Ozito Power xchange pxcblltc-318 User manual

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST

RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE

WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING

YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER

SERVICE HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL

NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER

SERVICE REPRESENTATIVE WILL TAKE YOUR CALL

AND ANSWER ANY QUESTIONS YOU MAY

HAVE RELATING TO THE WARRANTY POLICY

OR PROCEDURE.

OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

The benets provided under this warranty are in addition

to other rights and remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded

at law. You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired

or replaced if the goods fail to be of acceptable quality and the failure does not

amount to a major failure.

Generally you will be responsible for all costs associated with

a claim under this warranty, however, where you have suffered

any additional direct loss as a result of a defective product you

may be able to claim such expenses by contacting our customer service helpline

above.

0317

WARNING

The following actions will result in the warranty being

void.

• If the tool has been operated on a supply voltage other

than that specied on the tool.

• If the tool shows signs of damage or defects caused

by or resulting from abuse, accidents or alterations.

• Failure to perform maintenance as set out within the instruction manual.

• If the tool is disassembled or tampered with in any way.

5 YEAR REPLACEMENT WARRANTY

Your Product is guaranteed for a period of 60 months from the original date of

purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it

will be replaced in accordance with the terms of this warranty. Lithium Ion

batteries and chargers are covered by a 36 month

warranty. Warranty excludes consumable parts, for example: cutting blades.

CORDLESS

GRASS TRIMMER

INSTRUCTION MANUAL

SPECIFICATIONS

Voltage: 18V

Battery: 3.0Ah Li-ion

Charge Time: 60 min

No Load Speed: 8,500/min

Cutting Diameter: 240mm

Weight: 2.45kg

PXCBLLTC-318

WHAT’S IN THE BOX

Cordless Blower

3.0Ah Battery & Fast Charger

Grass Trimmer

ozito.com.au

Blades x 10

ONLINE MANUAL

Scan this QR Code with your mobile

device to take you to the online

manual.

Fitting the Adjustable Handle

1. Fit the handle mounting bracket

onto the upper section of the shaft.

Note: You will need to carefully ex

the mounting bracket just enough to

slip over the shaft. Do not over ex as

this can damage or break the mounting

bracket.

2. Place the adjustable handle on

the mounting bracket, then pass

the screw with washer through

the mounting bracket and onto the

adjustable handle lever.

14 15 16 17 18

KNOW YOUR PRODUCT

1. ASSEMBLY

SETUP & PREPARATION

WARNING! ENSURE THE TOOL IS SWITCHED

OFF AND BATTERY DISCONNECTED BEFORE

PERFORMING ANY OF THE FOLLOWING TASKS.

CORDLESS GRASS TRIMMER

1. Telescopic Shaft

2. Shaft Adjustment Collar

3. Adjustable Handle Lever

4. Adjustable Handle

5. Lock-off Switch

6. Sure Grip Handle

7. On/Off Trigger

8. Battery Seating

9. Head Tilt Button

10. Edging Guide

11. Cutter Head

12. Safety Guard

13. Cutting Blade

ACCESSORIES

14. Battery Release Tab

15. Battery Charge LED’s

16. Battery Charge Indicator Button

17. Charger LED’s

18. Charger

19. Blades x 10

Fitting the Safety Guard

Note: The Safety Guard can only be

tted before the Spindle Plate.

1. Align the tabs of the safety guard

with the recess in the back of the

cutter head.

1. Place the Spindle Plate onto the

spindle and secure in place with

screw provided.

2. Slide in until it clicks

into place.

WARNING! NEVER USE THE GRASS TRIMMER

UNLESS THE SAFETY GUARD IS PROPERLY FITTED.

Fitting the Spindle Plate

2. ADJUSTING THE TRIMMER

1. Release the adjustable handle

lever.

1. Place the big hole in the blade

onto the blade mount on the

bottom of the spindle plate.

3. To remove the blade push the

blade towards the centre of the

spindle and then slide off.

1. Press and hold the head tilt

button.

2. Tilt the cutter head to the desired

angle.

2. Rotate the head into the desired

position.

3. Ensure the head has clicked

into a secure position before

operating.

