Panasonic FP7 Series User manual

Safety Precautions
Observe the following notices to ensure personal safety or to prevent accidents.
To ensure that you use this product correctly, read this User’s Manual thoroughly before use.
Make sure that you fully understand the product and information on safety.
This manual uses two safety flags to indicate different levels of danger.
WARNING
If critical situations that could lead to user’s death or serious injury is assumed by
mishandling of the product.
-Always take precautions to ensure the overall safety of your system, so that the whole
system remains safe in the event of failure of this product or other external factor.
-Do not use this product in areas with inflammable gas. It could lead to an explosion.
-Exposing this product to excessive heat or open flames could cause damage to the lithium
battery or other electronic parts.
CAUTION
If critical situations that could lead to user’s injury or only property damage is
assumed by mishandling of the product.
-To prevent excessive exothermic heat or smoke generation, use this product at the values
less than the maximum of the characteristics and performance that are assured in these
specifications.
-Do not dismantle or remodel the product. It could cause excessive exothermic heat or smoke
generation.
-Do not touch the terminal while turning on electricity. It could lead to an electric shock.
-Use the external devices to function the emergency stop and interlock circuit.
-Connect the wires or connectors securely.
The loose connection could cause excessive exothermic heat or smoke generation.
-Do not allow foreign matters such as liquid, flammable materials, metals to go into the inside
of the product. It could cause excessive exothermic heat or smoke generation.
-Do not undertake construction (such as connection and disconnection) while the power
supply is on. It could lead to an electric shock.
Copyright / Trademarks
-This manual and its contents are copyrighted.
-You may not copy this manual, in whole or part, without written consent of Panasonic
Industrial Devices SUNX Co., Ltd.
-Windows is a registered trademark of Microsoft Corporation in the United States and other
countries.
-All other company names and product names are trademarks or registered trademarks of
their respective owners. PLC_ORG

Introduction
Thank you for buying a Panasonic product. Before you use the product, please carefully read
the installation instructions and the user’s manual, and understand their contents in detail to
use the product properly.
Types of Manual
•There are different types of user’s manual for the FP7 series, as listed below. Please refer to
a relevant manual for the unit and purpose of your use.
•The manuals can be downloaded on our website:
https://industrial.panasonic.com/ac/e/dl_center/manual/
Unit name or purpose of
use
Manual name Manual code
FP7 Power Supply Unit FP7 CPU Unit User‘s Manual
(Hardware) WUME-FP7CPUH
FP7 CPU Unit
FP7 CPU Unit Command Reference Manual WUME-FP7CPUPGR
FP7 CPU Unit User‘s Manual (Logging Trace
Function) WUME-FP7CPULOG
FP7 CPU Unit User‘s Manual (Security Function) WUME-FP7CPUSEC
Instructions for Built-in
LAN Port
FP7 CPU Unit User‘s Manual
(LAM Port Communication) WUME-FP7LAN
FP7 CPU Unit User‘s Manual (EtherNet IP
communication) See our web site.
FP7 Web Server Function Manual See our web site.
Instructions for Built-in
COM Port
FP7 series User‘s Manual (SCU communication) WUME-FP7COM
FP7 Extension
(Communication)
Cassette (RS-
232C/RS485 type)
FP7 Extension
(Communication)
Cassette (Ethernet type)
FP7 series User‘s Manual
(Communication cassette Ethernet type) WUME-FP7CCET
FP7 Extension (Function)
Cassette
Analog Cassette
FP7 Analog Cassette User‘s Manual WUME-FP7FCA
FP7 Digital Input/Output Unit FP7 Digital Input/Output Unit User‘s Manual WUME-FP7DIO
FP7 Analog Input Unit FP0R Analog Input Unit User’s Manual WUME-FP7AIH
FP7 Analog Output Unit FP7 Analog Output Unit User’s Manual WUME-FP7AOH

Table of Contents
ii
Unit name or purpose of
use
Manual name Manual code
FP7 Thermocouple Multi-
analog Input Unit FP7 Thermocouple Multi-analog Input Unit
FP7 RTD Input Unit
Users Manual
WUME-FP7TCRTD
FP7 RTD Input Unit
FP7 Multi Input/Output Unit FP7 Multi Input/Output Unit Users Manual WUME-FP7MXY
FP7 High-speed counter unit FP7 High-speed Counter Unit Users Manual WUME-FP7HSC
FP7 Pulse Output Unit FP7 Pulse Output Unit Users Manual WUME-FP7PG
FP7 Positioning Unit FP7 Positioning Unit Users Manual WUME-FP7POSP
FP7 Motion Control Unit FP7 Motion Control Unit Users Manual WUME-FP7MCEC
FP7 Serial Communication
Unit FP7 series Users Manual (SCU communication) WUME-FP7COM
FP7 Multi-wire Link Unit FP7 Multi-wire Link Unit Users Manual WUME-FP7MW
PHLS System PHLS System User’s Manual WUME-PHLS
Programming Software
FPWIN GR7 FPWIN GR7 Operation Guide WUME-FPWINGR7

