Unpacking Information
Thank you for purchasing the Pakedge Device & Software SE-8P gigabit switch.
Before installation, please verify that your package contains the following items.
1. One 8-Port Gigabit Ethernet Switch with 8-port PoE+
2. One AC power cord
3. Rack-mount brackets and screws (included, optional use)
4. User Manual
Introduction
General Description
The SE-8P provides 8*10/100/1000Mbps Gigabit ports with 8-port PoE+, making
it an excellent choice for a fast, cost effective and reliable networking
infrastructure. The store-and-forward architecture filters errors and forwards
packets in a non-blocking environment. Flow control ensures the accuracy of the
data transmitted. The PoE+ on the SE-8P supplies power for connected devices
that need it. Over current protection and circuit shorting protection are also
supported.
The switch was designed for easy installation and maintenance. It supports the
Nway auto-negotiation protocol that detects networking speed (10/100/1000
Mbps) and duplex modes (Full/Half) automatically. Auto-MDI/MDI-X function
alleviates the need for crossover cables. Also, rich diagnostic LEDs are provided
for real-time connection status information.
Key Features
Complies with 10BASE-T specifications of the IEEE802.3 standard
Complies with 100BASE-TX specifications of the IEEE802.3u standard
Complies with 1000BASE-T specifications of the IEEE802.3ab standard
Complies with IEEE 802.3af/at PoE standard
Supports 31.5W maximum per PoE port
Supports over current protection and circuit shorting protection
8* 10/100/1000Mbps RJ-45 Nway ports
Supports NWay protocol for speed (10/100/1000Mbps) and duplex mode
(Half/Full) auto-detection
Supports MDI/MDI-X auto crossover
Supports full and half duplex operation on all ports
Wire-speed packet filtering and forwarding rate
Store-and-forward architecture filters fragment & CRC error packets
Supports 8K MAC address entries in whole system

2
128K bytes buffer memory
Supports automatic loop detection and isolation
Supports9K bytes Jumbo Frames
Supports extensive LED indicators for network diagnostics
Internal power adapter
FCC, CE and LVD
The Front Panel
The front panel consists of LED indicators. For detailed LED definition, please
refer to the next paragraph.
LEDs Definition
System LED
LED
Status
Operation
PWR
Steady Blue
The switch is powered on
Off
The switch is powered off
LOOP
Blinking Red
Off
There is a loop
There is no loop
Port LEDs
LED
Status
Operation
LINK/ACT
Steady Blue
Valid port connection.
Blinking Blue
Valid port connection and there is data
transmitting/ receiving
Off
Port disconnected or the port is connected at 10
Mbps or 100 Mbps
PoE Steady Blue
A PoE compliant devices is connected to the
port
Off
No PoE complaint device is connected to the
port

3
Power Receptacle
To be compatible with the varying electric service standards around the world, the
switch comes with a power supply which can operate from 100 to 240VAC,
50/60Hz. Please make sure that your outlet standard is within this range.
To power on the switch, plug the female end of the power cord firmly into the
receptacle of the switch and the other end into an electric service outlet. After the
power cord installation, toggle the ON/OFF switch into the ON position and please
check if the power LED is illuminated to ensure normal operations.
Rear Panel
Installation
This switch can be placed on your desktop directly, or mounted in a rack. The
installation is simple. Users can utilize all the features of the switch just by
attaching the appropriate cables and turning the power on.
Before installing the switch, we strongly recommend:
1. The switch is placed in a well ventilated environment. A minimum of 25mm
(1 inch) space around the unit is recommended.
2. The switch and the relevant components are away from electrical noise
sources such as radios, transmitters and broadband amplifiers
3. The switch is not placed in a high humidity or moist environment.
Desktop Installation
1. Attach the provided rubber feet to the bottom of the switch to keep the
switch from slipping. The recommend position is square-marked.
2. Install the switch on a level surface that can support the weight of the unit
and the relevant components.
3. Plug the switch with the female end of the provided power cord and plug
the male end into the power outlet.

4
Rack-mount Installation
Rack mounting facilitates an orderly installation when a series of networking
devices are installed. The switch is supplied with rack mounting brackets and
screws
Procedures to Rack-Mount the Switch:
1. Disconnect all the cables from the switch before continuing.
2. Place the unit on a hard, flat surface with the front facing you.
3. Place a mounting bracket over the mounting holes on one side of the
unit.
4. Insert the screws and fully tighten with a suitable screwdriver.
5. Repeat the two previous steps for the other side of the unit.
6. Insert the unit into the rack and secure with suitable screws.
7. Reconnect all the cables.
Network Cables Installation
1. Crossover or straight-through cable: All the ports on the switch support
Auto-MDI/MDI-X functionality. Both straight-through or crossover cables
can be used to connect the switch with PCs as well as other devices like
switches, hubs or router.
2. Category 3, 4, 5 or 5e UTP/STP cable: To make a valid connection and
obtain the optimal performance use the appropriate cables corresponding
to different transmitting/receiving speed. To choose a suitable cable,
please refer to the following table.
Media
Speed
Wiring
10/100/1000Mbps copper
10Mbps
Category 3,4,5 UTP/STP
100Mbps
Category 5 UTP/STP
1000Mbps
Category 5,5e UTP/STP
Port Operation
The auto-negotiation feature allows ports running at one of the following
operation modes:
Media
Speed
Duplex Mode
10/100/1000Mbps(copper)
1000Mbps Fiber (Mini GBIC required)
10Mbps
Full Duplex
Half Duplex
100Mbps
Full Duplex
Half Duplex
1000Mbps
Full Duplex

5
Product Specifications
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3x full-duplex flow control
IEEE802.3ab 1000BASE-T
IEEE 802.3af/at PoE standard (DTE power via MDI)
Interface
8*10/100/1000 Mbps auto MDI/MDI-X RJ-45 switching ports
Supports 136W Max;
Full load:
31.5W(at) x 4 Ports
15.4W(af) x 8 Ports
Cable
Connections
RJ-45 (10BASE-T): Category 3,4,5 UTP/STP
RJ-45 (100BASE-TX): Category 5 UTP/STP
RJ-45 (1000BASE-T): Category 5,5e or enhanced UTP/STP
Transmission
Mode 10/100Mbps Full-duplex, Half-duplex
1000Mbps Full-duplex
LED indications
1 * power LED
8 * Link/ACT LEDS
8 * PoE LEDS
1 * loop LED
Memory
8K MAC entries
9216 bytes jumbo packet length
128K bytes Buffer Memory
Emission
FCC & CE
Safety
LVD
Operating
Temperature 00~ 400C (320~ 1040F)
Operating
Humidity 10% - 90%(non-condensing)
Power Supply
Internal power supply
100-240V/47-63 Hz universal input
Dimensions &
Weight 12.68 x 7.31 x 1.75
4.3 lbs.

6
