Panasonic KX-T7765 User manual

Features:
KX-T7765
Doorphone
New high quality design and metallic
colored front cover
Call button surrounded by luminous
ring for use in dark places
*1 If the ring is not exposed to light, it will not emit light.
Luminous ring*1
Suitable for SOHO and office use
Mounts directly onto walls
(in darkness)

The KX-T7765 is a new high quality
design doorphone.
It is suitable for SOHO and office
use and makes a nice match
with any door.
The KX-T7765 connects directly to
Panasonic's PBX and allows owners to
easily speak with visitors.
And, visitors can easily find the call
button thanks to the luminous ring,
so you will never miss a good
business opportunity.
Capability & Hardware Requirements
Luminous Ring Specifications
The Panasonic KX-T7765 Doorphone is compatible with the following
Panasonic PBX systems.
Once exposed to light (from fluorescent lamp or incandescent lamp) for about 30 min, this
ring keeps emitting light for about 1 to 1.5 hours in the darkness at normal temperatures.
Max. residual lighting time: About 1.5 hours
Notes:
• The duration of light emission varies according to light accumulation, place of installation and so forth.
• If the ring is not exposed to light, it will not emit light.
KX-TDE100/200
KX-TDA100/200/600
KX-TDA30
KX-TE824 /TE308
Optional doorphone, OPB card and DPH card
Optional doorphone, OPB card and DPH card
Optional doorphone and DPH card
Optional doorphone and DPH card
Maximum Number of Doorphones
Maximum Cabling Distance
Dimensions
Model No.
TDE/TDA
Series
TE824
Series
TE308
Series
KX-T7765
Cable
ø 0.4 mm :
ø 0.5 mm :
ø 0.6 mm :
CAT 5 :
70 m
113 m
180 m
113 m
Maximum Distance
Cable
ø 0.4 mm :
ø 0.5 mm :
ø 0.65 mm :
CAT 5 :
70 m
110 m
150 m
110 m
98
130
Maximum Distance
TDA30
416
TDE100
TDA100
16
TDE200
TDA200
16/32/48/64
TDA600
4
TE824
2
TE308
Number of doorphones
KX-T7765 Specifications
26
(unit : mm)
27.3
If exposed to any light, the ring emits light repeatedly.
Design and specifications are subject to change without notice. KX-T7765E-LT 0711KYEX0 Printed in Japan.
