Panasonic KX-TDA150 User manual

Model No. KX-TDA150
Hybrid IP-PBX
Installation Manual
Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA150: PDMPR Software File Version 5.1000 or later SD Logo is
a trademark of
SD-3C, LLC.

System Components
System Components Table
Category Model No. Description
Shelf KX-TDA150 Basic Shelf
Main Processing Card Main Processing Card (DMPR)
DMPR Option Card KX-TDA0196 Remote Card (RMT)
Trunk Cards KX-TDA0180 8-Port Analogue Trunk Card (LCOT8)
KX-TDA0181 16-Port Analogue Trunk Card (LCOT16)
KX-TDA0182 8-Port DID Card (DID8)
KX-TDA0183 4-Port Analogue Trunk Card (LCOT4)
KX-TDA0184 8-Port E & M Trunk Card (E&M8)
KX-TDA0187 T-1 Trunk Card (T1)
KX-TDA0188 E-1 Trunk Card (E1)
KX-TDA0189 8-Port Caller ID/Pay Tone Card (CID/PAY8)
KX-TDA0193 8-Port Caller ID Card (CID8)
KX-TDA0284 4-Port BRI Card (BRI4)
KX-TDA0288 8-Port BRI Card (BRI8)
KX-TDA0290CE/
CJ
PRI Card (PRI30)
KX-TDA0290 PRI Card (PRI23)
KX-TDA0484 4-Channel VoIP Gateway Card (IP-GW4E)
KX-TDA0490 16-Channel VoIP Gateway Card (IP-GW16)
KX-TDA1180 8-Port Analogue Trunk Card with CID (CLCOT8)
KX-TDA1186 8-Port Analogue Trunk with Caller ID Daughter Card
(CLCOT8E)
Extension Cards KX-TDA0143 4 Cell Station Interface Card (CSIF4)
KX-TDA0144 8 Cell Station Interface Card (CSIF8)
KX-TDA0171 8-Port Digital Extension Card (DLC8)
KX-TDA0172 16-Port Digital Extension Card (DLC16)
KX-TDA0470 16-Channel VoIP Extension Card (IP-EXT16)
KX-TDA1176 16-Port Single Line Telephone Extension with Caller
ID and Message Lamp Card (MCSLC16)
KX-TDA1178 24-Port Single Line Telephone Extension with Caller
ID and Message Lamp Card (MCSLC24)
2 Installation Manual
System Components

Category Model No. Description
Other Cards KX-TDA0161 4-Port Doorphone Card (DPH4)
KX-TDA0162 2-Port Doorphone Card (German Type) (DPH2)
KX-TDA0164 4-Port External Input/Output Card (EIO4)
KX-TDA0166 16-Channel Echo Canceller Card (ECHO16)
KX-TDA0190 Optional 3-Slot Base Card (OPB3)
KX-TDA0191 4-Channel Message Card (MSG4)
KX-TDA0192 2-Channel Simplified Voice Message Card (ESVM2)
KX-TDA0194 4-Channel Simplified Voice Message Card (ESVM4)
KX-TDA0410 CTI Link Card (CTI-LINK)
Optional SD Memory
Card
KX-TDA0920 SD Memory Card for Software Upgrade to Enhanced
Version
Cell Stations
(CSs)
2.4 GHz KX-TDA0151CN 2-Channel Cell Station Unit Using a DLC Card
(PT-interface CS) for 2.4 GHz Portable Station
DECT KX-TDA0155CE 2-Channel Cell Station Unit Using a DLC Card
(PT-interface CS) for DECT Portable Station
KX-TDA0156CE 4-Channel Cell Station Unit Using a CSIF Card for
DECT Portable Station
KX-TDA0158CE 8-Channel High-density Cell Station Unit Using a
DLC Card (PT-interface CS) for DECT Portable
Station
Proprietary Equipment KX-A228 Back-up Battery Cable
KX-A258 Blank Slot Cover
KX-T30865 Doorphone
KX-T7765
Equipment Compatibility
Compatible Panasonic Proprietary Telephones
The PBX supports the following telephones:
•Digital proprietary telephones (e.g., KX-DT300 series)
•IP proprietary telephones (e.g., KX-NT300 series)
•Portable stations (e.g., KX-TCA355, KX-TCA256)
•DSS consoles (e.g., KX-DT390)
•Single line telephones (e.g., KX-T7710)
Incompatible Panasonic Proprietary Telephones
The PBX does not support the following telephones:
•KX-T7400 series digital proprietary telephones
•KX-T7500 series digital proprietary telephones
•Analogue proprietary telephones (e.g., KX-T7700 series)
•KX-T30800 series proprietary telephones and DSS consoles
Installation Manual 3
System Components

