the cable glands by hand first, then use an appropriate
spanner or wrench to further tighten 1/2 to 3/4 turns.
CAUTION:

C-901TM-2-E
11
Fig. 3.5 Pulse output connection
3.5.1 Pulse Output
XXXX XXXX 42415161
    52
    62
PLC or Datalogger
COM DO1 DO2
Fig. 3.6 Mechanical relay etc. connection
+‒ 123456
123456
 XXXXXXXX 42415161
     52
     62
DCpowersupply
Reverseflowoutput(DO2)
Counter/totalizer
Forwardflowoutput(DO1)
Counter/totalizer
COM DO1 DO2
3.5 Output Connection
1. To limit voltage fluctuation, inductive load needs to be suppressed.
2. Setting of output operation can be changed through parameter.
3. Pulse and alarm circuits are electrically separated from all other outputs. External
isolator is normally unnecessary.
CAUTION:
Make sure not to mistake polarity of output DO1 and DO2. Common (negative)
connection for these outputs is assigned to "COM".
CAUTION:

C-901TM-2-E
12
Fig. 3.7 Remote measurement/electric counter etc. connection
+‒
+‒
 XXXXXXXX 42415161
     52
     62
Reverseflowoutput(DO2)
Counter/totalizer
Forwardflowoutput(DO1)
Counter/totalizer
COM DO1 DO2
123456
123456
Fig. 3.8 Alarm/logic output connection
3.5.2 Alarm Output/Logic Output
COM DO3
XXXX XXXX 42415161
    52
    62

C-901TM-2-E
1
Fig. 3.9 Alarm/logic output connection
XXXXXXXX 42415161
    52
    62
+
‒
DCpowersupply
COM DO1 DO2
Alarm1
Alarm2
and/or
Bell
Horn
DO3
Fig. 3.10 Relay and timer output connection
XXXXXXXX 42415161
    52
    62
+
‒
COM DO1 DO2
Relay
TimerSwitch
R
and/or
DCpowersupply
Alarm1
Alarm2
1. Regular alarm/log output uses DO3 (terminal 61). DO1 (41) and DO2 (51) may also
be set as alarm/logic output if necessary. In such cases they will be unavailable
as double pulse output as shown in Figs. 3.6 and 3.7.
2. The bell and horn are shown as an example only. Any appropriate alarm device,
such as a lamp, siren, or buzzer can be used.
CAUTION:
Relay and timer switch shown are shown as an example only. Make connection as
necessary.
CAUTION:

C-901TM-2-E
1
Fig. 3.11 Current output (4 to 20mA) - HART variant connection
3.5.3 Current Output (4 to 20mA) - HART (FEX100) Variant
Refer to the Programing Guide for details of HART protocol communication.
+ –
Fig. 3.12 Access to test points on transmitter backplane board
3.5.4 Test Point Access
IC+*IC‒*
Unused
O/P1
4to20mA
COM
O/P2
Alarm/logicoutput
Unused
Pulseoutput
(Alarm/logicoutputdependingonassignment)
These output connection test points are for maintenance purpose only and not
normally used.
CAUTION:
1. Digital outputs of WaterMaster are NPN optocoupled transistors used as
switches.
2. Maximum allowable voltage of collector is 30V DC.
3. Maximum allowable current across both ends of transistor is 220mA.
CAUTION:

C-901TM-2-E
1
Fig. 3.13 AC power supply connection
3.6.1 AC Power Supply
Transmitterlabel(AC)
Externalgroundscrew
ACpowersupplythroughsuitable
isolatorandfuse
ACfuseF1250mATypeT
>4mm2（<10AWG）Copperwire
PowerindicatorLED
Powersupply＋
Powersupply−
COM
Internalgroundscrews
3.6 Power Supply Connections
WARNING:
1. Electrical installation and earth grounding must be implemented in compliance
with relevant national and regional standards.
2. Power supply must be connected through suitable isolator and fuses must be
installed in compliance with relevant standards.
3. When changing fuses F1 or F2, isolate power supply device and wait 20 seconds
before opening the housing.
4. Replace fuses with appropriate parts. Refer to Fig. 3.13 (AC power) and Fig. 3.14 (DC
power) on page 16.

