Panasonic CZ-256ESMC3 User manual

Operating Instructions
Intelligent Controller
Model No. CZ-256ESMC3
ENGLISH
Before operating the unit, read these operating instructions thoroughly and keep them for future reference. Installation Instructions
Separately Attached.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan F1118-10419

2
Features
This unit is a centralized air conditioning management system designed for use with precision air
conditioning systems (PAC, air conditioning systems for ofces and shops, and multi-unit systems for
buildings) and gas heat pump (GHP) air conditioners.
zWith one of these units you can connect and control up to 128 indoor units (2 systems of 64 units each) and 60 outdoor units (2 systems of
30 units each).
zBy connecting a communication adaptor this can be increased to 256 indoor units and 120 outdoor units.
zThe unit is equipped with a 10.4-inch TFT colour touch panel display (1024 x 768 dots), enabling control by almost anyone.
Operation and status P.23
You can check to operational status (ON/OFF, operating
mode, alarms, etc.) of all indoor units and outdoor units in
real time.
You can also select indoor units to change their settings.
Distributing air conditioner
energy P.71
You can view cumulative operating times for indoor units,
engine operating times for outdoor units, and operation
cycles in a list. (Cumulative values)
Using these data, you can calculate the distribution ratio of
electricity or gas consumed for air conditioning and volumes
used (kWh, m3) per indoor unit or in an area, then show
these calculations in a list.
Operation scheduling P.40
You can register daily operation schedules (ON/OFF time,
operating modes, set temperatures, etc.) for individual
indoor units or groups of indoor units.
Operations can be schedule for up to 2 years in advance.
Remote control P.122
The LAN terminal on this unit enables you connect it to a
network.
Connecting to Internet will enable you to operate the unit
and check the status using a PC from a remote location.