3. Ensure the head has clicked

into a secure position before

operating.

1. Pull the telescopic shaft away

from the cutter head.

The grass trimmer head has 2 adjustments to allow for the optimal angle and

position for grass trimming or edging.

1. Loosen the shaft adjustment

collar.

2. Rotate the handle into

the desired position and

then lock in place with

the lever.

2. Pull the blade outwards

so that the small hole is

tted into the mount.

2. Extend to the desired

height and then

retighten the shaft

adjustment collar to

secure in place.

Adjusting the Handle

Adjusting the Cutter Head

Head Tilt Head Angle

Adjusting the Height

Attaching a Blade

Battery protection system

The tool is equipped with the battery protection system, which helps to ensure a long

service life.

The output power automatically cuts off during operation when the tool and/or battery

are placed under the following situations:

• When the tool is overloaded:

If this occurs, release the trigger switch and remove causes of overload, then pull

the switch trigger again to restart.

• When the remaining battery capacity becomes low:

Recharge the battery pack.

Note: The battery protection system does not in any way damage the tool.

Note: The indicated capacity may be lower than the actual level during use or

immediately after using the tool.

3. BATTERY & CHARGING

The purchased battery will be shipped in a low charge condition, and requires charging

prior to use. Allow several cycles of charging and discharging (through use of the tool)

for the battery to reach its optimum performance / runtime.

CAUTION: THE CHARGER FOR THIS PRODUCT

SHOULD BE PROTECTED BY A RESIDUAL CURRENT

DEVICE (RATED AT 30MA OR LESS).

1. Connect the charger into a mains power outlet.

4. The charger LED will illuminate

red signifying that the battery is

charging.

3. With the charger sitting on a at

surface, align the raised ribs on

the battery with the recess in the

charger and slide onto the charger

ensuring a rm connection.

2. The charger LED will ash green

showing power is being supplied

to the charger.

5. The charger LED will illuminate

green once the battery is fully

charged.

Charging your lithium ion battery - Fast Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Flashing) Battery is charging (low charge)

RED (Illuminated) Battery is charging (mid charge)

GREEN (Illuminated) Battery is fully charged

BOTH (Illuminated) Battery pack is too hot or too cold (charging will begin

automatically when battery reaches correct charging

temperature).

BOTH (Flashing) Defective battery. Never charge a defective battery

pack!

Remove battery pack from charger.

Battery Charge Indicator

The purchased battery is equipped with a

battery charge indicator to show the state of

the battery charge.

Press the charge indicator button and look to

see which LED lights.

Battery requires

immediate charging

Low state of charge, requires charging soon.

Mid state of charge

Full state of charge.

Note: The battery needs to be removed from the tool to check the state of charge.

4. CONTROLS & OPERATION

OPERATION

1. Press and hold the lock-

off switch forward.

Switching On and Off

CAUTION! BEFORE YOU START THE UNIT, MAKE SURE

THAT THE GRASS TRIMMER IS NOT MAKING CONTACT

WITH ANY OBJECTS.

WARNING! INSPECT THE AREA TO BE TRIMMED

AND REMOVE ANY WIRE, CORD OR STRING-LIKE

OBJECTS WHICH COULD BECOME ENTANGLED IN

THE ROTATING BLADE.

WARNING! DO NOT OPERATE THE TRIMMER ON A

TREE, ON A LADDER, OR ON A SCAFFOLD, THIS IS

EXTREMELY DANGEROUS.

CAUTION! BYSTANDERS MUST KEEP A MINIMUM SAFE

DISTANCE OF 10M AWAY FROM THE TRIMMER WHILE IT

IS OPERATING.

WARNING! STONES, PIECES OF METAL AND OTHER

OBJECTS CAN BE THROWN OUT AT HIGH SPEED BY

THE BLADE.

2. Squeeze the on/off trigger to

start the trimmer.

3. To stop the trimmer,

release the On/Off

trigger.

NOTE: DO NOT CUT GRASS WHEN WET. (THE BEST

RESULTS ARE ACHIEVED ON DRY GRASS.)

1. Extend the edging guide to

prevent the cutting head from

getting too close to an object

such as a tree trunk or wall.

2. Hold the trimmer with both

handles for best control and

balance.

