Panasonic SR-DF101 User manual

ORDER NO HMK1108057CE
Electronic Warm Jar
SR-DF101
SR-DF181
SR-DF101 SR-DF181
Power supply
TWN AC 110V/60Hz
Latin America,USA AC 120V/60Hz
Brazil AC 127V/50Hz
HongKong,Thailand,Viet Nam,RSU,
Peru,Indonesia,Singapore RBD AC 220V/50Hz
India,Singapore DBD AC 230V/50Hz
Malaysia,Oceania AC 240V/50Hz
Power consumption
Max.for
cooking
HongKong,Malaysia,India,
Singapore RBD,Viet Nam,
Singapore DBD,Thailand,
Oceania,USA,RUS,
Latin America,Peru,Brazil
750W
TWN,Indonesia 760W
Max.for
keeping
warm
HongKong,Malaysia,India,
Singapore RBD,Viet Nam,
Singapore DBD,Thailand,
Oceania,USA,RUS,
Latin America,Peru,Brazil
750W
TWN,Indonesia 760W
Cooking method Heat directly
Menu select HongKong,Malaysia,Singapore RBD,
USA, Oceania,Singapore DBD, India,
Viet Nam,Thailand,TWN,Indonesia Quick Cook/Steam,White Rice, Brown Rice,Porridge/Soup
Latin America,Peru,Brazil,RSU Quick Cook/Steam,White Rice,Cake,Porridge/Soup
© 2011 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized distribution is copying
and distribution is a violation of law.
®
IP3830_SR-DF101_Eng_19_121224.in1 1 2012-12-24 17:19:31

2
Keep Warm temperature
HongKong,Malaysia,India,
Singapore RBD, Oceania,
USA, Singapore DBD,
Viet Nam,RUS, Thailand,
TWN,Indonesia
73±4°C
TWN,Indonesia 73±4°C
Rice cooking volume
(rice quantify)
White Rice/Quick Cook 0.18L~1.0 L(1~5.5cups) 0.18L~1.8 L(1~10cups)
Quick Cook(1~8cups)
Brown Rice 0.18L~0.54L(1~3cups) 0.18L~1.08L(1~6cups)
Mixed rice/Glutinous rice 0.18L~0.54L(1~3cups) 0.18L~0.9L(1~5cups)
Porri cooking volume (rice quantify) 0.09L~0.18L(1/2~1cups) 0.09L~0.3.6L(1/2~2cups)
Maxinmun cooking volume (ingredints+water)for soup 1.5L※ 2.3L※
Cake Latin America,Peru,Brazil Max(480g) Max(480g)
Heat source (Heating part)
HongKong,Malaysia,India,
Singapore RBD,Oceania,
USA,Singapore DBD,
Viet Nam,RSU,Thailand,
TWN,Indonesia
Cooking....bottom(cast heater)
TWN,Indonesia Keep Warm....bottom(cast heater),side(warming heater),lid
(lid heater)
Temperature checking
HongKong,Malaysia,India,
Singapore RBD,Oceania,
USA,Singapore DBD,
Viet Nam,RSU,Thailand,
TWN,Indonesia
Pan sensor(thermal resistor with negative temperature coefficient)
TWN,Indonesia Pan sensor(thermal resistor with negative temperature coefficient),lid
sensor(thermal resistor with negative temperature coefficient)
Safe equipment Thermal fuse A 250V 10A 172°C,Thermal fuse B 250V 10A 172°C
Power cord Component coupling(the applicabie power cord is about 1.0m lcm
Dimension (W)24.5cm ×(L)33.9cm ×(H)19.9cm (
W)24.5cm ×(L)33.9cm ×(H)24.7cm
Weight 2.5kg 2.8kg
Accessory Measuring cup,rice scoop,steaming
※It means that the maximum cooking volume for soup is the highest waterline for "PORRIDGE".
●The power consumption is about 1W when both Cooking and Off mode(room temperature 20°C).
●lf any change occurred to the appearance, wiring or other parts of the warm jar due to property improvement or other reasons,there
will be additional notice.
IP3830_SR-DF101_Eng_19_121224.in2 2 2012-12-24 17:19:31

3
Accessories
Accessories
Power cord
Handle(both sides)
160
120
80
40
Please clean the accessories before using.
Rice scoop (1) Measuring cup (about180mL) (1) Steaming basket (1)
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt with in this service information by anyone else
could result in serious injury or death.
Entire unit
Outer Lid
Moisturizing cap
Pan seal ring
Heating plate
Pan
Hook button
Control panel
Body
IP3830_SR-DF101_Eng_19_121224.in3 3 2012-12-24 17:19:32

