Panasonic ET-DLE035 User manual

ENGLISH
DPQX1334ZA/X1
Model No. ET-DLE035
Fixed-Focus Lens
Operating Instructions
Thank you for purchasing this Panasonic product.
■To ensure correct use of this lens, please read the operating instructions supplied with the lens and the
projector carefully.
■Before using this product, be sure to read “Read this rst!” (Page 3).
■Please save this manual for future use.
Product information (for Turkey only)
 EEEYönetmeliğineUygundur.
EEE Complies with Directive of Turkey.
Commercial Use

2-ENGLISH
Read this rst! ......................................................................................3
Before Use.............................................................................................4
Attaching the Lens / Detaching the Lens...........................................4
Before replacing the projection lens........................................................ 4
Attaching the Lens................................................................................... 5
Detaching the Lens ................................................................................. 6
Projection relationships.......................................................................7
Lens position setup and focus adjustment .......................................9
Lens position setup ................................................................................. 9
Focus Adjustment Function................................................................... 12
Specications .....................................................................................13
Dimensions .........................................................................................13
Dimensional relationship.......................Appendix / Annexe / 付録 1
The "Appendix" can be found after the Japanese language section ( 日本語 ).
█ Contents

ENGLISH-3
Read this rst! Always follow these precautions
WARNING:
Do not look at or place your skin into the light emitted from the lens while the
projector is being used.
Doing so can cause burns or loss of sight.
zStrong light is emitted from the projector’s lens. Do not look at or place your hands
directly into this light.
zTurn off the power when moving away from the projection lens or projector.
Do not project an image with the lens cover attached.
zDoingsocancausere.
CAUTION:
Before replacing the projection lens, be sure to turn off the power and
disconnect the power plug from the wall outlet.
zUnexpectedprojectionoflightmaycauseinjurytoeyes.
zReplacing the projection lens without removing the power plug may result in electric
shock.
Do not stand in front of the lens while the projector is being used.
Doing so can cause damage and burns to clothing.
zStrong light is emitted from the projector’s lens.
Do not place objects in front of the lens while the projector is being used.
Doingsocancausere,damagetotheobject,ormalfunctionofthelensand
projector.
zStrong light is emitted from the projector’s lens.
Do not open the desiccant bag. Do not eat the contents.
Inadvertently ingesting desiccant could be harmful.
zIf the desiccant gets into your eyes or mouth, immediately rinse with plenty of water
and seek medical attention.
zKeep desiccant out of the reach of children.

4-ENGLISH
Before replacing the projection lens
Return the projection lens to the home position before replacing or removing it.
For details on how to return the lens to the home position, refer to the operating instructions of the projector.
Attention
zMake sure that the projector power supply is switched off before attaching or detaching the projection lens.
zAfter removing the projection lens, store it safely away from vibration or impacts.
zDonottouchtheelectriccontactpointsoftheprojectionlenswithyourngers.Dustanddirtonthecontacts
may cause contact malfunctions.
zBeforeattachingtheFixed-focuslens,removetheprotectivelmfromthelightprojectingsurfaceandthelens
cap from the lens.
Lens surface Light
projecting
surface
Lens cap
Protectivelm
zBesurenottotouchthelightprojectingsurfaceorthesurfaceofthelens.Anyngerprintsorsmudgeson
thesesurfaceswillbemagniedandlowerthequalityoftheimagedisplayedonthescreen.
zThe light projecting surface and lens are made of glass. The lens could be damaged if brought into contact
with or rubbed against hard objects. Handle the lens carefully.
zUseaclean,soft,anddryclothtowipeawaydustanddirtfromthelightprojectingsurfaceandprojectionlens.
Donotuseuffyclothscontainingoil,waterordustforcleaning.
zWhen the Fixed-focus lens is removed from the projector, place it with the light projecting surface facing
downwards.
Attaching the Lens / Detaching the Lens
Before Use
 Supported projectors
PT-RZ120 / PT-RZ970 / PT-RW930 / PT-RX110 / PT-RZ870 / PT-RZ770 / PT-RW730 / PT-RZ660 / PT-RW620 /
PT-DZ870 / PT-DW830 / PT-DX100 / PT-DZ780 / PT-DW750 / PT-DX820
Note
zModels other than the above may also be supported. Refer to the operating instructions of the projector you are using.
zIn this document, the alphabet letters at the end of the projector part numbers are omitted.
 Supplied Accessories
Make sure that the following has been provided. Numbers enclosed in < > show the number of accessories.
Lens cap <1> Lens shift gauge <1>
(The product is
delivered with a lens
cap attached.)

