Panasonic KX- TAW848 Owner's manual

KX-TAW848
Advanced Hybrid & Wireless PBX
Feature Manual
Thank you for purchasing a Panasonic Advanced Hybrid & Wireless PBX.
Please read this manual carefully before using this product and save this manual for future use.
PSMPR Software File Version 4.0000 or later
Document Version: 2007-02-01
www.voicesonic.com
Phone [phone]
Panasonic KX-TAW848, KX TAW848, KXTAW848, TAW848
Panasonic Telephone Systems

2 Feature Manual
Introduction
About the Feature Manual
The Feature Manual is designed to serve as an overall reference describing the features of the Panasonic
Advanced Hybrid & Wireless PBX. It explains what the PBX can do, as well as how to obtain the most of its
many features and facilities.
The Feature Manual is divided into the following sections:
Section 1 Features and Configurations
Describes the call handling, system configuration and administration features of the PBX.
Section 2 Appendix
Provides tables listing capacity of system resources, tone and ring tone tables, and the revision history of
this Feature Manual.
Index
An alphabetical listing of features and terms, as well as the page numbers of related sections.
References Found in the Feature Manual
Installation Manual References
The Advanced Hybrid & Wireless PBX Installation Manual provides instructions detailing the installation and
maintenance of the PBX. Sections from the Installation Manual are listed throughout the Feature Manual for
your reference.
Programming References
–PC Programming Manual
Commonly used settings can be programmed using the KX-TAW848 Maintenance Console
(→1.13.5 PC Programming). These PC programming items are noted throughout the Feature
Manual for your reference by title and System Menu number.
–PT Programming Manual
Commonly used settings can be programmed using a display PT (→1.13.15 PT Programming).
These PT programming items are noted throughout the Feature Manual for your reference by title
and program number.
Feature Manual References
Related sections of the Feature Manual are listed for your reference.
Operating Manual References
The Advanced Hybrid & Wireless PBX Operating Manual describes how users can access commonly used
PBX features and functions with their proprietary telephones (PTs), single line telephones (SLTs), portable
stations (PSs), and DSS Consoles. Sections from the Operating Manual are listed throughout the Feature
Manual for your reference.
Links to Other Pages and Manuals
If viewing this Feature Manual with a PC, certain items are linked to different sections of the Feature Manual
and other PBX manuals. Click on a link to jump to that section.

Feature Manual 3
Linked items include:
• Installation Manual References
• Feature Manual References
• Operating Manual References
• PT Programming References
• PC Programming References
Abbreviations
There are many abbreviations used in this manual (e.g., "PT", for proprietary telephone). Please refer to the
list in the next section for the meaning of each abbreviation.
Notes
• The contents of this manual apply to PBXs with a certain software version, as indicated on the
cover of this manual. To confirm the software version of your PBX, see How do I confirm the
software version of the PBX or installed cards? in the FAQ of the PC Programming Manual, or [190]
Main Processing (MPR) Software Version Reference in the PT Programming Manual.
• Some optional service cards, PTs, and features are not available in some areas. Please consult
your dealer for more information.
• Product specifications are subject to change without notice. In some cases, additional information,
including updates to this and other manuals, is included in the KX-TAW848 Maintenance Console's
Information Before Programming. Install the latest version of Maintenance Console to view this
information.
• All system programming can be performed through PC programming (→1.13.5 PC Programming).
However, only a subset can be performed through PT programming (→1.13.15 PT Programming).
Throughout this manual, programming references are included as follows:
PC Programming
The number within the brackets indicates the System Menu number for the Maintenance Console.
→2.12.1 [6-1] System Speed Dial—CO Line Access Number + Telephone Number
PT Programming
The number within the brackets indicates the programming number that is entered when
performing PT programming.
→[001] System Speed Dialing Number
For further details, please refer to the PC Programming Manual and PT Programming Manual.
WARNING
Unplug the PBX from the AC outlet if it emits smoke, an abnormal smell or makes
unusual noise. These conditions can cause fire or electric shock. Confirm that smoke
has stopped and contact an authorized Panasonic Factory Service Center.
Trademarks
• Microsoft, Windows, and Outlook are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Intel and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
• All other trademarks identified herein are the property of their respective owners.