Table of Contents
iii
Table of Contents
1. System Configuration .........................................................1-1
1.1 Unit Functions and Types....................................................................... 1-2
1.1.1 Functions of Unit .....................................................................................1-2
1.1.2 Unit Type.................................................................................................1-3
1.2 Network Type.......................................................................................... 1-4
1.2.1 MEWNET-W / MEWNET-W2 ..................................................................1-4
1.2.2 MEWNET-F .............................................................................................1-6
1.3Function Overview .................................................................................. 1-8
1.3.1 PLC Link (MEWNET-W / MEWNET-W2)................................................1-8
1.3.2 Data Transfer (MEWNT-W / MEWNET-W2).........................................1-10
1.3.3 Remote I/O Control (MEWNET-F) ........................................................1-11
1.3.4 Other Functions (MEWNET-W / MEWNE-W2) .....................................1-11
1.4 Restrictions on Combinations of Units.................................................. 1-12
1.4.1 Restrictions on Power Consumption.....................................................1-12
1.4.2 Applicable Versions of Unit and Software.............................................1-12
1.4.3 Restrictions on Number of Installed Units and Used Functions............1-12
1.4.4 Restrictions on Installation Position ......................................................1-13
1.5 Restrictions on Communication ............................................................ 1-14
1.5.1 Restrictions on Network Configuration..................................................1-14
2. Names and Functions of Parts...........................................2-1
2.1 Names and Functions of Parts ............................................................... 2-2
2.2 Switch Settings ....................................................................................... 2-3
2.3 Operation Monitor LEDs ......................................................................... 2-5
3. Wiring ...................................................................................3-1
3.1 Applicable Cables and Solderless Terminals ......................................... 3-2

Table of Contents
iv
3.1.1 Applicable cables ....................................................................................3-2
3.1.2 Terminals.................................................................................................3-3
3.2 Wiring ..................................................................................................... 3-4
3.2.1 Wiring of Transmission Line....................................................................3-4
4. MEWNET-W.......................................................................... 4-1
4.1 Overview ................................................................................................ 4-2
4.2 Setting the Switches of the Unit ............................................................. 4-3
4.3 Configuration.......................................................................................... 4-4
4.3.1 Registration in I/O Map............................................................................4-4
4.3.2 No. of Occupied I/O Points of MEWNET-W............................................4-5
4.3.3 Confirmation of Slot Numbers .................................................................4-5
4.3.4 W Link Unit Setting Procedure ................................................................4-6
4.3.5 W Link Unit Setting Dialog Box ...............................................................4-8
4.3.6 Configuration Using User Programs .....................................................4-10
4.4 PLC Link............................................................................................... 4-12
4.4.1 Example of Link Area Allocation ...........................................................4-12
4.4.2 Holding Start Number Setting ...............................................................4-15
4.4.3 Communication State Information Copy Destination Device ................4-15
4.5 Data Transfer ....................................................................................... 4-16
4.5.1 Data Transfer from Own Unit to Destination Unit (SEND) ....................4-16
4.5.2 Data Transfer from Destination Unit to Own Unit..................................4-18
4.5.3 Precautions When Using Data Transfer Function.................................4-20
5. MEWNET-W2........................................................................ 5-1
5.1 Overview ................................................................................................ 5-2
5.2 Setting the Switches of the Unit ............................................................. 5-3
5.3 Configuration.......................................................................................... 5-4
5.3.1 Registration in I/O Map............................................................................5-4
5.3.2 No. of Occupied I/O Points of MEWNET-W2..........................................5-5

