Ovislink AirLive WLA-5000AP Instruction Manual

WLA-5000AP and Mikrotik Router Board Connection Guide
This document guides you to connect WLA-5000AP and Mikrotik RB-433 with wireless
interface. When Mikrotik is set to be AP Bridge mode, WLA-5000AP can connect to it by using
client infrastructure mode and WDS Bridge pure MAC mode.
Topology:
Devices:
Mikrotik RB-433 Router Board with one Atheros AR5414A mini-PCI with RouterOS installed.
WLA-5000AP with firmware version 2.00e23 or later
Laptop * 2
Software:
Winbox configuration tool (download)
In this document, we use winbox for Mikrotik configuration only.
Note: Please change the IP address of WLA-5000AP and Laptops before process. In this
document, we use IP address as above topology. Default IP address of Mikrotik ether1
is 192.168.88.1.
Interface: wlan1
Address: 192.168.88.2/24
Network: 192.168.88.0
Broadcast: 192.168.88.255
WLA-5000AP
Address: 192.168.88.3/24
Network: 192.168.88.0
Broadcast: 192.168.88.255
Laptop2
Address: 192.168.88.25/24
Network: 192.168.88.0
Broadcast: 192.168.88.255
Laptop2
Address: 192.168.88.116/24
Network: 192.168.88.0
Broadcast: 192.168.88.255
Interface ether1
Address: 192.168.88.1/24
Network: 192.168.88.0
Broadcast: 192.168.88.255

Connection 1: Mikrotik in AP Bridge mode, WLA-5000AP in client infrastructure mode
1.1 Miktotik ap bridge configuration:
Step1. Launch winbox software, enter 192.168.88.1 in “Connect To” field and click “Connect”
button.
The management interface shows up as following.

Step2. Add IP address to wireless interface (waln1)
Click IP Address
It then Address List menu, click “+” to add IP address on network interface.
Click here to add IP address on
network interface

When “New Address” dialog box shows, fill the IP address information to wlan1.
In our example, wlan1’s IP address is set to be:
Address: 192.168.1.2/24
Network: 192.168.1.0
Broadcast: 192.168.1.255
Interface: wlan1
Click Apply and OK button to save.
Right click on wlan1 interface and click “Enable” button to enable.

Step3. Configure wlan1 to AP Bridge mode
Double click on wlan1 to configure.
Right click on wlan1
Wlan1 is enabled,
double click to configure

Select “ap bridge” mode and change parameters
In our sample, we use these parameters:
Mode: ap bridge
Band: 5GHz
Frequency: 5180MHz (Channel 36)
SSID: MikroTik
Security: default (none)
Antenna Mode: antenna a (main output of mini-PCI)
Step4. Bridge wlan1 and ether1
All interfaces can not communicate to each other by default, so that wlan1 and ether1 can not
send data to each other. It needs to add bridge to these two interfaces.
Click “Bridge” menu and “+” button.

It shows “New Interface” dialog box. Click “Apply” and “OK” to save. In our example, we did not
change parameters here.
Add wlan1 and ether1 to Ports. Click “Ports” and “+”

It then shows the “New Bridge Port” dialog box, select and set parameters then click “Apply”
and “OK” button to save.

In our example, we add ether1 and wlan1 to Bridge.
Note: Please add ether1 first.
Step5. Back to Interface and confirm interfaces are enabled. In our example, bridge1,
ethernet1 and wlan1 must be enabled.

1.2 WLA-5000AP connect to Mikrotik using client infrastructure mode
Step1. Change operation mode to client infrastructure
In “Advanced Settings” “Operational Mode” select “Client Infrastructure” and click “Apply”
button to save. WLA-5000AP then reboot to client infrastructure mode.

Step2. Site survey and connect to Mikrotik.
Click “Device Status” “Site Survey”, you will see Mikrotik’s SSID, click “ASSOCIATE” button
to connect.
Laptop2 ping to Laptop1:

Connection 2: Mikrotik in AP Bridge mode, WLA-5000AP in WDS Bridge pure MAC mode
This connection follows connection 1, Mikrotik add WDS interface in wlan1. WLA-5000AP
changes to WDS Bridge pure MAC mode.
2.1 Mikrotik add WDS in wlan1
Step1. Add WDS interface for wlan1. Click Interface “+” and select “WDS”
Enter the WLA-5000AP’s MAC address in the “WDS Address” field. Click “Apply” and “OK”
button to save.

The interface then shows WDS for wlan1, as following:
Step3. Add WDS to Bridge Ports

Step3. Enable WDS in wlan1
Double click wlan1, and change parameters in “Interface <wlan1>” dialog. Click “Apply” and
“OK” button to save.
In our example, we select “WDS Mode” to “static” and “WDS Default Bridge” to “bridge1”.
Some Access Point can not send SSID in WDS mode. Please enable “WDS Ignore SSID” in
this situation.
In our example, we use the original SSID “MikroTik”.
2.2 WLA-5000AP WDS configuration
Login to WLA-5000AP. In “Advanced Settings” “Operation Mode”, select “WDS Bridge” filled
parameters and click “ADD” button to add.
In our example, we use these parameters:
WDS Bridge Mode: Pure MAC Mode
Name: Mikrotik_Router
SSID: Mikrotik
MAC address: 00-0c-42-1f-98-5d
Security Policy: None
Double click wlan1

When configured successfully, the added WDS shows in the list.
Laptop2 ping Laptop1

Security Connection Configuration
In this document, we introduce WEP, WPA and WEP encryption in Mikrotik. Please note that
WLA-5000AP WDS mode provide WEP encryption only. If you need to use WPA and WPA2,
please configure WLA-5000AP to Client Infrastructure mode.
Click “Wireless” “Security Profiles”, and double click on default profile.
It then pops up the Security Profile <default> dialog.
Double Click to configure

In security mode, “dynamic keys” is to set WPA and WPA2 encryption and “static keys“ is to set
WEP encryption.
When select “dynamic keys”, you can select Authentication Types, Unicast Ciphers and Group
Ciphers.
When select “static keys”, you have to fill the key in “Static Keys” dialog.