3
Contents
Features ……………………………………………………………… 2
Contents ……………………………………………………………… 3
Simple guide to features …………………………………………… 4
Safety precautions ………………………………………………… 5
Operating precautions ……………………………………………… 6
Installation precautions……………………………………………… 6
System conguration ……………………………………………… 7
Explanation of terms………………………………………………… 8
The Energy Saving function ……………………………………… 9
Energy navigation function ……………………………………… 11
Preparations before changing settings 12
Part names………………………………………………………… 13
Operations on this unit …………………………………………… 14
Menu list …………………………………………………………… 18
Initial settings ……………………………………………………… 20
Input of the identication number (password) ………………… 22
Check the operation and status of
air conditioning units 23
Checking the settings on the indoor unit ……………………… 24
Operating the indoor unit ………………………………………… 26
Checking the operational status of indoor units ……………… 28
Checking the operational status of the outdoor unit ………… 33
Checking on current alarms……………………………………… 36
Setting a schedule 40
Schedule setting ow …………………………………………… 41
Setting a schedule………………………………………………… 44
Allocating a schedule to a calendar …………………………… 50
Checking the future schedule and past performance ………… 54
Temporarily modifying or adding a schedule ………………… 56
Checking the alarm logs and operation/status
change logs 58
Checking the alarm logs ………………………………………… 59
Checking the operation/status change log in a list …………… 61
Check accumulated values 64
Checking the list of accumulated values on the indoor unit … 65
Checking the list of accumulated values on the outdoor unit… 67
Checking the list of accumulated values on a pulse meter … 69
Checking distribution data 71
Checking distribution data in a list ……………………………… 72
Settings for energy saving 76
Automatically return to set temperatures
[Set temp. auto return] ……………………………………… 77
Automatically stopping restarts [Unattended auto shutoff]…… 80
Restricting the range of set temperatures
[Set temperature range limit] ……………………………… 83
Restricting operating capacity according to the time slot
[Energy saving timer]/[Efcient operation setting]………… 85
Reducing the noise of outdoor units [Out unit silent setting] … 87
Registering demand point input [Register demand point] …… 89
ySetting content after registering demand points
Demand settings on the indoor unit
[I/D unit demand settings] …………………………………… 90
Demand settings on the outdoor unit
[O/D unit demand settings] ………………………………… 93
Suppressing the consumption of electricity/gas
[Demand/peak shaving settings]/[Peak cut settings] …… 95
Control operation at regular intervals [I/D unit cyclic] ………… 98
Control operation at regular intervals [O/D unit cyclic] ……… 102
Displaying data in graphs 105
Graph display function …………………………………………… 106
Graphing operating times and energy usage ………………… 109
Graphing temperature changes ………………………………… 113
Setting items freely ……………………………………………… 116
Perform remote operation of the unit over a network 122
Setting the network ……………………………………………… 123
Setting the Web users …………………………………………… 125
Control remotely ………………………………………………… 128
Backing up/restoring data 129
Backing up data…………………………………………………… 130
Restoring data …………………………………………………… 132
Outputting settings as a CSV le ……………………………… 134
Inputting settings as a CSV le ………………………………… 136
Saving automatically generated les …………………………… 138
Conguring the system 140
Basic settings on the indoor unit………………………………… 141
Basic settings on the outdoor unit ……………………………… 145
Basic settings for distribution calculation ……………………… 148
Changing the name of the schedule group …………………… 151
Changing the name of the area group ………………………… 153
Changing the name of the distribution group ………………… 155
Basic settings for the pulse meter ……………………………… 158
Set the distribution mode ………………………………………… 160
Set the units for electricity/gas charges………………………… 161
Linked control of air conditioning units ………………………… 162
Conguring outgoing mail ……………………………………… 168
Registering a communication adaptor ………………………… 170
Conguring the Hybrid GHP/EHP control 172
Hybrid GHP/EHP control function ……………………………… 173
Setting the mode used for operation [Basic settings] ………… 175
Setting the control for each outdoor unit
[Outdoor unit settings] ……………………………………… 177
Viewing the current control status
[Hybrid GHP/EHP O/D unit info] …………………………… 180
Setting cost priority control [Cost settings] …………………… 182
Setting gas demand values [Gas demand settings] ………… 184
Checking the upper limit map used for cost priority control
[Check upper limit map] …………………………………… 186
Setting delay times [Delay time settings] ……………………… 188
Registering the power demand point inputs
[Register power demand point] …………………………… 192
Registering the gas demand point inputs
[Register gas demand point] ……………………………… 193
Registering the hot water demand point inputs
[Register hot water demand point] ………………………… 194
Using individually set upper limit maps
[Individual map settings] …………………………………… 195
Maintenance settings 198
Setting the screen display and volume for this unit …………… 199
Register the contacts for servicing for this unit………………… 200
Update the software ……………………………………………… 201
Initialising the unit and setting log levels ……………………… 202
Setting the date and time………………………………………… 204
Setting the language and time zone …………………………… 205
Running a test operation ………………………………………… 207
Setting communications with air conditioning units …………… 210
Ignoring alarms from the units…………………………………… 212
Appendix 213
Number and letter input ………………………………………… 214
Connections with external signals ……………………………… 216
Methodology for calculating distributions ……………………… 217
Things you should know ………………………………………… 221
Troubleshooting…………………………………………………… 226
Cautions when cleaning and maintaining ……………………… 227
Trademark and indemnity ……………………………………… 228
Specications……………………………………………………… 229
zRead the Operating Instructions carefully for safe use. This manual describes the Operating Instructions of the intelligent controller. Read this
manual as well as operating instructions supplied with indoor units and outdoor units.
zBe sure to read the “Safety precautions” (P.5) before using.
zKeep this manual with operating instructions supplied with indoor units and outdoor units in a safe place.
zBe sure to keep this manual in a place easily accessible by users. In the case of user change, be sure to give this manual to the new user.
NOTICE
The English text is the original instructions. Other languages are translation of the original instructions.