3 To turn on squeeze the on/off

trigger whilst holding the lock-off

button down.

4. Move the grass trimmer into the

grass to allow it to cut.

6. Release the on/off trigger and

allow the motor to come to a

complete standstill.

5. Several passes will be required

to cut long grass.

Using the Grass Trimmer

1. Align the ribs of the battery with

the recess in below the handle

and slide in until it clicks into

place.

2. To remove, press and hold the

battery release tab and then slide

out.

Inserting & Removing the Battery

30°

PXCBLLTC-318

MAINTENANCE

•Keep ventilation slots of the trimmer clean at all times. Periodically clean out the grass from the

cutting head and the rim of the blade guard to ensure efcient operation at all times.

•After each use, blow air through the tool housing to ensure it is free from all dust, dirt, etc. Build

up of dust, dirt particles may cause the tool to overheat and shorten the life of the tool.

•If the housing of the trimmer requires cleaning, do not use solvents but a moist soft cloth or soft

brush only.

•Never let any liquid get inside the tool, never immerse any part of the tool into liquid.

•Nolubricationisnecessaryasthetoolhassealedbearings.

•When not in use, the grass trimmer should be stored in a dry, frost free location not within the

reach of children.

WARNING! ALWAYS ENSURE THE TOOL HAS

COMPLETELY STOPPED AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of

the grass trimmer by an unauthorised person or by mishandling of the grass trimmer. This tool is

designed for DIY use - use in commercial or industrial environments will void the warranty.

5. TRIMMING & EDGING

OPERATION

Trimming

Edging

Move the grass trimmer from side to side as

you walk forward, holding it at an angle of

approx. 30° (Light cuts are better than heavy

cuts as they allow the cut grass to fall away

from the cutting head).

Place the edging guide along the ground

and slide the grass trimmer along the edge

of the path.

30°

Replacing the Spindle Plate

1. Unscrew the countersunk head

screw in the centre of the spindle

plate, rotate anti-clockwise to

remove. Once removed put aside

for re-assembly.

2. Lift off the spindle plate.

3. Mount and fasten the new

spindle plate.

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

TROUBLESHOOTING

Power tools that are no longer usable should not be disposed of with household

waste but in an environmentally friendly way. Please recycle where facilities exist.

Check with your local council authority for recycling advice.

Recycling packaging reduces the need for landll and raw materials. Reuse of

recycled material decreases pollution in the environment. Please recycle packaging

where facilities exist. Check with your local council authority for recycling advice.

Spare Part Part No.

Blades PXCLTA-020

Battery pack 3.0Ah PXBP-300

Fast charger PXCG-030

Spare parts can be ordered from the Special Orders

Desk at your local Bunnings Warehouse.

For further information, or any parts not listed here,

visit www.ozito.com.au or contact Ozito Customer

Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR

BATTERY CHARGER.

1. Before using the charger read all instructions and cautionary markings on the charger, battery pack

and the product using the battery pack.

2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use

may result in risk of re, electric shock or electrocution.

3. Do not place any object on top of the charger or place the charger on a soft surface that may result in

excessive internal heat. Place the charger in a position away from any heat source.

4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when

disconnecting the charger.

5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected

to damage or stress.

6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord

could result in the risk of re, electric shock or electrocution.

7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any

way. Have it checked by an electrician or power tool repairer.

8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is

required. Incorrect reassembly may result in a risk of electric shock, electrocution or re.

9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.

Removing the battery pack will not reduce this risk.

10. Never attempt to connect 2 chargers together.

11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed

40ºC (such as inside sheds or metal buildings in summer).

12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt

to use it on any other voltage!

13. The battery pack is not fully charged out of the carton. First read the safety instructions and then

follow the charging notes and procedures.

14. The longest life and best performance can be obtained if the battery pack is charged when the air

temperature is between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or

above 40ºC. This is important and will prevent damage to the battery pack.

15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery

can explode in a re.

16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or

cracks, immediately discontinue use and do not recharge.

17. During charging, the battery must be placed in a well ventilated area.

BATTERY AND CHARGER SAFETY WARNINGS

Problem Cause Remedy

Trimmer is not

starting

Possible clogging Clean the cutter head of any grass.