•KX-T61600 series proprietary telephones and DSS consoles
•KX-T123200 series proprietary telephones and DSS consoles
•KX-TD7500 DECT portable station
Note
•For the equipment (e.g., Add-on Key Module, USB Module, Headset) that can be connected to a
particular telephone, refer to the telephone’s manual.
•For other equipment that can be connected to the PBX, refer to "1.1.2 System Connection Diagram".
Notice
•Under power failure conditions, the connected telephones may not operate. Please ensure that a separate
telephone, not dependent on local power, is available for emergency use.
•Prior to connection of this product, please verify that the intended operating environment is supported.
Satisfactory performance cannot be guaranteed for the following:
–interoperability and compatibility with all devices and systems connected to this product
–proper operation and compatibility with services provided by telecommunications companies over
connected networks
Note
•Some optional hardware, software, and features are not available in some countries/areas. Please
consult your certified Panasonic dealer for more information.
•In this manual, the suffix of each model number (e.g., KX-TDA150BR) is omitted unless necessary.
Safety Notices
Please observe the safety notices in this manual in order to avoid danger to users or other people, and prevent
damage to property.
The notices are classified as follows, according to the severity of injury or damage:
WARNING This notice means that misuse could result in death or serious injury.
CAUTION This notice means that misuse could result in injury or damage to
property.
List of Abbreviations
•DPT ® Digital proprietary telephone
•IP-PT ® IP proprietary telephone
•PS ® Portable station
•PT ® Proprietary telephone
•SLT ® Single line telephone
4 Installation Manual
System Components

Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk
of fire, electric shock and injury to persons, including the following:
•Do not use the product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming pool.
•Avoid using wired telephones during an electrical storm. There is a remote risk of electric shock from
lightning.
•Do not use a telephone in the vicinity of a gas leak to report the leak.
SAVE THESE INSTRUCTIONS
Installation Manual 5
Important Safety Instructions

Important Information
SAVE THESE INSTRUCTIONS
WARNING
SAFETY REQUIREMENTS
For All Telephone Equipment
•Do not install the product in any other way than described in relevant manuals.
•The product must only be installed and serviced by qualified service personnel. The product should be
used as-is from the time of purchase; it should not be disassembled or modified. Disassembly or
modification can cause a fire, electric shock, or damage to the product.
•Do not install the product in a place exposed to rain or moisture, or a place where water, oil, or other liquids
can drip or splash onto on the product. Such conditions can lead to fire or electric shock, and may impair
the performance of the product.
•Follow all warnings and instructions marked on the product.
•Do not place the product on an unstable or uneven surface. If the product were to fall over, it may cause
injury or damage to the product.
•Products that require a power source should only be connected to the type of electrical power supply
specified on the product label. If you are not sure of the type of power supply to your home, consult your
dealer or local power company.
•For safety purposes some products are equipped with an earthed plug. If you do not have an earthed outlet,
please have one installed. Do not bypass this safety feature by tampering with the plug.
•Do not supply power to a combination of devices that exceeds the total rated capacity of the wall outlets
or extension cables used. If outlets, power strips, extension cords, etc. are used in a manner that exceeds
their rated capacity, they emit large amounts of heat, which could cause a fire.
•Unplug the product from the wall outlet and have it serviced by qualified service personnel in the following
cases:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate according to the operating instructions. Adjust only the controls that are
explained in the operating instructions. Improper adjustment of other controls may result in damage
and may require service by a qualified technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If product performance deteriorates.
For the PBX
•If damage to the unit exposes any internal parts, disconnect the power supply cord immediately and return
the unit to your dealer.
•To prevent fires, electric shock, injury, or damage to the product, be sure to follow these guidelines when
performing any wiring or cabling:
a. Before performing any wiring or cabling, unplug the product’s power cord from the outlet. After
completing all wiring and cabling, plug the power cord back into the outlet.
b. When laying cables, do not bundle the product’s power cord with the power cords of other devices.
c. Do not place any objects on top of the cables connected to the PBX.
d. When running cables along the floor, use protectors to prevent the cables from being stepped on.
e. Do not run any cables under carpeting.
6 Installation Manual
Important Information

