overstock 649-2X User manual

No. Description Q’ty
A
B
C
D
E
F
G
Top Panel
Left Panel
Right Panel
Shelf
Back Panel
Drawer
Front Drawer
1
1
1
1
1
1
1
Assembly Instruction
Item #649-2X
Notre Dame Night Stand
with USB Port
Top Panel (A)
Left Panel (B) Right Panel (C)
Shelf (D) Back Panel (E)
Drawer unit (F) Drawer Front (G)
Parts List
Page 1/4

No. Description Q’ty
RF10019
RF10002
RF10052
RF10041
RF40103
H00001
Screw F6 x 1”
Screw F6 x 1 1/4”
Screw JCB M6 x 30
Screw JCB M6 x 40
Allen Key
Handle
3
2
6
4
1
1
USB Port
RF10019 RF10002
RF10052 RF10041
RF40103 H00001
Input Voltage AC 100-240V 50/60Hz
Input Current ≤ 350mA @ 220V AC w/
full load
Output Voltage 5.0V ± 0.25V
Load Regulation -0.5% (Max)
Output Current 3.1A Max
Output Ripple < 400mV p-p
Eciency > 75% @ 220V AC
Output Plug USB Type A x 4
Over Power ≈ 17W @ 220V AC
Short Protection Auto Recovery
USB Adapter Specications
Hardware
Page 2/4
USB 1 & 2 PORTS
Fast charging ports for devices that
require higher current, ideal for iPads
and Android tablets, while also
compatible with other mobile devices.
USB 3 & 4 PORTS
Standard USB ports, ideal for
smartphones and other mobile
devices.
ON
OFF
1
2
3
4

A
E
RF10052
Step 1.
Invert the Top Panel (A) on a soft surface. Attach Back Panel (E)
into the Top Panel (A) using 2 screw (RF10052) as per Diag. 1.
Step 2.
Attach Left and Right Panel (B&C) into the Top Panel (A)
using 4 screw (RF10052) as per Diag. 2.
Diagram 2.
Diagram 1.
RF10052
E
A
B
C
Page 3/4

Step 3.
Insert Shelf (D) into Left and Right Panel (B&C)
using 4 screw (RF10041) as per Diag. 3.
Step 4.
Attach Handle (H0001) into the Drawer Front (G) using 2 screw (RF10002).
Then attach to the Drawer Unit (F) using 3 screw (RF10041)
and slide in Drawer as per Diag. 4.
Diagram 4.
Diagram 3.
A
B
C
D
RF10041
G
FRF10019
H00001
RF10002
Page 4/4