Battery is low in charge Charge battery

Battery not inserted

properly

Insert battery pack correctly

Trimmer is not

operating at

full capacity

Possible clogging Clean the cutter head of any grass.

Cutting tall grass at

ground level.

Make several passes from top down.

Motor

stops while

operating

Battery has no power Charge battery

Grass wraps

around the

shaft and

trimmer head.

Cutting tall grass at

ground level.

Make several passes from top down.

Wear safety glasses

Read instruction manual

Do not use in the rain or leave the grass trimmer outdors while raining

Keep bystanders away. Do not operate whilst people especially

children or pets are in the area.

Regulator compliance mark

Decibel level

GRASS TRIMMER SAFETY WARNINGS

WARNING! When using mains-powered tools, basic safety precautions, including

the following, should always be followed to reduce risk of ﬁre, electric shock, personal

injury and material damage.

Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.

Save these instructions and other documents supplied with this tool for future reference.

The charger has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating

plate.

Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.

This tools charger is double insulated therefore no earth wire is required.

If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.

Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for

added protection against injury resulting from a possible electrical insulation failure within the tool.

Using an Extension Lead

Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of

damage, wear and ageing. Replace the extension lead if damaged or defective.

When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power

input of the tool or which is damaged or defective may result in a risk of re and electric shock.

The power supply for this products charger should be protected by a residual current device (rated at 30mA

or less). A residual current device reduces the risk of electric shock.

GENERAL POWER TOOL SAFETY WARNINGS

ELECTRICAL SAFETY

WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or serious injury.

Save all warnings and instructions for future reference. The term “power tool” in the

warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)

power tool.

1. Work area safety

a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b. Do not operate power tools in explosive atmospheres, such as in the presence of

ﬂammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose

control.

2. Electrical safety

a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use

any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will

reduce risk of electric shock.

b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges

and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk

of electric shock.

d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power

tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords

increase the risk of electric shock.

e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk of electric shock.

f. If operating a power tool in a damp location is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. Personal safety

a. Stay alert, watch what you are doing and use common sense when operating a power

tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol

or medication. A moment of inattention while operating power tools may result in serious personal injury.

b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust

mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting

to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with

your nger on the switch or energising power tools that have the switch on invites accidents.

d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may result in personal injury.

e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the

power tool in unexpected situations.

f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and

gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g. If devices are provided for the connection of dust extraction and collection facilities,

ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

4. Power tool use and care

a. Do not force the power tool. Use the correct power tool for your application. The correct

power tool will do the job better and safer at the rate for which it was designed.

b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be

controlled with the switch is dangerous and must be repaired.

c. Disconnect the plug from the power source and/or the battery pack from the power

tool before making any adjustments, changing accessories, or storing power tools. Such

preventive safety measures reduce the risk of starting the power tool accidentally.

d. Store idle power tools out of the reach of children and do not allow persons unfamiliar

with the power tool or these instructions to operate the power tool. Power tools are dangerous in

the hands of untrained users.

e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of

parts and any other condition that may affect the power tool’s operation. If damaged,

have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to

bind and are easier to control.

g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,

taking into account the working conditions and the work to be performed. Use of the power

tool for operations different from those intended could result in a hazardous situation.

5. Battery tool use and care

a. Recharge only with the charger speciﬁed by the manufacturer. A charger that is suitable for one

type of battery pack may create a risk of re when used with another battery pack.

b. Use power tools only with speciﬁcally designated battery packs. Use of any other battery packs may

create a risk of injury and re.

c. When battery pack is not in use, keep it away from other metal objects, like paper clips,

coins, keys, nails, screws or other small metal objects, that can make a connection from

one terminal to another. Shorting the battery terminals together may cause burns or a re.

d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If

contact accidentally occurs, ﬂush with water. If liquid contacts eyes, additionally seek

medical help. Liquid ejected from the battery may cause irritation or burns.

6. Service

a. Have your power tool serviced by a qualiﬁed repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

Hold power tool by insulated gripping surfaces, when performing an

operation where the cutting accessory may contact hidden wiring. Cutting

accessory contacting a “live” wire may make exposed metal parts of the power tool “live“ and could give

the operator an electric shock.

