Panasonic EBL128 Technical manual

Planning Instructions
MEW01090
Revision 3
Fire Alarm System EBL128
V1.1.x
Author: Jan Pettersson
Date of issue: 2008-07-11
Date of rev: 2010-05-28

This page has deliberately been left blank.

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
1
Table of contents
1Introduction________________________________ 7
2Definitions / Explanations ____________________ 9
2.1 PEWF&STE AB ___________________________________ 9
2.2 Alarm point _______________________________________ 9
2.2.1 Smoke detector ________________________________ 9
2.2.2 Analog detector________________________________ 9
2.2.3 Sensor _______________________________________ 9
2.2.4 (Analog) Sensor Base (ASB) _____________________ 9
2.2.5 Conventional detector ___________________________ 9
2.2.6 Conventional Detector Base (CDB) ________________ 9
2.2.7 Addressable___________________________________ 9
2.2.8 Old detector__________________________________ 10
2.2.9 Conventional zone line _________________________ 10
2.2.10 Addressable zone interface ______________________ 10
2.3 Output unit ______________________________________ 10
2.4 Output / Control output_____________________________ 10
2.5 Short circuit isolator _______________________________ 10
2.6 Display unit (D.U.) ________________________________ 10
2.7 COM loop _______________________________________ 10
2.8 Control Unit (C.U.) / C.I.E.__________________________ 10
2.9 Fire Brigade Panel (FBP) ___________________________ 10
2.10 Control panel (CP) ________________________________ 11
2.11 LED____________________________________________ 11
2.12 External Indicator (LED) ___________________________ 11
2.13 Display / LCD____________________________________ 11
2.14 Door open / Key switch_____________________________ 11
2.15 SSD / Site Specific Data ____________________________ 11
2.16 S/W / Software / System program_____________________ 11
3Overview _________________________________ 12
3.1 The EBL128 c.i.e. _________________________________ 12
3.2 S/W Versions ____________________________________ 12
3.3 Documents ______________________________________ 12
3.4 Applications _____________________________________ 12
3.5 PC S/W _________________________________________ 12
4Control & Indicating Equipment _____________ 13
4.1 COM loop _______________________________________ 15
4.1.1 A single break (cut-off) on the COM loop __________ 16
4.1.2 Several breaks (cut-offs) on the COM loop _________ 17
4.1.3 Short-circuit on the COM loop ___________________ 18
4.2 Programmable voltage outputs (S0-S1) ________________ 18
4.3 Programmable relay output (R0)______________________ 19
4.4 Relay output for routing equipment (fault tx) (R1)________ 19

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
2
4.5 Programmable input (I0)____________________________ 19
4.6 24 V DC power supply outputs_______________________ 20
4.7 RS232 interfaces __________________________________ 20
4.8 RS485 transceiver (option) __________________________ 20
4.9 Power supply_____________________________________ 20
4.10 Internal Power supply ______________________________ 21
5Expansion boards 458x _____________________ 22
5.1 Expansion board address setting______________________ 23
5.2 8 zones expansion board 4580 _______________________ 23
5.2.1 Type of zone line input _________________________ 24
5.2.2 Input states __________________________________ 24
5.3 8 relays expansion board 4581 _______________________ 25
5.4 Inputs and outputs expansion board 4583_______________ 26
5.5 I/O Matrix board 4582 _____________________________ 27
5.5.1 Generic _____________________________________ 28
5.5.2 Fan control __________________________________ 29
5.5.3 Zone control _________________________________ 29
6Peripheral devices__________________________ 30
6.1 COM loop units___________________________________ 30
6.1.1 Input units ___________________________________ 31
6.1.2 Addressable I/O units __________________________ 39
6.1.3 Alarm devices (addressable sounders) _____________ 40
6.1.4 Short circuit isolators (addressable) _______________ 42
6.1.5 Units for Hazardous (Ex) areas___________________ 43
6.1.6 Other COM loop units__________________________ 44
6.1.7 COM loop addresses for Base station and Wireless
detectors46
6.2 Units connected to the RS485 interface ________________ 46
6.2.1 External Fire Brigade Panels_____________________ 47
6.2.2 Alert Annunciation Units _______________________ 48
6.2.3 External Presentation Units______________________ 49
6.2.4 German Fire Brigade Panels _____________________ 50
6.3 Units connected to the RS232 interface J5 ______________ 51
6.3.1 Web-servers__________________________________ 51
6.4 Units connected to the RS232 interface J3 ______________ 51
6.5 Other units_______________________________________ 51
6.5.1 Alert Annunciation Controllers___________________ 51
6.5.2 External LEDs________________________________ 52
6.5.3 Alarm devices (sounders, etc.) ___________________ 53
6.5.4 Door release magnets __________________________ 53
6.5.5 Boxes_______________________________________ 53
7Programmable inputs_______________________ 54
7.1 Control unit Input I0 & Inputs and Outputs exp. board 4583,
Input 0-4 ______________________________________________ 55
7.1.1 Not supervised________________________________ 55