4
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in4 4 2012-12-24 17:19:32

5
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in5 5 2012-12-24 17:19:33

6
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in6 6 2012-12-24 17:19:33

7
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in7 7 2012-12-24 17:19:34

8
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in8 8 2012-12-24 17:19:35

9
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in9 9 2012-12-24 17:19:35

9-1
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in10 10 2012-12-24 17:19:36

9-2
1 SR-DF101,181 Electric Circuit Diagram
IP3830_SR-DF101_Eng_19_121224.in11 11 2012-12-24 17:19:37

10
2 Schematic Diagram (SR-DF101, 181)
P.C.B.
(Power supply
side)
P.C.B.(operation side)
Terminal Cast Heater
Connecting line
A of PCB
IP3830_SR-DF101_Eng_19_121224.in章节1:10 章节1:10 2012-12-24 17:19:38

11
2 Schematic Diagram (SR-DF101, 181)
Inner lid
Terminal
Earth Lead
Cast Heater P.C.B.(operation side)
Insulation Heater
IP3830_SR-DF101_Eng_19_121224.in章节1:11 章节1:11 2012-12-24 17:19:38

12
3 Wiring Connection Diagram
DF181 Wiring Connection Diagram Note: For actual needs, some junctions
of the connecting wires of the product
are winded with flame retardant tapes.
Don’t attempt to tear off the tapes
unless it is absolutely necessary. And
wind the tapes on the initial positions
as before after repair.
connecting line A of PCB (Red)
Fuse (Orange)
Heater lead B (white)
Thermistor lead (Red)
Earth Lead (Green)
Lead !(18,15:Yellow 10:purple)
Lead (18, 15: Blue, 10:Red)
Factory:
HongKong
Singapore RBD
Singapore DBD
Oceania
India
Viet Nam
Malaysia
Thailand
Latin America
Brazil
Peru
IP3830_SR-DF101_Eng_19_121224.in章节1:12 章节1:12 2012-12-24 17:19:39

13
3 Wiring Connection Diagram
DF181 Wiring Connection Diagram Note: For actual needs, some junctions
of the connecting wires of the product
are winded with flame retardant tapes.
Don’t attempt to tear off the tapes
unless it is absolutely necessary. And
wind the tapes on the initial positions
as before after repair.
connecting line A of PCB (Red)
Fuse (Orange)
Heater lead B (white)
Thermistor lead (Red)
Earth Lead (Green)
Lead (18: Blue 10: White for TWN) (18: Yellow for Indonesia)
Lead (18: Red 10: Blue for TWN) (18: Blue for Indonesia)
Wiring Ducts
Terminal bottom withstands heater lug.
Side Heater lead (Yellow, White)
Lid Heater lead (Orange, White for TWN) (Yellow, White for Indonesia)
Lid Earth
Lid Heater
Factory:
TWN
Indonesia
IP3830_SR-DF101_Eng_19_121224.in章节1:13 章节1:13 2012-12-24 17:19:40

14
4 Troubleshooting
When receiving a cooker for service from the user, please check if the product remains intact (e.g. pan, valve for warming, etc.), and
ask the user to describe the symptom of the malfunction. Unplug the power cord when carrying out component-level checks.
4.1. Before Problem Diagnosis
•The problem diagnosis table is divided into two sections: Vol. 1 for the cooker's main unit, Vol. 2 for the control circuit board.
•Start diagnostic evaluations with Vol. 1.
•Check if the symptom of the malfunction cooker is listed in the Vol. 1 diagnostic section. If no item is found, perform a quick check
test of the control circuit board (refer to P9). If any fault is found, continue the diagnostic evaluation referring to Vol. 2.
•The problem diagnosis table primarily lists suspect component assemblies (parts) and areas.
•Refer to P11 for parts-level determination of malfunctions for each board.
Notes on handling the printed circuit board with microprocessor
Notes on handling the printed circuit board with microprocessor
The microprocessor is constructed of CMOS digital IC (integrated circuit) and MOS FET (Metal-Oxide-Semiconductor Field-Effect
Transistor) technology, and is extremely sensitive to static electricity, including static discharges from human body, clothing, and
from objects, including soldering irons. Handling with great care as specified below:
•When handling, workers should be well grounded.
•Ground soldering irons. Do not use poorly insulated soldering irons. It is recommended to use soldiering irons with microcircuitry.
•Do not touch the pins of ICs or other elements with your hands before well grounded. Do not place the board on a conductive
surface that may be charged.
IP3830_SR-DF101_Eng_19_121224.in章节1:14 章节1:14 2012-12-24 17:19:41