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Neverallowchildrenorpeopleunfamiliarwiththeseinstructionstousethegrasstrimmer.

• Avoidusingthegrasstrimmer,whilepeople,especiallychildrenorpets,arenearby.

• Usethegrasstrimmeronlyindaylightorgoodarticiallight.

• Neveroperatethegrasstrimmerwithdamagedguardsorwithoutguardsinplace.

• Switchonthegrasstrimmeronlywhenthehandsandfeetareawayfromthecuttinghead.

• Nevertmetalcuttingblades.

• Useonlythemanufacturer’srecommendedreplacementpartsandaccessories.

• Alwaysremovethebatteryfromthegrasstrimmerwhenleavingthegrasstrimmerunattended.

• Alwaysremovethebatteryfromthegrasstrimmerbeforecarryingoutmaintenanceorcleaning

work.

• Inspectandmaintainthegrasstrimmerregularly.Havethegrasstrimmerrepairedonlybyan

authorized repairer.

• Whennotinuse,storethegrasstrimmeroutofthereachofchildren.

• Facethecuttingheadawayfromyourself,otherpeopleandanimalswhilethepowerisconnectedto

the grass trimmer (especially during operation).

• Removethebatterywhenchangingspoolsorclearinggrassfromundertheguard.

• Removethebatteryfromthegrasstrimmerbeforemakinganyadjustments.

• Usebothhandlesatalltimes

• Keepventilationopeningsclearofdebris.Keephandlesdry,cleanandfreeofoilandgrease.

• Neverreachunderneaththegrasstrimmer(thecuttingbladearea)untilithascompletelystopped

and the battery has been removed.

WARNING! When servicing, use only identical replacement parts. Use of any other parts

may create a hazard or cause product damage. To ensure safety and reliability, all repairs

should be performed by a qualied service technician.

WARNING! This appliance is not intended for use by young or inrm persons unless

supervised by a responsible person to ensure that they can use the appliance safely. Children

should be supervised to ensure that they do not play with the appliance.

CORDLESS

BLOWER

INSTRUCTION MANUAL

SPECIFICATIONS

Voltage: 18V

Battery: 3.0Ah Li-ion

Charge Time: 60 min

No Load Speed: 12,000/min

Max. Air Speed: 210km/hr

Weight: 2.0kg

PXCBLLTC-318

WHAT’S IN THE BOX

Cordless Blower

3.0Ah Battery & Fast Charger

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST

RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE

WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING

YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER

SERVICE HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL

NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER

SERVICE REPRESENTATIVE WILL TAKE YOUR CALL

AND ANSWER ANY QUESTIONS YOU MAY

HAVE RELATING TO THE WARRANTY POLICY

OR PROCEDURE.

OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

The benets provided under this warranty are in addition

to other rights and remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded

at law. You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired

or replaced if the goods fail to be of acceptable quality and the failure does not

amount to a major failure.

Generally you will be responsible for all costs associated with

a claim under this warranty, however, where you have suffered

any additional direct loss as a result of a defective product you

may be able to claim such expenses by contacting our customer service helpline

above.

ozito.com.au

0217

WARNING

The following actions will result in the warranty being

void.

• If the tool has been operated on a supply voltage other

than that specied on the tool.

• If the tool shows signs of damage or defects caused

by or resulting from abuse, accidents or alterations.

• Failure to perform maintenance as set out within the instruction manual.

• If the tool is disassembled or tampered with in any way.

5 YEAR REPLACEMENT WARRANTY

Your Product is guaranteed for a period of 60 months from the original date of

purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it

will be replaced in accordance with the terms of this warranty. Lithium Ion

batteries and chargers are covered by a 36 month

warranty. Warranty excludes consumable parts, for example: blower tube.

Cordless Grass Trimmer

Blades x 10

ONLINE MANUAL

Scan this QR Code with your mobile

device to take you to the online

manual.

6. Battery Release Tab

7. Battery Charge LED’s

8. Battery Charge Indicator Button

9. Charger LED’s

10. Charger

ACCESSORIES

CORDLESS BLOWER

KNOW YOUR PRODUCT

1. ASSEMBLY

SETUP & PREPARATION

1. Align the blower tube with the

outlet of the blower.

