Panasonic KX-NS User manual

KX-NS Step by Step Guide
KX-NTV / KX-HDV430
September 29, 2016
Specifications are subject to change without notice.
Panasonic System Networks
PBX SE team

2
PBX, phone and security camera can be provided by Panasonic.
Other major PBX maker do not have security camera.
1. Introduction
Office
LAN
Ext 101 Ext 102 Ext 103
KX-HDV430
KX-NTV150
Ext 115
KX-NTV160
Ext 116
Panasonic
IP-PBX KXT7765
Internet
Ext 301 Ext 302
Bria SIP Software
phone with Video
Remote connection by
MRG is available.

3
2. Basic Specifications
KX-NTV150 : Communication SIP Camera
- PoE / Wi-Fi (*)
- Built-in Speaker and Microphone
- Call button
(*) AC Adaptor KX-A239 is required.
KX-NTV160 : SIP based Video Doorphone
- PoE only
- Built-in Speaker and Microphone
- Call button
-IP-Grade : IP43

4
KX-NS300/500/700/1000 version 4.3 or later with DSP
Version 4.2 can be used for demo only.
KX-NTV does NOT work with other PBX including SIP server.
Video call of KX-NTV is available with only following phones.
KX-HDV430
SIP software phone Bria by CounterPath for PC, tablet or smart-phone
(Other SIP video phones such as Grandstream are not recommended.)
3. Requirement
Phone Protocol Virtual card AK for KX-NS
KX
-NT MGCP V-IPEXT card KX-NSM5xx
KX
-HDV / KX-NTV SIP V-SIPEXT card KX-NSM5xx
3
rd party SIP phone SIP V-SIPEXT card KX-NSM7xx
http://www.counterpath.com/bria/
KX-NTV supports H.264. But X-Lite by CounterPath supports H.263.

5
4. Table of Contents
Chapter Contents
1KX-NS programming
2KX-NTV : Initial setup
3KX-NTV : SIP registration and video
4KX-HDV430 programming
5Bria
6KX-NTV : Maintenance

6
Chapter 1
KX-NS Programming

7
11. Make SIP Account for KX-NTV.
See step by step guide No.12 for details.

8
Chapter 2
KX-NTV : Initial Setup

9
21. Initialize KX-NTV.
If KX-NTV has bee already registered to other PBX, it is required to
initialize. Keep pressing reset button for 30s.
<KX-NTV150> <KX-NTV160>

10
22. Connect KX-NTV to PoE L2-Switch.
Connect KX-NTV150/160 to KX-HTS through PoE L2-Switch.
KX-NTV150/160 gets IP address.
(KX-NTV is not registered as SIP extension automatically.)
- Wait until yellow LED starts flashing.
- LED : Red (15s) -> Off (10s)-> Red (20s) -> Yellow Flash
Panasonic
KX-NS Panasonic
L2 Switch (PoE)
for example

11
23. Find IP address of KX-NTV using IW.exe.
Panasonic
KX-NS Panasonic
L2 Switch (PoE)
for example
http://panasonic.net/pcc/support/pbx/download/ntv/index1.html

12
24. Log-in using Internet Explorer.
Log-in to KX-NTV.
ID = admin
Password = adminpass
If web browser is Internet Explorer, add-in module is installed
automatically as camera viewer.

13
25. Connect KX-NTV150 by Wi-Fi.
KX-HTS Remove LAN and
connect AC Adapter.
Confirm IP address of KX-
NTV150 again.

14
Chapter 3
KX-NTV : SIP & Video

15
31. Log in to KX-NTV for SIP registration.
LED becomes
green after
registration.

16
32. Assign Destination of Call Button.
KX-NTV115
Ext 115 SIP Software phone
Ext 111 KX-NTV160
Ext 116 KX-HDV430
Ext 102
Video is displayed automatically after call is answered.

17
33. Reference : Group Call
KX-NTV116
If the destination is extension number for group, group call is also
available.
Ring
Ring
Ring
Ring Answered
Ext 102
Ext 103

18
34. Adjust General Settings.
<KX-NTV150> <KX-NTV160>
Default of call ring duration is 30s. This is too long for demo.
KX-HDV430 can call KX-NTV150 without tone by above programming example.

19
35. Adjust Video for KX-HDV430 display.

20
Chapter 4
KX-HDV430
