Get started_
All you need to know to get going.

Activate Your Phone
2
•If you purchased your phone at a
Sprint Store, it is probably activated
and ready to use.
•If you received your phone in the mail
and it is a new Sprint account or a
new phone number, your phone
activates automatically after you
complete setup (see p. 6).
•If you received your phone in the mail
and you are switching the number from
a previous Sprint phone, do not turn
on your new phone yet. Wait until
your old phone is deactivated. Go to
sprint.com/activate on your computer.
Follow the instructions to activate the
number on your new phone.
If you have any problems with activation,
contact Sprint Customer Service at
1-888-211-4727 from another phone.

Turn On Your Phone
3
Activate your phone before you turn it
on (see previous page). Then press and
hold the power button until you see the
Palm logo. Wait for setup to start (please
be patient).
Use of this device requires providing a valid email address,
mobile phonenumber, and related information for account
setup and activation. A data plan isalso required. An
unlimited usage data plan is strongly recommended or
additional data charges may apply.
Power button

Overview
4
6
1
7
8
9
11
4
5
Top
3
10
2

5
1 Earpiece
2 Speaker (on back)
3 Gesture area
4 Microphone
5Option key: See p. 12.
6 Ringer switch: Flip to turn the ringer
and notification sounds on and off
(red means off).
7 Volume: For call, ringer, and
music/video playback. See p. 14.
8 Charger/microUSB connector
9 Sym: See p. 12.
10 Power: Press to wake up and turn off
the screen. Press and hold to turn
the device completely on and off
(deep sleep; calls go to voicemail).
11 3.5mm headset jack

Set Up Your Phone
6
To use your phone, you must agree to
Palm’s terms and conditions, and then
create a Palm profile: Enter a working
email address and create a password.
Setting up a Palm profile is different from
setting up email. To set up email, see p. 15.
Why do I need a Palm profile?
A Palm profile gives you access to services
like software updates, daily backup of
your data, and remote erase of your data
should your phone be lost or stolen.
NOTE: Do you have a Palm profile from a
phone that you no longer use? Just sign in
to your existing profile. All info associated
with your profile is downloaded to your
new phone.

Set Up Contacts &
Calendar to Sync
7
To wirelessly sync Contacts and
Calendar info, set up online accounts
with providers like Google and Microsoft
Exchange ActiveSync.
If you don’t already have an account
with a service provider, you must create
one before you set up the account on
your phone.
•Google: Go to gmail.com.
•Exchange: Check with your
company’s IT department.
A sync relationship you set up in one app
is automatically set up in other apps. For
example, by setting up a Gmail email
account, your phone is also set to sync
Google Contacts, Calendar, and IM.

8
Set Up Accounts
on Your Phone
The first time you open Contacts,
Calendar, and Messaging, you see a
setup screen that appears only once:
Tap Add an Account > enter username
and password > Sign In.
Just want to jump to your contacts or
calendar, or send a message? Tap
Done .
Email: See p. 15.
Later, set up accounts this way: Open
the menu by tapping the app name in
the upper-left corner of the screen >
Preferences & Accounts > Add An
Account.
Your Palm profilealso has an account
associated with it. You can use it for
Contacts and Calendar info, and for other
kinds of info as well, like Memos. This info
is backed up daily, but you can access
this info only on your phone. Unlike info
stored with Google and other online
accounts, there’s no way to see Palm
profile account info on your computer.

Transfer Info to
Your Phone
9
On your computer, look for an email from
Palm at the address you used to create
your Palm profile. Finish setting up your
profile on your computer; then click the
link that takes you to a website
(palm.com/migrate-pixi) that explains
your data-transfer options.
What kinds of info can I transfer?
Contacts, calendar info, tasks, and
memos/notes.
Where can I export info from?
•Windows: Palm®Desktop and
standalone Outlook®(Outlook that
doesn’t sync with an Exchange server).
•Mac: iCal and Address Book.
Where do I transfer the info to?
Pick the account—for example, your
Google, Exchange, or Palm profile
account—to receive the info you exported
from your computer. We recommend
that you transfer your info to an online
account (see p. 7).

Open Applications
01
Launcher,
page 1
Page
indicator
Quick Launch
Phone Contacts Email Calendar Launcher Card view with three open cards
Launcher: To open the Launcher, flick
up twice from the gesture area to the
screen. (In Card view, flick up once.) The
Launcher displays all your apps. Swipe
left and right onscreen to scroll through
Launcher pages, up and down to see
everything on the page.
Quick Launch: To open Quick Launch
when you can't see it onscreen, drag up
from the gesture area to the screen. Quick
Launch displays up to five icons. To
customize it, drag out any icon except
Launcher and drag in another one.
Tap an icon to open an application.