•Unplug this unit from the AC outlet if it emits smoke, an abnormal smell or makes unusual noise. These
conditions can cause fire or electric shock. Confirm that smoke has stopped and contact an authorised
Panasonic Factory Service Centre.
•Danger of explosion exists if a battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the battery manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
•Make sure that the wall that the shelf will be attached to is strong enough to support the shelf. If not, it is
necessary for the wall to be reinforced.
•Only use the wall-mounting equipment (anchor plugs, screws, metal bracket) included with the PBX.
•Do not insert objects of any kind into this product, as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock.
CAUTION
SAFETY REQUIREMENTS
For All Telephone Equipment
•The product should be kept free of dust, moisture, high temperature (more than 40 °C) and vibration, and
should not be exposed to direct sunlight.
•Unplug the product from the wall outlet before cleaning. Wipe the product with a soft cloth. Do not clean
with abrasive powders or with chemical agents such as benzene or thinner. Do not use liquid cleaners or
aerosol cleaners.
For the PBX
•Before touching the product (PBX, cards, etc.), discharge static electricity by touching ground or wearing
an earthing strap. Failure to do so may cause the PBX to malfunction due to static electricity.
•When driving the screws into the wall, be careful to avoid touching any metal laths, wire laths or metal
plates in the wall.
•When relocating the equipment, first disconnect the telecom connection before disconnecting the power
connection. When the unit is installed in the new location, reconnect the power first, and then reconnect
the telecom connection.
•The power supply cord is used as the main disconnect device. Ensure that the AC outlet is located near
the equipment and is easily accessible.
•The SD Memory Card poses a choking hazard. Keep the SD Memory Card out of reach of children.
•Slots and openings in the front, back and bottom of the cabinet are provided for ventilation; to protect it
from overheating, these openings must not be blocked or covered. The openings should never be blocked
by placing the product on a bed, sofa, rug, or other similar surface while in use. The product should never
be placed near or over a radiator or other heat source. This product should not be placed in a sealed
environment unless proper ventilation is provided.
•When this product is no longer in use, make sure to detach it from the wall.
SECURITY REQUIREMENTS
In order to use the PBX safely and correctly, the Security Requirements below must be observed. Failure to
do so may result in:
•Loss, leakage, falsification or theft of user information.
•Illegal use of the PBX by a third party.
•Interference or suspension of service caused by a third party.
What is User Information?
User Information is defined as:
1. Information stored on the SD Memory Card
Installation Manual 7
Important Information

Phonebook data, user IDs, system settings data, passwords (User/Administrator/Installer), Personal
Identification Numbers (PINs), etc.
2. Information sent from the PBX to a PC or other external device:
Phone call data (including telephone numbers of outside parties), call charge data, etc.
Requirements
1. The SD Memory Card contains software for all the processes of the PBX and all customer data. It can be
easily removed and taken away from the PBX by a third party. Therefore, do not allow unauthorised access
to prevent data leakage.
2. Always make backups of data stored on the SD Memory Card. For details, refer to "2.6.2 Utility—File
Transfer PC to PBX (SD Card)" and "2.6.3 Utility—File Transfer PBX (SD Card) to PC" in the PC
Programming Manual.
3. To prevent illegal access from the Internet, activate a Firewall.
4. To avoid unauthorised access and possible abuse of the PBX, we strongly recommend:
a. Keeping the password secret.
b. Selecting a complex, random password that cannot be easily guessed.
c. Changing your password regularly.
5. Perform the following when sending the PBX for repair or handing it over to a third party.
a. Make a backup of data stored on the SD Memory Card.
b. Using an SD formatter, format the SD Memory Card so that information cannot be retrieved from it.
6. To prevent data leakage, render the SD Memory Card physically unusable before disposal.
7. When user information is sent from the PBX to a PC or other external device, the confidentiality of that
information becomes the responsibility of the customer. Before disposing of the PC or other external device,
ensure that data cannot be retrieved from it by formatting the hard disk and/or rendering it physically
unusable.
Notice
SAFETY REQUIREMENTS
For All Telephone Equipment
•Read and understand all instructions.
For the PBX
•When placing the metal bracket, make sure that the "TOP" arrow is pointing upward.
•Keep the unit away from heating appliances and devices that generate electrical noise such as fluorescent
lamps, motors and televisions. These noise sources can interfere with the performance of the PBX.
•If you are having problems making calls to outside destinations, follow this procedure to test the trunks:
a. Disconnect the PBX from all trunks.
b. Connect known working SLTs to those trunks.
c. Make a call to an external destination using those SLTs.
If a call cannot be carried out correctly, there may be a problem with the trunk that the SLT is connected
to. Contact your telephone company.
If all SLTs operate properly, there may be a problem with your PBX. Do not reconnect the PBX to the trunks
until it has been serviced by an authorised Panasonic Factory Service Centre.
8 Installation Manual
Important Information