ENGLISH-5
Guide groove
Lens mount cover
Positioning guide
Fixed-focus lens
1) With this lens already passed
through the lens mount cover that
came with your projector, align the
positioning guide with the guide
groove on the projector, and insert
the lens fully.
zThere is a red dot at the bottom right end of the
positioning guide.
2) Turn the xed-focus lens clockwise
until you hear a click.
3) Attach the lens mount cover to the
projector.
zTurnthelensmountcoverclockwisetoxitin
place.
Attention
zGently turn the projection lens counterclockwise
to check that it will not fall out.
Attaching the Lens
Attaching the Lens / Detaching the Lens (continued)
*Unlessspeciedotherwise,theillustrationsintheseoperatinginstructionsshowthelensusedwiththe
PT-DZ870 projector.

6-ENGLISH
B
A
Lens mount cover
A
C
B
Lens release
button
1) Turn the lens mount cover
counterclockwise to detach it from
the lens and slide it towards the
front end of the lens.
2) Hold down the lens release
button while turning the lens
counterclockwise to release it.
3) Turn the lens mount cover
clockwise to reattach it.
Attention
zAttach the supplied lens cap before storing the lens.
Detaching the Lens
Attaching the Lens / Detaching the Lens (continued)

ENGLISH-7
The dimensional relationship between the screen and the projector is shown below.
 Dimensional relationship diagram
SH
SW
SD
SH
A1
L3
L4
A2
L1
L2
Projected image
Screen
Note
zThe indications of this illustration are premised on aligning the projected image size and position to the full screen.
zThis illustration is not drawn to scale.
SH Projected image height L3 Screen to projector front end
SW Projected image width L4 Screen to projector rear end
SD Diagonal length of the projected image A1 Bottom edge of the screen to the top of the
projector
L1 Projection distance
(fromscreentomirrorreective surface*)
A2 Bottom edge of the screen to the bottom of the
projector
L2 Screen to lens front end
*Themirrorreectivesurfaceisinsidethexed-focuslens,andisnotvisiblefromtheoutside.
Note
zTheillustrationsofprojectorsinthismanualareforinformationalpurposesonlyanddonotrepresentaspecic
projectormodel.Congurationsmayvarywiththemodel.
zDimension L4 is the distance from the projector rear panel to the screen.
zDimension A2 is the distance from the bottom edge of the screen to the bottom of the adjustable projector legs
(with the legs fully screwed in).
Attention
zDimension L4 is not the distance from the projector rear panel to a wall, but the distance from the projector
rear panel to the screen. To prevent obstruction of the intake and exhaust vents, install the projector with a
clearance at least 500 mm (19-11/16") from walls and objects.
 Whenplacingtheprojectorinaconnedspace,aventilationand/orairconditioningsystemisrequired.
 Exhaustheatmayaccumulatewhentheventilationisnotsufcienttriggeringtheprotectioncircuitofthe
projector.
● Avoidsettingupinplaceswhicharesubjecttosuddentemperaturechanges,suchasnearanairconditioner
orlightingequipment(studiolamps,etc.).
Projection relationships

8-ENGLISH
Projection relationships (continued)
zWhen using one of PT-DW830 / PT-DX100 / PT-DZ780 / PT-DW750 / PT-DX820
If keystone distortion in vertical direction or horizontal direction is corrected, the projected image overall will no
longer be in focus. Set up the projector so that the projected image is rectangular and the back of the projector
and the screen are parallel.
zWhen using a projector other than one listed above
Please see "Setting up" in the operating instructions for the projector you are using.
 Dimensional relationship
zWhen using one of PT-RZ120 / PT-RZ970 / PT-RW930 / PT-RX110 / PT-RZ870 / PT-RZ770 /
PT-RW730 / PT-RZ660 / PT-RW620 / PT-DZ870 / PT-DW830 / PT-DX100 / PT-DZ780 /
PT-DW750 / PT-DX820
For details on projection distance (L1), and A1, A2, L2, L3 and L4 values, refer to "Projected image size and
Projection distance" or "Projection distance formulas" in the Appendix.
zWhen using a projector other than one listed above
Please see "Setting up" in the operating instructions for the projector you are using.
 Keystone distortion correction
When attaching this lens for use, regardless of the projector model, set up the projector so that the projected
image is rectangular and the back of the projector and the screen are parallel.
In addition, depending on the projector used, keystone distortion correction may be feasible after setup.
zWhen using one of PT-RZ120 / PT-RZ970 / PT-RW930 / PT-RX110 / PT-RZ870 / PT-RZ770 / PT-RW730 /
PT-RZ660 / PT-RW620 /PT-DZ870
Forkeystonedistortionintheverticaldirectiongeneratedwithintheanglerangebelow,select[MAINMENU]
→[POSITION]→[GEOMETRY]/[GEOMETRY(2D)]→[KEYSTONE]→[VERTICALKEYSTONE]toperform
correction.
Keystone distortion in the vertical direction greater than this angle and keystone distortion in the horizontal
direction can be corrected but the projected image overall will no longer be in focus.
Correctionfeasibleangle(α):0-5°
α
Screen
(Side view)

