Pakedge Device & Software SW24-GBP User manual

pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 1of 73
pakedgedevice&software inc.
pakedgedevice&software inc.
SW24-GBP
Enterprise-Class, Fully Managed, 24 Ports Gigabit Switch with SFP back-
side cable connections and QoS prioritization
User Guide
Version 1.1

pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 2of 73
pakedgedevice&software inc.
FCC Certifications
This Equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received; including interference that may cause undesired operation.
CE Mark Warning
This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022
class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the
approximation of the laws of the Member States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be possible that information in this
document is not up-to-date. Please check with your local distributors for the latest information. No part
of this document can be copied or reproduced in any form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
Copyright © 2013, All Rights Reserved.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. THE UNIT MUST NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER. CAUTION: DO
NOT OPEN THE UNIT. DO NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
INSTALLATION AND TROUBLESHOOTING INSTRUCTIONS. REFER ALL SERVICING TO QUALIFIED
SERVICE PERSONNEL. CAUTION: THIS DEVICE MUST BE INSTALLED AND USED IN STRICT ACCORDANCE
WITH THE MANUFACTURER’S INSTRUCTIONS AS DESCRIBED IN THE USER DOCUMENTATION THAT
COMES WITH THE PRODUCT. WARNING: POSTPONE INSTALLATION UNTIL THERE IS NO RISK OF
THUNDERSTORM OR LIGHTNING ACTIVITY IN THE AREA.

pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 3of 73
pakedgedevice&software inc.
Safety Precautions:
When using this device, always follow basic safety precautions, to reduce the risk of fire, electric shock,
and injury to persons, including the following:
Read all of the instructions (listed here and/or in the user manual) before you operate this equipment.
Comply with all warning and caution statements in the instructions.
Retain the instructions for future reference.
Observe all warning and caution symbols that are affixed to this equipment.
Comply with all instructions that accompany this equipment.
Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in safe operating condition.
Installation of this product must be in accordance with national wiring codes and conform to local
regulations.
Give particular attention to all safety precautions.
Operate this product only from the type of power source indicated on the product’s marking label. If
you are not sure of the type of power supplied to your home, consult your dealer or local power
company.
It is recommended that the customer install an AC surge protector in the AC outlet to which this device
is connected. This is to avoid damage to the equipment from lightning strikes and other electrical
surges.
Wipe the unit with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray
cleaners directly on the unit or use forced air to remove dust.
Keep the device away from excessive heat and humidity and keep the device free from vibration and
dust.
Do not directly cover the device, or block the airflow to the device with insulation or any other objects.

pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 4of 73
pakedgedevice&software inc.
Contents
1. Introduction....................................................................................................................................................................................................6
1.1. Package Contents ................................................................................................................................................................................6
1.2. General Description............................................................................................................................................................................. 6
1.3. Key Features: .......................................................................................................................................................................................7
1.3.1. Device Management.................................................................................................................................................................7
1.3.2. Standards..................................................................................................................................................................................7
1.3.3. Protocol features: .....................................................................................................................................................................7
1.3.4. Ports:.........................................................................................................................................................................................7
1.3.5. Security .....................................................................................................................................................................................7
1.3.6. MAC Address Management ...................................................................................................................................................... 8
1.3.7. Other Features..........................................................................................................................................................................8
1.4. Overview of Switch Functions:............................................................................................................................................................. 8
1.4.1. Abbreviations and Acronyms ..................................................................................................................................................... 8
1.4.2. Functional Descriptions .............................................................................................................................................................. 9
1.5. The Front Panel..................................................................................................................................................................................11
1.5.1. LED Definitions........................................................................................................................................................................11
1.6. The Rear Panel................................................................................................................................................................................... 12
2. Hardware Installation ...................................................................................................................................................................................12
2.1. Desktop Installation...........................................................................................................................................................................13
2.2. Rack-mount Installation..................................................................................................................................................................... 13
2.3. Installing Network Cables ..................................................................................................................................................................13
2.4. Port Operation...................................................................................................................................................................................14
2.4.1. Configuring the Switch............................................................................................................................................................14
3. Web-based Configuration:............................................................................................................................................................................14
3.1. Configuration.....................................................................................................................................................................................15
3.1.1. System ....................................................................................................................................................................................16
3.1.2. Port Configuration .................................................................................................................................................................. 19
3.1.3. Aggregation/Trunking ............................................................................................................................................................. 21
3.1.4. RSTP........................................................................................................................................................................................21
3.1.5. IGMP Snooping .......................................................................................................................................................................23
3.1.6. Mirroring................................................................................................................................................................................. 24
3.1.7. Quality of Service .................................................................................................................................................................... 25
3.1.8. Rate Limit................................................................................................................................................................................ 27
3.1.9. Storm Control ......................................................................................................................................................................... 28
3.1.10. Advanced Security ..................................................................................................................................................................28
3.2. Monitor..............................................................................................................................................................................................33
3.2.1. Statistics Overview..................................................................................................................................................................33
3.2.2. Detailed Statistics ...................................................................................................................................................................34
3.2.3. RSTP Status .............................................................................................................................................................................35

pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 5of 73
pakedgedevice&software inc.
3.2.4. IGMP Status ............................................................................................................................................................................35
3.3. Diagnostic ..........................................................................................................................................................................................36
3.3.1. Ping......................................................................................................................................................................................... 36
3.4. Maintenance......................................................................................................................................................................................36
3.4.1. Reset Device ...........................................................................................................................................................................36
3.4.2. Factory Default .......................................................................................................................................................................37
3.4.3. Software Upload ..................................................................................................................................................................... 37
3.4.4. Configuration File....................................................................................................................................................................38
3.4.5. Log Out ...................................................................................................................................................................................38
4. Command Line-Based Configuration ............................................................................................................................................................39
4.1. Com Port Setup.................................................................................................................................................................................. 39
4.2. General ..............................................................................................................................................................................................42
4.2.1. Command Hierarchy ............................................................................................................................................................... 42
4.2.2. Login/Logout Procedures........................................................................................................................................................42
4.2.3. Help Utility ..............................................................................................................................................................................43
4.2.4. Example ..................................................................................................................................................................................43
4.2.5. Entering Commands................................................................................................................................................................44
4.2.6. Terminology............................................................................................................................................................................44
4.3. Command Overview ..........................................................................................................................................................................45
4.4. Detailed Command Descriptions .......................................................................................................................................................50
4.4.1. System Commands.................................................................................................................................................................. 50
4.4.2. Console Commands ................................................................................................................................................................ 52
4.4.3. Port Commands ......................................................................................................................................................................53
4.4.4. MAC Table Commands............................................................................................................................................................ 55
4.4.5. Aggregation / Trunking Commands ........................................................................................................................................57
4.4.6. RSTP-IEEE 802.1w Rapid Spanning Tree.................................................................................................................................. 58
4.4.7. User Group Commands...........................................................................................................................................................61
4.4.8. Mirror Commands...................................................................................................................................................................62
4.4.9. IP Commands.......................................................................................................................................................................... 63
4.4.10. IGMP Snooping Commands ....................................................................................................................................................64
5. Appendix A –Specifications..........................................................................................................................................................................67
6. Appendix B –Technical Support ................................................................................................................................................................... 70
7. Appendix C –Limited Warranty.................................................................................................................................................................... 71

pakedgedevice&software inc. / SW24-GBP 6
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 6of 73
1. Introduction
1.1. Package Contents
Open the package carefully, and make sure that none of the items listed below are missing. Do not
discard the packing materials. In case of return, the unit must be shipped in its original package.
One SW24-GBP
Rack Mount hardware
One Power Cable
One Serial Cable- RJ45 8-pin plug to a 9-hole DB9 plug.
1.2. General Description
The SW24-GBP Enterprise-Class rack-mountable Gigabit Ethernet switch is designed for maximum
performance and convenience. It incorporates QoS functionality to allow you to prioritize devices on
your network according to your clients needs. All of this is preconfigured for you to minimize
installation time.
All cables install from the rear, for the clean-finished rack appearance that custom installers and
their clients prefer. The SW24-GBP can be configured by Web GUI, serial command-line interface
(CLI), or Telnet. Plug-and-play and auto-negotiation capabilities allow the switch to auto-detect a link
partner with the best available speed.
The SW24-GBP is cased in a heavy-duty 1U housing designed for easy installation and maintenance.
(Rack-mount hardware is included.) The SW24-GBP supports Nway auto-negotiation to automatically
detect network speed (10/100/1000 Mbps) and Full/Half duplex mode. And Auto-MDI/MDI-X port
functionality eliminates the need for crossover cables. Rich diagnostic blue LEDs provide real-time
status monitoring. The SW24-GBP combines two SFP expansion slots to support Mini-GBIC modules.
Series modules can be smoothly connected with Gigabit networking to ensure optimal networking
speed and performance. Finally, the SW24-GBP supports both Command Line and Web Graphical
User Interfaces.