Precaution
For users in the United Kingdom
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three-pin mains plug for your safety and convenience. A 5 amp fuse
is fitted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating
of 5 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from your local Panasonic dealer.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE AC OUTLET IN YOUR PREMISES, THEN THE
FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY. THERE IS A
DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT-OFF PLUG IS INSERTED INTO ANY 13 AMP
SOCKET.
If a new plug is to be fitted, please observe the wiring code as shown below. If in any doubt, please consult a
qualified electrician.
WARNING
This appliance must be earthed.
IMPORTANT: The wires in the mains lead are coloured as follows:
Green-and-yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows.
The wire that is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug that is marked
with the letter E or by the safety earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire that is coloured BLUE must be connected to the terminal that is marked with the letter N or coloured
BLACK.
The wire that is coloured BROWN must be connected to the terminal that is marked with the letter L or coloured
RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse and fuse cover.
The equipment must be connected to direct extension lines, and a payphone should not be connected as an
extension.
999 and 112 can be dialled on the apparatus after accessing the Exchange line for the purpose of making
outgoing calls to the BT emergency services.
Installation Manual 9
Precaution

During dialling, this apparatus may tinkle the bells of other telephones using the same line. This is not a fault
and we advise you not to call the Fault Repair Service.
For users in the European Union only
Information for Users on Collection and Disposal of Old Equipment and used Batteries
These symbols on the products, packaging, and/or accompanying documents mean that
used electrical and electronic products and batteries should not be mixed with general
household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take
them to applicable collection points, in accordance with your national legislation and the
Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable
resources and prevent any potential negative effects on human health and the environment
which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please
contact your local municipality, your waste disposal service or the point of sale where you
purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or
supplier for further information.
Information on Disposal in other Countries outside the European Union
These symbols are only valid in the European Union. If you wish to discard these items,
please contact your local authorities or dealer and ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it complies
with the requirement set by the Directive for the chemical involved.
For users in Germany only
•Machine Noise Information Ordinance, 3rd GPSGV: The highest sound pressure level is 70 dB (A) or less
according to EN ISO 7779.
•This equipment is not for use at video display work stations according to BildscharbV.
For users in Finland, Norway and Sweden only
•This equipment is intended for installation in restricted access locations where only authorised personnel
may gain access through the use of a special tool, lock and key or other means of security.
For users in Taiwan only
•Lithium batteries can be found in the circuit boards of the main board and optional cards of the PBX.
Notice
Regarding removing or replacing a battery in the circuit board, consult your dealer.
10 Installation Manual
Precaution

Note
•When disposing of any of the above products, all batteries must be removed. Follow the applicable
laws, regulations, and guidelines in your country/area regarding disposal of batteries.
•When replacing a battery, use only the same battery type, or an equivalent recommended by the battery
manufacturer.
Installation Manual 11
Precaution