ENGLISH-9
Lens position setup and focus adjustment
Lens position setup
zWhen using PT-RZ120
When moving the lens position to the home position, perform the operation with the following procedure.
1) Turn on the projector to start the
projection.
2) Press the <MENU> button to
display the [MAIN MENU] screen.
3) Select [PROJECTOR SETUP] in
the main menu and then press the
<ENTER> button.
4) Select [LENS] in the [PROJECTOR
SETUP] menu and then press the
<ENTER> button.
zThe[LENS]screenappears.
5) Select [LENS TYPE] on the [LENS]
screen and then use the
◄►
buttons to select [ET-DLE035].
zEach press of the
◄► buttons switches the
itemto[NORMAL]or[ET-DLE035].
6) Select [LENS HOME POSITION] on
the [LENS] screen and then press
the <ENTER> button.
zAconrmationscreenappears.
7) Use the ◄► buttons to select [OK]
and then press the <ENTER>
button.
z[PROGRESS]isdisplayedonthe[HOME
POSITION]screenandtheprojectionlens
moves to the home position.
MAIN MENU
POSITION
ADVANCED MENU
DISPLAY LANGUAGE
DISPLAY OPTION
PROJECTOR SETUP
TEST PATTERN
SIGNAL LIST
SECURITY
NETWORK
MENU SELECT
SUB MENU
ENTER
1/2
1/2
MENU SELECT
SUB MENU
PROJECTOR SETUP
PROJECTOR ID ALL
PROJECTION METHOD
LENS
OPERATION SETTING NORMAL
LIGHT OUTPUT 100.0%
BRIGHTNESS CONTROL AUTO
STANDBY MODE NORMAL
QUICK STARTUP OFF
NO SIGNAL SHUT-OFF DISABLE
NO SIGNAL LIGHTS-OUT DISABLE
ENTER
MENU SELECT
CHANGE
LENS
LENS TYPE NORMAL
LENS HOME POSITION
LENS CALIBRATION
Note
zIf[LENSTYPE]ismistakenlysetto[NORMAL],theprojectionlenswillnotmovetothecorrecthomeposition.

10-ENGLISH
Lens position setup and focus adjustment (continued)
zWhen using one of PT-RZ970 / PT-RW930 / PT-RX110 / PT-RZ870 / PT-RZ770 / PT-RW730 /
PT-RZ660 / PT-RW620 / PT-DZ780 / PT-DW750 / PT-DX820
When moving the lens position to the lens standard position, perform the operation with the following procedure.
1) Turn on the projector to start the
projection.
2) Press the <SHIFT> button on the
remote control.
zThe shift adjustment screen appears.
3) Press the <DEFAULT> button on
the remote control while the shift
adjustment screen is displayed.
zThe[HOMEPOSITION]screenappears.
4) Use the ◄► buttons to select
[ET-DLE030].
zEach press of the
◄► buttons switches the
itemto[NORMAL]or[ET-DLE030].
5) Press the <ENTER> button.
z[PROGRESS]isdisplayedonthe[HOME
POSITION]screenandthelensposition
moves to the lens standard position for
ET-DLE035.
HOME POSITION
ADJUST
DEFAULT
LENS
SHIFT
VERTICAL POSITION
HORIZONTAL POSITION
LENS
CANCEL
MENU
ENTER
CHANGE
EXECUTE
HOME POSITION NORMAL