4
Simple guide to features
This guide only shows the main features.
Operations on the air conditioning unit
What you want to do Title Page
To operate the indoor unit Operating the indoor unit 26
To change the operating mode Operating the indoor unit 26
To change the set temperature Operating the indoor unit 26
To reset the lter sign Checking the settings on the indoor unit 25
To change the airow direction and fan speed Operating the indoor unit 26
To prevent operation by remote controllers Operating the indoor unit 26
Checking the operating status
What you want to do Title Page
To check the operational status of the indoor units you are managing Checking the operational status of indoor units 28
To check the current alarms Checking on current alarms 36
To check alarm history Checking the alarm logs 59
To check the current or past cumulative times Checking the list of accumulated values on the indoor unit 65
To check the current or past distribution ratios Checking distribution data in a list 72
Settings
What you want to do Title Page
To change the name of an indoor unit Basic settings on the indoor unit 141
To change the name of the area group Changing the name of the area group 153
To adjust the date or time Setting the date and time 204
To operate an indoor unit according to a schedule Setting a schedule 40
To adjust the brightness of the screen Setting the screen display and volume for this unit 199
To adjust the sound of the buzzer Setting the screen display and volume for this unit 199
Miscellaneous
What you want to do Title Page
To backup data (settings, cumulative values, distribution data, etc.) to a USB
memory device
Backing up data 130
To show the operating times, temperature changes, and other information in
graphs
Displaying data in graphs 105

5
Safety precautions
WARNING CAUTION
This symbol refers to a hazard or unsafe
practice which can result in severe personal
injury or death.
This symbol refers to a hazard or unsafe
practice which can result in personal injury or
product or property damage.
Matters to be observed Prohibited matters
WARNING
Do not use this appliance in a potentially explosive atmosphere.
In case of malfunction of this appliance, do not repair by yourself. Contact the sales or
service dealer for repair.
In case of emergency, remove the power plug from the socket or switch off the
circuit breaker or the means by which the system is isolated from the mains
power.
CAUTION
This appliance is intended to be used by expert or trained users in shops, in light
industry and on farms, or for commercial use by lay persons.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
yDo not operate with wet hands.
yDo not wash with water.

6
Operating precautions
zDo not use in the following locations
yWhere ammable gases, etc. may leak
yNear the ocean or other areas with a lot of salt
yIn areas where sulphurous gases occur such as natural spa areas
yIn places where there may be airborne water or oil (including machinery lubricants, etc.) or steam
yWhere there are large uctuations in voltage
yWhere machinery emitting electromagnetic waves are located
yWhere there may be airborne organic solvents
zDo not apply strong shocks
(This may cause malfunction)
zDo not use heaters near the controller
(This may cause deformation or discolouration)
zDo not use hard or pointy objects
(This may cause scratches or malfunction)
zDo not hit the touch panel or push on it too strongly
(This may cause malfunction)
Installation precautions
zDo not install in locations with high humidity, lots of oil, vibrations, where direct sunlight can reach the unit, or near sources of
heating
(This may cause malfunction)
zDo not install in noisy locations
(This may cause incorrect operation)
zInstall at least 1 m away from TV, radio, PC. etc.
(To prevent fuzzy images or noise)
Information for Users on Collection and Disposal of Old Equipment and Used Batteries
These symbols on the products, packaging, and/or accompanying documents mean that used electrical and
electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable
collection points, in accordance with your national legislation and the Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable resources and prevent any
potential negative effects on human health and the environment which could otherwise arise from inappropriate
waste handling.
For more information about collection and recycling of old products and batteries, please contact your local
municipality, your waste disposal service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further
information.
[Information on Disposal in other Countries outside the European Union]
These symbols are only valid in the European Union. If you wish to discard these items, please contact your local
authorities or dealer and ask for the correct method of disposal.
Pb
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it complies with the requirement
set by the Directive for the chemical involved.

7
System conguration
The following is an example of a system conguration.
Intelligent Controller
Communication
adaptor
Inter-unit control wiring
(no polarity)
Inter-unit control wiring
(no polarity)
Pulse meter x 3
Pulse meter x 3
Inter-unit control
wiring (no polarity)
Area group (P.8)
Distribution group (P.8)
Inter-unit
control
wiring (no
polarity)
Linked systems #1
Linked systems #2
Linked systems #3
Linked systems #4
Communication adaptor
control wiring (RS-485
(polarity present))
Communication adaptor
control wiring (RS-485
(polarity present))
Signal input x 3
Signal output x 2
Signal input x 3
Signal output x 2
Indoor units: 256 units (64 units x 16 systems)
Outdoor units: 120 units (30 units x 16 systems)
Communication adaptor: 7 units