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
3
7.1.2 Supervised___________________________________ 55
7.2 3361 unit Inputs In0 / Z & In1 _______________________ 56
8Input programming ________________________ 57
8.1 Type (trigger conditions)____________________________ 57
8.2 Logic ___________________________________________ 59
8.2.1 Not supervised (default) ________________________ 60
8.2.2 Supervised___________________________________ 60
9Programmable outputs______________________ 61
9.1 Control unit outputs S0 –S1_________________________ 62
9.2 Control unit output R0 _____________________________ 63
9.3 8 relay outputs expansion board 4581 Output 0 –Output 7 _ 63
9.4 Inputs and Outputs expansion board 4583 Output 0 –1____ 63
9.5 The 3361 unit outputs Re0 –Re1 _____________________ 64
9.6 The 3364 unit outputs VO0, VO1 & VO2 ______________ 64
9.7 The 3377 unit output (siren) _________________________ 64
9.8 The 3378 unit output (sounder)_______________________ 64
9.9 The 3379 unit output (sounder)_______________________ 64
10 Output programming_______________________ 65
10.1 Type ___________________________________________ 65
10.2 Logic ___________________________________________ 66
10.3 Supervised_______________________________________ 66
10.4 Output signal period _______________________________ 66
10.5 Control expression ________________________________ 69
10.5.1 Trigger conditions_____________________________ 69
10.5.2 Logical operators______________________________ 72
10.5.3 Control expression examples ____________________ 72
11 Interlocking function _______________________ 76
11.1 Interlocking programming __________________________ 76
11.1.1 Interlocking output ____________________________ 76
11.1.2 Interlocking input _____________________________ 76
11.1.3 Interlocking combination _______________________ 76
11.2 Interlocking indications_____________________________ 78
11.3 Information of interlocking combinations (H9) __________ 78
11.3.1 Display interlocking information (H9/C1) __________ 78
11.3.2 Activate interlocking output (H9/C2) ______________ 79
11.3.3 Reset interlocking output (H9/C3) ________________ 79
11.3.4 Disable interlocking output (H9/C4)_______________ 79
11.3.5 Re-enable interlocking output (H9/C5)_____________ 79
11.4 Interlocking control expressions ______________________ 79
12 Fire Door Closing function __________________ 80
13 Functions / Services / Features _______________ 81
13.1 Analog smoke detectors ____________________________ 81
13.1.1 Sensor value _________________________________ 81
13.1.2 Week average sensor value______________________ 81

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
4
13.1.3 Decision value________________________________ 82
13.1.4 Alarm algorithms for smoke detectors / Detection levels /
Offsets 82
13.1.5 Alarm algorithm / Alternative alarm algorithm ______ 83
13.1.6 Filtering algorithm ____________________________ 84
13.1.7 Smouldering smoke algorithm ___________________ 86
13.1.8 Performance factor ____________________________ 88
13.2 Analog heat detectors ______________________________ 88
13.2.1 Class A1 algorithm ____________________________ 89
13.2.2 Class A2 S algorithm __________________________ 89
13.2.3 Class B S algorithm____________________________ 89
13.3 Self verification___________________________________ 90
13.4 Minimum / Maximum sensor values___________________ 90
13.5 Two-unit dependence (co-incidence alarm) _____________ 90
13.6 Two-zone dependence (co-incidence alarm)_____________ 91
13.7 Delayed alarm ____________________________________ 92
13.8 Alarm Verification Facility__________________________ 92
13.9 Alert Annunciation ________________________________ 92
13.10 Alarm Acknowledgement Facility (AAF)_____________ 94
13.11 Quiet alarm ____________________________________ 96
13.12 Fire alarm type A and Fire alarm type B______________ 96
13.12.1 Fire alarm type B____________________________ 97
13.12.2 Fire alarm type A ___________________________ 97
13.13 Disable zones, alarm points, outputs, etc._____________ 97
13.13.1 Disable zone _______________________________ 98
13.13.2 Disconnect / Re-connect zone line ______________ 98
13.13.3 Disable zone / address________________________ 98
13.13.4 Disable control output________________________ 98
13.13.5 Disable / Re-enable all control, exting. and ventilation
outputs 98
13.13.6 Disable / Re-enable alarm devices ______________ 98
13.13.7 Disable outputs for routing equipment ___________ 98
13.13.8 Disable interlocking output____________________ 99
13.13.9 Disconnect / Re-connect COM loop _____________ 99
13.14 Test mode _____________________________________ 99
13.15 Test alarm devices_______________________________ 99
13.16 Test of routing equipment________________________ 100
13.17 Calibration of supervised outputs __________________ 100
13.18 Service signal _________________________________ 100
13.19 Fault signal (fault condition)______________________ 100
13.20 Alarm texts ___________________________________ 101
13.20.1 Creating the alarm texts via Win128____________ 101
13.20.2 Downloading texts to the EPU 1728, AAUs 1735 /
1736 and ext. FBPs 1826 / 1828 ________________________ 103
13.21 Real time clock (RTC) __________________________ 103
13.21.1 Daylight saving time ________________________ 104

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
5
13.22 Time channels 1-4______________________________ 104
13.23 Time channels 5-12_____________________________ 104
13.24 Event log _____________________________________ 105
13.25 Loss of main power source _______________________ 105
13.25.1 Fault: Loss of main power source ______________ 105
13.25.2 LCD backlight_____________________________ 105
13.26 Win128 Tools menu ____________________________ 105
14 Special New Zealand functions ______________ 108
14.1 Alarm devices ___________________________________ 108
14.1.1 Silence alarm devices (inside switch) _____________ 108
14.1.2 New Zealand FB Silence switch (outside switch)____ 108
14.2 Battery faults____________________________________ 109
14.2.1 FAULT: Battery _____________________________ 109
14.2.2 FAULT: Low battery capacity __________________ 109
14.3 Watchdog reset __________________________________ 110
14.4 Routing equipment isolate (disable) __________________ 110
14.5 Acknowledged alarm _____________________________ 110
15 Cyber sensor functions_____________________ 111
15.1 Pulse up –down counter ___________________________ 112
15.1.1 Pulse up –down counter for smoke ______________ 112
15.1.2 Pulse up –down counter for temperature __________ 112
15.1.3 Pulse up –down counter for smoke & temperature __ 112
15.2 Fire judgement __________________________________ 112
15.3 Alarm threshold levels ____________________________ 113
15.4 Learning function / Learning conditions_______________ 113
15.4.1 Learning conditions___________________________ 113
15.5 Alarm delay time_________________________________ 115
15.6 Analog data output _______________________________ 116
15.7 Sensitivity compensation __________________________ 116
15.8 Self diagnosis of internal devices ____________________ 116
15.9 Address setting check _____________________________ 117
16 Control unit properties (settings) ____________ 118
16.1 Control Unit Properties____________________________ 118
16.1.1 AAF times__________________________________ 118
16.1.2 Alert annunciation times _______________________ 118
16.2 Time Channels __________________________________ 119
16.3 Alarm Algorithms ________________________________ 121
16.3.1 Parameters for smoke algorithms ________________ 122
16.3.2 Parameters for heat algorithms __________________ 122
16.3.3 Parameters for combined decision algorithm _______ 123
16.4 National Holidays ________________________________ 123
16.5 Output Signal Periods _____________________________ 125
16.6 Advanced ______________________________________ 126
16.6.1 Main power loss fault _________________________ 126
16.6.2 Alarm reset _________________________________ 126