3. To remove the blower tube, press

the blower tube release tab

while pulling the tube away from

the housing.

2. Push the blower tube

onto the blower until it

clicks into place.

Fitting the Blower Tube

WARNING! ENSURE THE TOOL IS SWITCHED

OFF AND BATTERY DISCONNECTED BEFORE

PERFORMING ANY OF THE FOLLOWING TASKS.

1. Blow Tube

2. Blow Tube Release Tab

3. Sure Grip Handle

4. Trigger Switch

5. Battery Seating

2. BATTERY & CHARGING

Charging your lithium ion battery

The tools battery has been shipped in a low charge condition, and requires charging

prior to use. Allow several cycles of charging and discharging (through use of the tool)

for the battery to reach its optimum performance / runtime.

CAUTION: THE CHARGER FOR THIS PRODUCT

SHOULD BE PROTECTED BY A RESIDUAL CURRENT

DEVICE (RATED AT 30MA OR LESS).

Battery Charge Indicator

The purchased battery is equipped with a

battery charge indicator to show the state of

the battery charge.

Press the charge indicator button and look to

see which LED lights.

Battery requires immediate charging

Low state of charge, requires charging soon.

Mid state of charge

Full state of charge.

Note: The battery needs to be removed from the tool to check the state of charge.

Battery protection system

The tool is equipped with the battery protection system, which helps to ensure a long

service life.

The output power automatically cuts off during operation when the tool and/or battery

are placed under the following situations:

• When the tool is overloaded:

If this occurs, release the trigger switch and remove causes of overload, then pull

the switch trigger again to restart.

• When the remaining battery capacity becomes low:

Recharge the battery pack.

Note: The battery protection system does not in any way damage the tool.

Note: The indicated capacity may be lower than the actual level during use or

immediately after using the tool.

1. Connect the charger into a mains power outlet.

4. The charger LED will illuminate

red signifying that the battery is

charging.

3. With the charger sitting on a at

surface, align the raised ribs on

the battery with the recess in the

charger and slide onto the charger

ensuring a rm connection.

2. The charger LED will ash green

showing power is being supplied

to the charger.

5. The charger LED will illuminate

green once the battery is fully

charged.

Charging your lithium ion battery - Fast Charger

Charger LED Indicator

LED Indicator Situation

GREEN (Flashing) Stand By (no battery pack is inserted)

RED (Flashing) Battery is charging (low charge)

RED (Illuminated) Battery is charging (mid charge)

GREEN (Illuminated) Battery is fully charged

BOTH (Illuminated) Battery pack is too hot or too cold (charging will begin

automatically when battery reaches correct charging

temperature).

BOTH (Flashing) Defective battery. Never charge a defective battery

pack!

Remove battery pack from charger.

3. INSERTING &

REMOVING THE BATTERY

4. CONTROLS & OPERATION

OPERATION

1. Align the ribs of the battery with

the recess in below the handle.

1. Press and hold the battery

release tab to release the

battery.

2. Slide the battery in so

that it clicks into place.

1. To start the blower

squeeze the on/off

switch.

2. To stop the blower

release the on/off

switch.

2. Slide the battery out.

Inserting the Battery into the Blower

Removing the Battery from the Blower

Switching On and Off

Blowing

The blower is ideal for blowing

leaves, grass clippings and

other debris.

Hold the blower rmly, squeeze

the on/off switch, point the jet

of air in front of you and move

forward slowly. Move the

blower from side to side, with

the tube several inches above

the ground.

Be careful where you point the

jet of air as it can move heavy

material and cause injury or

damage to bystanders.

Note: Be aware of other people and animals in the area where you are to

be operating the blower.

Note: Avoid collisions with hard objects which could damage your machine.

WARNING!: DO NOT USE THE BLOWER WITH ANY

TYPE OF ACCESSORY OR ATTACHMENT. SUCH

USAGE MIGHT BE HAZARDOUS.

WARNING!: DO NOT PUT PART OF YOUR BODY

SUCH AS HANDS AND FINGERS IN THE VACUUM

OPENING OR EXHAUST OPENING.