8
Explanation of terms
This section explains the terms used in this document.
Term Explanation
Adaptor address The address allocated to a single communication adaptor (sold separately). If the pulse meter is connected to a
communication adaptor, use the address of the adaptor.
Setting
No.0: This unit (setting complete)
No.1 to 7: Settings with the communication adaptor
Linked systems address This is a grouping of indoor units and/or outdoor units connected to the same inter-unit control wiring.
2 linked systems can be connected to this unit or a communication adaptor (sold separately).
Setting
No.1 and 2 (xed)
Outdoor unit systems address An outdoor unit and the grouping of indoor units connected by the coolant piping.
A single linked system can consist of a maximum of 30 outdoor unit systems.
Setting
No.1 to 30: Set on the outdoor unit for each linked system
Indoor unit address In an indoor unit system, this is a xed number allocated to an indoor unit.
This is also allocated to each indoor unit for group control.
Setting
No.1 to 64: Set on the indoor unit for each outdoor unit system
Central address This is a xed value within the linked system and is shared with other centralised controllers (system controllers,
etc.).
In group control, all indoor units belonging to a group have the same address.
In this document and on the unit, this is described as the “CNTR addr.”.
Setting
No.1 to 64: Set on this unit and other central controllers for each linked system
Unit name In group control, this will be the same name. This is the minimum unit used for operation, monitoring, and scheduling.
Setting
Set on this unit
Distribution group A distribution group consists of multiple (or single) areas and matches with the measuring range of a pulse meter,
with the distribution ratio of the grouping totalling to 100%. A maximum of 256 groups can be created across the
whole system.
With time distributing, it is not possible to mix PAC and GHP in a single distribution group.
You can have PAC and GHP in the same group if you are using load distributing.
Setting
No.1 to 256: Set on this unit
Area group An area group is one grouping used for calculating distributions (or for operating or monitoring) and consists of
multiple (or single) indoor units. A maximum of 256 groups can be created across the whole system.
Setting
No.1 to 256: Set on this unit
Control groups Control groups consist of multiple (or single) indoor units or outdoor units controlled the same in cyclic control
settings. A maximum of 10 groups can be set for indoor units and a maximum of 5 groups can be set for outdoor
units.

9
The Energy Saving function
This reduces waste in air conditioning so that you can save energy without replacing the air conditioning
units.
e-CUT function
The Demand function
Set temperature auto return
When you want to return to the set temperature after a certain
time even if the temperature is changed. (P.77)
30 minutes later
Change Change
30 minutes later
Return!
28 °C
22 °C
Return!
Demand settings (indoor unit/outdoor unit)
When you want to suppress the maximum demand for electricity
or maximum gas consumption. (P.90, P.93)
Reduces CO2
emissions, helps
prevent global warming!
8:00 12:00 20:00 Time16:00
Electricity or gas consumed
Demand 1
Demand 2
Set temperature range limit
When you want to limit the temperatures that can be set. (P.83)
30 °C28 °C26 °C24 °C22 °C20 °C
Reduced consumption of electricity
or gas by over cooling
Set temperature restricted to the
range between 26 °C and 30 °C
18 °C
High LowElectricity or gas consumed
Unattended auto shutoff
When you want to operate outside of a schedule but to monitor
and stop automatically. (P.80)
Time set for unattended auto shutoff
ON
OFF
Detect Detect Detect
60 min. 60 min.
Forget to turn off
60 min.
AUTO
OFF
AUTO
OFF
MANUAL
ON
MANUAL
ON
9:0023:0022:0821:00
Demand/peak shaving settings/
Peak cut settings*2
Specify time slots
when you want
operation capacity
of the outdoor
units reduced.
(P.95)
*1 The “Efcient operation setting” is the name of setting when using gas heat
pump air conditioners.
*2 The “Peak cut settings” is the name of setting when using gas heat pump air
conditioners.
Time
10:00 12:00 15:0013:00
High
Electricity or gas consumed
Low
Energy saving timer/Efcient operation
setting*1
Specify time slots
when you want
operation capacity
reduced. (P.85)
10:00 12:00 15:00 Time 13:00
High
Electricity or gas consumed
Low
Indoor/outdoor unit cyclic
When you want operation capacity of the outdoor units reduced
during certain repeated intervals. (P.98, P.102)
5 min.
Forced stop
Forced stop
Forced stop
Forced stop
Forced stop
Control group 1
Control group 2
Control group 3
Control group 4
Control group 5
5 min.5 min. 5 min. 5 min.
Note
ySome models may not support these functions.

