Publication date: December 2002 SJC00281BED
2SC4626J
Silicon NPN epitaxial planar type
For high-frequency amplification
■Features
•Optimum for RF amplification of FM/AM radios
•High transition frequency fT
•SS-Mini type package, allowing downsizing of the equipment and
automatic insertion through the tape packing
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 30 V
Collector-emitter voltage (Base open) VCEO 20 V
Emitter-base voltage (Collector open) VEBO 5V
Collector current IC30 mA
Collector power dissipation PC125 mW
Junction temperature Tj125 °C
Storage temperature Tstg −55 to +125 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base cutoff current (Emitter open) ICBO VCB =10 V, IE=0 0.1 µA
Forward current transfer ratio *hFE VCB =10 V, IE=−1 mA 70 220 
Transition frequency fTVCB =10 V, IE=−1 mA, f =200 MHz 150 250 MHz
Noise figure NF VCB =10 V, IE=−1 mA, f =5 MHz 2.8 4.0 dB
Reverse transfer impedance Zrb VCB =10 V, IE=−1 mA, f =2 MHz 22 50 Ω
Common-emitter reverse transfer Cre VCB =10 V, IE=−1 mA, f =10.7 MHz 0.9 1.5 pF
capacitance
■Electrical Characteristics Ta=25°C ±3°C
Rank B C No-rank
hFE 70 to 140 110 to 220 70 to 220
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
Unit: mm
Marking Symbol: V
0.27 ±0.02
3
12
0.12
+0.03
–0.01
0.80
±0.05
(0.80)
0.85
1.60
±0.05
0 to 0.02
0.10 max.
0.70
+0.05 –0.03
(0.375)
5˚
5˚
1.60
+0.05
–0.03
1.00 ±0.05
(0.50)(0.50)
+0.05 –0.03
1: Base
2: Emitter
3: Collector
EIAJ: SC-89
SSMini3-F1 Package
Product of no-rank is not classified and have no indication for rank.
This product complies with the RoHS Directive (EU 2002/95/EC).

2SC4626J
2SJC00281BED
IBVBE ICVBE VCE(sat) IC
PCTaICVCE ICIB
hFE ICCob VCB
0 1406020 80 12040 100
0
140
120
100
60
80
40
20
Ambient temperature Ta(°C)
Collector power dissipation P
C
(mW)
012108264
0
16
12
4
10
14
8
2
6
T
a
= 25°C
I
B
= 100 µA
80 µA
60 µA
40 µA
20 µA
Collector-emitter voltage V
CE
(V)
Collector current I
C
(mA)
012108264
0
100
80
60
40
20
90
70
50
30
10
VCE = 10 V
Ta= 25°C
Base current IB(mA)
Collector current IC(mA)
0 1.21.00.80.2 0.60.4
0
10
20
30
40
50
60
70
80
90 V
CE
= 10 V
T
a
= 25°C
Base-emitter voltage V
BE
(V)
Base current I
B
(mA)
0 0.2 0.6 0.8 1.0 1.20.4 1.4
0
120
100
80
60
40
20
V
CE
= 10 V
T
a
= 85°C
25°C−25°C
Base-emitter voltage VBE (V)
Collector current IC(mA)
0.1 1 10 100 1 000
0.01
10
1
0.1
I
C
/ I
B
= 10
T
a
= 85°C
25°C−25°C
Collector current IC(mA)
Collector-emitter saturation voltage VCE(sat) (V)
1 10 100
0
250
200
150
100
50
VCE = 10 V
Ta= 85°C
25°C
−25°C
Collector current IC(mA)
Forward current transfer ratio hFE
0 5 15 20 25 3010 35
1
10
f = 1 MHz
T
a
= 25°C
Collector-base voltage VCB (V)
Collector output capacitance (Common base, input open circuited) C
ob
(pF)
