Panasonic CS-A9KKD-2 User manual

© Panasonic HA Air-Conditioning (M) Sdn. Bhd. 2010.
Unauthorized copying and distribution is a violation of law.
Order No: PHAAM1003127C3
Indoor Unit Outdoor Unit
CS-A9KKD-2
CS-A12KKD-2
CS-A18KKD-2
CS-A24KKD-2
CS-A28KKD-2
CU-A9KKD-2
CU-A12KKD-2
CU-A18KKD-2
CU-A24KKD-2
CU-A28KKD-2
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
WARNING

2
TABLE OF CONTENTS
1. Safety Precautions .............................................4
2. Specification .......................................................6
3. Features.............................................................15
4. Location of Controls and Components..........16
4.1 Indoor Unit ..................................................16
4.2 Outdoor Unit ...............................................16
4.3 Remote Control ..........................................16
5. Dimensions .......................................................17
5.1 Indoor Unit ..................................................17
5.2 Outdoor Unit ...............................................19
6. Refrigeration Cycle Diagram ...........................21
6.1 CS-A9KKD-2 CU-A9KKD-2
CS-A12KKD-2 CU-A12KKD-2...................21
6.2 CS-A18KKD-2 CU-A18KKD-2
CS-A24KKD-2 CU-A24KKD-2
CS-A28KKD-2 CU-A28KKD-2....................22
7. Block Diagram ..................................................23
7.1 CS-A9KKD-2 CU-A9KKD-2.......................23
7.2 CS-A12KKD-2 CU-A12KKD-2...................24
7.3 CS-A18KKD-2 CU-A18KKD-2
CS-A24KKD-2 CU-A24KKD-2...................25
7.4 CS-A28KKD-2 CU-A28KKD-2...................26
8. Wiring Connection Diagram ............................27
8.1 CS-A9KKD-2 CU-A9KKD-2.......................27
8.2 CS-A12KKD-2 CU-A12KKD-2...................28
8.3 CS-A18KKD-2 CU-A18KKD-2
CS-A24KKD-2 CU-A24KKD-2....................29
8.4 CS-A28KKD-2 CU-A28KKD-2....................30
9. Electronic Circuit Diagram ..............................31
9.1 CS-A9KKD-2 CU-A9KKD-2.......................31
9.2 CS-A12KKD-2 CU-A12KKD-2...................32
9.3 CS-A18KKD-2 CU-A18KKD-2
CS-A24KKD-2 CU-A24KKD-2...................33
9.4 CS-A28KKD-2 CU-A28KKD-2...................34
10. Printed Circuit Board .......................................35
10.1 Indoor Unit ..................................................35
11. Installation Instruction.....................................40
11.1 Select the Best Location.............................40
11.2 Indoor Unit ..................................................41
11.3 Outdoor Unit ...............................................45
12. Operation Control.............................................49
12.1 Heating Operation ......................................49
12.2 Cooling Operation.......................................51
12.3 Soft Dry Operation......................................53
12.4 Automatic Operation...................................55
12.5 Indoor Fan Speed Control ..........................57
12.6 Outdoor Fan Speed Control .......................62
12.7 Vertical Airflow Direction Control................62
12.8 Horizontal Airflow Direction Control............65
12.9 Powerful Operation.....................................66
12.10 Quiet Operation ......................................... 67
12.11 Timer Control............................................. 69
12.12 Random Auto Restart Control ................... 69
12.13 Remote Control Signal Receiving Sound.. 69
12.14 Patrol Operation ........................................ 70
12.15 E-ion operation .......................................... 74
12.16 ECO Patrol Operation................................ 77
13. Protection Control........................................... 82
13.1 Restart Control (Time Delay Safety Control)..
................................................................... 82
13.2 7 Minutes Time Save Control .................... 82
13.3 60 Seconds Forced Operation .................. 82
13.4 Starting Current Control ............................ 82
13.5 Freeze Prevention Control ........................ 82
13.6 Compressor Reverse Rotation Protection
Control ....................................................... 83
13.7 Dew Prevention Control ............................ 83
13.8 30 Minutes Time Save Control .................. 83
13.9 Compressor Overload Protection Control . 83
13.10 4-Way Valve Control.................................. 83
13.11 Outdoor Fan Motor Control ....................... 84
13.12 Hot Start Control........................................ 84
13.13 Cold Draft Prevention Control ................... 84
13.14 Deice Control............................................. 85
13.15 Restart Control (Time Delay Safety Control)..
................................................................... 87
13.16 7 Minutes Time Save Control .................... 87
13.17 60 Seconds Forced Operation .................. 87
13.18 Starting Current Control ............................ 87
13.19 Freeze Prevention Control ........................ 87
13.20 Compressor Reverse Rotation Protection
Control ....................................................... 88
13.21 Dew Prevention Control ............................ 88
13.22 Restart Control (Time Delay Safety Control)..
................................................................... 88
13.23 Compressor Reverse Rotation Protection
Control ....................................................... 88
13.24 Overload Protection Control ...................... 89
13.25 4-Way Valve Control.................................. 89
13.26 Hot Start Control........................................ 89
13.27 Cold Draft Prevention Control ................... 90
13.28 Deice Control............................................. 90
14. Servicing Mode ................................................ 92
14.1 Auto OFF/ON Button ................................. 92
14.2 Remote Control Button.............................. 93
15. Troubleshooting Guide................................... 94
15.1 Refrigeration cycle system ........................ 94
16. Disassembly and Assembly Instructions ..... 96
16.1 CS-A9KKD-2 CS-A12KKD-2 .................... 96
16.2 CS-A18KKD-2 CS-A24KKD-2
CS-A28KKD-2 ......................................... 100
17. Technical Data ............................................... 104
17.1 Thermostat Characteristics ..................... 104
17.2 Operation Characteristics........................ 105