ENGLISH-11
zWhen using one of PT-DZ870 / PT-DW830 / PT-DX100
When moving the lens position to the lens standard position, perform the operation with the following procedure.
1) Turn on the projector to start the
projection.
2) Press the <MENU> button to dis-
play the [MAIN MENU] screen.
3) Select [PROJECTOR SETUP] in
the main menu and then press the
<ENTER> button.
4) Select [SERVICE PASSWORD] in
the [PROJECTOR SETUP] menu
and then press the <ENTER> but-
ton.
zThe[SERVICEPASSWORD]inputscreen
appears.
5) Use the <0> and <3> numeric
buttons on the remote control to
enter “030” in the [SERVICE PASS-
WORD] input screen and then
press the <ENTER> button.
zThe[DLE030POSITION]screenappears.
6) Press the <ENTER> button on the
[DLE030 POSITION] screen.
z[PROGRESS]isdisplayedonthe[DLE030
POSITION]screenandthelensposition
moves to the standard position for
ET-DLE035.
Note
zAfter returning the lens to the standard projection position, lens shift adjustments are possible within the range
where the projector will not interfere with the edges of the projected image.
zIf the rear of the projector blocks the bottom edge of the projected image, it may also obscure the view of an
On-screen display (OSD) that is positioned at the lower edge of the screen. If this happens, open the [DISPLAY
OPTIONS]menuandselect[ON-SCREENDISPLAY]→[OSDPOSITION]tochangedisplaylocationsothat
the whole OSD menu can be seen.
LAST USED
SW1234567
ET-LAD120
DISABLE
DEFAULT
1.00
1.00
ACTIVATED
2/2
PROJECTOR SETUP
STARTUP INPUT SELECT
RS-232C
STATUS
NO SIGNAL SHUT-OFF
REMOTE2 MODE
FUNCTION BUTTON
DATE AND TIME
LENS CALIBRATION
SAVE ALL USER DATA
LOAD ALL USER DATA
INITIALIZE
SERVICE PASSWORD
LENS
DLE030 POSITION
OK
CANCEL
MENU
ENTER
MAIN MENU
POSITION
ADVANCED MENU
DISPLAY LANGUAGE
DISPLAY OPTION
3D SETTINGS
PROJECTOR SETUP
TEST PATTERN
SIGNAL LIST
SECURITY
NETWORK
MENU SELECT
SUB MENU
P IN P
ENTER
Lens position setup and focus adjustment (continued)

12-ENGLISH
Focus Adjustment Function
After setting the lens position, adjust the focus.
The focal balance between the center and periphery of the projected image changes depending on the size of the
projectedimage.Thelensisequippedwithafocusbalanceadjustmentfunctionforthescreenperiphery.
 Adjusting the Focus
Periphery focus adjustment ring
1) Focus the center of the screen by
operating the projector unit.
2) Turn the periphery focus ring by
hand as shown in the gure to
adjust the focus in the periphery
of the screen.
3) Again check focus at the center of
the screen and use the projector
controls to make ne adjustments.
Note
zThe projected image sizes and scale shown on the periphery focus adjustment ring are an approximate guide.
Lens position setup and focus adjustment (continued)

ENGLISH-13
Dimensions
132 (5-3/16")
102 (4-1/32")
311 (12-1/4")
(Unit:mm)
Specications
F value 2.0
Focal Length (f) 5.3 mm (7/32")
Dimensions*1
Width
Height
Depth
132 mm (5-3/16")
102 mm (4-1/32")
311 mm (12-1/4")
Net Weight Approx. 1.3 k](2.9 lb)
*1:Excludingprotrusions.

14-ENGLISH
MEMO

ENGLISH-15
MEMO

SS1018MY0 -PS
Printed in Japan
Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying documents means that
used electrical and electronic products must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any
potential negative effects on human health and the environment.
For more information about collection and recycling, please contact your local municipality.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
Information on Disposal in other Countries outside the European Union
ThissymbolisonlyvalidintheEuropeanUnion.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct
method of disposal.
Information for users in the European Union
Importer’snameandaddresswithintheEuropeanUnion
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Product Information (for Turkey only)
AEEEYönetmeliğineUygundur.
EskiEkipmanveBataryalarınİşlenmesi.
SadecegeridönüşümsistemleriolanAvrupaBirliğiveülkeleriiçingeçerlidir.
Ürünler,ambalajve/veyaeklibelgelerüzerindekibusembollerkullanılmışelektrikve
elektronikürünleringenelevatığıilekarıştırılmamasıgerektiğiniifadeeder.
Eskiürünlerintoplanmasıvegerikazanılmasıiçinbuatıklarlütfenyasaylabelirlenmişolan
uygun toplama merkezlerine teslim ediniz.
Buatıklarındoğruişlenmesiyle,değerlikaynaklarınkorunmasınaveinsansağlığıve
çevreyeolasınegatifetkilerininengellenmesineyardımcıolabilirsiniz.
Atıklarıntoplanmasıvegeridönüşümüiçindetaylıbilgiiçinlütfenbağlıolduğunuzyerel
yönetimlerleiletişimegeçiniz.
Atıklarınatılmasıylailgiliyanlışuygulamalaryasaylabelirlenmişolancezalarasebebiyet
verebilir.
Panasonic System Solutions Company of North America
Two Riverfront Plaza, Newark, NJ 07102
TEL: (877) 803 - 8492
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
TEL: (905) 624 - 5010
Panasonic Corporation
Web Site : https://panasonic.net/cns/projector/
© Panasonic Corporation 2018