Introduction
This Installation Manual is designed to serve as an overall technical reference for the Panasonic Hybrid
IP-PBX, KX-TDA150. It provides instructions for installing the hardware, and programming the PBX using the
Maintenance Console.
The Structure of this Manual
This manual contains the following sections:
Section 1 System Outline
Provides general information on the PBX, including the system capacity and specifications.
Section 2 Installation
Describes the procedures to install the PBX. Detailed instructions for planning the installation site, installing
the optional service cards, and cabling of peripheral equipment are provided. Further information on system
expansion and peripheral equipment installation is included.
Section 3 Guide for the Maintenance Console
Explains the installation procedure, structure, and basic information of the Maintenance Console.
Section 4 Troubleshooting
Provides information on the PBX and telephone troubleshooting.
About the Other Manuals
Along with this Installation Manual, the following manuals are available:
Feature Guide
Describes all basic, optional and programmable features of the PBX.
PC Programming Manual
Provides step-by-step instructions for performing system programming using a PC.
PT Programming Manual
Provides step-by-step instructions for performing system programming using a PT.
User Manual
Provides operating instructions for end users using a PT, SLT, PS, or DSS Console.
About the software version of your PBX
The contents of this manual apply to PBXs with a certain software version, as indicated on the cover of this
manual. To confirm the software version of your PBX, see "How do I confirm the software version of the PBX
or installed cards?" in 2.7.1 Frequently Asked Questions (FAQ) of the PC Programming Manual, or "[190]
Main Processing (MPR) Software Version Reference" in the PT Programming Manual.
Trademarks
•The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
Panasonic Corporation is under licence.
•Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
•Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
12 Installation Manual
Introduction

Table of Contents
1 System Outline .......................................................................................15
1.1 Basic System Construction ...........................................................................................16
1.1.1 Basic Shelf .....................................................................................................................16
1.1.2 System Connection Diagram ..........................................................................................17
1.2 Optional Equipment ........................................................................................................19
1.2.1 Optional Equipment ........................................................................................................19
1.3 Specifications ..................................................................................................................22
1.3.1 General Description ........................................................................................................22
1.3.2 Characteristics ................................................................................................................24
1.3.3 System Capacity ............................................................................................................25
2 Installation ..............................................................................................31
2.1 Before Installation ...........................................................................................................32
2.1.1 Before Installation ...........................................................................................................32
2.2 Installation of the PBX ....................................................................................................34
2.2.1 Unpacking ......................................................................................................................34
2.2.2 Names and Locations .....................................................................................................35
2.2.3 Opening/Closing the Front Cover ...................................................................................37
2.2.4 Frame Earth Connection ................................................................................................39
2.2.5 Backup Battery Connection ............................................................................................40
2.2.6 Installing/Removing the Optional Service Cards ............................................................42
2.2.7 Types of Connectors ......................................................................................................47
2.2.8 Attaching a Ferrite Core .................................................................................................49
2.2.9 Fastening Amphenol Connector .....................................................................................53
2.2.10 Wall Mounting .................................................................................................................55
2.2.11 Surge Protector Installation ............................................................................................57
2.3 Information about the Main Processing Card ..............................................................60
2.3.1 DMPR Card ....................................................................................................................60
2.3.2 RMT Card (KX-TDA0196) ..............................................................................................62
2.4 Information about the Trunk Cards ...............................................................................63
2.4.1 LCOT4 Card (KX-TDA0183), LCOT8 Card (KX-TDA0180), LCOT16 Card (KX-TDA0181),
and CLCOT8 Card (KX-TDA1180) .................................................................................63
2.4.2 DID8 Card (KX-TDA0182) ..............................................................................................65
2.4.3 CID/PAY8 Card (KX-TDA0189) ......................................................................................67
2.4.4 CID8 Card (KX-TDA0193) ..............................................................................................68
2.4.5 CLCOT8E Card (KX-TDA1186) .....................................................................................69
2.4.6 E&M8 Card (KX-TDA0184) ............................................................................................70
2.4.7 T1 Card (KX-TDA0187) ..................................................................................................72
2.4.8 E1 Card (KX-TDA0188) ..................................................................................................75
2.4.9 BRI4 Card (KX-TDA0284) and BRI8 Card (KX-TDA0288) .............................................78
2.4.10 PRI30 Card (KX-TDA0290CE/KX-TDA0290CJ) ............................................................82
2.4.11 PRI23 Card (KX-TDA0290) ............................................................................................85
2.4.12 IP-GW4E Card (KX-TDA0484) .......................................................................................88
2.4.13 IP-GW16 Card (KX-TDA0490) .......................................................................................90
2.5 Information about the Extension Cards ........................................................................92
2.5.1 CSIF4 Card (KX-TDA0143) and CSIF8 Card (KX-TDA0144) ........................................92
2.5.2 DLC8 Card (KX-TDA0171) .............................................................................................94
2.5.3 DLC16 Card (KX-TDA0172) ...........................................................................................96
2.5.4 MCSLC16 Card (KX-TDA1176) and MCSLC24 Card (KX-TDA1178) ...........................98
2.5.5 IP-EXT16 Card (KX-TDA0470) ....................................................................................101
2.6 Information about the Other Cards .............................................................................103
2.6.1 OPB3 Card (KX-TDA0190) ..........................................................................................103
Installation Manual 13
Table of Contents

