2SC5632G
Silicon NPN epitaxial planar type
For high-frequency amplification and switching
■Features
•High transition frequency fT
•S-Mini type package, allowing downsizing of the equipment
and automatic insertion through the tape packing
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC=100 µA, IE=015 V
Emitter-base cutoff current (Collector open) IEBO VEB =2 V, IC=02µA
Forward current transfer ratio hFE VCE =4 V, IC=2 mA 100 350 
hFE ratio *∆hFE hFE2: VCE =4 V, IC=100 µA 0.6 1.5 
hFE1: VCE =4 V, IC=2 mA
Collector-emitter saturation voltage VCE(sat) IC=20 mA, IB=4 mA 0.1 V
Transition frequency fTVCE =5 V, IC=15 mA, f =200 MHz 0.6 1.1 GHz
Collector output capacitance Cob VCB =10 V, IE=0, f =1 MHz 1.0 1.6 pF
(Common base, input open circuited)
■Electrical Characteristics Ta=25°C ±3°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 15 V
Collector-emitter voltage (Base open) VCEO 8V
Emitter-base voltage (Collector open) VEBO 3V
Collector current IC50 mA
Collector power dissipation PC150 mW
Junction temperature Tj150 °C
Storage temperature Tstg −55 to +150 °C
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *:∆hFE =hFE2 / hFE1
■Package
•Code
SMini3-F2
•Marking Symbol: 2R
•Pin Name
1: Base
2: Emitter
3: Collector

2SC5632G
2SJC00369AED
This product complies with the RoHS Directive (EU 2002/95/EC).
PCTaICVCE ICVBE
VCE(sat) IChFE ICCob VCB
0 16040 12080
0
160
120
80
40
Ambient temperature T
a
(°C)
Collector power dissipation P
C
(mW)
06842
0
60
40
20
T
a
= 25°C
I
B
= 300 µA
250 µA
200 µA
150 µA
100 µA
50 µA
Collector current I
C
(mA)
Collector-emitter voltage V
CE
(V)
0 1.20.80.4
0
120
80
40
T
a
= 85°C
−25°C
25°C
V
CE
= 4 V
Collector current I
C
(mA)
Base-emitter voltage V
BE
(V)
11010
2
10
−1
10
−1
10
−2
10
−3
1
T
a
= 85°C
I
C
/ I
B
= 10
25°C
−25°C
Collector-emitter saturation voltage V
CE(sat)
(V)
Collector current I
C
(mA)
11010
2
0
40
80
120
200
160 Ta= 85°C
25°C
−25°C
Forward current transfer ratio h
FE
Collector current I
C
(mA)
VCE = 4 V
11010
2
0
2.5
2
1.5
1
0.5
f = 1 MHz
T
a
= 25˚C
Collector-base voltage V
CB
(V)
Collector output capacitance (Common base, input open circuited) C
ob
(pF)

This product complies with the RoHS Directive (EU 2002/95/EC).
SMini3-F2 Unit: mm
0.30 +0.05 −0.02
0.13 +0.05 −0.02
2.00 ±0.20
(0.89)
0.90 ±0.10
(0.65)(0.65)
1.30 ±0.10
1.25 ±0.10
2.10 ±0.10
0.425 ±0.050
(0.49)
0 to 0.10
(5°)
(5°)
3
12