pakedgedevice&software inc. / SW24-GBP 7
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 7of 73
1.3. Key Features:
1.3.1. Device Management
Network management through Web GUI, command-line interface (CLI), and
Telnet
Easy firmware upgrading
Save configuration files and upload them for one-step configuration of multiple
devices.
Auto-logging for easy debugging
User password protection
Easy-to-read blue LED indicators aid in cable installation and diagnostics.
1.3.2. Standards
IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, and IEEE 802.3ab 1000BASE-T
Gigabit Ethernet
1.3.3. Protocol features:
Full-duplex flow control (IEEE 802.3x), and half-duplex backpressure
Supports 802.1P, DSCP/COS
Supports IEEE 802.1D Spanning Tree and IEEE802.1W fast Spanning Tree
protocols
1.3.4. Ports:
24 ports, 10/100/1000Mbps UTP/STP RJ45 (MDI/MDIX supported)
Port trunking and bandwidth control
Port send/receive statistics through GUI
Configurable port speed, duplex mode, and priority queues.
Supports Aggregation for each port
Port-based mirroring
1.3.5. Security
Port security control, broadcast storm control, and address aging
Support for Static Port Priority and IEEE 802.1p Priority
Supports Priority Queues and ingress policy
Supports IGMP Snooping

pakedgedevice&software inc. / SW24-GBP 8
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 8of 73
1.3.6. MAC Address Management
Full MAC address management, including MAC address auto-scanning, filtering,
and self-learning
Supports configuration of MAC address aging time
Supports maximum 8K MAC address table
Supports IP address and MAC address binding
1.3.7. Other Features
SNMP
LACP link aggregation
Supports ARP setup
Supports ARP flooding protection
2 SFP expanding modular socket interfaces: 1000M fiber/UTP module
Built-in universal power supply
19-inch 1U heavy duty metal case with back-side cable connections
Blue LED’s Indicators
1.4. Overview of Switch Functions:
1.4.1. Abbreviations and Acronyms
ARP Address Resolution Protocol
CLI Command Line Interface
CPOL Clock Polarity
CPHA Clock Phase
DHCP Dynamic Host Configuration Protocol
E2PROM Electrically Erasable Programmable Read Only Memory
IP Internet Protocol
LACP Link Aggregation Control Protocol
LED Light Emitting Diode
L2 Layer 2
MAC Media Access Control
PCB Printed Circuit Board
PHY Physical Layer Transceiver
PVID Port VLAN Identifier

pakedgedevice&software inc. / SW24-GBP 9
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 9of 73
Abbreviations and acronyms (continued)
QoS Quality of Service
RAM Random Access Memory
ROM Read-Only Memory
RSTP Rapid Spanning Tree Protocol
TCP Transmission Control Protocol
UART Universal Asynchronous Receiver Transmitter
UDP User Datagram Protocol
VID VLAN Identifier
1.4.2. Functional Descriptions
1.4.2.1. PHY Monitoring and Port Mode Set-up
The software continually monitors the PHYs to aid in setting up the switch ports. If the link is
active, the software determines the current speed, duplex mode, and pause capabilities of
the PHYs by polling them every 100 ms.
1.4.2.2. Flow Control
Flow control (back pressure) is supported in both full-duplex and half-duplex. Flow control
can be enabled or disabled on a per-port basis from the command line interface or from the
WEB GUI interface. If flow control is enabled for a port, the associated PHY is set to support
“Symmetric Pause,” but not “Asymmetric Pause.” If the station connected to the port also
supports “Symmetric Pause,” flow control is enabled on the switch port. Watermarks are set
to hard-coded values. Different values are used depending on whether flow control is enabled
or not, and depending on the current speed.