Table of Contents
v
5.3.3 Confirmation of Slot Numbers.................................................................5-5
5.3.4 W2 Link Unit Setting Procedure..............................................................5-6
5.3.5 W2 Link Unit Setting dialog box ..............................................................5-8
5.3.6 Configuration Using User Programs .....................................................5-10
5.4 PLC Link ............................................................................................... 5-11
5.4.1 Example of Link Area Allocation ...........................................................5-11
5.4.2 PLC Link Operation State Flag .............................................................5-12
5.4.3 Link Error Information............................................................................5-13
5.5 Data Transfer........................................................................................ 5-14
5.5.1 Data Transfer from Own Unit to Destination Unit (SEND) ....................5-14
5.5.2 Data Transfer from Destination Unit to Own Unit..................................5-16
5.5.3 Precautions When Using Data Transfer Function.................................5-18
6. MEWNET-F ...........................................................................6-1
6.1 Overview................................................................................................. 6-2
6.2 Settings of the Unit .................................................................................6-3
6.3 Configuration ..........................................................................................6-4
6.3.1 Registration in I/O Map ...........................................................................6-4
6.3.2Number of Occupied I/O Points for the Unit............................................6-5
6.3.3 Confirmation of Slot Numbers.................................................................6-5
6.3.4 F Link Unit Setting Procedure .................................................................6-6
6.3.5 F Link Unit Setting Dialog Box ................................................................6-8
6.4 Allocation of Remote I/O Map............................................................... 6-10
6.4.1 I/O Numbers Allocated to Slaves ..........................................................6-10
6.4.2 Registration by Configuration................................................................6-12
6.4.3 Online Mount Allocation ........................................................................6-14
6.5 Starting MEWNET-F System ................................................................ 6-15
6.5.1 Check Before Turning On the Power ....................................................6-15
6.5.2 Power-on and Power-off Sequences ....................................................6-15
6.5.3 Setting and Operation of Slave Connection Wait Time ........................6-16
6.6 Checking Before Operation (Before Switching to RUN Mode) ............. 6-17

Table of Contents
vi
6.6.1 Checking Communication State............................................................6-17
6.7 Behavior During Operation................................................................... 6-18
6.7.1 Remote I/O Refresh ..............................................................................6-18
7. Other Functions .................................................................. 7-1
7.1 Remote Programming ............................................................................ 7-2
7.1.1 Overview .................................................................................................7-2
7.1.2 Operation of Tool Software .....................................................................7-3
7.2 Computer Link ........................................................................................ 7-4
7.2.1 Overview .................................................................................................7-4
7.2.2 Specifications and Restrictions ...............................................................7-5
7.3 Hierarchy Link ........................................................................................ 7-6
7.3.1 Overview .................................................................................................7-6
7.3.2 Specifications and Restrictions ...............................................................7-7
7.4 Relevant Information .............................................................................. 7-8
7.4.1 Format of [LC] Command Response ......................................................7-8
7.4.2 Format of [0C] Command Response ....................................................7-10
8. Troubleshooting.................................................................. 8-1
8.1 Self-diagnostic Function ......................................................................... 8-2
8.1.1 Operation Monitor LEDs of CPU Unit......................................................8-2
8.1.2 Operation State of CPU Unit When an Error Occurs..............................8-2
8.1.3 Operation Monitor LEDs of FP7 MW Unit ...............................................8-3
8.2 Confirmation by System Relays / System Data Registers ..................... 8-4
8.2.1 Confirmation by System Registers..........................................................8-4
8.2.2 Confirmation by System Data Registers .................................................8-5
8.3 Monitor and Operation by User Programs.............................................. 8-6
8.3.1 Monitoring Status by PMGET Instruction ................................................8-6
8.3.2 Clearing Errors by ERR Instruction .........................................................8-7
8.4 What to Do If an Error Occurs ................................................................ 8-8

Table of Contents
vii
8.4.1 When Transmission Error Occurs (COM.LED of FP7 MW Unit Turns Off)8-8
8.4.2 When ERR LED on FP7 MW Unit Turns ON..........................................8-8
8.4.3 When ERR LED on FP7 MW Unit is Flashing ........................................8-8
9. Instruction References........................................................9-1
9.1 Communication Instructions ................................................................... 9-2
9.1.1 SEND Instruction (When Using FP7 MW Unit) .......................................9-2
9.1.2 RECV instruction (When using FP7 MW Unit)........................................9-4
9.1.3 PMGET Instruction (For MEWNET-W) ...................................................9-6
9.1.4 PMGET Instruction (For MEWNET-W2) .................................................9-8
9.1.5 PMGET Instruction (For MEWNET-F) ..................................................9-11
9.1.6 PMSET/pPMSET Instruction (For MEWNET-W) ..................................9-12
9.1.7 PMSET/pPMSET instruction (For MEWNET-W2) ................................9-14
9.2 Special Instructions............................................................................... 9-16
9.2.1 ERR Instruction .....................................................................................9-16
10. Specifications ...................................................................10-1
10.1 Specifications........................................................................................10-2
10.1.1 General Specifications ..........................................................................10-2
10.1.2 Performance Specifications ..................................................................10-2
10.2 List of System Relays (SR)................................................................... 10-4
10.3 List of System Data Registers (SD)...................................................... 10-5
11. Appendix ...........................................................................11-1
11.1 Compatibility with Conventional Model FP2SH .................................... 11-2
11.1.1 Restrictions on the Number of Units Installed.......................................11-2
11.1.2 PLC Link Function (W Mode, W2 Mode) ..............................................11-2
11.1.3 Data Transfer Function (W Mode, W2 Mode).......................................11-3
11.1.4 Command Relay Function (W Mode, W2 Mode) ..................................11-4
11.1.5 Remote I/O Function (F Mode) .............................................................11-5
11.1.6 Serial Communication Unit....................................................................11-5