3
18. Exploded View and Replacement Parts List .....
.........................................................................125
18.1 Indoor Unit................................................125
18.2 Outdoor Unit .............................................131

4
CAUTION
WARNING
WARNING
1. Safety Precautions
•Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing.
•Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the
power plug and main circuit for the model installed.
•The caution items stated here must be followed because these important contents are related to safety. The
meaning of each indication used is as below. Incorrect installation or servicing due to ignoring of the instruction
will cause harm or damage, and the seriousness is classified by the following indications.
This indication shows the possibility of causing death or serious injury.
This indication shows the possibility of causing injury or damage to properties.
•The items to be followed are classified by the symbols:
•Carry out test running to confirm that no abnormality occurs after the servicing. Then, explain to user the
operation, care and maintenance as stated in instructions. Please remind the customer to keep the operating
instructions for future reference.
1. Do not modify the machine, part, material during repairing service.
2. If wiring unit is supplied as repairing part, do not repair or connect the wire even only partial wire break. Exchange the whole wiring unit.
3. Do not wrench the fasten terminal. Pull it out or insert it straightly.
4. Engage dealer or specialist for installation and servicing. If installation of servicing done by the user is defective, it will cause water leakage,
electrical shock or fire.
5. Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electric shock or fire.
6. Use the attached accessories parts and specified parts for installation and servicing. Otherwise, it will cause the set to fall, water leakage, fire
or electrical shock.
7. Install at a strong and firm location which is able to withstand the set’s weight. If the strength is not enough or installation is not properly done,
the set will drop and cause injury.
8. For electrical work, follow the local national wiring standard, regulation and the installation instruction. An independent circuit and single outlet
must be used. If electrical circuit capacity is not enough or defect found in electrical work, it will cause electrical shock or fire.
9. This equipment is strongly recommended to install with Earth Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD). Otherwise, it
may cause electrical shock and fire in case equipment breakdown or insulation breakdown.
10. Do not use joint cable for indoor / outdoor connection cable. Use the specified Indoor/Outdoor connection cable, refer to installation instruction
CONNECT THE CABLE TO THE INDOOR UNIT and connect tightly for indoor / outdoor connection. Clamp the cable so that no external force
will be acted on the terminal. If connecting or fixing is not perfect, it will cause heat up or fire at the connection.
11. Wire routing must be properly arranged so that control board cover is fixed properly. If control board cover is not fixed perfectly, it will cause
heat-up or fire at the connection point of terminal, fire or electrical shock.
12. When install or relocate air conditioner, do not let any substance other than the specified refrigerant, eg. air etc. mix into refrigeration
cycle (piping). (Mixing of air etc. will cause abnormal high pressure in refrigeration cycle and result in explosion, injury etc.).
13. Do not install outdoor unit near handrail of veranda. When installing air-conditioner unit at veranda of high rise building, child may climb up to
outdoor unit and cross over the handrail and causing accident.
14. This equipment must be properly earthed. Earth line must not be connected to gas pipe, water pipe, earth of lightning rod and
telephone. Otherwise, it may cause electric shock in case equipment breakdown or insulation breakdown.
15. Keep away from small children, the thin film may cling to nose and mouth and prevent breathing.
16. Do not use unspecified cord, modified cord, joint cord or extension cord for power supply cord. Do not share the single outlet with
other electrical appliances. Poor contact, poor insulation or over current will cause electrical shock or fire.
17. Tighten the flare nut with torque wrench according to specified method. If the flare nut is over-tightened, after a long period, the flare
may break and cause refrigerant gas leakage.
18. During pump down operation, stop the compressor before remove the refrigeration piping. (Removal of compressor while compressor
is operating and valves are opened will cause suck-in of air, abnormal high pressure in refrigeration cycle and result in explosion,
injury etc.)
This symbol denotes item that is PROHIBITED from doing.