pakedgedevice&software inc. / SW24-GBP 10
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 10 of 73
1.4.2.3. Aging
To prevent an automatically learned MAC address of a station that has been detached from
remaining in the MAC address table permanently, the aging function in the switch is activated
on a regular basis.
The period for which the aging function is performed is determined by the aging time
parameter. The period must be half the value of the aging time parameter in order to make
the aging time parameter comply with IEEE 802.1D.
For example, if the aging time parameter is 300 seconds, the period must be 150 seconds to
ensure that an unused MAC address will not remain in the MAC address table for more than
300 seconds. The aging time parameter can be set from the command line interface. The
default value is 300 seconds. Setting the aging time parameter to 0 disables the aging
function.
1.4.2.4. Link Aggregation
Link aggregation groups (or channels) can be defined statically. LACP (Link Aggregation
Control Protocol) is also supported. The maximum number of aggregation groups is 8. The
software will automatically detect when a link has gone down and reassign packet distribution
to the other links in the group.
1.4.2.5. Quality of Service
Various classifications and prioritizations are supported to enable Quality of Service for real-
time applications such as VoIP (Voice over IP).
1.4.2.6. Test Functions
Internal and external loopback tests can be run on the switch ports using the command line
interface. In the internal loopback test, the PHYs are set in loopback mode and the ports are
set to copy frames to the CPU capture buffer. For each speed, a single frame of fixed size (128
bytes) is sent from the CPU and the software checks that the frame is received in the CPU
capture buffer within a proper time. If a port fails, an error code is shown (1 if the frame was
received, but corrupted, 2 if the frame was not received).
In the external loopback test the ports must be connected pair-wise through external cables
- port 0 and port 1 must be connected, port 2 and port 3 must be connected, etc. The ports
are tested pair-wise. A frame is sent from the CPU to a port and the software checks that the
frame is received in the CPU capture buffer from the port’s counterpart within a proper time.
A frame of fixed size (128 bytes) is sent for each speed. If a port fails, an error code is shown
(1 if the frame was received, but corrupted, 2 if the frame was not received).

pakedgedevice&software inc. / SW24-GBP 11
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 11 of 73
1.5. The Front Panel
The front panel consists of LED indicators. For a description of detailed LED functions, see the tables
in the next sections.
1.5.1. LED Definitions
1.5.1.1. System LED
LED
Status
Operation
Power
Steady Blue
The switch is powered on
Off
The switch is powered off
1.5.1.2. Port LEDs
LED
Status
Operation
1000M
Steady Blue
Valid port connection at 1000 Mbps
Blinking Blue
Valid port connection and data is being transmitted/received
Off
Port disconnected or the port is connected at 10 Mbps or 100
Mbps
10/ 100M
Steady Blue
Valid port connection at 10/100 Mbps
Blinking Blue
Valid port connection and data is being transmitted/received
Off
Port disconnected or the port is connected at 10 Mbps or
10/100 Mbps
Note: The SFP 1 Mini-GBIC slot shares the same port with the copper RJ45 port 23 and SFP 2
Mini-GBIC slot shares the same port with the copper RJ45 port 24

pakedgedevice&software inc. / SW24-GBP 12
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 12 of 73
1.6. The Rear Panel
Ports
The SW24-GBP has 24 10/100/1000 ports, and two SFP fiber ports (SFP 1 and SFP 2). A Mini-GBIC is
required to use the SFP ports. The SFP 1 Mini-GBIC slot shares the same port with the copper RJ45
port 23, and the SFP 2 Mini-GBIC slot shares the same port with the copper RJ45 port 24. Only the
Mini-GBIC or the RJ45 port can be used at the same time, but not both.
Power Receptacle
For compatibility with the diverse electrical service standards around the world, the switch comes
with a power supply that can operate from 100 to 240VAC, 50/60Hz. Please make sure that your outlet
standard is within this range.
To power on the switch, plug the female end of the power cord firmly into the receptacle of the switch
and the other end into an electric service outlet. Once the power cord is plugged in, check if the power
LED is lit to ensure normal operation.
2. Hardware Installation
The switch can be placed on a desktop, or mounted in a rack. Installation is simple; all features of the
switch can be operated easily by attaching the appropriate cables and turning the power on.
Before installing the switch, we strongly recommend:
Placing the switch in a well-ventilated area, with a minimum of 25mm (1 inch) space around the
unit.
Placing the switch and related components away from electrical noise sources such as radios,
transmitters, and broadband amplifiers.
Not placing the switch in a high-humidity or moist environment.

