Palazzetti Ecofire Adagio Operating instructions
ECOFIRE®ADAGIO
EASY TOUCH
MANUALE DI INSTALLAZIONE USO E MANUTENZIONE
INSTALLATION, USER AND MAINTENANCE MANUAL
INSTALLATIONS, BEDIENUNGS UND WARTUNGSANLEITUNGEN
NOTICE D’INSTALLATION
MANUAL DE INSTALACIÓN, USO Y MANTENIMIENTO
cod. 00 477 2290 - 07/2013 - Palazzetti - PN - Italy 3/136
Gentile cliente,
desideriamo innanzitutto ringraziarLa per la preferenza che ha voluto accordarci acquistando
il nostro prodotto e ci congratuliamo con Lei per la scelta.
Per consentirLe di utilizzare al meglio la Sua nuova stufa, la invitiamo a seguire attentamente
quanto descritto nel presente manuale.
IT
Dear Customer,
We’d like to thank you for having purchased one of our products and congratulate you on
your choice.
To make sure you get the most out of your new stove, please carefully follow the instructions
provided in this manual.
Sehr geehrter Kunde,
Zuallererst möchten wir Ihnen für den uns gewährten Vorzug danken und Ihnen zur Wahl
gratulieren.
Damit Sie Ihren neuen Heizofen so gut wie möglich benutzen können, bitten wir Sie, die in
dieser Bedienungs- und Wartungsanleitung enthaltenen Angaben genau zu befolgen.
Cher client,
Nous souhaitons avant tout vous remercier de la préférence que vous nous avez accordée
en achetant notre produit et vous félicitions pour votre choix.
suivre attentivement les instructions reportées dans cette notice.
Estimado Cliente,
Deseamos agradecerle por la preferencia que nos ha otorgado adquiriendo nuestro producto
y lo felicitamos por su elección.
Para el mejor uso de su nueva estufa, lo invitamos a leer con atención cuanto se describe
en el presente manual.
GB
DE
F
ES
30/136 cod. 00 477 2290 - 07/2013 - Palazzetti - PN - Italy
USE AND MAINTENANCE
SHUNTER
TRANSPORTER
INSTALLER
ASSISTANCE
CENTER
ELECTRICIAN
USER
SUMMARY FOR SKILLS
1 INTRODUCTION..............................................................................................................32
2 SAFETY WARNINGS.......................................................................................................34
4 HANDLING AND TRANSPORT ......................................................................................35
7 STOVE DESCRIPTION....................................................................................................43
8 PRELIMINARY OPERATIONS ........................................................................................46
9 STOVE OPERATION .......................................................................................................48
10 FUNCTIONS AVAILABLE..............................................................................................49
11 ALARM MANAGEMENT................................................................................................51
12 MAINTENANCE.............................................................................................................52
13 DECOMMISSIONING AND DISPOSAL.........................................................................54
1 INTRODUCTION..............................................................................................................32
2 SAFETY WARNINGS.......................................................................................................34
3 FUEL SPECIFICATIONS .................................................................................................35
4 HANDLING AND TRANSPORT ......................................................................................35
5 INSTALLATION SITE PREPARATION ............................................................................36
6 INSTALLATION................................................................................................................40
7 STOVE DESCRIPTION....................................................................................................43
8 PRELIMINARY OPERATIONS ........................................................................................46
12 MAINTENANCE.............................................................................................................52
13 DECOMMISSIONING AND DISPOSAL.........................................................................54
1 INTRODUCTION..............................................................................................................32
2 SAFETY WARNINGS.......................................................................................................34
3 FUEL SPECIFICATIONS .................................................................................................35
4 HANDLING AND TRANSPORT ......................................................................................35
13 DECOMMISSIONING AND DISPOSAL.........................................................................54
cod. 00 477 2290 - 07/2013 - Palazzetti - PN - Italy 31/136
ENGLISH
USE AND MAINTENANCE
INDEX
1 INTRODUCTION 32
1.1 SYMBOLS 32
1.2 INTENDED USE 32
1.3 PURPOSE AND CONTENTS OF THIS MANUAL 32
1.4 HOW TO KEEP THIS MANUAL 32
1.5 UPDATES TO THE MANUAL 32
1.6 GENERAL INFORMATION 32
1.7 MAIN REFERENCE STANDARDS 32
1.8 PRODUCT WARRANTY 33
1.9 MANUFACTURER’S LIABILITY 33
1.10 INTENDED USERS 33
1.11 TECHNICAL SERVICE 33
1.12 SPARE PARTS 33
1.13 IDENTIFICATION LABEL 33
1.14 DELIVERY OF THE STOVE 33
2 SAFETY WARNINGS 34
2.1 INSTALLATION WARNINGS 34
2.2 MAINTENANCE WARNINGS 34
2.3 WARNINGS FOR THE USER 34
3 FUEL SPECIFICATIONS 35
3.1 FUEL SPECIFICATIONS 35
3.2 STORING THE PELLETS 35
4 HANDLING AND TRANSPORT 35
4.1 REMOVING THE STOVE FROM THE PALLET 35
5 INSTALLATION SITE PREPARATION 36
5.1 GENERAL INFORMATION 36
5.2 SAFETY PRECAUTIONS 36
5.3 STOVE INSTALLATION SITE 36
5.4 COMBUSTION AIR 37
5.5 FLUE GAS EXHAUST 38
6 INSTALLATION 40
6.1 LEVELLING THE STOVE 40
6.2 SYSTEM CONNECTIONS 40
6.3 INITIAL CONFIGURATION 41
7 STOVE DESCRIPTION 43
7.1 CONTROL PANEL 43
7.2 USING THE CONTROL PANEL 44
7.3 OPERATING PARAMETERS 45
8 PRELIMINARY OPERATIONS 46
8.1 LOADING THE PELLETS 46
8.2 POWER SUPPLY 46
8.3 INITIAL SETTINGS 46
9 STOVE OPERATION 48
9.1 STARTING THE STOVE 48
9.2 MODIFYING THE PARAMETERS 48
9.3 SWITCHING OFF 48
9.4 OPERATION WITH ROOM THERMOSTAT 48
9.5 OPERATION WITH ROOM PROBE ON THE STOVE 48
10 FUNCTIONS AVAILABLE 49
10.1 TIMER 49
10.2 “ECO MODE” SAVING FUNCTION 49
10.3 RESTART DELTA FUNCTION 50
10.4 AUTONOMY FUNCTION 50
10.5 REFILL FUNCTION 50
10.6 RESTARTING AFTER A POWER FAILURE 50
10.7 “LOCK KEYPAD” FUNCTION 50
10.8 FROST PROTECTION FUNCTION 51
11 ALARM MANAGEMENT 51
12 MAINTENANCE 52
12.1 SAFETY PRECAUTIONS 52
12.2 ROUTINE USER MAINTENANCE 52
12.3 SPECIAL MAINTENANCE 54
13 DECOMMISSIONING AND DISPOSAL 54
