Panasonic LN352GPX User manual

SHD00524BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: November 2008 1
Light Emitting Diodes
LN352GPX
Square Type
4.0 mm ×4.0 mm
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD90 mW
Forward current IF30 mA
Pulse forward current *IFP 150 mA
Reverse voltage VR4 V
Operating ambient temperature Topr –25 to +85 °C
Storage temperature Tstg –30 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IO0.7 2.0 mcd
Reverse current IRVR= 4 V 10 µA
Forward voltage VFIF= 20 mA 2.2 2.8 V
Peak emission wavelength λPIF= 20 mA 565 nm
Spectral half band width Δλ IF= 20 mA 30 nm
Directive characteristics
IOIFIFVF
IFTa
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)
Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Forward current IF(mA)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
500
1000
300
30
50
100
10 0−20 80 100604020
1.6 1.8 2.0 2.42.2
31 5 10 50 10030
100
50
30
5
3
10
1
10
5
3
0.5
0.3
1
0.1
20°
30°
40°
50°
10°
0°
60°
70°
80°
90°
90°
80°
20°
30°
40°
50°
10°
60°
70°
80°
20°
40°
60°
0
020
20
10
30
40
50
40 60 80 100
100
500 600 700 800
80
60
40
20
0
0 20 40 60 80 10020406080100
Lighting Color
Yellow Green

SHD00524BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LN352GPX
2
Package (Unit: mm)
LLXFTN2SK520
5
.8
±2
.0
5.
6
2
±0
.
1
3
.3
±3
.0 5.6 ± 2
.0
0.2
0.
1
5.1
D
E
R
ED
L
O
S
TO
N
.
xa
M
2
2− 0.7 Max
2− 0.45 ± 0.1
2.54
1 2
4.3 ±0.2
4.0 ±0.2
5.6 ±0.2
5.4 ±0.2
4.2 ±0.2 4.0 ±0.2
0.45 ±0.1
Pin name
1: Anode
2: Cathode