pakedgedevice&software inc. / SW24-GBP 13
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 13 of 73
2.1. Desktop Installation
Attach the provided rubber feet to the bottom of the switch to keep the switch from slipping. The
recommend position for the feet is marked with squares.
Install the switch on a level surface that can support the weight of the unit and related components.
Plug the female end of the provided power cord into the switch and plug the male end into the power
outlet.
2.2. Rack-mount Installation
Rack mounting facilitates orderly installation when a series of networking devices are installed. The
switch is supplied with rack mounting brackets and screws.
Procedures to rack-mount the switch:
1. Disconnect all cables from the switch.
2. Place the unit on a hard, flat surface with the front facing you.
3. Place a mounting bracket over the mounting holes on one side of the unit.
4. Insert the screws and fully tighten.
5. Repeat the two previous steps for the other side of the unit.
6. Insert the unit into the rack and secure with screws.
7. Reconnect cables.
2.3. Installing Network Cables
1. Crossover or straight-through cable. All the ports on the switch support Auto-MDI/MDI-X
functionality. Either straight-through or crossover cables can be used to connect the switch
with PCs and other devices such as switches, hubs, or routers.
2. Category 3, 4, 5 or 5e UTP/STP cable. To make a valid connection and obtain optimal
performance, use the appropriate cables for the transmitting/receiving speeds. To choose a
suitable cable, refer to the following table.
Media
Speed
Wiring
10/100/1000Mbps copper
10Mbps
Category 3,4,5 UTP/STP
100Mbps
Category 5 UTP/STP
1000Mbps
Category 5,5e UTP/STP
1000Mbps Fiber (Mini GBIC required)
1000Mbps
The fiber type will vary based on the GBIC type you use.
Please refer to your GBIC User Guide

pakedgedevice&software inc. / SW24-GBP 14
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 14 of 73
2.4. Port Operation
The auto-negotiation feature allows the ports to run in one of the following operating modes:
Media
Speed
Wiring
10/100/1000Mbps copper
10Mbps
Category 3,4,5 UTP/STP
100Mbps
Category 5 UTP/STP
1000Mbps
Category 5,5e UTP/STP
1000Mbps Fiber
(Mini GBIC required)
1000Mbps
The fiber type will vary based on the GBIC type
you use. Please refer to your GBIC User Guide
2.4.1. Configuring the Switch
The SW24-GBP can be configured and managed using a Web browser or command console. The
steps for logging in and configuring the switch through the Web-based GUI are explained below.
The section that follows gives instructions for configuring the switch using the command line
interface.
3. Web-based Configuration:
Log in to the Web interface
The default values are:
IP Address: 192.168.1.201
Password: None
In order to log in to the SW24-GBP, you must first configure the TCP/IP settings of your PC/notebook.
Follow these steps:
1. In the Windows Control Panel, double-click Network Connections and double-click the
connection of your Network Interface Card (NIC). The Local Area Connection Properties dialog
appears:

pakedgedevice&software inc. / SW24-GBP 15
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 15 of 73
Web-Based configuration (continued)
2. Select Internet Protocol (TCP/IP) and click Properties. The Internet Protocol (TCP/IP) dialog
appears, where you can configure the TCP/IP settings of your PC.
3. Select Use the following IP Address and type the IP address and subnet mask, as in the example
above. (Be sure the IP address and subnet mask are on the same subnet as the SW24-GBP.)
4. Click OK.
5. Click OK to close the dialog, and click OK to close the Local Area Connection Properties dialog.
3.1. Configuration
To configure the SW24-GBP using a Web browser:
1. Type the IP address of the SW24-GBP (default: 192.168.1.201) in the address bar of the
browser and press Enter.