Table of Contents
viii
11.1.7 No. of Occupied I/O Points....................................................................11-5

1
System Configuration

System Configuration
1-2
1.1 Unit Functions and Types
1.1.1 Functions of Unit
0
2
5
3
1
4
8
7
9
6
0
2
5
3
1
4
8
7
9
6
Overview
FP7 Multi-wire Link Unit can be used as an interface unit connected to any of the following
networks by switching with the mode setting switches of the unit.
Network
Trans-
mission
line
Trans-
mission
distance
Baud rate Number of
units Main functions
MEWNET-W Twisted
pair Max. 800m 500k bit/s
Max. 16 units PLC link
Max. 32 units Data transmission and
remote programming
MEWNET-W2 Twisted
pair
Max. 800m 500k bit/s Max. 32 units PLC link, data transmission
and remote programming
Max. 1200m 250k bit/s
MEWNET-F
Twisted
pair Max. 700m 500k bit/s Max. 32 units Remote I/O control
VCTF Max. 400m
Term: Product name
To simplify the expression in the manual, the product name is abbreviated to "FP7 MW Unit".

1.1 Unit Functions and Types
1-3
1.1.2 Unit Type
Unit Type
Name Specifications Product
number
FP7 Multi-wire Link Unit Unit for connecting the FP7 series to MEWNET-W,
MEWNET-W2 or MEWNET-F. AFP7MW
Product related to MEWNET-W / MEWNET-W2
Item name Specifications Product
number
FP2 Multi-wire Link Unit Unit for connecting the conventional model FP2 series to
MEWNET-W, MEWNET-W2 or MEWNET-F. AFP2720
Product related to MEWNET-F
The following are connectable products when using FP7 MW Unit in F mode.
Item name Specifications Product
number
FP I/O terminal unit (Primary
unit)
DC input: 8 points AFP87421
DC input: 16 points AFP87422
Transistor output: 8 points AFP87423
Transistor output: 16 points AFP87424
FP I/O terminal unit
(Expansion unit)
DC input: 8 points AFP87425
DC input: 16 points AFP87426
Transistor output: 8 points AFP87427
Transistor output: 16 points AFP87428
FP I/O terminal board
(Terminal block type)
DC Input: 16 points, Relay output: 8 points AFP87432
DC input: 16 points, Transistor output: 16 points AFP87444
FP I/O terminal board (MIL
connector type)
DC input: 16 points, Transistor output: 16 points,
Power supply: 12 VDC AFP87445
DC input: 16 points, Transistor output: 16 points,
Power supply: 24 VDC AFP87446

System Configuration
1-4
1.2 Network Type
1.2.1 MEWNET-W / MEWNET-W2
4
9
4
9
4
9
4
9
4
9
4
9
Overview
•They are used to link data between PLCs connected to each network.
•The PLC link function is used to share and transmit exclusive internal relays “link relays (L)”
and data registers “link registers (LD)” between PLCs cyclically. For MEWNET-W2, internal
relays (WR) and data registers (DT) can be specified as well as link relays (L) and link
registers (LD).
•With the data transfer function, data can be transferred from a specified arbitrary source to
arbitrary destination by executing the SEND/RECV instructions with user programs.
•Also, monitoring or programming destination PLCs can also be possible via network.
•Either MEWNET-W or MEWNET-W2 can be used in the same network. They are selected
by the switches of the FP7 MW Unit.