Move Among Open
Applications
11
Phone Contacts Email Calendar Launcher Card view with three open cards
You can open and use multiple
applications at the same time. To move
among them, first tap the center of the
gesture area to shrink the app you’re
using. You’re now in Card view, where
all open apps appear as small windows
(cards).
In Card view, swipe left or right on the
screen to scroll through open apps.
To close an app, throw the card off the
top of the screen in Card view.
To use an open app, tap its card.

Enter and Save Info
21
To select text: You can select text in
messages, web pages, memos, and so
on. See the text selection gestures on
the back of the Gesture Guide attached
to this guide. Open the application menu
to use Cut, Copy, and Paste.
To enter uppercase letters: Press
Shift and the letter key. To turn on
Caps Lock, press Shift twice.
To enter numbers and symbols that
appear at the top of the keys: Press
Option and the key for the character.
To turn on Option Lock, press Option
twice.
To enter symbols like currency
symbols and accented characters:
Press Sym to open the symbols
table, scroll to the character you want,
and tap to select.
How do I save the info I entered?
Info is saved automatically. Make the
back gesture, and your information is
saved automatically. If you see a Done
button, tap it to save and move on. If you
throw the card off the screen to close an
app, new info is always saved
automatically.

Make a Call, Use the Phone
31
Make a call
Quick Launch > > enter the
number with the keyboard > tap the
number. To end the call, tap .
If you need to wake up the screen,
press power .
Turn the phone off and on
Tap the upper-right corner of any
screen > Turn on/off Airplane Mode.
Dial a number by contact name
Launcher or Card view > type the first or
last name or initials > tap the number.
Phone ison
Phone isoff

41
Set up/listen to voicemail
Quick Launch > > > listen for
instructions.
NOTE: Sprint strongly recommends
setting a voicemail passcode. Without a
passcode, anyone who has access to
your phone can access your messages
and place outbound calls through your
wireless account.
Silence the ringer when the screen is off
Press power twice.
Adjust call volume
Press volume up or down.
Volume

Set Up Email
51
Email
Quick Launch > .
The first time you open Email, the
address you used to create your Palm
profile is already in the Email Address
field. Enter the password > Sign In to
complete setup of that account.
Setting up email from some providers
automatically adds your contacts and
calendar data from that provider to
your phone. See pp. 7-8.
Later, to add other email accounts: Open
the application menu > Preferences &
Accounts > Add An Account.

Find It Fast
61
In Launcher or Card view, simply start
typing a word, name, or first and last
initials.
Your phone displays any matching
results. Tap the one you want.
Tap a phone number to dial it. Or tap
beside a phone number to send a text
message.
To search the Web or the on-device
Help, tap the text you entered. Tap a Web
search option, or tap Help.

MergedViews
71
The Palm®Synergy™ feature displays
data from several sources in a single
view on your phone, but keeps the
sources of your data separate.
Let’s say you use Google calendar for
your personal appointments and your
company’s Outlook calendar for
business appointments. Your phone’s
Calendar application can display
appointments from both calendars in
a single view.
Likewise, if you set up multiple email
accounts, the Email application lets you
display the messages from all your
account inboxes in a single view.
And in Messaging, all your messages
with a person show up in a single
conversation view, whether they are text,
multimedia, or instant messages.

Linked Contacts
81
The Contacts application also offers
a merged view—all your contacts from all
your accounts appear in a single list. But
more than that, Contacts lets you see all
your information for a person in a single
view—even if that information comes from
multiple sources.
For example, let’s say you have a work
contact in Exchange and a personal
contact for the same person in Google
contacts. Contacts recognizes the
similarity and automatically links the
two contacts so that you can see all the
information in one place. You can also
manually link and unlink contacts.

Notifications
91
Notifications at the bottom of the screen
alert you to voicemail, incoming messages,
upcoming appointments, and more. For
some notifications, tap the notification to
act on it. For others, such as Calendar
reminders, the notification gives you
options such as opening the appointment
or dismissing the notification.
If you do not act on a notification after a
few seconds, it becomes an icon in the
lower-right portion of the screen. Tap the
icon area to display your notifications.
Throw a notificationoff the side of the
screen to dismiss it.

Get Help
02
Need help with setup?
After your phone is activated with Sprint,
Palm support staff can help you set up
your phone and get you up and running.
Call 1-866-750-PALM (7256) from 6:00 AM
to 8:00 PM Pacific, Monday through Friday,
and 8:00 AM to 5:00 PM Pacific, Saturday
and Sunday. This service is free within 90
days of purchase. Palm may refer you to
Sprint for help with carrier-specific features.
Offer subject to change without notice.
Help on your phone
Tap Help in the Launcher or in an
applicationmenu to view Tips (short
how-tos), Clips (animations about your
phone), and helpful Featured articles.
Features Guide
Take a peek at other thingsyou can do
with your phone to get the information you
want when you want it.
Online support
•Visit sprint.com/palmpixisupport
to access the User Guide, how-to
videos, tutorials, and helpful
support information.
•Visit palm.com/support to edit your
Palm profile, manage your phone, and
obtain additional support.