pakedgedevice&software inc. / SW24-GBP 16
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 16 of 73
Configuration (continued)
2. After connecting to the IP address, the web-browser displays the login page. Leave the
password field blank.
After logging in, the main page of the graphical user interface (GUI) appears. This is the System
Configuration window which is a link in the Navigation Menu on the left side of the screen.
The navigation drop-down menu on left is divided into four main sections, which will be described in
the sections that follow.
3.1.1. System
This page displays the basic system properties of the SW24-GBP and allows you to configure them.
The System Configuration page is displayed upon login and can also be reached by clicking System
in the navigation menu.
The System page displays the port status, as in the figure below. A green color indicates that a
port is connected; black indicates that a port is not connected.

pakedgedevice&software inc. / SW24-GBP 17
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 17 of 73
System (continued)
Click a port icon to view details of the corresponding port, as shown in the figure below.
The System Configuration page is displayed upon login and can also be reached by clicking System
in the navigation menu.
The first table in the figure below displays the current configuration status of the SW24-GBP.

pakedgedevice&software inc. / SW24-GBP 18
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 18 of 73
System (continued)
The second table on this page is where you can configure the properties of the switch:
DHCP Enabled: If your SW24-GBP is connected to a DHCP server (such as a router), select
the DHCP Enabled checkbox to enable automatic IP address assignment.
Fallback IP Address: Type the IP address you wish to assign to the SW24-GBP when the
DHCP function is not enabled.
Fallback Subnet Mask: Type the Subnet mask you wish to assign to the SW24-GBP when
the DHCP function is not enabled.
Fallback Gateway: Type the Gateway address you wish to assign to the SW24-GBP when
the DHCP function is not enabled.
Management VLAN: Type the ID number for the VLAN you wish to give access to the GUI.
This will be the only VLAN with access to configure the switch. It is recommended to leave
the management VLAN on VLAN 1.

pakedgedevice&software inc. / SW24-GBP 19
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 19 of 73
System (continued)
Name: Type the Username to be used to log on to the switch.
Password: Type the password that will be used to log on to the switch.
Inactivity Timeout: Type the amount of time in seconds the system will wait before
logging out due to inactivity.
SNMP Enabled: Select the checkbox enable SNMP (Simple Network Management
Protocol).
SNMP Trap destination: Type the IP address for the SNMP Trap.
SNMP Read Community: Type a password for SNMP read-only access.
SNMP Write Community: Type a password for SNMP Read/Write access.
SNMP Trap Community: Type a password for SNMP Trap access.
To save your changes, click Apply.
3.1.2. Port Configuration
To configure the network settings for individual ports, click Port Configuration in the navigation
menu.
Enable Jumbo Frames: Enable this function if you want larger frames sizes to be used. This
will allow data to be sent in fewer frames. However, make sure the receiving clients are
capable of receiving Jumbo Frames.
Intrusion Lock: This feature disables all ports when an Ethernet cable is disconnected to
prevent an intruder from disconnecting a cable and plugging a rogue device into the
network.

pakedgedevice&software inc. / SW24-GBP 20
pakedgedevice&software inc. | 1163 Triton Drive | Foster City | California | 94404 | USA | 650.385.8700
Page 20 of 73
Port Configuration (continued)
This table displays the link status for each port on the SW24-GBP and allows the user to configure
the speed settings for each port and enable Flow Control.
Port: Displays the port number.
Link Status: Displays the current status of the port –“Down” if the port is inactive, or
displays the current speed of the port if the port is active.
Mode: This allows the user to manually specify a speed for the port. “Auto Speed” enables
auto-negotiation between the switch and client, while “Disable” causes the port to
become inactive.
Flow Control: Click to enable flow control. Use this setting if there is a possibility that the
sending machine is much faster than the receiving machine. Flow control ensures that a
fast sender will not outrun a slower receiver.
Drop frames: With this feature enabled, the SW24 will drop frames if excessive collisions
happen, rather than storing them and resending them.