5
CAUTION
WARNING
19. After completion of installation or service, confirm there is no leakage or refrigerant gas. It may generate toxic gas when the refrigerant
contacts with fire.
20. Ventilate if there is refrigerant gas leakage during operation. It may cause toxic gas when refrigerant contacts with fire.
21. Do not insert your fingers or other objects into the unit, high speed rotating fan may cause injury.
22. Must not use other parts except original parts described in catalog and manual.
1. Do not install the unit at place where leakage of flammable gas may occur. In case gas leaks and accumulates at surrounding of the
unit, it may cause fire.
2. Carry out drainage piping as mentioned in installation instructions. If drainage is not perfect, water may enter the room and damage
the furniture.
3. Tighten the flare nut with torque wrench according to specified method. If the flare nut is over-tightened, after a long period, the flare
may break and cause refrigerant gas leakage.
4. Do not touch outdoor unit air inlet and aluminium fin. It may cause injury.
5. Select an installation location which is easy for maintenance.
6. Pb free solder has a higher melting point than standard solder; typically the melting point is 50°F – 70°F (30°C – 40°C) higher. Please use
a high temperature solder iron. In case of the soldering iron with temperature control, please set it to 700 ± 20°F (370 ± 10°C).
Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
7. Power supply connection to the air conditioner. Connect the power supply cord of the air conditioner to the mains using one of the following
methods.
Power supply point shall be the place where there is ease for access for the power disconnection in case of emergency. In some countries,
permanent connection of this room air conditioner to the power supply is prohibited.
i. Power supply connection to the receptacle using a power plug. Use an approved 15/16A (3/4~1.5HP) or 16A (2.0HP) or 20A (2.5HP) or
25A (3.0HP) power plug with earth pin for the connection to the socket.
ii. Power supply connection to a circuit breaker for the permanent component. Use an approved 16A (3/4~2.0HP) or 20A (2.5HP) or
25A (3.0HP) circuit breaker for the permanent connection. It must be a double pole switch with a minimum 3.0 mm contact gap.
8. Do not release refrigerant during piping work for installation, servicing, reinstallation and during repairing a refrigerant parts. Take
care of the liquid refrigerant, it may cause frostbite.
9. Installation or servicing work: It may need two people to carry out the installation or servicing work.
10. Do not install this appliance in a laundry room or other location where water may drip from the ceiling, etc.
11. Do not sit or step on the unit, you may fall down accidentally.
12. Do not touch the sharp aluminium fin, sharp parts may cause injury.