10
The Energy Saving function
Demand control
“Demand” indicates the “electricity demand” (average electricity over 30 minutes).
The basic charges for electricity are determined by the maximum value of
demand (the maximum electricity demand). This maximum demand for electricity
occurs during summer and winter when the air conditioning burden is the
greatest. One way of reducing electric power costs is to suppress the maximum
electricity demand during these periods. (Your actual situation depends on your
contract with your electricity provider)
Furthermore, by suppressing the maximum demand for electricity, you can assist
in the reduction of carbon dioxide emissions and help reduce global warming.
Demand control means that the air conditioning units are monitored so that their
electricity consumption does not exceed a contracted amount, and by setting a level as shown in the following diagram (demand 1, 2, or 3), the
performance of the air conditioning units can be controlled so that energy usage is reduced.
This unit suppress the maximum demand for electricity through automated control of air conditioning units by demand control output (demand
output) signals emitted by external equipments.
Demand control (with indoor unit demand settings)
Pulse signal generated
Intelligent Controller
Setting level Setting example
Control group A Control group B
Demand 1 (contact A) Set temperature of the indoor unit
±1 °C
No setting
Demand 2 (contact B) Set temperature of the indoor unit
±2 °C
Set temperature of the indoor unit
±2 °C
Demand 3 (contact C) Indoor unit thermostat OFF Indoor unit thermostat OFF
Pulse meter
(electricity)
Pulse detector
Pulse converter
Control group A
Contact A comes on (when cooling)
Set temperature of indoor unit rises 1 °C
Contact A comes on (when cooling)
Set temperature of the indoor unit
remains unchanged
Control group B
External equipment
Load control output (demand output)
Contact A
Contact B
Contact C
Reduced electricity
consumption
Demand 1
Demand 2
8:00 12:00 20:00 Time16:00
Electricity consumed

11
Energy navigation function
Indoor units will run in energy saving modes according to the amount of human activity detected by
ECONAVI sensors (sold separately).
Warning
Do not use the ECONAVI feature in rooms where only disabled people or infants are present.
(It may cause damage to their condition or worsen their health)
If there is not much movement for a long time, the ECONAVI sensor may determine that the room is unoccupied and stop the air
conditioning unit.
Note
yYou can turn on or off the ECONAVI feature on this unit.
yYou will need a separate remote controller* with ECONAVI functionality in order to make advanced settings for the ECONAVI feature. Refer to
the operating instructions for the remote controller* with ECONAVI functionality for details on how to congure the feature.
yEven if the target temperature is changed by ECONAVI, the set temperature displayed on the unit will not change.
yEven if the mode is switched to fan due to the absence of people (standby mode), the mode displayed on the unit will not change.
yWhen running multiple indoor units, the energy reduction effect may be reduced depending on the conditions in the room.
* Multi-function wired remote controller (CZ-RTC5 or later)
When there is a lot of human activity
zIn cooling or drying mode
Operates at the set temperature.
zIn heating mode
The air conditioners run at a temperature lower than the set
temperature.
When there is not a lot of human activity
zIn cooling or drying mode
The air conditioners run at a temperature higher than the set
temperature.
zIn heating mode
Operates at the set temperature.
When there are no people
When there is a continuous 20 minute period of no people
zIn cooling or drying mode
The temperature is set higher than when there are people in the
room.
zIn heating mode
The temperature is set lower than when there are people in the
room.
When there are no people for about an hour
yThe units run according to the mode set for when there are no
people. The factory preset is for low energy use operation to
continue with the temperature suppressed. (Refer to the operating
instructions for the ECONAVI sensor for information on the
operation mode when there are no people.)
yIf people are detected while operating in the Absent mode, the air
conditioners return to a mode appropriate to the level of activity.

12
Preparations before changing settings
Preparation
Preparations before changing settings
This chapter describes the part names of the unit and their functions and also explains some basic operations.