4 Feature Manual
Feature Highlights
Voice Mail Features
A Voice Processing System (VPS) can be connected to the PBX to provide Voice Mail (VM) and Automated
Attendant (AA) services. A Panasonic VPS which supports DPT (Digital) Integration can be connected to
the PBX effortlessly and with minimal setup required. Conventional DTMF (analog) voice mail systems,
including those from other manufacturers, are also supported.
(→1.19.3 Voice Mail (VM) Group)
Paralleled Telephone Features
By connecting an SLT in parallel to an analog proprietary telephone (APT) that is connected to a Hybrid port
of the PBX, you can increase the number of telephones connected to the PBX without adding additional
extension cards. The SLT shares the same extension number with the APT.
(→1.13.2 Paralleled Telephone)
Portable Station (PS) Features
A Panasonic PS can be used in place of a PT to provide wireless access to PBX features and call handling.
When in Wireless XDP Parallel Mode, a PS can share an extension number with a wired telephone, allowing
extension users to use their PSs when they are away from their desks to answer or make calls as if they
were using their wired telephones.
Built-in Simplified Voice Message (SVM) Features
By just installing an optional voice message card in the PBX, simple answering machine services can be
provided. (→1.16.5 SVM (Simplified Voice Message))

Feature Manual 5
List of Abbreviations
A
AA →Automated Attendant
ANI →Automatic Number Identification
APT →Analog Proprietary Telephone
ARS →Automatic Route Selection
B
BGM →Background Music
C
CLI →Calling Line Identification
COS →Class of Service
CPC →Calling Party Control
CS →Cell Station
D
DIL →Direct In Line
DISA →Direct Inward System Access
DND →Do Not Disturb
DSS →Direct Station Selection
DTMF →Dual Tone Multi-Frequency
E
EFA →External Feature Access
F
FWD →Call Forwarding
G
G-CO →Group-CO
I
ICD →Incoming Call Distribution
IRNA →Intercept Routing—No Answer
L
L-CO →Loop-CO
LCS →Live Call Screening
LED →Light Emitting Diode
O
OGM →Outgoing Message

6 Feature Manual
P
PIN →Personal Identification Number
PS →Portable Station
PT →Proprietary Telephone
S
S-CO →Single-CO
SLT →Single Line Telephone
SMDR →Station Message Detail Recording
SVM →Simplified Voice Message
T
TA FA S →Trunk Answer from Any Station
TRG →Trunk Group
TRS →Toll Restriction
U
UCD →Uniform Call Distribution
V
VM →Voice Mail
VPS →Voice Processing System
X
XDP →EXtra Device Port