6
2. Specification
Indoor CS-A9KKD-2 CS-A12KKD-2
Model
Outdoor CU-A9KKD-2 CU-A12KKD-2
Performance Test Condition NEW JIS NEW JIS
Phase, Hz Single, 50 Single, 50
Power Supply
V 220 230 220 230
kW 2.43 2.43 3.22 3.23
BTU/h 8300 8300 11000 11030
Capacity
kJ/h 2090 2090 2770 2780
Running Current A 4.3 4.2 5.0 5.0
Input Power W 930 950 1.08k 1.10k
W/W 2.61 2.56 2.98 2.94
EER
Btu/hW 8.92 8.74 10.19 10.03
Power Factor % 98 98 98 96
dB-A 36 / 26 36 / 26 39 / 29 39 / 29
Indoor Noise (H / L)
Power Level dB - - - -
dB-A 48 / - 49 / - 55 / - 55 / -
Cooling
Outdoor Noise (H / L)
Power Level dB - - - -
kW 2.64 2.66 3.81 3.83
BTU/h 9010 9080 13000 13080
Capacity
kcal/h 2270 2290 3280 3290
Running Current A 3.3 3.3 4.8 4.8
Input Power W 710 740 1.03k 1.06k
W/W 3.72 3.59 3.70 3.61
COP
Btu/hW 12.69 12.27 12.62 12.34
Power Factor % 98 97 98 96
dB-A 38 / 28 38 / 28 40 / 29 40 / 29
Indoor Noise (H / L)
Power Level dB - - - -
dB-A 48 / - 49 / - 56 / - 56 / -
Heating
Outdoor Noise (H / L)
Power Level dB - - - -
Max Current (A) / Max Input Power (W) 5.1 / 1.13k 6.0 / 1.35k
Starting Current (A) 18.0 20.0
Type Hermetic Motor Hermetic Motor
Motor Type Induction (2 poles) Induction (2 poles)
Compressor
Output Power W 750 950
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Induction (4 poles) Induction (4 poles)
Input Power W 32.6 - 33.6 41.4 - 42.9
Output Power W 24 24
QLo rpm - -
Lo rpm Cooling: 730 - 730
Heating: 780 - 780
Cooling: 800 - 800
Heating: 840 - 840
Me rpm Cooling: 870 - 870
Heating: 870 - 870
Cooling: 950 - 950
Heating: 950 - 950
Hi rpm Cooling: 1040 - 1040
Heating: 1080 - 1080
Cooling: 1100 - 1100
Heating: 1120 - 1120
Indoor Fan
Speed
SHi rpm Cooling: 1080 - 1080 Cooling: 1120 - 1120

7
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W 66.0 - 74.8 71.5 - 80.3
Output Power W 30 30
Outdoor Fan
Speed Hi rpm 800 - 830 830 - 840
Moisture Removal L/h (Pt/h) 1.5 (3.2) 1.8 (3.8)
Lo m3/min (ft3/min) Cooling: 7.2 (253) - 7.2 (253)
Heating: 7.7 (270) – 7.7 (270)
Cooling: 7.9 (277) - 7.9 (277)
Heating: 8.3 (291) - 8.3 (291)
Me m3/min (ft3/min) Cooling: 8.5 (301) - 8.5 (301)
Heating: 8.5 (301) – 8.5 (301)
Cooling: 9.3 (329) - 9.3 (329)
Heating: 9.3 (329) - 9.3 (329)
Hi m3/min (ft3/min) Cooling: 10.2 (360) - 10.2 (360)
Heating: 10.6 (374) - 10.6 (374)
Cooling: 10.8 (381) - 10.8 (381)
Heating: 11.0 (388) - 11.0 (388)
Indoor Airflow
SHi m3/min (ft3/min) Cooling: 10.6 (374) - 10.6 (374) Cooling: 11.0 (388) - 11.0 (388)
Outdoor
Airflow Hi m3/min (ft3/min) 29.5 (1040) - 30.0 (1060) 32.5 (1150) - 33.0 (1160)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm3Suniso 4GDID or ATMOS NM56M (350) Suniso 4GDID or ATMOS NM56M (350)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 670 (23.7) R22, 1010 (35.7)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 510 (20-3/32) 290 (11-7/16) / 540 (21-9/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 650 (25-19/32) 870 (34-9/32) / 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 230 (9-1/16) 204 (8-1/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 27 (60) 9 (20) / 33 (73)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.7 (1/2)
Standard length m (ft) 7.5 (24.6) 7.5 (24.6)
Length range (min – max) m (ft) 3 ~ 10 (9.8 ~ 32.8) 3 ~ 15 (9.8 ~ 49.2)
I/D & O/D Height different m (ft) 5 (16.4) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16 16
Drain Hose
Length mm 650 650
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI 2 x 15 x 21 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Fin Material Aluminium (Blue coated) Aluminium (Blue coated)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x
FPI 1 x 19 x 19 2 x 24 x 19
Outdoor Heat
Exchanger
Size (W x H x L) mm 22 x 483 x 567.4 36.38 x 504 x 684.0:713.0
Material - -
Air Filter
Type - -
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat - -
Protection Device 2 stage Overload Protector Overload Protector