13
Preparations before changing settings
Preparation
Part names
(1)
(2)
(3)
(4)
Name Explanation
(1) Colour LCD with touch panel You can operate the unit by touching the screen with your ngers.
(2) Power indicator This lights when the power is on.
(3) USB terminal Connect a USB memory device here to backup data from this unit (settings, accumulation/distribution).
(4) Storage door Open this cover to connect a USB memory device to the USB terminal.
To open, gently push on the storage door and then allow to drop down.
To close, lift the storage door and gently press closed.
(5) LAN terminal Connect to a network with wiring.
(The illustration shows the storage door open)
(Left side)
(5)

14
Preparations before changing settings
Preparation
Operations on this unit
Operations on this unit are performed by following menus.
The screens used for operations all follow a common pattern, with the screens being easy to read and easy
to use.
Touch
This is a light touch with a nger on the buttons or text
boxes displayed on the touch panel.
Swipe
This is an operation where the nger is slid in a direction
(up or down) on the touch panel.
This is used to scroll slowly.
Flick
This is an operation where the nger on the touch panel is
icked in a direction (up or down).
This is used to scroll quickly.
Picker
This is an up and down movement of the nger touching
the screen, used to pick settings in elements such as spin
boxes.
Basic operation of the touch panel
This section describes the basic operations on the touch panel.
Touch!
Picker!
Swipe!
(slide the
nger)
Flick!
Touch
Touch

15
Preparations before changing settings
Preparation
Operations on this unit
Buttons and boxes
There are varieties of buttons and boxes on the screen that you use to perform operations and settings on the touch panel.
Buttons
These are used to switch screens, save settings, switch settings on or off, select items, and similar operations.
Display example Status Explanation
Setting is off In this state the setting is off.
Setting is on In this state the setting is on.
Setting
unavailable
This indicates that the setting is currently unavailable due to other conditions.
Display example Status Explanation
Selected The highlighted item is the one that is currently selected.
Selection
disabled
This indicates that the selection is currently unavailable due to other conditions.
Check boxes
These are mainly used to switch on or off item selection and functions.
Display example Status Explanation
Unselected In this state the item is not selected.
Selected In this state the item is selected. (In this example, the automatic stop feature will operate.)
A check mark appears when you touch it. The check mark disappears when you touch it
again.
Spin boxes
These are used to switch the display of items and to set numeric items such as time.
Display example Explanation
takes you to the next item. takes you to the previous item.
Items may cycle around in the following way:
Gr.1 Gr.2 Gr.5
increases the numeric gure. decreases the numeric gure.
The numbers will change continuously if you continue to touch the button.
The numbers cycle around in the following way:
For example: When the number is an “hour”
“(blank)” “00” “01” “23”

16
Preparations before changing settings
Preparation
Operations on this unit
Buttons and boxes (continued)
Text boxes
These are used when you need to edit some text.
Display example Explanation
The touchscreen keyboard appears when you touch the text box.
Use the touchscreen keyboard to enter the text.
Refer to “Number and letter input” (P.214) for instructions on how to enter text.
Dialogues
These are elements that appear on the screen and are mainly used for settings.
They close automatically once you have registered the settings.
Touch to close the dialogue without changing the setting.
(There may also be cases where you touch at the top right of the screen to register the setting)
Notations in this document
Menu names, screen names, etc., are shown as follows in this document.
Type Notation Example
Top menus
Screen names
Screen display items
“xxx” “Oper./Status”
“I/D unit list” screen
“Select” column, “ON/OFF”
Submenu names
Screen menu names
Button names
[xxx] [Operation/Status]
[I/D unit list]
[Operation]

17
Preparations before changing settings
Preparation
Operations on this unit
How to read the screens
There are some items and icons common to the operations and settings screens.
The following explains the items and icons.
A B C D
F
E
G
Name Explanation
A Submenu name This displays the submenu name.
B Operations/Settings
screen name
This displays the operations/settings screen name.
C Date and time The current date and time is displayed.
D “Home” icon Touch this to display the Top menu (P.18).
E Scroll buttons
Touch on the right side of the screen to scroll to the right. Touch to scroll to the left. (The display changes according to the
direction you can scroll.)
F “Back” icon Touch this to go back to the previous menu.
G “Warning” icon The “Alarm list” screen is displayed when you touch this. (→ “Checking on current alarms” (P.36))
zIn this document and on the unit, indoor units are described as the “I/D”.
zIn this document and on the unit, outdoor units are described as the “O/D”.
Automatic refresh function
The screen may be reset or you may be returned to the Top menu under some rare circumstances, but this is an automatic refresh function and
is not indicative of a malfunction.