2.6.2 DPH4 Card (KX-TDA0161) ..........................................................................................104
2.6.3 DPH2 Card (KX-TDA0162) ..........................................................................................106
2.6.4 EIO4 Card (KX-TDA0164) ............................................................................................109
2.6.5 ECHO16 Card (KX-TDA0166) ......................................................................................112
2.6.6 MSG4 Card (KX-TDA0191) ..........................................................................................113
2.6.7 ESVM2 Card (KX-TDA0192) and ESVM4 Card (KX-TDA0194) ..................................114
2.6.8 CTI-LINK Card (KX-TDA0410) .....................................................................................115
2.7 Connection of Extensions ............................................................................................117
2.7.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) ........................117
2.7.2 Digital EXtra Device Port (Digital XDP) Connection .....................................................119
2.7.3 First Party Call Control CTI Connection .......................................................................121
2.8 Connection of Doorphones, Door Openers, External Sensors, and External
Relays .............................................................................................................................122
2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External
Relays ..........................................................................................................................122
2.9 Connection of Peripherals ...........................................................................................125
2.9.1 Connection of Peripherals ............................................................................................125
2.10 Power Failure Connections ..........................................................................................130
2.10.1 Power Failure Connections ..........................................................................................130
2.11 Starting the PBX ............................................................................................................134
2.11.1 Starting the PBX ...........................................................................................................134
3 Guide for the Maintenance Console ...................................................137
3.1 Overview ........................................................................................................................138
3.1.1 Overview ......................................................................................................................138
3.2 PC Connection ..............................................................................................................139
3.2.1 PC Connection .............................................................................................................139
3.3 Installation of the Maintenance Console ....................................................................141
3.3.1 Installing and Starting the Maintenance Console .........................................................141
4 Troubleshooting ...................................................................................145
4.1 Troubleshooting ............................................................................................................146
4.1.1 Installation ....................................................................................................................146
4.1.2 Connection ...................................................................................................................147
4.1.3 Operation ......................................................................................................................149
4.1.4 Using the Reset Button ................................................................................................150
4.1.5 Troubleshooting by Error Log .......................................................................................151
Index............................................................................................................153
14 Installation Manual
Table of Contents

Section 1
System Outline
This section provides general information on the PBX,
including the system capacity and specifications.
Installation Manual 15

1.1 Basic System Construction
1.1.1 Basic Shelf
The basic shelf contains a power supply unit (PSU) and a DMPR card for starting and controlling the PBX. To
use the system, install optional service cards in the basic shelf.
Construction of the Basic Shelf
A. PSU
B. Slots for Expansion
C. DMPR Card
C
BA
16 Installation Manual
1.1.1 Basic Shelf

1.1.2 System Connection Diagram
Doorphone & Door Opener
BGM/Music On Hold (MOH)
Pager/
Speaker
Batteries
Voice Processing
System
KX-T7636/
KX-T7633
Remote PC
PC
Printer
Trunk (Telephone Company Lines)
Analogue/BRI/PRI/T1/E1
PBX
SLT
CSPS
Wireless Phone
Fax Machine
PC
USB
DPT
ISDN Telephone
Amplifier
SLT
DPT
DSS Console
KX-T7600 KX-T7600
External Sensor/
External Relay Device
Router
Private
IP Network
PC
IP Softphone
CTI Server
PC
PC
IP-PT
PC
USB
KX-DT346/
KX-DT343
KX-DT300 KX-DT300
Installation Manual 17
1.1.2 System Connection Diagram

