Panasonic 2SA1806J User manual

Transistors
1
Publication date: August 2003 SJC00300AED
2SA1806J
Silicon PNP epitaxial planar type
For high speed switching
■Features
•High speed switching
•Low collector-emitter saturation voltage VCE(sat)
•SS-Mini type package, allowing downsizing of the equipment and
automatic insertion through the tape packing
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO −15 V
Collector-emitter voltage (Base open) VCEO −15 V
Emitter-base voltage (Collector open) VEBO −4V
Collector current IC−50 mA
Peak collector current ICP −100 mA
Collector power dissipation PC125 mW
Junction temperature Tj125 °C
Storage temperature Tstg −55 to +125 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base cutoff current (Emitter open) ICBO VCB =−8 V, IE=0 −0.1 µA
Emitter-base cutoff current (Collector open) IEBO VCE =−3 V, IC=0 −0.1 µA
Forward current transfer ratio hFE1 *VCE =−1 V, IC=−10 mA 50 150 
hFE2 VCE =−1 V, IC=−1 mA 30
Collector-emitter saturation voltage VCE(sat) IC=−10 mA, IB=−1 mA −0.1 −0.2 V
Transition frequency fTVCB =−10 V, IE=10 mA, f =200 MHz 800 1 500 MHz
Collector output capacitance Cob VCB = −5 V, IE= 0, f = 1 MHz 1 pF
(Common base, input open circuited)
Turn-on time ton Refer to the switching time 12 ns
Turn-off time toff measurement circuit 20 ns
Storage time tstg 19 ns
■Electrical Characteristics Ta=25°C ±3°C
Unit: mm
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
0.27 ±0.02
3
12
0.12
+0.03
–0.01
0.80
±0.05
(0.80)
0.85
1.60
±0.05
0 to 0.02
0.10 max.
0.70
+0.05 –0.03
(0.375)
5˚
5˚
1.60
+0.05
–0.03
1.00 ±0.05
(0.50)(0.50)
+0.05 –0.03
Marking Symbol: AK
1: Base
2: Emitter
3: Collector
EIAJ: SC-89
SSMini3-F1 Package
Ranking is not given for any product.
Rank Q R
hFE1 50 to 120 90 to 150
This product complies with the RoHS Directive (EU 2002/95/EC).

2SA1806J
2SJC00300AED
ICVCE VCE(sat) ICVBE(sat) IC
PCTa
hFE ICCob VCB
Switching time measurement circuit
ton , toff Test circuit tstg Test circuit
508 Ω30 Ω
51 Ω
VBB =−10 V
VIN
VCC =−3 V
VIN =9.0 VVIN =−5.8 V
VBB =Ground
VIN =9.8 V
VBB =−8.0 V
VOUT
0.1 µF34 Ω
VIN 0
0
VOUT
VIN
VOUT
90%
90%
90% 10%
10%
tstg
ton toff
90%
2 kΩ62 Ω
51 Ω
VBB
VIN
VCC =−1.5 V
VOUT
0.1 µF52 Ω
020 40 60 80 100 120 140
0
20
40
60
80
100
120
140
Collector power dissipation PC(mW)
Ambient temperature Ta(°C)
Collector current IC(mA)
Collector-emitter voltage VCE (V)
0−12−10−8−2−6−4
0
−80
−60
−70
−50
−40
−30
−10
−20
−500 µA
−400 µA
−300 µA
−200 µA
−100 µA
IB=−600 µA
Ta=25°C
Collector-emitter saturation voltage VCE(sat) (V)
Collector current IC(mA)
25°C
−25°C
Ta=75°C
−1−10 −100 −1 000
−0.01
−0.1
−1.0
−10 IC/ IB=10
Base-emitter saturation voltage VBE(sat) (V)
Collector current IC(mA)
−1− 0.1−10 −100 −1000
− 0.1
−1
−10
25°C
75°C
Ta=−25°C
IC/ IB=10
Forward current transfer ratio h
FE
Collector current I
C
(mA)
−0.1 −1−10 −100
0
120
140
160
180
100
80
60
40
20
T
a
=75°C
25°C
−25°C
V
CE
=−1 V
Collector-base voltage VCB (V)
Collector output capacitance (Common base, input open circuited) Cob (pF)
0.1
1
10
0 2 4 6 8 1012141618
f =1 MHz
Ta=25°C
This product complies with the RoHS Directive (EU 2002/95/EC).
