Panasonic LN41YPH User manual

SHD00564BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: November 2008 1
Light Emitting Diodes
LN41YPH
Round Type
φ5.0 mm
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD90 mW
Forward current IF30 mA
Pulse forward current *IFP 150 mA
Reverse voltage VR4 V
Operating ambient temperature Topr –25 to +85 °C
Storage temperature Tstg –30 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IO3.0 8.0 mcd
Reverse current IRVR= 4 V 10 µA
Forward voltage VFIF= 20 mA 2.2 2.8 V
Peak emission wavelength λPIF= 20 mA 590 nm
Spectral half band width Δλ IF= 20 mA 30 nm
Directive characteristics
IOIFIFVF
IFTa
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)
Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Forward current IF(mA)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
500
1000
300
30
50
100
10 0−20 80 100604020
1.6 1.8 2.0 2.42.2
31 5 10 50 10030
100
50
30
5
3
10
1
100
50
30
5
3
10
1
20°
30°
40°
50°
10°
0°
60°
70°
80°
90°
90°
80°
20°
30°
40°
50°
10°
60°
70°
80°
20°
40°
60°
020
20
10
0
30
40
50
40 60 80 100
100
500 600 700 800
80
60
40
20
0
0 20 40 60 80 10020406080100
Lighting Color
Amber

SHD00564BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LN41YPH
2
Package (Unit: mm)
LLXLTN2SF010
0.6 ±0.1
2.5
φ 0.
6
±2.
0
1 2
2.54
5.
1
2− 0.8 Max
2− 0.6 ± 0.1
0.52
±56
.
8
0
.1
±2
.
0
5
.
2 ± 3
.0
5
.
0
5
.15.
1
0.80.6
0.
1
φ 5.0 ± 0.2
D
E
REDLOSTO
N
.xaM0
.
2
Pin name
1: Anode
2: Cathode