External Sensor/External Relay Device
PC
KX-DT346/KX-DT343/
KX-T7636/KX-T7633
DSS Console
Doorphone & Door Opener
PT-interface CS PS
Private
IP Network
Router
ISDN BRI Line
ISDN BRI Line
(Digital Trunk)
(Digital Trunk)
ISDN BRI Line
(Digital Trunk)
Station Message
Detail Recording (SMDR)
Analogue
Analogue
Trunk
Trunk
Analogue
Trunk
SLT Wireless Phone Fax Machine
PC Mountable Equipment
DPT
Radio
Amplifier Pager/Speaker
LCOT16
(KX-TDA0181)
LCOT8
(KX-TDA0180)
DLC16
(KX-TDA0172)
DLC8
(KX-TDA0171)
IP-GW4E
(KX-TDA0484)
IP-GW16
(KX-TDA0490)
ISDN PRI Line
ISDN PRI Line
(Digital Trunk)
(Digital Trunk)
ISDN PRI Line
(Digital Trunk)
PRI30
(KX-TDA0290
CE/KX-TDA0290
CJ)
PRI23
(KX-TDA0290)
BRI4
(KX-TDA0284)
BRI8
(KX-TDA0288)
T1 Line
T1 Line
(Digital Trunk)
(Digital Trunk)
T1 Line
(Digital Trunk)
E1 Line
E1 Line
(Digital Trunk)
(Digital Trunk)
E1 Line
(Digital Trunk)
E1
(KX-TDA0188)
T1
(KX-TDA0187)
E & M Line
E & M Line
E & M Line
E&M8
(KX-TDA0184)
DID8
(KX-TDA0182)
PSU
(Installed by
default)
LCOT4
(KX-TDA0183)
OPB3
(KX-TDA0190)
DPH4
(KX-TDA0161)
DPH2
(KX-TDA0162)
ECHO16
(KX-TDA0166)
MSG4
(KX-TDA0191)
ESVM2
(KX-TDA0192)
ESVM4
(KX-TDA0194)
EIO4
(KX-TDA0164)
Voice
Processing
System
CS PS
CSIF4
(KX-TDA0143)
CSIF8
(KX-TDA0144)
PC
LAN
CTI Server
CTI-LINK
(KX-TDA0410)
IP-EXT16
(KX-TDA0470)
IP-PTIP Softphone
LAN
KX-DT300/
KX-T7600 KX-DT300/ KX-T7600
LCOT4
(KX-TDA0183)
LCOT16
(KX-TDA0181)
LCOT8
(KX-TDA0180)
CID/PAY8
(KX-TDA0189)
CID8
(KX-TDA0193)
Telephone
Company
MCSLC24
(KX-TDA1178)
MCSLC16
(KX-TDA1176)
CLCOT8
(KX-TDA1180)
CLCOT8E
(KX-TDA1186)
PC
KX-DT346/KX-DT343/
KX-T7636/KX-T7633
DSS Console PT-interface CS PS
DPT
Voice
Processing
System
KX-DT300/
KX-T7600 KX-DT300/ KX-T7600
Batteries
USB
CTI Server
RMT
(KX-TDA0196)
DLC4
DMPR
(Installed by default)
18 Installation Manual
1.1.2 System Connection Diagram

1.2 Optional Equipment
1.2.1 Optional Equipment
Model No. Model Name Description
KX-TDA0143 4 Cell Station Interface Card
(CSIF4)
4-port CS interface card for 4 CSs.
KX-TDA0144 8 Cell Station Interface Card
(CSIF8)
8-port CS interface card for 8 CSs.
KX-TDA0161 4-Port Doorphone Card (DPH4) 4-port doorphone card for 4 doorphones and 4
door openers. To be mounted on the OPB3 card.
KX-TDA0162 2-Port Doorphone Card (German
Type) (DPH2)
2-port doorphone card for 2 German-type
doorphones and 2 door openers. To be mounted
on the OPB3 card.
KX-TDA0164 4-Port External Input/Output Card
(EIO4)
4-port external input/output card. To be mounted
on the OPB3 card.
KX-TDA0166 16-Channel Echo Canceller Card
(ECHO16)
16-channel card for echo cancellation during
conferences. To be mounted on the OPB3 card.
KX-TDA0171 8-Port Digital Extension Card
(DLC8)
8-port digital extension card for DPTs, DSS
consoles, and PT-interface CSs.
KX-TDA0172 16-Port Digital Extension Card
(DLC16)
16-port digital extension card for DPTs, DSS
consoles, and PT-interface CSs.
KX-TDA0180 8-Port Analogue Trunk Card
(LCOT8)
8-port analogue trunk card with 2 power failure
transfer (PFT) ports.
KX-TDA0181 16-Port Analogue Trunk Card
(LCOT16)
16-port analogue trunk card with 4 power failure
transfer (PFT) ports.
KX-TDA0182 8-Port DID Card (DID8) 8-port DID trunk card.
KX-TDA0183 4-Port Analogue Trunk Card
(LCOT4)
4-port analogue trunk card with 2 power failure
transfer (PFT) ports.
KX-TDA0184 8-Port E & M Trunk Card (E&M8) 8-port E & M (TIE) trunk card. Type 5 support.
KX-TDA0187 T-1 Trunk Card (T1) 1-port T1 trunk card. EIA/TIA standard
compliant.
KX-TDA0188 E-1 Trunk Card (E1) 1-port E1 trunk card. ITU-T standard compliant.
KX-TDA0189 8-Port Caller ID/Pay Tone Card
(CID/PAY8)
8-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF, and
8-port Pay Tone Service (12 kHz/16 kHz). To be
mounted on the LCOT8/LCOT16 card.
KX-TDA0190 Optional 3-Slot Base Card (OPB3) Optional 3-slot base card for mounting a
maximum of 3 optional service cards from the
following: MSG4, ESVM4, ESVM2, DPH4,
DPH2 or EIO4 card.
Installation Manual 19
1.2.1 Optional Equipment

Model No. Model Name Description
KX-TDA0191 4-Channel Message Card (MSG4) 4-channel message card. To be mounted on the
OPB3 card.
KX-TDA0192 2-Channel Simplified Voice
Message Card (ESVM2)
2-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports MSG card features. To be mounted on
the OPB3 card.
KX-TDA0193 8-Port Caller ID Card (CID8) 8-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF. To be
mounted on the LCOT8/LCOT16 card.
KX-TDA0194 4-Channel Simplified Voice
Message Card (ESVM4)
4-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports MSG card features. To be mounted on
the OPB3 card.
KX-TDA0196 Remote Card (RMT) Analogue modem card for remote
communication with the PBX. ITU-T V.90
support. To be mounted on the DMPR card.
KX-TDA0284 4-Port BRI Card (BRI4) 4-port ISDN Basic Rate Interface card with 1
power failure transfer port. EURO-ISDN/ETSI
compliant.
KX-TDA0288 8-Port BRI Card (BRI8) 8-port ISDN Basic Rate Interface card with 1
power failure transfer port. EURO-ISDN/ETSI
compliant.
KX-TDA0290CE/
KX-TDA0290CJ
PRI Card (PRI30) 1-port ISDN Primary Rate Interface card (30B
channels). EURO-ISDN/ETSI compliant.
KX-TDA0290 PRI Card (PRI23) 1-port ISDN Primary Rate Interface card (23B
channels). NI (North American standard ISDN
protocol) compliant.
KX-TDA0410 CTI Link Card (CTI-LINK) Ethernet card for CTI communication via
10BASE-T port. CSTA Phase 3 protocol
compatible.
KX-TDA0470 16-Channel VoIP Extension Card
(IP-EXT16)
16-channel VoIP extension card. Compliant with
Panasonic proprietary protocol, and ITU-T G.
729a and G.711 codec methods.
KX-TDA0484 4-Channel VoIP Gateway Card
(IP-GW4E)
4-channel VoIP gateway card. Compliant with
VoIP H.323 V.2 protocol, and ITU-T G.729a, G.
723.1, and G.711 codec methods.
KX-TDA0490 16-Channel VoIP Gateway Card
(IP-GW16)
16-channel VoIP gateway card. Compliant with
VoIP H.323 V.2 protocol, and ITU-T G.729a, G.
723.1, and G.711 codec methods.
KX-TDA0920 SD Memory Card for Software
Upgrade to Enhanced Version
Optional SD Memory Card to use enhanced
features. For more details, refer to the SD
Memory Card Installation/Upgrade Guide.
20 Installation Manual
1.2.1 Optional Equipment