8
DRY BULB WET BULB DRY BULB WET BULB
Maximum 32 23 32 23
Cooling
Minimum 16 11 16 11
Maximum 30 - 30 -
Indoor
Operation
Range Heating
Minimum 16 - 16 -
Maximum 43 26 43 26
Cooling
Minimum 16 11 16 11
Maximum 24 18 24 18
Outdoor
Operation
Range Heating
Minimum -5 -6 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.

9
Indoor CS-A18KKD-2 CS-A24KKD-2
Model
Outdoor CU-A18KKD-2 CU-A24KKD-2
Performance Test Condition NEW JIS NEW JIS
Phase, Hz Single, 50 Single, 50
Power Supply
V 220 230 220 230
kW 5.15 5.15 6.43 6.43
Btu/h 17600 17600 22000 22000
Capacity
kJ/h 18540 18540 23150 23150
Running Current A 8.3 8.1 12.6 12.6
Input Power W 1.80k 1.82k 2.62k 2.64k
W/W 2.86 2.83 2.45 2.44
EER
Btu/hW 9.78 9.67 8.40 8.33
Power Factor % 99 98 95 91
dB-A 43 - 38 43 - 38 47 - 41 47 - 41
Indoor Noise (H / L)
Power Level dB - -
dB-A 53 / - 54 / - 53 / - 54 / -
Cooling
Outdoor Noise (H / L)
Power Level dB - -
kW 5.50 5.52 7.15 7.15
BTU/h 18800 18800 24400 24400
Capacity
kJ/h 19800 19870 25740 25740
Running Current A 7.8 7.6 12.3 12.4
Input Power W 1.68k 1.72k 2.53k 2.55k
W/W 3.27 3.21 2.83 2.80
COP
Btu/hW 11.19 10.93 9.64 9.58
Power Factor % 98 98 93 89
dB-A 42 - 38 42 - 38 46 - 41 46 - 41
Indoor Noise (H / L)
Power Level dB - -
dB-A 54 / - 55 / - 54 / - 54 / -
Heating
Outdoor Noise (H / L)
Power Level dB - -
Max Current (A) / Max Input Power (W) 10.2 / 2.20k 15.8 / 3.30k
Starting Current (A) 40.0 65.0
Type Rotary (1 cylinder) rolling piston type Rotary (1 cylinder) rolling piston type
Motor Type Induction (2 poles) Induction (2 poles)
Compressor
Output Power W 1.5k 2.0k
Type Cross-Flow Fan Cross-Flow Fan
Material ASG30K1 ASG30K1
Motor Type Transistor (8 poles) Transistor (8 poles)
Input Power W - -
Output Power W 30 40
Lo rpm Cooling: 1040 - 1040
Heating: 1100 - 1100
Cooling: 1150 - 1150
Heating: 1230 - 1230
Me rpm Cooling: 1140 - 1140
Heating: 1140 - 1140
Cooling: 1270 - 1270
Heating: 1270 - 1270
Hi rpm Cooling: 1240 - 1240
Heating: 1310 - 1310
Cooling: 1390 - 1390
Heating: 1530 - 1530
Indoor Fan
Speed
SHi rpm Cooling: 1310 - 1310 Cooling: 1530 - 1530