18
Preparations before changing settings
Preparation
Menu list
1Select the top menu.
zTouch one of the “EnergySaving”,
“Oper./Status”, or “Settings” tabs.
2Select the submenu.
Oper./Status EnergySaving
Oper./Status (Check on the status of connected units)
Submenu Screen menu Overview Page
I/D unit list Check the operational status of the indoor units in a list. 24
I/D unit information Check the details about the indoor units (number of operation cycles, etc.) in a list. 28
O/D unit information Check the details about the outdoor units (outdoor temperatures, etc.) in a list. 33
Alarm list You can view a list of units with current alarms, where you can check the unit, the alarm
type, and the date of the alarm.
36
Schedule/results You can see the schedules set up for the future and how they performed in the past in a
list.
54
Calendar You can allocate a single day’s schedule to a calendar. 50
Schedule setting You can register the schedule for a single day. 44
Update schedule You can modify a schedule that you have registered (only from the day of the change up
to 4 days later, or a total of 5 days).
56
Alarm log Check the log of alarms that have occurred in the system in a list. 59
Operation/Status change log Check the log of operation/status changes of the indoor units in a list. 61
I/D unit acc. Check the accumulated data for the indoor units in a list. 65
O/D unit acc. Check the accumulated data for the outdoor units in a list. 67
Pulse acc. Check the accumulated data for the pulse meters in a list. 69
Distribution data Check the details about distribution calculations in a list. 72
EnergySaving (Perform energy saving settings)
Submenu Screen menu Overview Page
Set temp. auto return Even if the temperature initially set is changed, the temperature automatically returns to
the set one after a certain amount of time.
77
Unattended auto shutoff If the indoor unit automatically stops at the set time but then is started again, this setting
automatically stops the unit again repeatedly at set intervals.
80
Set temperature range limit Restrict the temperatures that can be set by setting upper and lower limits on
temperatures.
83
Energy saving timer/Efcient
operation setting*
You can specify time slots when you want operation capacity reduced. 85
Out unit silent setting Set a time for the outdoor unit to operate at a lower level at night compared to the day. 87
Register demand point Register the contacts between the external equipments and the main unit (Contact A,
Contact B, Contact C).
89
I/D unit demand settings
You can automatically control indoor units to cut the maximum demand for electricity or
maximum gas consumption.
90
O/D unit demand settings
You can automatically control outdoor units to cut the maximum demand for electricity or
maximum gas consumption.
93
I/D unit cyclic At specied intervals (3, 4, or 5 minutes), the thermostats of indoor units in control
groups are turned off and restored repeatedly in order.
98
O/D unit cyclic At specied 10 minute intervals, the thermostats of outdoor units in control groups are
turned off and restored repeatedly in order.
102
Demand/peak shaving settings/
Peak cut settings*
Limit the electricity or gas consumed by outdoor units during the set time slot. 95
Bar chart Quantities of energy usage (electricity, gas), etc., are shown in bar charts. 109
Line graph Temperature changes, etc., are shown in line graphs. 113
* When using gas heat pump air conditioners