C-901TM-2-E
1
Fig. 3.14 DC power supply connection
3.6.2 DC Power Supply
Internalgroundscrews
DCfuseF22ATypeT
PowerindicatorLED
DCpowersupplythroughsuitable
isolatorandfuse
Externalgroundscrew
>4mm2（<10AWG）Copperwire
Transmitterlabel(DC)
Powersupply＋
Powersupply−
COM

C-901TM-2-E
1
Fig. 3.15 DIP switches for setting
3.6.3 DIP Switches for Setting
Three DIP setting switches are installed on backplane board of the transmitter.
Following is the factory setting of these switches:
1. Separately mounted transmitter - All OFF
2. Integrally mounted transmitter - SW3 ON
DIPsetting
switches
SW3 SW2 SW1
OFF
ON
FunctionofDIPswitches
（SW1）−Read-only/Protection
（SW2）−Unused
（SW3）−Integraltransmitter
(Internalsensormemory)
PROFIBUS cartridge label
WARNING:
Make sure that the transmitter is isolated from power supply device before restoring
the front cover on.
3.7 Reassembling Cartridge and Front Cover
1. Cartridge is categorized by communication type. (Standard: HART communication)
2. The communication types of the cartridge and that of
transmitter's backplane board must be the same.
Pay extra attention if the communication type is special
kind such as PROFIBUS.
The cartridge label of PROFIBUS communication type
is shown on the right for reference.
3. To prevent damage to the cartridge during reassembling,
do not over-tighten the cartridge screws.
CAUTION:

C-901TM-2-E
1
1. Check label on the side of the cartridge and conrm that the cartridge to be installed is of the
correct power supply device and communication bus type (Standard: HART communication).
- An AC cartridge has a black label on its side.
- A DC (and low voltage AC) cartridge has two red DC labels; one on its side, the other on its
backplane board.
2. Align three cartridge screws in line with housing pillars of the cartridge, then carefully tighten the
screws until the cartridge is xed in the appropriate position.
3. If necessary, turn the cartridge to desired position before reassembling the front cover. Refer to Fig.
3.2 on page 8 for detail.
4. Set DIP switch 1 (SW1) to "ON" (Read-only) as necessary. Refer to Fig. 3.15 on page 17.
5. Adjust the position of the transmitter front cover and housing, then carefully tighten the four screws
of the front cover.
Fig. 3.16 Reassembling of cartridge and front cover
Redlabelonthebackof
DCcartridge
RedlabelonDCcartridge
Blacklabelon
ACcartridge

C-901TM-2-E
19
4. START-UP AND OPERATION
4.1 Menu and Parameter Navigation
All system commands and selections can be executed by scrolling between menus using four keys under
the display.
Fig. 4.1 Display and keys
Menu
EasySetup
Exit Select
Item Description
Title of screen with current level/parameter
Main level icon
Menu level title
Prompt started by pressing the Left key
Prompt started by pressing the Right key
Left key - Used for navigating parameters and entering editable parameters
Up/Down key - Used for scrolling menu option and increasing or decreasing editable parameters
Right key - Used for accepting or choosing parameters/options or terminating sub levels
This section explains the options available in "Easy Setup" menu. For details of
other menus and operating levels, refer to Programing Guide.
CAUTION:

C-901TM-2-E
20
4.2 Start-up Screens
At start-up, system status is indicated by the displayed screen type.
Following are four common start-up screen types:
SystemStartup
LOADINGSYSTEMDATA
SystemStartup
NOSENSORDETECTED
DeviceResetting
Offline
SystemStartup
DUALSENSORMEMORY
Rectify&Reset
OK
System Startup
A progress bar is displayed during system start-up to indicate the
duration of start-up process.
Upon completion of system start-up, one of the four following
screens will be displayed depending on the current condition.
NO SENSOR DETECTED
When a sensor cannot be detected during start-up, auto-
recovery routine runs to search the sensor. This routine will
continue to run until the sensor is detected or the routine is
manually stopped.
If [Ofine] is selected ( key is pressed) during auto-recovery,
the transmitter stops operating as flowmeter and makes a
transition to the following condition:
・Plant data and transmitter data: Congurable
・Sensor data: Not congurable
DUAL SENSOR MEMORY
The sensor memory is mounted on the transmitter backplane
board. If two kinds of sensor memories (sensor terminal box
and separately mounted transmitter) are detected for separately
mounted transmitter at start-up, a warning "DUAL SENSOR
MEMORY" will be displayed.
Turn OFF DIP switch SW3 to correct this state.
SystemStartup
LOADINGSYSTEMDATA
SystemStartup
NOSENSORDETECTED
DeviceResetting
Offline
SystemStartup
DUALSENSORMEMORY
Rectify&Reset
OK
If this screen is displayed for an integral
transmitter, confirm that DIP switch SW3 is
turned ON (refer to Fig. 3.15 on page 17).
CAUTION:
