Installation Guide
Model Name Model No.
VL-SV70
Video Intercom System
Door station Main monitor station
RDoor station is described as "doorphone" and Main monitor station is described as "main
monitor" in this guide.
RIn this guide, the suffix of each model number (e.g., the "BX" in "VL-SV70BX") is omitted
unless necessary.
Note to the installer
RBefore attempting to connect or operate this product, please read the nameplate on the
bottom or rear of the product.
RPlease read this guide carefully, and install the product safely and correctly by following
the instructions. Carefully read the information found in the section titled "For your
safety" in particular.
ROnly use attachments/accessories specified by the manufacturer.
RThe installation shall be carried out in accordance with all applicable installation rules.
RTo the maximum extent permitted by law, Panasonic assumes no responsibility for
injuries or property damage resulting from failures arising out of improper installation
or operation inconsistent with this document.
RAfter installation, make sure to leave this guide with the customer.

2
For your safety
To prevent severe injury and loss of life/
property, read this section carefully
before using the product to ensure proper
and safe operation of your product.
Preventing fire, electric shock and
short circuits
RLeave installation work to the
dealer. Installation work requires
technique and experiences. Failure
to observe this may cause fire,
electric shock, injury, or damage to
the product. Consult the dealer.
RElectrical connection work should
be performed by certified
personnel only. Certification is
required for performing electrical
connection work. Consult your
dealer.
RDo not attempt to disassemble or
modify this product. Contact an
authorised service centre for repairs.
RNever install wiring during a lightning
storm.
RDo not connect non-specified devices.
RDo not connect a power cable to a
terminal that is not specified in this
guide.
RWhen opening holes in walls for
installation or wiring, or when securing
the power cable, make sure you do not
damage existing wiring and ductwork.
RDo not make any wiring connections
when the power supply is turned on.
RDo not install the main monitor in the
following places:
– Places where the main monitor may
be splashed with water or chemicals.
– Places where there is a high
concentration of dust, or high
humidity.
RDo not place objects on the power
cables. Install the product where no
one can step or trip on the power
cables.
RDo not allow the power cables to be
excessively pulled, bent or placed
under heavy objects.
RWhen existing wires are used, it is
possible that they contain AC voltage.
Contact an authorised service centre.
Preventing electric shock
RIf the wiring is underground, do not
make any connections underground.
RIf the wiring is underground, use a
protection tube.
RIf the wiring is outdoors, use a
protection tube or a surge protector.
Preventing injury
RInstall the product securely adhering
to the instructions in this guide to
prevent it from falling off the wall.
Avoid installing onto low-strength
walls, such as gypsum board, ALC
(autoclaved lightweight concrete),
concrete block, or veneer (less than
18 mm thick) walls.
RTo prevent serious injuries due to the
product unexpectedly falling, the
product with a wall mount feature must
be installed at a height of 2 m or lower.
WARNING
CAUTION

Supplied accessories for installation
For the doorphone
Screw ´ 2
(3.8 mm ´ 20 mm)
For the main monitor
Screw ´ 2
(4 mm ´ 16 mm)
Mounting bracket ´ 1
Important:
RYou will need the following additional items to install and configure the doorphone and the
main monitor.
[Locally procured]
– Wires (for doorphone and other connections):
Prepare wires of the appropriate specification. (a"Wire type and length")
Note:
RThe illustrations in the supplied manual(s) may vary slightly from the actual product.
3

Precautions for installation
To avoid malfunction or communication disturbances, do not install the doorphone or the main monitor in
the following locations:
– Places where vibration or any other kind of impact occurs.
– Places where echoing is frequent.
– Places near a high concentration of dust, hydrogen sulphide, ammonia, sulphur, or noxious fumes.
For the doorphone
RIf a strong light is shining on the doorphone, the visitor’s face may not be distinguishable. Do not place
the doorphone in the following locations:
– Where most of the background is the sky.
– Where the background is a white wall, and direct sunlight will reflect off it.
– Where direct sunlight will shine on the doorphone.
RDo not place the doorphone in locations where echoing occurs, as this will cause the doorphone to
beep frequently.
RMake sure the rear of the doorphone is not subject to water.
RDepending on the installation location, condensation may form on the doorphone’s lens cover. This
may cause images to become obscured. Condensation will dissipate as the temperature rises.
For the main monitor
RLeave at least 20 cm of space above, below, and to the left and right sides of the main monitor. Do not
install on a wall that is deeply recessed.
RDo not install the main monitor inside a wall.
RBe sure to install the main monitor more than 5 m away from the doorphone.
RIn areas surrounded by a high electrical field, disturbances may occur in the main monitor’s image or
sound.
Important:
RDo not use any cleaning products that contain alcohol, polish powder, powder soap, benzine,
thinner, wax, petroleum, or boiling water. Also do not spray the product with insecticide, glass
cleaner, hair spray or wall paint. This may cause a change in colour or quality of the product.
4

Wiring schematic diagram
Set up correctly according to the following wiring schematic diagram and "Wire type and length".
RFor information, such as order numbers, about optional devices that can be connected to, refer to the
"Additional/replacement accessories" section in the Operating Instructions.
DOORPHONE 1
Electric
lock NP: Non-polarised
MAIN MONITOR
Connection device
for option Input
(A contact) *2
A
*1
D1
D2
IN1
IN2
Power plug
(220-240 V AC)
NP
NP
NP
S1
S2
Power supply
*1 When you use an additional doorphone, the maximum number of the electric locks that can be
connected to the doorphone depends on the type of doorphone. Consult your dealer for further
information.
For VL-V554 users:
– Only connect the electric lock to either the S1/S2 terminals of the main monitor or the S1/S2
terminals of the doorphone.
*2 Connection devices for option input (A contact).
– Make sure to connect doorbells to the IN1/IN2 terminals.
5

Wire type and length
Wiring run Wire type*1
Diameter Length (Max.)
Doorphone –
Main monitor
ø 0.65 mm 22 AWG 100 m
ø 1.0 mm 18 AWG 130 m
ø 0.5 mm CAT 5 50 m
Main monitor –
Electric lock*2
ø 0.5 mm - ø 1.2 mm
(24 AWG - 17 AWG)
According to the
specifications of the
connected device.
Main monitor –
Connection device for
option input (A contact)*2
ø 0.5 mm - ø 1.2 mm
(24 AWG - 17 AWG)
According to the
specifications of the
connected device.
*1 Type: Single-pair cable with outer sheath (jacket)
Conductor: Copper solid
RA certified power supply wiring has to be used with this equipment. The relevant national
installation and/or equipment regulations shall be considered. A certified power supply wiring not
lighter than ordinary polyvinyl chloride flexible wiring according to IEC 60227 shall be used.
*2 When using an electric lock or a connection device for option input (A contact), select a device that
meets the following guidelines:
RElectric lock connection terminal (S1/S2):
– N/O dry closure contact
– 30 V AC (1 A)/24 V DC (1 A) or lower
RConnection device for option input (A contact) terminal (IN1/IN2):
– Input method: No-voltage contact
– Open-circuit voltage between terminals: DC 7 V or less
– Detection definite time: 0.1 second or more
– Short-circuit between terminals: 5 mA or less
– Resistance value: make: 500 W or less, break: 15 KW or more
6

Doorphone installation position
Installation position of the doorphone and camera range
Views when the camera is facing forwards at 0° (default).
RExample: Installation height is 1450 mm (standard position).
(Units: mm)
A
C
D
E
G
H
I
J
K
A view when looking
from above
B
F
A Image range B Approx. 66° C Centre of doorphone D Approx. 1450 E Approx. 500
F Approx. 1810 G Approx. 650 H Approx. 1160 I Image range: Approx. 960 J Approx. 87°
K Approx. 500
The camera angle can be adjusted using the camera angle control lever on the rear of the
doorphone (step 3, “Installing the doorphone”), so that the image range can be changed.
Side view when the camera is installed
lower than the standard position, and
facing upwards at 15°.
Top view when the camera is facing left or
right at 15° *1.
RExample: Installation height is 1100 mm.
(Units: mm)
RExample: Camera angle faces left 15°.
A
B
C
D
E
F
G
H
I
JK
LM
A Image range B Approx. 66° C Centre of doorphone D Approx. 1100 E Approx. 500
F Approx. 1690 G Approx. 710 H Approx. 980 I Image range: Approx. 1080 J Approx. 270
K Approx. 810 L Approx. 87° M Approx. 500
*1 If the camera points 15° upwards, the left or right angle is less than 7°.
Note:
The measurements and angles are for reference purposes and may vary depending on the environment.
7

Installing the doorphone
Important:
ROn the bottom surface of the doorphone and the
mounting base, there are holes to allow water to
drain. Do not cover them up when installing.
RWhen existing wiring (such as chime wires) is
used:
– It may contain AC voltage that may cause
electric shock and/or damage the product.
– Never use the following types of wiring.
Consult a qualified technician/dealer.
RSee "Wire type and length" for information about
wiring materials.
1Remove the mounting base.
Open the screw cover (A).
A
B
B Screwdriver
Loosen the mounting screw (C).
C
D
E
D Water drain holes
E Mounting base
2Attach the mounting base (A) to the wall
securely using the wood screws (B)
(accessory).
RInstall the mounting base on a vertical flat
wall.
RBefore drilling, refer to “Precautions for
installation” for installation location.
A
B
C
D
*1
C Wire (locally procured)
D 83.5 mm
*1 To prevent dew condensation, fill a hole
for wiring as much as possible.
3Adjust the camera angle using the camera
angle control lever.
A
BC
D
Rear view
A Camera angle control lever
B Left (maximum 15°)
C Right (maximum 15°)
D Upwards (maximum 15°)
8

Examples of camera angle
Facing forwards Facing upwards
Facing left Facing upper left
RThe angle can also be adjusted to the right
or upper right.
Important:
RWhen the camera angle is adjusted to the
upper left or upper right, the image may be
slightly distorted.
4Connect the wire, then mount the doorphone
to the mounting base.
Unscrew the screws.
Push in the wire to the terminal connectors
(non polar), then tightly fasten the screws
(A).
A– Recommended torque: 0.5 N·m
{5.1 kgf·cm}
– Maximum torque: 0.7 N·m {7.1
kgf·cm}
A
B
B Wire (connecting to the main monitor)
Mount the doorphone to the mounting
base. Fasten the screw, then close the
screw cover (C).
C
9

Main monitor installation
position
About the installation position of the main
monitor and mounting bracket
RPlace the main monitor in a location that your
eyes are the same height as the centre of the
display.
RFor the following reasons, leave at least 20 cm
(A) of space above, below, and to the left and
right sides of the main monitor:
– To prevent malfunction and sound cutting out
– To ensure to make sure the reset button (B)
can be used (the reset button is on the
bottom of the main monitor)
1
1
1
2
1
RAfter deciding where to install the main monitor,
attach the mounting bracket in the location
shown below.
D
E
C
C Main monitor installation position
D 121.5 mm
E 58 mm
Installing the main monitor
1Attach the mounting bracket (A) to the wall
securely.
RInstall the mounting bracket on a vertical flat
wall (B).
AB
C
D
EF
G
H
C Screws (accessory)
D Hole in wall E 60 mm F 83.5 mm
G 7 mm H 50 mm
2Connect the wires.
RConnect the wires correctly according to
"Wiring schematic diagram".
RHow to make wiring connections
While pressing on the button (A) with a
pointed object such as a screwdriver, insert
the wire into the terminal connector (B).
(To disconnect a wire, while pressing on the
button (A), pull out the wire.)
B
C
A
D
C Core conductor wire at tip: 9 mm
D Wiring from doorphone or other device
Important:
Do not connect the power cable.
(Damage may occur.)
10

3Mount the main monitor to the mounting
bracket.
3-1 Line up the tab on the bottom of the
bracket with the groove on the main monitor.
3-2 Line up the tab on the top of the bracket
with the groove on the main monitor, and push
the main monitor down until it is secure.
11

Notes
12

Notes
13

Notes
14

Notes
15

© Panasonic Corporation 2020
PNQX9134ZA C1020MM0
1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8501, Japan
http://www.panasonic.com