Feature Manual 7
Table of Contents
1 Features and Configurations............................................................... 11
1.1 A ...................................................................................................................................... 12
1.1.1 Absent Message .............................................................................................................. 12
1.1.2 Account Code Entry.........................................................................................................13
1.1.3 ARS (Automatic Route Selection).................................................................................... 14
1.1.4 Automatic Callback Busy (Camp-on) ............................................................................... 20
1.1.5 Automatic Extension Release .......................................................................................... 21
1.1.6 Automatic Fax Transfer .................................................................................................... 22
1.1.7 Automatic Time Adjustment ............................................................................................. 23
1.2 B ...................................................................................................................................... 25
1.2.1 BGM (Background Music)................................................................................................ 25
1.3 C ...................................................................................................................................... 26
1.3.1 Caller ID ........................................................................................................................... 26
1.3.2 Call Hold .......................................................................................................................... 29
1.3.3 Call Log, Incoming ........................................................................................................... 32
1.3.4 Call Monitor...................................................................................................................... 34
1.3.5 Call Park .......................................................................................................................... 36
1.3.6 Call Pickup ....................................................................................................................... 37
1.3.7 Call Splitting ..................................................................................................................... 39
1.3.8 Call Transfer ..................................................................................................................... 39
1.3.9 Call Waiting Tone ............................................................................................................. 41
1.3.10 CLI (Calling Line Identification) Distribution ..................................................................... 42
1.3.11 CO Line Access ............................................................................................................... 44
1.3.12 CO Line Call Limitation .................................................................................................... 46
1.3.13 Conference ...................................................................................................................... 47
1.3.14 Confirmation Tone............................................................................................................ 48
1.3.15 Consultation Hold............................................................................................................. 50
1.3.16 COS (Class of Service)....................................................................................................50
1.3.17 CPC (Calling Party Control) Signal Detection.................................................................. 51
1.4 D ...................................................................................................................................... 53
1.4.1 Data Line Security............................................................................................................ 53
1.4.2 Dial Mode Selection ......................................................................................................... 53
1.4.3 Dial Tone .......................................................................................................................... 54
1.4.4 Dial Tone Transfer ............................................................................................................ 55
1.4.5 DIL (Direct In Line)........................................................................................................... 57
1.4.6 DISA (Direct Inward System Access) .............................................................................. 58
1.4.7 Display Information .......................................................................................................... 67
1.4.8 DND (Do Not Disturb) ...................................................................................................... 68
1.4.9 Door Open ....................................................................................................................... 69
1.4.10 Doorphone Call................................................................................................................ 70
1.5 E....................................................................................................................................... 72
1.5.1 EFA (External Feature Access)........................................................................................ 72
1.5.2 Emergency Call................................................................................................................ 73
1.5.3 Executive Busy Override.................................................................................................. 73
1.5.4 Extension Dial Lock ......................................................................................................... 74
1.5.5 Extension Feature Clear .................................................................................................. 75
1.5.6 Extension PIN (Personal Identification Number).............................................................. 76

8 Feature Manual
1.5.7 Extension Port Configuration ...........................................................................................78
1.5.8 External Relay..................................................................................................................78
1.5.9 External Sensor ...............................................................................................................79
1.6 F .......................................................................................................................................82
1.6.1 Fixed Buttons ...................................................................................................................82
1.6.2 Flash/Recall/Terminate.....................................................................................................83
1.6.3 Flexible Buttons................................................................................................................84
1.6.4 Flexible Numbering/Fixed Numbering ..............................................................................87
1.6.5 Floating Extension............................................................................................................92
1.6.6 FWD (Call Forwarding).....................................................................................................93
1.6.7 FWD/DND Button, Group FWD Button ............................................................................97
1.7 G ....................................................................................................................................101
1.7.1 GROUP FEATURES ......................................................................................................101
1.8 H.....................................................................................................................................105
1.8.1 Hands-free Answerback .................................................................................................105
1.8.2 Hands-free Operation.....................................................................................................106
1.8.3 Headset Operation .........................................................................................................106
1.8.4 HOSPITALITY FEATURES ............................................................................................107
1.8.5
Host PBX Access Code (Access Code to the Telephone Company from a Host PBX) ........107
1.8.6 Hot Line..........................................................................................................................109
1.9 I ...................................................................................................................................... 111
1.9.1 ICD GROUP FEATURES ...............................................................................................111
1.9.2 ICD Group Features—Group Call Distribution ............................................................... 114
1.9.3 ICD Group Features—Log-in/Log-out ............................................................................117
1.9.4 ICD Group Features—Overflow .....................................................................................119
1.9.5 ICD Group Features—Queuing......................................................................................121
1.9.6 ICD Group Features—VIP Call ...................................................................................... 123
1.9.7 Idle Extension Hunting ...................................................................................................124
1.9.8 INCOMING CALL FEATURES .......................................................................................126
1.9.9 Intercept Routing............................................................................................................128
1.9.10 Intercept Routing—No Destination.................................................................................132
1.9.11 Intercom Call .................................................................................................................. 133
1.9.12 Internal Call Block ..........................................................................................................134
1.10 L ..................................................................................................................................... 136
1.10.1 LED Indication................................................................................................................136
1.10.2 Line Preference—Incoming............................................................................................138
1.10.3 Line Preference—Outgoing............................................................................................ 139
1.10.4 Local Alarm Information .................................................................................................139
1.11 M .................................................................................................................................... 142
1.11.1 Manager Features..........................................................................................................142
1.11.2 MEMORY DIALING FEATURES ....................................................................................143
1.11.3 Message Waiting............................................................................................................145
1.11.4 Music on Hold ................................................................................................................ 146
1.11.5 Mute ............................................................................................................................... 147
1.12 O .................................................................................................................................... 148
1.12.1 OGM (Outgoing Message) .............................................................................................148
1.12.2 One-touch Dialing ..........................................................................................................150
1.12.3 Operator Features ..........................................................................................................151
1.13 P..................................................................................................................................... 152
1.13.1 Paging ............................................................................................................................152