1.2 Network Type
1-5
Specifications
Item
Specifications
MEWNET-W
MEWNET-W2
Communication
method Token bus
Transmission system Baseband
Transmission line Twisted pair shield cable
Transmission
distance (Total
length)
Max. 800m Max. 800m Max. 1200m
Baud rate 500 kbit/s 500 kbit/s 250 kbit/s
Function / Number of
units
PLC link: Max. 16 units PLC link: Max. 32 units
data transfer: Max. 32 units data transfer: Max. 32 units
PLC link capacity
Per unit
Link relay: 1,024 points Link relay: 4,096 points
Link register: 128 words Link register: 4,096 words
Other functions Remote programming (USB port, COM port), Computer link, Hierarchy link
Interface Conforming to RS-485
RAS function Hardware self-diagnosis Function
(Note 1): For MEWNET-W2, the transmission distance depends on the setting of baud rate. The baud rate is set by
the mode setting switches of the unit.
Example of application
They are used when using the following Panasonic PLCs and link function.
•FP7 (Using FP7 MW Unit)
•FP2/FP2SH (Using FP2 MW Unit)
Note) MEWNET-W can also be connected to the conventional models FP3/FP10SH (discontinued products) with the
MEWNET-W link function.

System Configuration
1-6
1.2.2 MEWNET-F
Configuration diagram
ⓐMaster station ①FP7 MW Unit
ⓑSlave station ②FP I/O terminal board ③FP I/O terminal unit
Overview
•A remote I/O system in which the FP7 is applied as a master unit can be established. I/O in
a remote place can be controlled via a two-wire cable so that saving wiring, reducing man-
hours and saving space is achievable.
•Up to 32 slave units, or 4096 I/O points can be controlled per FP7 MW Unit.
•The I/O of slave units can be treated as external input (X) and external output (Y) as well as
general I/O devices.

1.2 Network Type
1-7
Specifications
Item
Specifications
Communication
method Polling
Transmission system Baseband
Transmission line Twisted pair cable / VCTF cable
Transmission
distance (Note 1)
Max. 700 m (when using twisted pair cable)
Max. 400 m (when using VCTF cable)
Baud rate 500 kbps
No. of slave units Max. 32 units (Per master unit)
No. of control I/O
points (Note 2) Max. 4,096 units (Per master unit)
Interface Conforming to RS-485
Transmission error
check CRC method
(Note1): The transmission distance varies according to the used cable and unit.
(Note 2): The number of I/O points that can be actually controlled varies according to the configuration..
Example of application
The remote I/O control can be performed by connecting slave units compliant with Panasonic
MEWNET-F.
•FP I/O terminal board
•FP I/O terminal unit
(Note): It cannot be connected to FP2 Slave Unit or FP3 Slave Unit (discontinued products).

System Configuration
1-8
1.3 Function Overview
1.3.1 PLC Link (MEWNET-W / MEWNET-W2)
Overview of Function
•The PLC link function is a communication function which enables data sharing between
PLCs easily using link relays (L) and link registers (LD) transmitted cyclically.
•For MEWNET-F, data of link relays (1008 points) and link registers (128 words) can be
converted between max. 16 PLC units.
•For MEWNET-W2, data of link relays (4,096 points) and link registers (4,096 words) can be
converted between max. 32 PLC units. Also, internal relays (WR) and data registers (DT)
can be specified as well as link relays (L) and link registers (LD).
•Send area and receive area can be allocated for each PLC connected to the network. They
are set from the configuration menu of tool software.
Example of PLC link allocation
•Either one of MEWNET-W and MEWNET-W2 can be used in the same network. It is
selected by the switch on the FP7 MW Unit.

1.3 Function Overview
1-9
Role of link relays and link registers
•If the link relay contact for one PLC goes on, the same link relay also goes on in each of the
other PLCs connected to the network.
•Likewise, if the value of a link register in one PLC is changed, the values of the same link
register are changed in all PLCs on the same network.

System Configuration
1-10
1.3.2 Data Transfer (MEWNT-W / MEWNET-W2)
•With the data transfer function, data can be transferred from a specified arbitrary source to
arbitrary destination by executing the SEND/RECV instructions with user programs.
•Destination PLCs need no program for sending/receiving data.
PLC PLC PLC PLC
RS-485
No.1 No.2 No.3 No.4
No. 1 Program
No. 1 No. 4
No. 1 No. 3
SEND.US DT0
DT0
DT1
DT2
DT3
DT100 DT1000U2 U3
DT100
DT101
DT102
DT103
SEND
No. 1 Program
RECV.US U4
DT0
DT1
DT2
DT3
DT2 DT1000DT102 U2
DT100
DT101
DT102
DT103
RECV
(Note): For the FP7 MW Unit, either one of SEND and RECV instructions can be executed.