10
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W 138.0 -150.3 138.0 -150.3
Output Power W 80 80
Lo rpm 460 - 490 460 - 490
Outdoor Fan
Speed
Hi rpm 815 - 830 815 - 830
Moisture Removal L/h (Pt/h) 2.8 (5.9) 3.6 (7.6)
Lo m3/min (ft3/min) Cooling: 13.8 (486) - 13.8 (486)
Heating: 14.4 (507) - 14.4 (507)
Cooling: 15.4 (544) - 15.4 (544)
Heating: 16.1 (568) - 16.1 (568)
Me m3/min (ft3/min) Cooling: 15.1 (532) - 15.1 (532)
Heating: 14.9 (526) – 14.9 (526)
Cooling: 17.0 (600) - 17.0 (600)
Heating: 16.6 (586) – 16.6 (586)
Hi m3/min (ft3/min) Cooling: 16.4 (579) - 16.4 (579)
Heating: 17.1 (604) - 17.1 (604)
Cooling: 18.6 (657) - 18.6 (657)
Heating: 20.0 (706) - 20.0 (706)
Indoor Airflow
SHi m3/min (ft3/min) 17.3 (612) - 17.3 (612) 20.5 (723) - 20.5 (723)
Lo m3/min (ft3/min) 28.6 (1010) - 30.5 (1080) 28.6 (1010) - 30.5 (1080)
Outdoor
Airflow Hi m3/min (ft3/min) 50.7 (1790) - 51.7 (1830) 50.7 (1790) - 51.7 (1830)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm3Suniso 4GDID or ATMOS NM56M (700) Suniso 4GDID or ATMOS M60 (1130)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 1710 (60.4) R22, 2050 (72.4)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 750 (29-17/32) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 345 (13-19/32) 235 (9-9/32) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 60 (132) 12 (26) / 60 (132)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 ~ 25 (9.8 ~ 82.0) 3 ~ 25 (9.8 ~ 82.0)
I/D & O/D Height different m (ft) 20.0 (65.6) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 30 (0.3)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 12 12
Drain Hose
Length mm 560 560
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI 2 x 15 x 21 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) mm 810 x 315 x 25.4 810 x 315 x 25.4
Fin Material Aluminium (Blue coated) Aluminium (Blue coated)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x
FPI 2 x 28 x 17 2 x 28 x 17
Outdoor Heat
Exchanger
Size (W x H x L) mm 44 x 711.2 x 782.4:816.9 44.0 x 711.2 x 782.4:816.9
Material - -
Air Filter
Type - -
Power Supply Indoor Indoor
Power Supply Cord A 16 20
Thermostat - -
Protection Device Inner Protector Inner Protector

11
DRY BULB WET BULB DRY BULB WET BULB
Maximum 32 23 32 23
Cooling
Minimum 16 11 16 11
Maximum 30 - 30 -
Indoor
Operation
Range Heating
Minimum 16 - 16 -
Maximum 43 26 43 26
Cooling
Minimum 16 11 16 11
Maximum 24 18 24 18
Outdoor
Operation
Range Heating
Minimum -5 -6 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.

12
Indoor CS-A28KKD-2
Model
Outdoor CU-A28KKD-2
Performance Test Condition NEW JIS
Phase, Hz Single, 50
Power Supply
V 220 230
kW 7.20 7.20
BTU/h 24600 24600
Capacity
kJ/h 25920 25920
Running Current A 13.1 12.8
Input Power W 2.86k 2.87k
W/W 2.52 2.51
EER
BTU/hW 8.60 8.57
Power Factor % 99 97
dB-A 49 / 44
Indoor Noise (H / L)
Power Level dB -
dB-A 65 / -
Cooling
Outdoor Noise (H / L)
Power Level dB -
kW 8.60 8.60
BTU/h 29400 29400
Capacity
kJ/h 30960 30960
Running Current A 14.1 13.8
Input Power W 3.08k 3.09k
W/W 2.79 2.78
COP
BTU/hW 9.55 9.51
Power Factor % 99 97
dB-A 48 / 44
Indoor Noise (H / L)
Power Level dB -
dB-A 64 / -
Heating
Outdoor Noise (H / L)
Power Level dB -
Max Current (A) / Max Input Power (W) 16.4 / 3.45k
Starting Current (A) 40
Type Hermetic motor
Motor Type Induction (2 poles)
Compressor
Output Power W 2.4k
Type Cross-Flow Fan
Material ASG30K1
Motor Type Transistor (8 poles)
Input Power W 94.8 - 94.8
Output Power W 40
Lo rpm Cooling: 1250 - 1250
Heating: 1330 - 1330
Me rpm Cooling: 1380 - 1380
Heating: 1380 - 1380
Hi rpm Cooling: 1500 - 1500
Heating: 1540 - 1540
Indoor Fan
Speed
SHi rpm Cooling: 1540 - 1540