19
Preparations before changing settings
Preparation
Menu list
Settings
Settings (Perform other miscellaneous settings)
Submenu Screen menu Overview Page
Calendr sttngs for distr calc Set specied days, cut-off days, particular time slots (regular hour ranges) and days of
the week for calculating distributions.
148
I/D unit settings Change settings on indoor units, such as indoor unit addresses, groups belonged to, etc. 141
O/D unit settings Change settings on outdoor units (addresses, etc.). 145
Schedule group name settings Edit the name of the schedule group. 151
Area group name settings Edit the name of the area group. 153
Distribution group settings Edit the name of the distribution group. 155
Pulse meter settings Make allocations between pulse meters and distribution groups. 158
Distribution mode settings Set the mode used for distributing when calculating charges. 160
Distribution Ratio settings Set the units for calculating electricity and gas usage charges. 161
Event control Perform linked control by setting input and output conditions for devices. 162
Network settings Make settings to enable remote control over a network. 123
Email settings Congure the outgoing mail server. 168
Web user settings Register users that will access the unit over a network. 125
Communication adapter setting Register the communication adaptor connected to this unit. 170
Check conguration* Modify the registered conguration when there have been changes to the conguration
of the system.
226
Hybrid GHP/EHP settings Make settings for Hybrid GHP/EHP control. 172
Backup Save data (settings, accumulation/distribution, logs) to USB memory devices. 130
Restore Restore data that has been stored in the unit or saved to a USB memory device. 132
CSV Output Export (output) the settings for this unit in CSV format. 134
CSV Input Import (input) the settings for this unit in CSV format. 136
Auto-save CSV le Saves the CSV les (distributions, logs) automatically generated in this unit. 138
Display/Volume settings* Adjust the brightness of the unit’s screen and the sound of the buzzer. 199
Intelligent Controller info Register the contacts for servicing (telephone numbers) for this unit. 200
Software update* Update the software for this unit. 201
Initialize* Initialise the settings for this unit. 202
All data will be lost when you initialise.
Do not initialise under any circumstances.
Language&TimeZone sttngs Set the language to be used when setting and operating this unit. 205
Date settings Manually set the date and time. 204
Open license The licences for the freeware is displayed. —
Test run Perform a test operation of the indoor unit after installing this unit. 207
A/C communication settings Make settings such as the communications protocol between this unit and the air
conditioning units.
210
Maintenance information Register the units that will require maintenance. 212
* These settings are not available for setting or operation over the network.
Menus marked with  require you to enter the identication number (password) when you select them.
 menus require entry of the level 1 or higher identication number, while  requires the level 2 identication number.
Refer to “Input of the identication number (password)” (P.22) for details.

20
Preparations before changing settings
Preparation
Initial settings
The initial settings are those items that require setting after the unit is installed so that the system operates
normally.
The unit will operate normally if you make settings according to the following ow for the type of operation
intended.
: Settings required. : Settings may be required. : Settings not required.
Step Category step Setting Screen menu names Reference
page
Operation
Air
conditioning
operations
only
Distribution rate
display only
Quantity used,
charges display
Time Load Time Load
1 Date settings Setting the current date
and time
Date settings 204  
2Composition
loading
Conrming the connection
conguration
Check conguration — 
3 Unit related
Central address*1I/D unit settings 141  
Name of the indoor units I/D unit settings 141  
Distribution group I/D unit settings 141  
Area group I/D unit settings 141 *2
Control group I/D unit settings 141  
Not batch, not managed I/D unit settings 141  
Name of the outdoor units O/D unit settings 145  
Local remote controller
prohibition setting
A/C communication settings 210  
4 Group related
Name of the area group Area group name settings 153 *2
Name of the distribution
group
Distribution group settings 155  
Name of the schedule group Schedule group name settings 151  
5Pulse meter
related
Association with the
distribution group
Pulse meter settings 158  
Type of pulse meter
(electricity/gas), multiplying
factor (number of pulse
units)
Pulse meter settings
158  
Name of the pulse meter Pulse meter settings 158     
6Distribution
related
Distribution modes (time/
load)
Distribution mode settings 160  
Power distribution
calculation target*3
Distribution mode settings 160  
Energy saving distribution
setting
Distribution mode settings 160   *4*4
Distribution of gas for power
generation
Distribution mode settings 160    *5*5
Setting the monthly cut-off
days
Calendr sttngs for distr calc 148 *6
Setting the regular hour
range
Calendr sttngs for distr calc 148 
Setting specied days Calendr sttngs for distr calc 148 
Currency for electricity or
gas charges*7
Distribution Ratio settings 161     
Setting the capacity of the
indoor units*8
I/D unit settings 141 
Setting the capacity of the
electric heater*9
I/D unit settings 141   
7Scheduling
related
Schedule for a single day Schedule setting 44  
Allocating a schedule to a
calendar
Calendar 50  
Schedule group I/D unit settings 141  
8 Event control
Input point (names and
conditions)*10
Event control 162  
Output point (names and
operation)*11
Event control 162  