Feature Manual 9
1.13.2 Paralleled Telephone...................................................................................................... 154
1.13.3 Password Security ......................................................................................................... 155
1.13.4 Pause Insertion .............................................................................................................. 156
1.13.5 PC Programming ........................................................................................................... 157
1.13.6 Power Failure Restart .................................................................................................... 159
1.13.7 Power Failure Transfer ................................................................................................... 160
1.13.8 Predialing ....................................................................................................................... 160
1.13.9 Printing Message ........................................................................................................... 161
1.13.10 Privacy Release ............................................................................................................. 161
1.13.11 PS Connection ............................................................................................................... 162
1.13.12 PS Directory................................................................................................................... 164
1.13.13 PS Feature Buttons........................................................................................................ 165
1.13.14 PS Ring Group............................................................................................................... 165
1.13.15 PT Programming............................................................................................................ 169
1.14 Q .................................................................................................................................... 171
1.14.1 Quick Dialing.................................................................................................................. 171
1.14.2 Quick Setup ................................................................................................................... 172
1.15 R .................................................................................................................................... 173
1.15.1 Redial, Last Number ...................................................................................................... 173
1.15.2 Ring Tone Pattern Selection .......................................................................................... 173
1.16 S..................................................................................................................................... 176
1.16.1 SMDR (Station Message Detail Recording)................................................................... 176
1.16.2 Special Carrier Access Code ......................................................................................... 183
1.16.3 Speed Dialing, Personal................................................................................................. 183
1.16.4 Speed Dialing, System................................................................................................... 184
1.16.5 SVM (Simplified Voice Message)................................................................................... 185
1.17 T..................................................................................................................................... 192
1.17.1 TAFAS (Trunk Answer From Any Station) ...................................................................... 192
1.17.2 Tenant Service ............................................................................................................... 192
1.17.3 Timed Reminder ............................................................................................................ 196
1.17.4 Time Service .................................................................................................................. 198
1.17.5 TRS (Toll Restriction) ..................................................................................................... 202
1.18 U .................................................................................................................................... 210
1.18.1 Upgrading the Software ................................................................................................. 210
1.19 V..................................................................................................................................... 211
1.19.1 Verification Code Entry ..................................................................................................211
1.19.2 Virtual PS....................................................................................................................... 212
1.19.3 Voice Mail (VM) Group ................................................................................................... 213
1.19.4 Voice Mail DPT (Digital) Integration ............................................................................... 216
1.19.5 Voice Mail DTMF Integration.......................................................................................... 222
1.20 W.................................................................................................................................... 229
1.20.1 Walking COS.................................................................................................................. 229
1.20.2 Walking Extension.......................................................................................................... 230
1.20.3 Wireless XDP Parallel Mode .......................................................................................... 231
2 Appendix ............................................................................................. 235
2.1 Capacity of System Resources .................................................................................. 236
2.2 Tones/Ring Tones ........................................................................................................ 239
2.3 Revision History........................................................................................................... 241
2.3.1 PSMPR Software File Version 1.1xxx ............................................................................ 241
2.3.2 PSMPR Software File Version 2.0xxx ............................................................................ 241

10 Feature Manual
2.3.3 PSMPR Software File Version 3.0xxx ............................................................................242
2.3.4 PSMPR Software File Version 4.0xxx ............................................................................242
Index .......................................................................................................... 245

Feature Manual 11
Section 1
Features and Configurations

1.1 A
12 Feature Manual
1.1 A
1.1.1 Absent Message
Description
Extension users can prepare a brief text message (Absent Message) that will be displayed to other
extension users when they are called. These messages can explain the reason for their absence, and may
be edited through system programming and personal programming.
The following Absent Messages may be programmed:
Note
The "%" shown above indicates a parameter to be entered when assigning a message at an individual
extension.
Up to seven "%"s can be stored for each message.
Conditions
• An extension user can select only one Absent Message at a time. The selected message is displayed
at the extension while on-hook.
• The caller must use a display proprietary telephone (PT) to see the Absent Message.
Programming References
PC Programming Manual
2.8.8 [2-6-1] Numbering Plan—Main—Features—Absent Message Set / Cancel
2.10.1 [4-1-1] Wired Extension—Extension Settings—Option 3—Absent Message
2.10.8 [4-2-1] Portable Station—Extension Settings—Option 3—Absent Message
Type Message
No. Message (Example) Description
System
message
1Will Return Soon Messages may be edited through
system programming. They can be
used by any extension user.
2Gone Home
3At Ext %%%% (Extension
Number)
4Back at %%:%% (Hour:Minute)
5Out until %%/%% (Month/Day)
6In a Meeting
7
8
Personal
message
9 A message is programmable by each
extension through personal
programming (Personal Absent
Message), which can only be used by
that extension user.

1.1 A
Feature Manual 13
2.12.5 [6-5] Absent Message
PT Programming Manual
[008] Absent Message
Feature Manual References
2.1 Capacity of System Resources
Operating Manual References
1.3.1 Absent Message
3.1.2 Personal Programming
1.1.2 Account Code Entry
Description
An account code is used to identify outgoing CO line calls for accounting and billing purposes. The account
code is appended to the Station Message Detail Recording (SMDR) call record. For example, a firm can
use an account code for each client to determine which calls were made for which client, and can submit a
bill to the client according to the client's account code as shown on the SMDR call record.
There are two methods of entering account codes explained below.
One of the methods is selected for each extension based on Class of Service (COS) programming.
Conditions
• An account code can be stored in Memory Dialing (One-touch Dialing, for example).
•Account Button
A flexible button can be customized as the Account button. The Account button is used in place of the
feature number for entering an account code. This button is useful because it can be used at any time,
while feature number entry is allowed only when hearing a dial tone before seizing a CO line.
• Extension users can enter an account code at any time during a call, including after the call has been
disconnected and a reorder tone is heard. However, if an account code is entered after there is no
longer a reorder tone, the call will not be stored in the SMDR record.
• If an account code is entered more than once, the code entered last is logged in the SMDR.
• Even in Forced mode, emergency numbers can be dialed without an account code. (→1.5.2
Emergency Call)
• Proprietary telephone (PT) users can also enter an account code for incoming CO line calls during a
conversation.
•Verification Code Entry
To identify who made a CO line call for accounting and billing purposes, a verification code can be used.
This code can be used at any extension. (→1.19.1 Verification Code Entry)
Mode Description
Option An extension user can enter an account code, but is not required to.
Forced An extension user must always enter an account code before seizing
a CO line.

1.1 A
14 Feature Manual
Programming References
PC Programming Manual
2.8.8 [2-6-1] Numbering Plan—Main—Features—Account Code Entry
2.8.11 [2-7-1] Class of Service—COS Settings—CO & SMDR—Account Code Mode
PT Programming Manual
[508] Account Code Mode
Feature Manual References
1.3.16 COS (Class of Service)
1.6.3 Flexible Buttons
1.16.1 SMDR (Station Message Detail Recording)
Operating Manual References
1.2.1 Making Calls
1.1.3 ARS (Automatic Route Selection)
Description
Different telephone carriers charge different rates for calls placed to different areas. Your PBX may use
different telephone carriers to make calls to different areas in an effort to reduce costs.
Automatic Route Selection (ARS) is a feature which automatically selects different carriers each time a CO
line call is made. In order to use ARS effectively, various ARS-related tables must be preprogrammed to tell
the PBX which calls should be placed using which carriers, during which time of day.
If you do not activate ARS, if ARS is bypassed, or if you do not use multiple carriers, CO line calls will be
connected via the carrier contracted for each line (default carrier).

1.1 A
Feature Manual 15
[Carrier Selection Procedure Flowchart]
The numbers in parentheses indicate the corresponding items found under [Programming Procedures] on
the following pages.
[Programming Procedures]
1. ARS Mode
ARS is turned on by selecting under which circumstances it operates – either when an extension user
makes a call using the Idle Line Access method, or when any CO Line Access method is used. (→
1.3.11 CO Line Access). ARS can also be turned off for the entire system.
→2.14.1 [8-1] System Settings—ARS Mode
→[320] ARS Mode
2. Leading Number Exception Table
Once ARS is activated, store the telephone numbers that will bypass ARS in the Leading Number
Exception Table.
Note that the first few digits (leading number) of a telephone number, such as an area code or local
exchange, can also be stored, so that all calls to those areas or exchanges are exempted from ARS.
No
No (Normal CO Line Access)
No
No
Yes
Is the ARS mode (1) enabled?
An extension user accesses a CO
line and dials a telephone number.
Sends a
reorder tone.
Sends a
busy tone.
Checks the Routing Plan (4) to
determine which carrier to use.
Modifies the dialed number by
removing the digits and following
the modify commands (5).
Sends the modified number
to the CO line.
Yes
No
Is the carrier found in the
appropriate time block (4)?
Yes
Is the dialed number found in the
Leading Number Exception Table (2)?
No
Yes
(default)
Yes Is normal
CO Line Access
allowed?
Because all CO
lines are busy?
Yes
Is the dialed number found in
the Leading Number Table (3)?
No
Is there an available
trunk group (5)?
Yes
Sends the telephone
number by the Idle
Line Access.
Sends the telephone
number as dialed.

1.1 A
16 Feature Manual
Also note that the CO Line Access number is always ignored by ARS and does not need to be
programmed here.
Calls that are exempt from ARS are connected to the user-selected line, via the default carrier for that
line.
[Programming Example: ARS Leading Number Exception Table]
In this example:
555, 556, and 567 are local exchanges. (555-XXXX, 556-XXXX, 567-XXXX)
These calls can be made using any carrier, and are therefore exempt from ARS.
3. Leading Number Table
Next, store the leading numbers of telephone numbers that should be routed by ARS, and assign a
Routing Plan to each leading number that will control how calls containing these leading numbers are
routed.
When an extension user dials a number which contains a leading number stored in the ARS Leading
Number Table, the call will be routed the corresponding Routing Plan assigned here. Note that the CO
Line Access number is always ignored by ARS and does not need to be programmed here.
Before programming the details of each Routing Plan (explained below), you can simply assign here
the same Routing Plan number to all the different leading numbers which will be routed the same way.
If a dialed number matches two or more leading numbers stored in the ARS Leading Number Table, the
lowest numbered location will have priority.
[Programming Example: ARS Leading Number Table]
Additional Number of Digits
In order for calls to be made using the desired carrier, telephone numbers dialed by extension users
must be modified to meet the criteria required by the carrier. (Refer to 5. Carrier Table.) This
*1 →2.14.7 [8-6] Leading Number Exception
→[325] ARS Exception Number
*1 →2.14.2 [8-2] Leading Number—Leading Number
→[321] ARS Leading Number
*2 →2.14.2 [8-2] Leading Number—Additional Number of Digits
*3 →2.14.2 [8-2] Leading Number—Routing Plan Number
→[322] ARS Routing Plan Table Number
Location
No.
1
2
3
Leading No.
Exception *1
555
556
567
Location
No.
1
2
3
Leading
No.
*1
1212
01181
01144
Routing Plan
No.
*3
1
5
12
Additional
No. of Digits
*2
7
0
0

1.1 A
Feature Manual 17
modification usually involves removing digits and adding access codes to the beginning of the dialed
number.
In situations where a preprogrammed number (such as an Itemized Billing Code) must be added
automatically after the telephone number that was dialed by the extension user, set the Additional
Number of Digits to a value greater than 0.
4. Routing Plan
Since the preferred carrier may vary depending on the time of day, you can create an ARS-specific time
table and break each day of the week into different time blocks. A different carrier can then be assigned
to each time block.
Routing Plan Time Table: For each Routing Plan, a different carrier can be assigned for each time of
day and each day of the week. Each day can have up to four programmable time blocks.
Routing Plan Priority: For each Routing Plan, a different carrier can be assigned a different priority
for each time of day. Generally, the carrier assigned to priority 1 will be used, however, if the CO lines
assigned to this carrier are busy, a different available carrier will be used according to priority level.
5. Carrier Table
Each carrier must be programmed in the Carrier Table. Here each carrier is assigned a carrier number,
name, the CO lines it is used with, etc.
→2.14.6 [8-5] Carrier—Carrier
Carrier Name: Assign a name for the carrier. Used only as a reference.
Trunk Group: Assign the trunk groups which can be used when making calls via this carrier.
Carrier Access Code: Enter the carrier's access code. Consult carrier for details.
Removed Number of Digits: There may be circumstances where the user-dialed number must be
modified in order for the carrier to connect the call. In this case, enter here the number of digits to be
removed automatically from the beginning of the dialed number.
*1 →2.14.4 [8-3] Routing Plan Time—Time Setting
→[330] ARS Routing Plan Time Table
*2 →2.14.5 [8-4] Routing Plan Priority
→[331–346] ARS Routing Plan Table (1–16)
ARS Leading Number Table
ARS Routing Plan No. 1
1
2
3
Location
No.
1212
01181
01144
Leading
No.
7
0
0
1
5
12
Additional No.
of Digits
Routing Plan
No.
Monday
Time Table
*1
Carrier
*2
Time Block A
Time Block B
Time Block C
Time Block D
Priority 1
Carrier A
Carrier A
Carrier C
Carrier J
Priority 2
Carrier M
Carrier M
Carrier M
Carrier M
9:00
12:00
17:00
23:00

1.1 A
18 Feature Manual
Modify Command: When a call is made using this carrier, the telephone number must be modified to
meet the criteria required by the carrier in order to connect the call. Program here the commands
needed to modify the user-dialed number as necessary.
[Command Explanation]
[Programming Example: Carrier Table]
*1 →2.14.6 [8-5] Carrier—Carrier—Carrier Name
→[350] ARS Carrier Name
*2 →2.14.6 [8-5] Carrier—TRG 01–TRG 64
→[351] ARS Trunk Group for Carrier Access
*3 →2.14.6 [8-5] Carrier—Carrier—Carrier Access Code
→[353] ARS Carrier Access Code
*4 →2.14.6 [8-5] Carrier—Carrier—Removed Number of Digits
→[352] ARS Removed Number of Digits for Carrier Access
*5 →2.14.6 [8-5] Carrier—Carrier—Modify Command
Command Description
Inserts the Carrier Access Code
Inserts the user-dialed number minus any removed digits
Inserts a pause
Inserts the Authorization Code for Tenant
Inserts the Authorization Code for Trunk Group
Inserts the Itemized Billing Code
You can enter any of these digits in a modify command
C
H
P
A
G
I
[0-9, , #]
In this example
Dialed number: 9-1-212-555-5555
Modification:
9 1 2125555555 0880 2125555555
Remove 1 digit Add the Carrier Access Code
CO Line Access no. is ignored
Carrier A
1, 2, 3
0880
1
CH
Carrier Name
*1
Trunk Group
*2
Carrier Access Code
*3
Removed No. of Digits
*4
Modify Command
*5
Carrier J
4
0700
3
CPH
Carrier 1Carrier 2

1.1 A
Feature Manual 19
6. ARS Options
Authorization Code for Tenant
A Carrier Authorization Code can be assigned to each tenant.
→2.14.6 [8-5] Carrier—Authorization Code for Tenant
Authorization Code for Trunk Group
A Carrier Authorization Code can be assigned to each trunk group.
→2.14.8 [8-7] Authorization Code for TRG
Itemized Billing Code
An Itemized Billing Code can be assigned for each extension and for each verification code.
If a call is not made from an extension, such as via Direct Inward System Access (DISA), and no
verification code is used, the Itemized Billing Code assigned to location 1 in the Verification Code Table
will be used.
→2.10.1 [4-1-1] Wired Extension—Extension Settings—Option 2—ARS Itemized Code
→2.10.8 [4-2-1] Portable Station—Extension Settings—Option 2—ARS Itemized Code
→2.12.3 [6-3] Verification Code—Itemized Billing Code for ARS
Conditions
WARNING
The software contained in the ARS feature to allow user access to the network must be upgraded to
recognize newly established network area codes and exchange codes as they are placed into
service.
Failure to upgrade the premises PBXs or peripheral equipment to recognize the new codes as they
are established will restrict the customer and the customer's employees from gaining access to the
network and to these codes.
KEEP THE SOFTWARE UP-TO-DATE WITH THE LATEST DATA.
•Logging Outgoing Calls by SMDR
Whether SMDR logs the user-dialed number or the ARS-modified number is determined through
system programming. (→1.16.1 SMDR (Station Message Detail Recording))
→2.16.1 [10-1] Main—SMDR—SMDR Options—ARS Dial
•ARS Data Import/Export
ARS tables and data can be copied to and from the PBX and a PC using the KX-TAW848 Maintenance
Console software. Files are saved in CSV (Comma Separated Value) format. Because of the large
amounts of programming that may be necessary to use ARS effectively, you may choose to export ARS
tables and data to a PC, edit them using the software of your choosing, then import the new data to the
PBX. This is particularly convenient if you need to update your ARS tables for new area codes or
telephone rates, or when you'd like to copy ARS tables from one PBX to another.
→2.4.5 Tool—Import
→2.4.6 Tool—Export
•TRS
Toll Restriction (TRS) checks are performed before ARS number modification, so program TRS Denied
Code Tables and Exception Code Tables accordingly. (→1.17.5 TRS (Toll Restriction))
•When ARS Routing Takes Place
ARS routing takes place after the preprogrammed number of digits (leading number + additional
number of digits) have been dialed.
Programming References
PC Programming Manual

1.1 A
20 Feature Manual
2.4.5 Tool—Import
→ARS - Leading Digit
→ARS - Except Code
→ARS - Routing Plan
2.4.6 Tool—Export
2.8.4 [2-3] Timers & Counters—Dial / IRNA / Recall / Tone—Dial—Extension Inter-digit
2.8.17 [2-9] System Options—Option 3—Dial Tone—Dial Tone for ARS
2.10.1 [4-1-1] Wired Extension—Extension Settings—Option 2—ARS Itemized Code
2.10.8 [4-2-1] Portable Station—Extension Settings—Option 2—ARS Itemized Code
2.12.3 [6-3] Verification Code—Itemized Billing Code for ARS
2.14 [8] ARS
2.16.1 [10-1] Main—SMDR—SMDR Options—ARS Dial
PT Programming Manual
[320] ARS Mode
[321] ARS Leading Number
[322] ARS Routing Plan Table Number
[325] ARS Exception Number
[330] ARS Routing Plan Time Table
[331–346] ARS Routing Plan Table (1–16)
[350] ARS Carrier Name
[351] ARS Trunk Group for Carrier Access
[352] ARS Removed Number of Digits for Carrier Access
[353] ARS Carrier Access Code
Feature Manual References
2.1 Capacity of System Resources
1.1.4 Automatic Callback Busy (Camp-on)
Description
If the line is busy when a call is made, a callback ring can inform the caller when the line becomes free.
If the called party was another extension, or if the dialed number is handled by Automatic Route Selection
(ARS), the number is automatically redialed after the extension user answers the callback ring.
Conditions
• If the callback ring is not answered within 10 seconds, callback is canceled.
• If the extension hears a busy tone before dialing the telephone number, only the CO line or trunk group
is reserved. After answering the callback ring, the extension should dial the telephone number.
• An extension can set only one Automatic Callback Busy. The last setting is effective.
• Multiple extension users can set this feature for the same CO line at the same time.
However, a maximum of four extension users can set this feature to one extension.
Callback ringing will be sent to extensions in the order that the feature was set. In other words, the
extension that set the feature first will receive a callback ringing first.