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
6
16.6.3 Door closing by time__________________________ 126
16.6.4 Zone line input alarm delay time_________________ 127
16.6.5 Miscellaneous _______________________________ 127
16.7 Statistics _______________________________________ 128
17 Cable types ______________________________ 129
17.1 COM loop cables_________________________________ 129
17.2 Ext. FBP / EPU / AAU cables_______________________ 129
17.3 Conventional zone line cables_______________________ 129
17.4 Alarm device cables ______________________________ 129
17.5 Other equipment cables____________________________ 129
18 COM loop cable length_____________________ 131
19 Current consumption ______________________ 134
20 Power supply_____________________________ 137
20.1 Charger functions ________________________________ 137
20.1.1 Battery charging functions:_____________________ 138
20.1.2 Security functions ____________________________ 138
20.2 Current consumption calculations____________________ 139
20.3 Main power source (Power Supply) __________________ 140
20.4 Second power source (Battery)______________________ 140
20.5 Form / Table of current consumption _________________ 141
21 S/W versions _____________________________ 142
22 Technical data____________________________ 143
23 Limitations_______________________________ 144
23.1 C.i.e. __________________________________________ 144
24 National regulations / requirements __________ 145
24.1 Conventions_____________________________________ 145
24.2 Language_______________________________________ 145
25 Drawings / connection diagrams_____________ 146
26 Revision history___________________________ 147
Drawings according to the valid table of drawings.

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
7
1 Introduction
EBL128 Planning Instructions is a document
1
with information of
special interest for planning engineers as well as service /
commissioning engineers.
It should be read in conjunction with the EBL128 Operating
Instructions, since most of the information in one of the documents is
not found in the other document and vice versa.
It should also be read in conjunction with the EBL128 drawings
2
,
according to the valid Table of drawings.
A Product Leaflet is also available at:
http://www.panasonic-fire-security.com/pewfste/en/html (Data sheets)
When planning a fire alarm installation the national regulations have
to be obeyed. A lot of detector types can be used. Detector coverage
area and detector placing in the room / building, etc. are matters for
the planning engineers and are not described in this document.
Due to continual development and improvement, different S/W
versions are to be found. This document is valid for the EBL128 S/W
version 1.1.x. On the date of this document is x=2.
EBL128 S/W version 1.1.x support and some functions require the
EBL128 main board 4556 with p.c.b. no. 9285-6A. S/W version 1.1.x
also support main board with p.c.b. no. < 9285-6A (e.g. 9285-5A).
EBL128 is produced for many countries, accordingly the look, the
texts, the functions, etc. might vary from country to country.
Products
Products consists of one or more parts (H/W) according to a Product
Parts List. A product has:
a type number (e.g. 4550)
an article number, often the same as the type no. but sometimes
a country code is added (e.g. 4550SE)
a product name (e.g. EBL128 Control & Indicating
Equipment, 128 addresses)
H/W
A H/W (e.g. a printed circuit board) has:
a type number (e.g. 1556)
an article number, often the same as the type no. but sometimes a
country code is added (e.g. 1556SE)
a product name (e.g. Main Board 128 addr.)
1
File name: K:\PRO\FIRE\128\Doc\V1.1.x\MEW01090 (Rev 3).doc
2
Dimensions & overviews, connection diagrams, etc.

Panasonic Electric Works Nordic AB
MEW01090 Rev: 3 EBL128 Planning Instructions V1.1.x
8
a p.c.b. number (e.g. 9285-6A) and can also have a configuration
(e.g. CFG: 1) and a revision (e.g. REV: 2)
sometimes is a S/W (software) downloaded.
S/W
A S/W has:
a version number (e.g. V1.1 or V1.1.0)
sometimes is additional information, such as Convention
(different functions / facilities), Language, etc. added.
PC S/W
A PC S/W is a program used for programming, commissioning, etc. It
has a version number.