15
•Do not insert parts from the reverse side of the board.
•When testing with a multimeter during continuous tests, do not use high resistance ranges (×10,000), which may subject ICs and
other components on the board to excess voltage and thus cause damage.
•Keep soldering time as short as possible (within a few seconds)
•Unplug the power cord before replacing any components.
•Be aware of the risk of electric shock or injury when handling a live control board. The control board's transformer carries 220 VAC.
IP3830_SR-DF101_Eng_19_121224.in章节1:15 章节1:15 2012-12-24 17:19:41

16
5 PROBLEM DIAGNOSIS TABLE Vol.1 (for the cooker's main
unit)
Drawing No. 16 37 43 51 15 7 27
※Refer to P9 and P10 if the defective location
is on the PCB.
Does not
cook rice
COOKING
LED lights up 〇〇
COOKING
LED does not
light up 〇〇〇 〇
If the thermal fuse has
melted, firstly find out
the reasons and then
exchange the defective
parts.
Cannot cook rice correctly.(stops
early or cooking is uneven, etc.) 〇〇 〇 〇
This may occur due
to user’s wrong
measurement or
insufficient loosening
of rice.
Rice on the bottom of the inner
pan is scorched dark brown. 〇〇 〇 〇
Check that there
is no dirt or foreign
substances stuck to
the surface of the pan
sensor.
Keep Warm temperature is high.
(78°C or higher) 〇〇〇 〇
Keep Warm temperature is low.
(68°C or lower) 〇〇 〇〇 〇
Does not Keep
Warm Keep Warm LED lights up 〇
Droplets fall onto the surface of
the rice. 〇〇 〇
This may occur by
cutting off the power or
insufficient loosening of
rice.
The surface of the rice dries up. 〇〇 〇
This may occur when the
lid is kept open for a long
time or by insufficient
loosening of rice, or the
valve for warming comes
off.
The bottom of the cooker melts or
gets on fire. 〇
Malfunction
Symptom Status of main unit
Malfunction
Suspect
Component
Cast Heater Pan Sensor Complete power terminal AC cord Pan Parts on PCB Lid Heater (only for TWN and Indonesia) Side Heater (only for TWN and Indonesia)
IP3830_SR-DF101_Eng_19_121224.in章节1:16 章节1:16 2012-12-24 17:19:42

17
6 QUICK CHECK TEST OF THE CONTROL BOARD
Before beginning diagnostic evaluation of a problem, perform a quick check test of the control board, as explained below. If anything
abnormal, then perform reset operation once (refer to P11)
If still abnormal, please refer to the problem diagnosis table Vol. 2. (P9) and diagnosis methods for defective components (P10) ), to
exchange the parts on P.C.B or control board comp.
1
Connect the unit to a power source. In stand-by mode, using three fingers simultaneously press and hold [Start], [Off], [White
Rice] buttons.
Quick Cook/Steam
Brown Rice
Off Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
[Figure A]
2
As soon as you release the three buttons, as shown in Fig. B on the right, [Quick Cook/Steam] indicator lights up, and press [Quick
Cook/Steam] button.
Quick Cook/Steam
Brown Rice
Off Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
[Figure B]
3
Repeat according to the sequence of: Quick Cook/Steam indicator lamp
White Rice indicator lamp
indicator lamp for Brown Rice
indicator lamp for Porridge/Soup
Keep Warm indicator lamp
and then the heating becomes the full-power heating mode. When it is heated
to the final temperature of cooking, it will automatically shift to constant
temperature mode.
Quick Cook/Steam
Brown Rice
Off Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
[Figure C]
4
Press [off] button once. Press other buttons and confirm that operation is normal.
After carrying out procedures 1 to 4, if test results are normal, you can conclude that P.C.B.(Comp.) has passed the test.
IP3830_SR-DF101_Eng_19_121224.in章节1:17 章节1:17 2012-12-24 17:19:42

18
7 PROBLEM DIAGNOSIS TABLE Vol.2 (for PCB)
SW X1 RL Remarks
Parts on control board
Does not cook
rice
COOKING LED
lights up. 〇〇
COOKING LED
does not light up. 〇〇〇
Cannot cook rice correctly. (Stops
early or cooking is uneven, etc.) 〇
Rice on the bottom of the inner pan is
scorched dark brown. 〇
Keep Warm temperature is high. (78°C
or higher) 〇
Keep Warm temperature is low.(68°C
or lower) 〇
Does not Keep
Warm Keep Warm LED lights up 〇
Don’t keep warm continuously. 〇
Droplets fall onto the surface of the
rice. 〇
Malfunction
Symptom Status of
main unit
Malfunction
Suspect
Component
Control board
Tact switch Relay Crystal
IP3830_SR-DF101_Eng_19_121224.in章节1:18 章节1:18 2012-12-24 17:19:42