WARNING!: DO NOT SWITCH THE BLOWER ON

IN ENCLOSED OR POORLY VENTILATED SPACES

OR IN THE PRESENCE OF FLAMMABLE AND/OR

EXPLOSIVE LIQUIDS, GASES AND POWDERS.

WARNING! DO NOT USE ANY ATTACHMENTS

OR ACCESSORIES NOT RECOMMENDED BY THE

MANUFACTURER OF THIS PRODUCT, AS IT CAN

RESULT IN SERIOUS PERSONAL INJURY.

PXCBLLTC-318

MAINTENANCE

DESCRIPTION OF SYMBOLS

CARING FOR THE ENVIRONMENT

TROUBLESHOOTING

Power tools that are no longer usable should not be disposed of with household

waste but in an environmentally friendly way. Please recycle where facilities exist.

Check with your local council authority for recycling advice.

Recycling packaging reduces the need for landll and raw materials. Reuse of

recycled material decreases pollution in the environment. Please recycle packaging

where facilities exist. Check with your local council authority for recycling advice.

Spare Part Part No.

Battery pack 3.0Ah PXBP-300

Fast charger PXCG-030

Spare parts can be ordered from the Special Orders

Desk at your local Bunnings Warehouse.

For further information, or any parts not listed here,

visit www.ozito.com.au or contact Ozito Customer

Service:

Australia 1800 069 486

New Zealand 0508 069 486

E-mail: [email protected]

SPARE PARTS

THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR

BATTERY CHARGER.

1. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product

using the battery pack.

2. This charger is not intended for any uses other than charging rechargeable batteries. Any other use may result in risk

of re, electric shock or electrocution.

3. Do not place any object on top of the charger or place the charger on a soft surface that may result in excessive

internal heat. Place the charger in a position away from any heat source.

4. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the

charger.

5. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or

stress.

6. An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk

of re, electric shock or electrocution.

7. Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Have it

checked by an electrician or power tool repairer.

8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect

reassembly may result in a risk of electric shock, electrocution or re.

9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the

battery pack will not reduce this risk.

10. Never attempt to connect 2 chargers together.

11. DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as inside

sheds or metal buildings in summer).

12. The charger is designed to operate on standard household electrical power (240 volts). Do not attempt to use it on any

other voltage!

13. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging

notes and procedures.

14. The longest life and best performance can be obtained if the battery pack is charged when the air temperature is

between 18 - 24ºC. Do not charge the battery pack in an air temperature below 10ºC or above 40ºC. This is important

and will prevent damage to the battery pack.

15. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The battery can explode in

a re.

16. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, immedi-

ately discontinue use and do not recharge.

17. During charging, the battery must be placed in a well ventilated area.

BATTERY AND CHARGER SAFETY WARNINGS

• Keepairintakecleanandairventsfreeofdebristoavoidoverheatingthemotor.

• Donotusecleaningagentstocleantheplasticpartsofthetool.

A mild detergent on a damp cloth is recommended. Water must never come into contact with

the tool.

• Iftheblowervibratesabnormally,stopmotorimmediately.Abnormalvibrationusuallyindicates

a mechanical problem continued operation could lead to injury or damage.

• Nolubricationisnecessaryasthemotorisequippedwithlifetime-lubricatedbearings.

WARNING! ALWAYS ENSURE THE TOOL HAS

COMPLETELY STOPPED AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Problem Cause Remedy

Blower is not

starting

Possible clogging Clean the blower tube and blower outlet of

any leaves or debris.

Battery is low in charge Charge battery

Battery not inserted

properly

Insert battery pack correctly

Blower is not

operating at

full capacity

Possible clogging Clean the blower tube and blower outlet of

any leaves or debris.

Motor stops

while blowing

Battery has no power Charge battery

Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the

blower by an unauthorised person or by mishandling of the blower. This tool is designed for DIY use

- use in commercial or industrial environments will void the warranty.

Read instruction manual

Do not use in the rain or leave the blower outdoors while raining.

Regulator compliance mark

Keep bystanders away. Do not operate whilst people especially

children or pets are in the area.

Wear eye and ear protection.

BLOWER SAFETY WARNINGS