13
Type Propeller Fan
Material PP
Motor Type Induction (8 poles)
Input Power W 147.0 -163.1
Output Power W 80
Lo rpm 490 - 520
Outdoor Fan
Speed
Hi rpm 855 - 870
Moisture Removal L/h (Pt/h) 4.1 (8.7)
Lo m3/min (ft3/min) Cooling: 16.5 (583) - 16.5 (583)
Heating: 17.6 (622) – 17.6 (622)
Me m3/min (ft3/min) Cooling: 18.2 (643) - 18.2 (643)
Heating: 18.3 (645) – 18.3 (645)
Hi m3/min (ft3/min) Cooling: 19.8 (699) - 19.8 (699)
Heating: 20.4 (720) – 20.4 (720)
Indoor Airflow
SHi m3/min (ft3/min) 20.3 (718) - 20.3 (718)
Lo m3/min (ft3/min) 30.1 (1060) - 32.0 (1130)
Outdoor Airflow
Hi m3/min (ft3/min) 52.5 (1850) - 53.5 (1890)
Control Device Capillary Tube
Refrigerant Oil cm3SUNISO 4GDID or ATMOS M60 or ATMOS 56M (900)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 2130 (75.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 66 (146)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 ~ 30 (9.8 ~ 98.4)
I/D & O/D Height different m (ft) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
Inner Diameter mm 12
Drain Hose
Length mm 560
Fin Material Aluminium (Pre coat)
Fin Type Slit Fin
Row x Stage x FPI 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) mm 810 x 315 x 25.4
Fin Material Aluminium (Blue coated)
Fin Type Corrugated Fin
Row x Stage x FPI 2 x 28 x 17
Outdoor Heat
Exchanger
Size (W x H x L) mm 44.0 x 711.2 x 802.4
836.9
Material Polypropelene
Air Filter
Type One-touch
Power Supply Outdoor
Power Supply Cord A 20
Thermostat -
Protection Device Inner Protector

14
DRY BULB WET BULB
Maximum 32 23
Cooling
Minimum 16 11
Maximum 30 -
Indoor Operation
Range
Heating
Minimum 16 -
Maximum 43 26
Cooling
Minimum 16 11
Maximum 24 18
Outdoor Operation
Range
Heating
Minimum -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.

15
3. Features
•E-ion Air Purifying System with Patrol Sensor
oActive e-ions are released to catch dust particles and bring them back the large positively charged filter.
oPatrol Sensor color changes to indicate the dirt level in the air
•Long Installation Piping
oCS/CU-A9KK, long piping up to 10 meters.
oCS/CU-A12KK, long piping up to 15 meters.
oCS/CU-A18KK, CS/CU-A24KK, long piping up to 25 meters.
oCS/CU-A28KK, long piping up to 30 meters.
•Easy to use remote control
•Quality Improvement
oRandom auto restart after power failure for safety restart operation
oGas leakage protection
oPrevent compressor reverse cycle
oInner protector to protect compressor
oNoise prevention during soft dry operation
oBlue coated condenser for high resistance to corrosion
•Operation Improvement
oQuiet mode to reduce the indoor unit operating sound
oPowerful mode to reach the desired room temperature quickly
o24-hour timer setting

16
4. Location of Controls and Components
4.1 Indoor Unit
4.2 Outdoor Unit
4.3 Remote Control

17
5. Dimensions
5.1 Indoor Unit
5.1.1 CS-A9KKD-2 CS-A12KKD-2

18
5.1.2 CS-A18KKD-2 CS-A24KKD-2 CS-A28KKD-2

19
5.2 Outdoor Unit
5.2.1 CU-A9KKD-2
5.2.2 CU-A12KKD-2

20
5.2.3 CU-A18KKD-2 CU-A24KKD-2 CU-A28KKD-2
